EDS-P308 Series & SPL-24
Quick Installation Guide
Moxa EtherDeviceTM Switch & PoE Splitter
Edition 6.0, February 2017
Technical Support Contact Information
www.moxa.com/support
Moxa Americas:
Toll
-free: 1-888-669-2872
Tel:
1-714-528-6777
Fax:
1-714-528-6778
Moxa China (Shanghai office):
Toll
-free: 800-820-5036
Tel:
[phone]
Fax:
[phone]
Moxa Europe:
Tel:
[phone]
Fax:
[phone]
Moxa Asia-Pacific:
Tel:
[phone]
Fax:
[phone]
Moxa India:
Tel:
[phone]
Fax:
[phone]

2017 Moxa Inc. All rights reserved.

- 2 -
Overview
We describe two products in this manual:
The Moxa EtherDevice™ EDS-P308 Series is an 8-port smart Ethernet
switch that provides an economical solution for your Ethernet connections.
The switch supports PoE (Power-over-Ethernet) on ports 1 to 4, which
means that the EDS-P308 Series can double as a piece of power source
equipment (PSE). When used in this way, the EDS-P308 Series can supply
up to 15.4 watts of power per port, and can power IEEE 802.3af compliant
powered devices (PD), eliminating the need for additional wiring. The
EDS-P308 Series switch is highly versatile, and its FX fiber port can
transmit data up to 40 km from the device to the control center with high
EMI immunity. As an added bonus, the built-in smart alarm function helps
system maintainers monitor the health of your Ethernet network.
The SPL-24 plays the role of PD, and splits the data signal and power
signal that are transmitted from the PSE. The SPL-24 plays a dual role of
providing power to industrial devices, and enabling Ethernet connections.
The EDS-P308 and SPL-24 have a wide operating temperature range of
-40 to 75°C, and are designed to withstand a high degree of vibration and
shock. The rugged hardware design makes the EDS-P308 Series and
SPL-24 perfect for ensuring that your Ethernet equipment can operate in
critical industrial environments, such as in hazardous locations, and
complies with FCC and CE standards.
The installation of the EDS-P308 Series is presented on pages 3 to 11. The
installation of the SPL-24 is presented on pages 11 to 15.
NOTE
Throughout this Hardware Installation Guide, we use EDS as an
abbreviation for Moxa EtherDevice Switch, and we use SPL as an
abbreviation for Moxa PoE Splitter:
EDS = Moxa EtherDevice Switch
SPL = Moxa PoE Splitter

- 3 -
Wiring Requirements
WARNING
Do not disconnect modules or wires unless the power supply has
been switched off or the area is known to be non
-
hazardous. The
devices may only be connected to the supply voltage shown on
the type plate. The devices a
re designed for operation with a
Safety Extra
-
Low Voltage. Thus, they may only be connected to
the supply voltage connections and to the signal contact with the
Safety Extra
-Low Voltages (SELV) in compliance with IEC
60950-1/EN 60950-1.
WARNING
The power for this product is intended to be supplied by a Listed
Power Unit, with output marked LPS, and rated to deliver 48 VDC
at a maximum of 300 mA.
WARNING
This unit is a
built-
in type. When the unit is installed in another
piece of equipment, the equipment enclosing the unit must
comply with fire enclosure regulation IEC 60950
-1/EN60950-1
(or similar regulation).
WARNING
Safety First!
Be
sure to disconnect the power cord before installing and/or
wiring your
Moxa EtherDevice Switch. Calculate the maximum
possible current in each power wire and common wire. Observe
all electrical codes dictating the maximum current allowable for
each wire size. If the current goes above the maximum ratings,
the wiring could overheat, causing serious damage to your
equipment.
You should also pay attention to the following items:
•Use separate paths to route wiring for power and devices. If power
wiring and device wiring paths must cross, make sure the wires are
perpendicular at the intersection point.
NOTE: Do not run signal or communications wiring and power wiring
in the same wire conduit. To avoid interference, wires with different
signal characteristics should be routed separately.
•You can use the type of signal transmitted through a wire to
determine which wires should be kept separate. The rule of thumb is
that wiring that shares similar electrical characteristics can be
bundled together.
•Keep the input wiring and the output wiring separated.
•It is strongly advised that you label the wiring to all devices in the
system when necessary.

