Moxa Technologies EDS-516A Series User manual

MOXA EtherDevice™ Switch
EDS-516A Series User’s Manual
www.moxa.com/product
First Edition, November 2006
MOXA Networking Co., Ltd.
Tel: [phone]
Fax: [phone]
Web: www.moxa.com
MOXA Technical Support
Worldwide: [e-mail]
The Americas [e-mail]

MOXA EtherDevice™ Switch
EDS-516A Series User’s Manual
The software described in this manual is furnished under a license agreement and may be used only in
accordance with the terms of that agreement.
Copyright Notice
Copyright ©2006 Moxa Networking Co., Ltd.
All rights reserved.
Reproduction without permission is prohibited.
Trademarks
MOXA is a registered trademark of the MOXA Group.
All other trademarks or registered marks in this manual belong to their respective manufacturers.
Disclaimer
Information in this document is subject to change without notice and does not represent a commitment on the
part of MOXA.
MOXA provides this document “as is,” without warranty of any kind, either expressed or implied, including, but
not limited to, its particular purpose. MOXA reserves the right to make improvements and/or changes to this
manual, or to the products and/or the programs described in this manual, at any time.
Information provided in this manual is intended to be accurate and reliable. However, MOXA assumes no
responsibility for its use, or for any infringements on the rights of third parties that may result from its use.
This product might include unintentional technical or typographical errors. Changes are periodically made to the
information herein to correct such errors, and these changes are incorporated into new editions of the
publication.

Table of Contents
Chapter 1 Introduction ...............................................................................................1-1
Overview .............................................................................................................................. 1-2
Package Checklist................................................................................................................. 1-2
Features ................................................................................................................................ 1-2
Industrial Networking Capability .............................................................................. 1-2
Designed for Industrial Applications......................................................................... 1-2
Useful Utility and Remote Configuration ................................................................. 1-3
Recommended Software and Accessories................................................................. 1-3
Chapter 2 Getting Started ..........................................................................................2-1
RS-232 Console Configuration (115200, None, 8, 1, VT100) ............................................. 2-2
Configuration using a Telnet Console .................................................................................. 2-5
Configuration using a Web Browser..................................................................................... 2-6
Disabling Telnet and Browser Access .................................................................................. 2-8
Chapter 3 Featured Functions...................................................................................3-1
Configuring Basic Settings................................................................................................... 3-2
System....................................................................................................................... 3-2
Password ................................................................................................................... 3-3
Accessible IP ............................................................................................................. 3-4
Port ............................................................................................................................3-5
Network..................................................................................................................... 3-6
Time .......................................................................................................................... 3-8
System File Update—By Remote TFTP ................................................................... 3-9
System File Update—By Local Import/Export....................................................... 3-10
System File Update—By Backup Media ................................................................ 3-11
Restart ..................................................................................................................... 3-11
Factory Default........................................................................................................ 3-11
Using Port Trunking ........................................................................................................... 3-12
The Port Trunking Concept..................................................................................... 3-12
Configuring Port Trunking...................................................................................... 3-13
Configuring SNMP............................................................................................................. 3-14
SNMP Read/Write Settings..................................................................................... 3-15
Trap Settings ........................................................................................................... 3-17
Private MIB information ......................................................................................... 3-17
Using Communication Redundancy ................................................................................... 3-17
Gigabit Ethernet Redundant Ring Capability (< 300 ms) ....................................... 3-18
The Turbo Ring Concept......................................................................................... 3-18
Configuring Turbo Ring.......................................................................................... 3-21
The STP/RSTP Concept.......................................................................................... 3-22
Configuring STP/RSTP........................................................................................... 3-27
Using Traffic Prioritization................................................................................................. 3-30
The Traffic Prioritization Concept .......................................................................... 3-30
Configuring Traffic Prioritization ........................................................................... 3-32

