1. Introduction
Moxa AirWorks AWK-5222 with dual-RF wireless capability allows wireless users to access network resources
more reliably. The AWK-5222 is rated to operate at temperatures ranging from 0 to 60°C for standard models
and -40 to 75°C for extended temperature models, and is rugged enough for any harsh industrial environment.
The following topics are covered in this chapter:

Overview

Package Checklist

Product Features

Product Specifications

Functional Design
LED Indicators
Beeper
Reset Button
Relay (Digital Output)
Antenna

AWK-5222 Introduction
1-2
Overview
The AWK-5222 Access Point/Bridge and AP Client is ideal for applications that need a more reliable solution,
and are hard to wire, too expensive to wire, or use mobile equipment that connects to a TCP/IP network. The
AWK-5222 can operate at temperatures ranging from 0 to 60°C for standard models and -40 to 75°C for
extended temperature models, and is rugged enough for any harsh industrial environment. Installation is easy,
with either DIN-rail mounting or wall mounting in distribution boxes. The DIN-rail/wall mounting ability, wide
operating temperature range, and IP30 housing with LED indicators make the AWK-5222 a convenient yet
reliable solution for any industrial wireless application.
Package Checklist
Moxa’s AWK-5222 is shipped with the following items. If any of these items is missing or damaged, please
contact your customer service representative for assistance.
•AWK-5222 wireless AP/bridge/client
•DIN-rail kit
•2 plastic RJ45 protective caps for LAN &
•Console ports
•Cable holder with one screw
•Documentation and software CD
•Quick installation guide (printed)
•Warranty card
NOTE
The above items
come with the AWK-5222 standard version. The package contents may vary in customized
version
s.
Product Features
•IEEE802.11a/b/g compliant
•Three-in-one design (AP/bridge/client)
•Dual-RF design for redundant wireless communication
•Advanced wireless security:
64-bit and 128-bit WEP/WPA/WPA2
SSID hiding/IEEE 802.1X/RADIUS
Packet access control & filtering
•STP/RSTP support for redundancy of system networking
•Long-distance transmission support
•Turbo Roaming™ enables rapid handover (Client mode)
•Dedicated antenna selection
•Free firmware update for more advanced functions
•RS-232 console management
•2DI +1 DO for onsite monitoring and warnings
•Operating temperature range from -40 to 75°C (-T model)
•Power input by redundant 24 VDC power inputs or IEEE802.3af Power-over-Ethernet
•DIN-rail or wall mounting ability
•IP30 protected high-strength metal housing

AWK-5222 Introduction
1-3
Product Specifications
WLAN Interface
Standards:
IEEE 802.11a/b/g for
Wireless LAN
IEEE 802.11i for Wireless Security
IEEE 802.3 for 10BaseT(X)
IEEE 802.3u for 100BaseT(X)
IEEE 802.3af for Power
-over-Ethernet
IEEE 802.1D for Spanning Tree Protocol
IEEE 802.1w for Rapid STP
IEEE 802.1Q for VLAN
Spread Spectrum and
Modulation (typical):
• DSSS with DBPSK, DQPSK, CCK
• OFDM with BPSK, QPSK, 16QAM, 64QAM
64QAM @ 54 Mbps, 16QAM @ 24/36 Mbps, QPSK @ 12/18 Mbps, CCK @ 11/5.5 Mbps, DQPSK @ 2 Mbps,
DBSK@ 1 Mbps
• 802.11b: CCK @ 11/5.5 Mbps, DQPSK @ 2 Mbps, DBPSK @ 11 Mbps
•
802.11a/g: 64QAM @ 54/48 Mbps, 16QAM @ 36/24 Mbps, QPSK @ 18/12 Mbps, BPSK @ 9/6 Mbps
Operating Channels (central frequency):
US:
2.412 to 2.462 GHz (11 channels)
5.18 to 5.24 GHz (4 channels)
EU:
2.412 to 2.472 GHz (13 channels)
5.18 to 5.24 GHz (4 c
hannels)
JP:
2.412 to 2.472 GHz (13 channels, OFDM)
2.412 to 2.484 GHz (14 channels, DSSS)
5.18 to 5.24 GHz (4 channels for W52)
Security:
• SSID broadcast enable/disable
• Firewall for MAC/IP/Protocol/Port
-based filtering
• 64
-bit and 128-bit WEP encryption, WPA /WPA2 Personal and Enterprise (IEEE 802.1X/RADIUS, TKIP and
AES)
Transmission Rates:
802.11b: 1, 2, 5.5, 11
Mbps
802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54
Mbps
TX Transmit Power:
802.11b:
Typ. 23±1.5 dBm @ 1 to 11 Mbps
802.11g:
Typ. 20±1.5 dBm @ 6
to 24 Mbps, Typ. 19±1.5 dBm @ 36 Mbps, Typ. 18±1.5 dBm @ 48 Mbps, Typ. 17±1.5
dBm @ 54 Mbps
802.11a:
Typ. 18±1.5 dBm @ 6 to 24 Mbps, Typ. 16±1.5 dBm @ 36 to 48 Mbps, Typ. 15±1.5 dBm @ 54 Mbps