- 4 -
Package Checklist for EDS-P308 Series
The Moxa EDS-P308 Series is shipped with the following items. If any of
these items is missing or damaged, please contact your customer service
representative for assistance.
•Moxa EtherDevice™ Switch EDS-P308
•Protective caps for unused ports
•Quick installation guide (printed)
•Warranty card
Features of EDS-P308 Series
High Performance Network Switching Technology
•10/100BaseT(X) (RJ45)
•100BaseFX (SC type, Multi/Single mode)
•IEEE802.3/802.3u/802.3x 100BaseFX (SC type, multi-mode, and
single-mode)
•Store and Forward switching process type, with 1024 address entries
•10/100M, Full/Half-Duplex, MDI/MDIX auto-sensing
•Provides up to 15.4 watts per PoE port
•Active circuit protection
•Auto disconnection for over voltage or under voltage
•Power consumption detection and classification
Industrial Grade Reliability
•Power failure, port break alarm by relay output
•Redundant dual DC power inputs
Rugged Design
•Operating temperature range from 0 to 60°C, or extended operating
temperature from -40 to 75°C for “-T” models
•IP30, rugged high-strength case
•DIN-Rail or panel mounting ability
Specifications of EDS-P308 Series
Technology
Standards
IEEE802.3, 802.3u, 802.3x, 802.3af
Forward and Filtering Rate
148810 pps
Packet Buffer Memory
256 KB
Processing Type
Store and Forward, with IEEE802.3x full
duplex, back pressure flow control
Address Table Size
1,000 uni-cast addresses
Latency
Less than 5 μs
Interface
RJ45 Ports
10/100BaseT(X) auto negotiation speed,
F/H duplex mode, and auto MDI/MDI-X
connection
Fiber Ports
100BaseFX (SC type, multi-mode, and
single-mode)
LED Indicators
Power, Fault, FX, 10/100, PoE
DIP Switch
Port break alarm mask
Alarm Contact
One relay output with current carrying
capacity of 0.5A @ 48 VDC

- 5 -
PoE
Total Power Budget
61.6 W
PoE Output Voltage
45.3 VDC @ 48 VDC power input
PoE Output Power
15.4 W for 802.3af
PoE Output Current
350 mA for 802.3af
Overload Current Protection
(at the port)
Present
PoE Pinout
Mode A: Pair 1, 2 (V-); Pair 3, 6 (V+)
Power
Rated Voltage
48 VDC, redundant dual inputs
Operating Voltage
44 to 57 VDC
Rated Current
1.47 A @ 48 VDC
Power Consumption
8.96 W max., without PDs' consumption
Inrush Current
29 A @ 48 VDC
Electrical Isolation
2250 VDC to chassis for 60 s
Heat Dissipation
27.3 BTU/h
Overload Current Protection
(at the input)
Present
Reverse Polarity Protection
Present
Connection
1 removable 6-contact terminal block
Mechanical
Casing
IP30 protection, metal case
Dimensions
53.6 × 135 × 105 mm (W × H × D)
Weight
0.84 kg
Installation
DIN-Rail, Wall Mounting
Environmental
Operating Temperature
0 to 60°C (32 to 140°F)
-40 to 75°C (-40 to 167°F) for -T models
Storage Temperature
-40 to 85°C (-40 to 185°F)
Ambient Relative Humidity
5 to 95% (non-condensing)
Regulatory Approvals
Safety
UL 508
EMI
FCC Part 15, CISPR 32 class A
EMS
EN61000-4-2 (ESD), Level 3
EN61000-4-3 (RS), Level 3
EN61000-4-4 (EFT), Level 3
EN61000-4-5 (Surge), Level 3
EN61000-4-6 (CS), Level 3
EN61000-4-8
EN61000-4-11
Shock
IEC60068-2-27
Freefall
IEC60068-2-32
Vibration
IEC60068-2-6
WARRANTY
5 years