Using Virtual LAN ............................................................................................................. 3-35
The Virtual LAN (VLAN) Concept ........................................................................ 3-35
Sample Applications of VLANs using MOXA EDS-516A .................................... 3-37
Configuring Virtual LAN........................................................................................ 3-38
Using Multicast Filtering.................................................................................................... 3-41
The Concept of Multicast Filtering ......................................................................... 3-41
Configuring IGMP Snooping .................................................................................. 3-44
Add Static Multicast MAC...................................................................................... 3-45
Configuring GMRP ................................................................................................. 3-46
GMRP Table ........................................................................................................... 3-46
Using Bandwidth Management .......................................................................................... 3-47
Configuring Bandwidth Management ..................................................................... 3-47
Broadcast Storm Protection..................................................................................... 3-47
Traffic Rate Limiting Settings................................................................................. 3-47
Using Port Access Control.................................................................................................. 3-48
Configuring Static Port Lock .................................................................................. 3-50
Configuring IEEE 802.1X....................................................................................... 3-50
Using Auto Warning ........................................................................................................... 3-53
Configuring Email Warning.................................................................................... 3-53
Event Type .............................................................................................................. 3-54
Email Setup ............................................................................................................. 3-55
Configuring Relay Warning .................................................................................... 3-56
Event Setup ............................................................................................................. 3-57
Warning List............................................................................................................ 3-58
Using Line-Swap-Fast-Recovery........................................................................................ 3-58
Configuring Line-Swap Fast Recovery................................................................... 3-58
Using Set Device IP............................................................................................................ 3-58
Configuring Set Device IP ...................................................................................... 3-60
Using Diagnosis.................................................................................................................. 3-60
Mirror Port .............................................................................................................. 3-60
Ping ......................................................................................................................... 3-61
Using Monitor .................................................................................................................... 3-61
Monitor by Switch................................................................................................... 3-61
Monitor by Port ....................................................................................................... 3-62
Using the MAC Address Table ........................................................................................... 3-63
Using System Log .............................................................................................................. 3-63
Event Log ................................................................................................................ 3-63
Syslog Settings ........................................................................................................ 3-64
Using HTTPS/SSL ............................................................................................................. 3-65
Chapter 4 EDS Configurator GUI...............................................................................4-1
Starting EDS Configurator ................................................................................................... 4-2
Broadcast Search .................................................................................................................. 4-2
Search by IP address............................................................................................................. 4-3
Upgrade Firmware................................................................................................................4-3
Modify IP Address................................................................................................................ 4-4
Export Configuration............................................................................................................4-5
Import Configuration............................................................................................................4-6
Unlock Server....................................................................................................................... 4-7

Appendix A MIB Groups...............................................................................................A-1
Appendix B Specifications...........................................................................................B-1
Appendix C Service Information..................................................................................C-1
MOXA Internet Services ......................................................................................................C-2
Problem Report Form ...........................................................................................................C-3
Product Return Procedure.....................................................................................................C-4

1
1
Chapter 1 Introduction
Welcome to MOXA EtherDevice Switch EDS-516A Series, the Managed Redundant Ethernet
Switch designed specially for connecting Ethernet-enabled devices in industrial field applications.
The following topics are covered in this chapter:
Overview
Package Checklist
Features

EDS-516A Series User’s Manual Introduction
1-2
Overview
As the world’s network and information technology becomes more mature, the trend is to use
Ethernet as the major communications interface in many industrial communications and
automation applications. In fact, a whole new industry has sprung up to provide Ethernet products
that comply with the requirements of demanding industrial applications. EDS-516A is designed
for high port density amd ultra-reliable operation in rugged industrial environments, and is
therefore the best choice for each industrial application.
Package Checklist
MOXA EtherDevice Switch EDS-516A Series is shipped with the following items. If any of these
items are missing or damaged, please contact your customer service representative for assistance.
y1 MOXA EtherDevice Switch EDS-516A
yHardware Installation Guide
yCD-ROM with User’s Manual and Windows Utility
yMOXA Product Warranty booklet
yRJ45 to DB9 Console port cable
yProtective caps for unused ports
yPanel mounting kit (optional—must order separately)
Features
Industrial Networking Capability
yRedundant Ethernet Ring Capability (recovery time < 300 ms at full load)
yIGMP Snooping and GMRP for filtering multicast traffic from industrial Ethernet Protocols
ySupports IEEE 802.1Q, Tag-based VLAN, GVRP, and Port-based VLAN to ease network
planning
ySupports QoS—IEEE 802.1p/1Q and ToS/DiffServ to increase determinism
ySupports 802.3ad, LACP for optimum bandwidth utilization
ySupports IEEE 802.1X and SSL to enhance network security
ySNMP V1/V2c/V3 for different levels of network management security
yRMON for efficient network monitoring and proactive capability
Designed for Industrial Applications
yBandwidth management prevents unpredictable network status
ySupport ABC-01 (Automatic Backup Configurator) for system configuration back up
yLong-haul transmission distance of 40 km or 80 km
yRedundant, dual 12-45 VDC power inputs
yIP 30, rugged high-strength metal case
yDIN-Rail or panel mounting ability
yBandwidth management to prevent unpredictable network status
yLock port for authorized MAC address access only
yPort mirroring for online debugging
yAutomatic warning by exception through email, relay output
yDigital inputs to integrate a sensor and alarm with an IP network
yAutomatic recovery of connected device IP addresses
yLine-swap fast recovery