- 6 -
EDS-P308 Series Panel Layout
1. Grounding screw
2. Terminal block for power inputs
PWR1, PWR2, and relay output
3. Heat dissipation orifices
4. DIP switches
5. Power input PWR1 LED
6. Power input PWR2 LED
7. Fault LED
8. 10/100BaseT(X) Port
9. TP port’s 100 Mbps LED
10.
TP port’s 10 Mbps LED
11.
Model Name
12.
Screw holes for wall mounting kit
13.
DIN-Rail Kit
14.
PoE port LEDs (ports 1 to 4)

- 7 -
EDS-P308 (SC-type) Panel Layout
NOTE:
MSC
: Multi-Mode SC Connector
SSC: Single-Mode SC Connector
Product models not shown here:
EDS
-P308-S-SC is identical to
EDS-P308-M-SC.
EDS
-P308-SS-SC is identical to
EDS-P308-MM-SC.
1. Grounding screw
2. Terminal block for power inputs
PWR1, PWR2 and relay output
3. Heat dissipation orifices
4. DIP switches
5. Power input PWR1 LED
6. Power input PWR2 LED
7. Fault LED
8. 10/100BaseT(X) Port
9. 100BaseFX Port (SC type,
Multi/Single mode)
10.
TP port’s 100 Mbps LED
11.
TP port’s 10 Mbps LED
12.
FX port's 100 Mbps LED
13.
Model Name
14.
Screw holes for wall mounting kit
15.
DIN-Rail Kit
16.
PoE port LEDs (ports 1 to 4)

- 8 -
Mounting Dimensions
Unit = mm (inch)

- 9 -
DIN-Rail Mounting
The aluminum DIN-Rail attachment plate should already be fixed to the
back panel of the EDS-P308 Series when you take it out of the box. If you
need to reattach the DIN-Rail attachment plate, make sure the stiff metal
spring is situated towards the top, as shown in the figures below.
STEP 1:
Insert the top of the DIN
-Rail into
the slot just below
the stiff metal spring.
STEP 2:
The DIN
-Rail attachment unit will
snap into pla
ce as shown below.
To remove the Moxa EtherDevice Switch from the DIN-Rail, simply
reverse Steps 1 and 2 above.
Wall Mounting (optional)
For some applications, you will find it convenient to mount EDS-P308
Series on the wall, as illustrated below.
STEP 1:
Remove the aluminum
DIN
-Rail attachment plate
from the EDS
-P308’s rear
panel, and then attach the
wall mount plates, as shown
in the diagram below.
STEP 2:
Mounting the EDS-
P308 on the wall requires 4
screws. Use the switch, with wall mount pla
tes
attached, as a guide to mark the correct locations of the
4 screws. The heads of the screws should be less than
6.0 mm in diameter, and the shafts should be less than
3.5 mm in diameter, as shown in the figure at the right.
NOTE
Before tightening the screws into the wall, make sure the screw
head and shank size are suitable by inserting the screw into one
of the keyhole-shaped apertures of the wall mounting plates.
Do not screw the screws in all the way—leave about 2 mm to allow room
for sliding the wall mount panel between the wall and the screws.

- 10 -
STEP 3:
Once the screws are fixed in the wall,
insert the four screw heads through the
large parts of the keyhole
-shaped
apertures, and then slide the EDS
-P308
downwards, as indicated. Tighten the four
screws for added stability.
Grounding the EDS-P308 Series
Grounding and wire routing help limit the effects of noise due to
electromagnetic interference (EMI). Run the ground connection from the
ground screw to the grounding surface prior to connecting devices.
ATTENTION
This product is intended to be mounted to a well
-grounded
mounting surface, such as a metal panel.
EDS-P308 Series’ Redundant Power Inputs
Both power inputs can be connected simultaneously to live DC power
sources. If one power source fails, the other live source acts as a backup,
and automatically supplies all of EDS-P308 Series’s power needs.
Wiring the Redundant Power Inputs
The top two contacts and the bottom two contacts of the 6-contact
terminal block connector on EDS’s top panel are used for EDS’s two DC
inputs. Top and front views of one of the terminal block connectors are
shown here.
STEP 1:
Insert the negative/positive DC wires into
the V
-/V+ terminals.
STEP 2:
To keep the DC wires from pulling loose,
use a small flat
-blade screwdriver to
tighten the wire
-
clamp screws on the front
of
the terminal block connector.
STEP 3:
Insert the plastic terminal block connector
prongs into the terminal block receptor,
which is located on ED
S’s top panel.
ATTENTION
Before connecting EDS to the DC power inputs, make sure the DC
power source voltage is stable.

- 11 -
EDS-P308 Series’ Alarm Contact
The EDS-P308 Series has one alarm contact located on its top panel. For
detailed instructions on how to connect the alarm contact power wires to
the two middle contacts of the 6-contact terminal block connector, see
the Wiring the Alarm Contact section on page 10. A typical scenario would
be to connect the Fault circuit to a warning light located in the control
room. The light can be set up to switch on when a fault is detected.
The alarm contact has two terminals that form a Fault circuit for
connecting to an alarm system. The two wires attached to the Fault
contacts form an open circuit when (1) EDS has lost power from one of
the DC power inputs, or (2) one of the ports for which the corresponding
PORT ALARM DIP Switch is set to ON is not properly connected.
If neither of these two conditions occurs, the Fault circuit will be closed.
EDS-P308 Series’ DIP Switch Settings
ON:
Enables the corresponding PORT Alarm. If
the port’s link fails, the relay will form an
open circuit and the fault LED will light up.
Off:
Disables the corresponding PORT Alarm.
The relay will form a closed circuit and the
Fault LED will never light up.
Wiring the Alarm Contact
The alarm contact consists of the two middle contacts of the terminal
block on EDS’s top panel. Refer to below for detailed instructions on how
to connect the wires to the terminal block connector, and how to attach
the terminal block connector to the terminal block receptor. In this
section, we explain the meaning of the two contacts used to connect the
alarm contact.
FAULT:
The two middle contacts of the
6
-
contact terminal block connector are used to
detect both power faults and port faults. The
two wires attached to the Fault cont
acts form
an open circuit when:
1. EDS has lost power from one of the DC
power inputs.
OR
2. One of the ports for which the
corresponding PORT ALARM DIP Switch is
set to ON is not properly connected.
If neither of these two conditions is satisfied,
the Fault circuit will be closed.

- 12 -
LED Indicators
The front panel of the EDS-P308 Series contains several LED indicators.
The function of each LED is described in the table below.
LED
Color
State
Description
PWR1 AMBER On Power is being supplied to power input
PWR1
Off
Power is not being supplied to power
input PWR1
PWR2 AMBER On
Power is being supplied to power input
PWR2
Off
Power is not being supplied to power
input PWR2
FAULT RED
On
When the corresponding PORT alarm is
enabled, and the port’s link is inactive.
Off
When the corresponding PORT alarm is
enabled and the port’s link is active, or
when the corresponding PORT alarm is
disabled.
10M GREEN
On
TP port’s 10 Mbps link is active
Blinking
Data is being transmitted at 10 Mbps
Off
TP Port’s 10 Mbps link is inactive
100M GREEN
On
TP port’s 100 Mbps link is active
Blinking
Data is being transmitted at 100 Mbps
Off
100BaseTX Port’s link is inactive
FX GREEN
On
FX port’s 100 Mbps link is active.
Blinking
Data is being transmitted at 100 Mbps.
Off
100BaseFX Port’s link is inactive.
PoE AMBER On
Power is being supplied to Powered Device
(PD)
Off Power is
not
being supplied to Powered
Device (PD)
Package Checklist for SPL-24
The Moxa SPL-24 is shipped with the following items. If any of these items
is missing or damaged, please contact your customer service
representative for assistance.
•Moxa PoE Splitter, SPL-24
•Quick installation guide (printed)
•Warranty card
Features of SPL-24
High Performance Network Switching Technology
•IEEE802.3af compliance
•Power/data split from PoE lines using either spare-pairs or data pairs
•Support for up to 12.95 W at 24 VDC
•Support for up to 15.4 watts per PoE port
•Short circuit protection
•Auto disconnection for over voltage or under voltage
•Power consumption detection and classification