EDS-516A Series User’s Manual Introduction
1-3
Useful Utility and Remote Configuration
yConfigurable using a Web browser, Telnet/Serial console, and Windows utility
ySend ping commands to identify network segment integrity
Recommended Software and Accessories
yEDS-SNMP OPC Server Pro
yDR-4524, DR-75-24, DR-120-24 DIN-Rail 24 VDC Power Supply Series

2
2
Chapter 2 Getting Started
This chapter explains how to access EDS-516A for the first time. There are three ways to access
the switch: serial console, Telnet console, and web browser. The serial console connection method,
which requires using a short serial cable to connect EDS-516A to a PC’s COM port, can be used if
you do not know EDS-516A’s IP address. The Telnet console and web browser connection
methods can be used to access EDS-516A over an Ethernet LAN, or over the Internet.
The following topics are covered:
RS-232 Console Configuration (115200, None, 8, 1, VT100)
Configuration using a Telnet Console
Configuration using a Web Browser
Disabling Telnet and Browser Access

EDS-516A Series User’s Manual Getting Started
2-2
RS-232 Console Configuration (115200, None, 8, 1, VT100)
NOTE Connection Caution!
1. You cannot connect to EDS-516A simultaneously by serial console and Telnet.
2. You can connect to EDS-516A simultaneously by web browser and serial console, or by web
browser and Telnet.
However, we strongly suggest that you do NOT use more than one connection method at the
same time. Following this advice will allow you to maintain better control over the
configuration of your EDS-516A.
NOTE We recommend using MOXA PComm Terminal Emulator, which can be downloaded free of
charge from MOXA’s website.
Before running PComm Terminal Emulator, use an RJ45 to DB9-F (or RJ45 to DB25-F) cable to
connect EDS-516A’s RS-232 Console port to your PC’s COM port (generally COM1 or COM2,
depending on how your system is set up).
After installing PComm Terminal Emulator, perform the following steps to access the RS-232
Console utility.
1. From the Windows desktop, click Start ÆPrograms ÆPCommLite2.5 ÆTerminal
Emulator.
2. Select Open under Port Manager to open a new connection.

EDS-516A Series User’s Manual Getting Started
2-3
3. The Communication Parameter page of the Property window opens. Select the appropriate
COM port for Console Connection, 115200 for Baud Rate, 8for Data Bits, None for Parity,
and 1for Stop Bits.
4. Click the Terminal tab, and select VT100 for Terminal Type. Click OK to continue.
5. Type 1to select ansi/VT100 terminal type, and then press Enter.

EDS-516A Series User’s Manual Getting Started
2-4
6. The Console login screen will appear. Press Enter to open the Account pop-up selector and
then select either admin or user. Use the keyboard’s down arrow to move the cursor to the
Password field, enter the Console Password (this is the same as the Web Browser password;
leave the Password field blank if a console password has not been set), and then press Enter.
7. EDS-516A’s Main Menu will be displayed. (NOTE: To modify the appearance of the
PComm Terminal Emulator window, select Font… under the Edit menu, and then choose the
desired formatting options.)
8. After entering the Main Menu, use the following keys to move the cursor, and to select
options.
Key Function
Up/Down/Left/Right arrows, or Tab Move the onscreen cursor
Enter Display & select options
Space Toggle options
Esc Previous Menu