- 13 -
Rugged Design
•Operating temperature range from 0 to 60°C, or extended operating
temperature from -40 to 75°C for “-T” models
•IP30, plastic case
•DIN-Rail or panel mounting ability
Specifications of SPL-24
Technology
Standards
IEEE802.3af
Interface
RJ45 Ports 10/100BaseT(X) for PoE IN, and
10/100BaseT(X) for DATA OUT
LED Indicators
Power
Power
Input voltage
44 to 56 VDC
Output voltage
24 VDC
Output current
0.54 A @ 24V
Output Power
12.95 W (@ 24 VDC)
Connection
Removable “3-pin” Terminal Block for output
Overload current Protection
400 mA (@ 48 VDC input)
Efficiency
85% (at 25°C, full-loaded)
Mechanical
Casing
IP30 protection, plastic case
Dimensions
25 × 109 × 88 mm (W × H × D)
Weight
95 g
Installation
DIN-Rail, Wall Mounting
Environmental
Operating Temperature
0 to 60°C (32 to 140°F)
-40 to 75°C (-40 to 167°F) for -T models
Storage Temperature
-40 to 85°C (-40 to 185°F)
Ambient Relative Humidity
5 to 95% (non-condensing)
Regulatory Approvals
Safety
Pending: UL60950, UL 508, CSA C22.2 No.
60950, EN60950 (pending)
Hazardous Location UL/cUL Class I, Division 2, Groups A, B, C
and D (pending)
ATEX Class I, Zone 2, EEx nC IIC (pending)
EMI
FCC Part 15, CISPR 32 class A
EMS
EN61000-4-2 (ESD), Level 3
EN61000-4-3 (RS), Level 3
EN61000-4-4 (EFT), Level 3
EN61000-4-5 (Surge), Level 3
EN61000-4-6 (CS), Level 3
Shock
IEC60068-2-27
Freefall
IEC60068-2-32
Vibration
IEC60068-2-6
WARRANTY
5 years

- 14 -
SPL-24 Panel Layout
1.
Heat dissipation orifices
2. Terminal block for power input and grounding
3. Moxa Logo
4. PoE power LED
5. DATA-OUT port
6. PoE IN port
7. DIN-Rail
Mounting Dimensions
Unit = mm (inch)

- 15 -
DIN-Rail Mounting for SPL-24
The plastic DIN-Rail attachment plate should already be fixed to the back
panel of SPL-24 when you take it out of the box. If you need to reattach
the DIN-Rail attachment plate, make sure the stiff metal spring is situated
towards the top, as shown in the figures below.
STEP 1:
Insert the top of the DIN
-Rail into
the slot.
STEP 2:
The DIN
-Rail attachment unit will
snap into place as shown below.
To remove the SPL
-24 from the
DIN
-Rail, insert a flat-blade screw
driver horizontally into the DIN
-
Rail
kit under
the SPL-
24, and then pull it
upwards and release SPL
-24
towards you away from the
DIN
-Rail.
Grounding the SPL-24
Grounding and wire routing help limit the
effects of noise due to electromagnetic
interference (EMI). Run the right most contact
of the 3
-co
ntact terminal block to the grounding
surface prior to connecting devices.
ATTENTION
This product is intended to be mounted to a well
-grounded
mounting surface, such as a metal panel.

- 16 -
Wiring the SPL-24’s Power Outputs
The two left-most contacts of the 3-contact terminal block connector on
the SPL-24’s top panel are used for 24 VDC output. Top and front views of
one of the terminal block connectors are shown here.
STEP 1:
Insert the negative/positive DC
wires into the V-
/V+
terminals.
STEP 2:
To keep the DC wires from pulling loose, use a small
flat
-blade screwdriver to tighten the wire-clamp
screws on the front of the terminal block connector.
STEP 3:
Insert the plastic terminal block connector prongs
into the terminal block receptor, which is located on
SPL
-24's top panel.
Patent http://www.moxa.com/doc/operations/Moxa_Patent_Marking.pdf