EDS-516A Series User’s Manual Getting Started
2-5
Configuration using a Telnet Console
You may use Telnet to access EDS-516A’s console utility over a network. To be able to access
EDS’s functions over the network (by Telnet or Web Browser) from a PC host that is connected to
the same LAN as EDS-516A, you need to make sure that the PC host and EDS-516A are on the
same logical subnet. To do this, check your PC host’s IP address and subnet mask. By default,
EDS-516A’s IP address is 192.168.127.253 and EDS-516A’s subnet mask is 255.255.0.0 (for a
Class B network). If you do not change these values, and your PC host’s subnet mask is
255.255.0.0, then its IP address must have the form 192.168.xxx.xxx. On the other hand, if your
PC host’s subnet mask is 255.255.255.0, then its IP address must have the form 192.168.127.xxx.
NOTE To use EDS-516A’s management and monitoring functions from a PC host connected to the same
LAN as EDS-516A, you must make sure that the PC host and EDS-516A are on the same logical
subnet.
NOTE Before accessing the console utility via Telnet, first connect one of EDS-516A’s RJ45 Ethernet
ports to your Ethernet LAN, or directly to your PC’s Ethernet NIC. You can establish a
connection with either a straight-through or cross-over Ethernet cable.
NOTE EDS-516A’s default IP is 192.168.127.253.
Perform the following steps to access the console utility via Telnet.
1. Click Start ÆRun, and then telnet to EDS-516A’s IP address from the Windows Run
window. (You may also issue the telnet command from the MS-DOS prompt.)
2. Type 1to choose ansi/vt100, and then press Enter.

EDS-516A Series User’s Manual Getting Started
2-6
3. The Console login screen will appear. Press Enter to open the Account pop-up selector and
then select either admin or user. Use the keyboard’s down arrow to move the cursor to the
Password field, enter the Console Password (this is the same as the Web Browser password;
leave the Password field blank if a console password has not been set), and then press Enter.
4. When the Main Menu of EDS-516A’s console utility opens, click Terminal Æ
preferences… from the menu at the top of the window.
5. When the Terminal Preferences window opens, make sure that the VT100 Arrows option is
selected.
NOTE The Telnet Console looks and operates in precisely the same manner as the RS-232 Console.
Configuration using a Web Browser
MOXA EDS-516A’s web browser interface provides a convenient way to modify the switch’s
configuration and access the built-in monitoring and network administration functions. You may
use either Internet Explorer or Netscape to access EDS-516A.
NOTE To use EDS-516A’s management and monitoring functions from a PC host connected to the same
LAN as EDS-516A, you must make sure that the PC host and EDS-516A are on the same logical
subnet.

EDS-516A Series User’s Manual Getting Started
2-7
NOTE If EDS-516A is configured for other VLAN settings, you must make sure your PC host is on the
management VLAN.
NOTE Before accessing EDS-516A’s web browser interface, first connect one of its RJ45 Ethernet ports
to your Ethernet LAN, or directly to your PC’s Ethernet NIC. You can establish a connection
with either a straight-through or cross-over Ethernet cable.
NOTE MOXA EDS-516A’s default IP is 192.168.127.253.
Perform the following steps to access EDS-516A’s web browser interface.
1. Open Internet Explorer and type EDS-516A’s IP address in the Address field. Press Enter to
establish the connection.
2. The web login page will open. Select the login account (Admin or User) and enter the
Password (this is the same as the Console password), and then click Login to continue. Leave
the Password field blank if a password has not been set.
NOTE By default, EDS-516A’s password is not set (i.e., is blank).
You may need to wait a few moments for the web page to be downloaded to your computer. Use
the menu tree on the left side of the window to open the function pages to access each of MOXA
EtherDevice Switch’s functions.

EDS-516A Series User’s Manual Getting Started
2-8
Disabling Telnet and Browser Access
If you are connecting EDS-516A to a public network, but do not intend to use its management
functions over the network, we suggest disabling both Telnet Console and Web Configuration
from the RS-232 Console’s Basic Settings ÆSystem Identification page, as shown in the
following figure.

3
3
Chapter 3 Featured Functions
This chapter explains how to access EDS-516A’s various configuration, monitoring, and
administration functions. There are three ways to access these functions: RS-232 console, Telnet
console, and web browser. The serial console connection method, which requires using a short
serial cable to connect EDS-516A to a PC’s COM port, can be used if you do not know
EDS-516A’s IP address. The Telnet console and web browser connection methods can be used to
access EDS-516A over an Ethernet LAN, or over the Internet.
The Web Console is the most user-friendly way to configure EDS-516A. In this chapter, we use
the Web Console interface to introduce the functions. There are only a few differences between the
Web Console, Serial Console, and Telnet Console.
The following topics are covered in this chapter:
Configuring Basic Settings
Using Port Trunking
Configuring SNMP
Using Communication Redundancy
Using Traffic Prioritization
Using Virtual LAN
Using Multicast Filtering
Using Bandwidth Management
Using Port Access Control
Using Auto Warning
Using Line-Swap-Fast-Recovery
Using Set Device IP
Using Diagnosis
Using Monitor
Using the MAC Address Table
Using System Log
Using HTTPS/SSL

EDS-516A Series User’s Manual Featured Functions
3-2
Configuring Basic Settings
The Basic Settings group includes the most commonly used settings required by administrators to
maintain and control EDS-516A.
System
The system identification items are displayed at the top of the web page, and will be included in
alarm emails. Entering the system identification information makes it easier to identify the
different switches connected to your network.
Switch Name
Setting Description Factory Default
Max. 30
Characters
This option is useful for specifying the role or
application of different EDS-516A units.
E.g., Factory Switch 1.
Managed Redundant Switch
[Serial No. of this switch]
Switch Location
Setting Description Factory Default
Max. 80
Characters
To specify the location of different EDS-516A
units. E.g., production line 1.
Switch Location
Switch Description
Setting Description Factory Default
Max. 30
Characters
Use this to enter a more detailed description of
the EDS-516A unit.
None
Maintainer Contact Info
Setting Description Factory Default
Max. 30
Characters
To provide information about whom to contact
in order to resolve problems. Use this to enter
contact information of the person responsible
for maintaining this EDS-516A.
None

EDS-516A Series User’s Manual Featured Functions
3-3
Password
EDS-516A provides two levels of access privileges: admin privilege gives read/write access to all
EDS-516A configuration parameters, and user privilege provides read access only. You will be
able to view the configuration, but will not be able to make modifications.
ATTENTION
EDS-516A’s default Password is not set (i.e., is blank). If a Password is already set, then you
will be required to type the Password when logging into the RS-232 Console, Telnet Console, or
Web Browser interface.
Account
Setting Description Factory Default
admin “admin” privilege allows the user to modify all
EDS-516A configurations.
user “user” privilege only allows viewing EDS-516A
configurations.
admin
Password
Setting Description Factory Default
Old Password
(Max. 16 Characters)
Type current password when changing the
password
None
New Password
(Max. 16 Characters)
Type new password when changing the password None
Retype Password
(Max. 16 Characters)
If you type a new password in the Password field,
you will be required to retype the password in the
Retype new password field before updating the
new password.
None

EDS-516A Series User’s Manual Featured Functions
3-4
Accessible IP
MOXA EDS-516A uses an IP address-based filtering method to control access to EDS-516A
units.
Accessible IP Settings allows you to add or remove “Legal” remote host IP addresses to prevent
unauthorized access. Access to EDS-516A is controlled by IP address. If a host’s IP address is in
the accessible IP table, then the host will be allowed access to the EDS-516A. You can allow one
of the following cases by setting this parameter:
yOnly one host with the specified IP address can access the EDS-516A
E.g., enter “192.168.1.1/255.255.255.255” to allow access to just the IP address 192.168.1.1.
yAny host on a specific subnetwork can access the EDS-516A
E.g., enter “192.168.1.0/255.255.255.0” to allow access to all IPs on the subnet defined by
this IP address/subnet mask combination.
yAny host can access the EDS-516A
Disable this function by deselecting the Enable the accessible IP list option.
The following table shows additional configuration examples:
Allowable Hosts Input format
Any host Disable
192.168.1.120 192.168.1.120 / 255.255.255.255
192.168.1.1 to 192.168.1.254 192.168.1.0 / 255.255.255.0
192.168.0.1 to 192.168.255.254 192.168.0.0 / 255.255.0.0
192.168.1.1 to 192.168.1.126 192.168.1.0 / 255.255.255.128
192.168.1.129 to 192.168.1.254 192.168.1.128 / 255.255.255.128