AWK-5222 Introduction
1-4
RX Sensitivity:
802.11b:
-
97 dBm @ 1 Mbps, -94 dBm @ 2 Mbps, -92 dBm @ 5.5 Mbps, -90 dBm @ 11 Mbps
802.11g:
-
93 dBm @ 6 Mbps, -91 dBm @ 9 Mbps, -90 dBm @ 12 Mbps, -88 dBm @ 18 Mbps, -84 dBm @ 24 Mbps, -
80
dBm @ 36 Mbps,
-76 dBm @ 48 Mbps, -74 dBm @ 54 Mbps
802.11a:
-
90 dBm @ 6 Mbps, -89 dBm @ 9 Mbps, -89 dBm @ 12 Mbps, -85 dBm @ 18 Mbps, -83 dBm @ 24 Mbps, -
79
dBm @ 36 Mbps,
-75 dBm @ 48 Mbps, -74 dBm @ 54 Mbps
Protocol Support
General Protocols:
Proxy ARP, DNS, HTTP, HTTPS, IP, ICMP, SNTP, TCP, UDP, RADIUS, SNMP, PPPoE, DHCP
AP
-only Protocols: ARP, BOOTP, DHCP, STP/RSTP (IEEE 802.1D/w)
Interface
Default Antennas:
2 dual-band omni-directional antennas, 2 dBi, RP-SMA (male)
Connector for External Antennas:
RP-SMA (female)
RJ45 Ports: 2, 10/100BaseT(X), auto negotiation speed, F/H duplex
mode, and auto MDI/MDI-X connection
Console Port:
RS-232 (RJ45-type)
Reset:
Present
LED Indicators:
PWR1, PWR2, PoE, FAULT, STATE, WLAN1, WLAN2, 10M, 100M
Alarm Contact (digital output):
1 relay output with current carrying capacity of 1 A @ 24 VDC
Digital Inputs:
2 electrically isolated inputs
• +13 to +30 V for state “1”
• +3 to
-30 V for state “0”
• Max. input current: 8 mA
Physical Characteristics
Housing:
Metal, IP30 protection
Weight:
1.1 kg (2.43 lb)
Dimensions:
62 x 135 x 105 mm (2.4 x 5.3 x 4.1 in)
Installation:
DIN-rail mounting (standard), Wall mounting (optional)
Environmental Limits
Operating Temperature:
Standard Models:
-25 to 60°C (-13 to 140°F)
Wide Temp. Models:
-40 to 75°C (-40 to 167°F)
Storage
Temperature: -40 to 85°C (-40 to 185°F)
Ambient Relative Humidity:
5% to 95% (non-condensing)
Power Requirements
Input Voltage:
12 to 48 VDC, redundant dual DC power inputs or 48 VDC Power-over-
Ethernet (IEEE 802.3af
compliant)
Connector:
10-pin removable terminal block
Power Consumption:
12 to 48 VDC, 800 mA (max.)
Reverse Polarity Protection:
Present
Standards and Certifications
Safety:
UL 60950-1, EN 60950-1
EMC:
EN 301 489-1/17, FCC Part 15 Subpart B, EN 55022/55024,
IEC
61000-6-2/4
Radio:
EN 300 328, EN 301 893, FCC ID SLE-WAPA003
Note: Please check Moxa’s website for the most up
-to-date certification status.
MTBF (mean time between failures)
Time:
291,367 hrs
Warranty
Warranty Period:
5 years
Details:
See www.moxa.com/warranty

AWK-5222 Introduction
1-5
ATTENTION
The AWK
-5222 is NOT a portable mobile device and should be located at least 20 cm away from the human
body. The AWK
-5222 is NOT designed for the general public. To deploy AWK-5222s and establish a wireless
network safely, a well
-trained technician is required for installation.
Patent http://www.moxa.com/doc/operations/Moxa_Patent_Marking.pdf
Functional Design
LED Indicators
The LEDs on the front panel help you to quickly identity the status and wireless settings of the AWK-5222.
LED Color State Description
Front Panel LED Indicators (System)
PWR1 Green On Power is being supplied from power input 1.
Off Power is not being supplied from power input 1.
PWR2 Green On Power is being supplied from power input 2.
Off Power is not being supplied from power input 2.
PoE Amber On Power is being supplied via PoE.
Off Power is not being supplied via PoE.
FAULT Red
Blinking (slow at
1-second intervals)
Cannot get an IP address from the DHCP server
Off No error conditions exist
STATE Green/Red
Green System startup is complete and the system is in operation
Green (Blinking at
1-second intervals)
The AWK has been located by the Wireless Search Utility
Red Booting or Error condition
WLAN1 Green/Amber
Green On WLAN1 functions in client mode.
Blinking Green WLAN1’s data communication is running in client mode
Amber On WLAN1 functions in AP/bridge mode.
Blinking Amber WLAN1’s data communication is running in AP/bridge
mode
Off WLAN1 is not in use.
WLAN2 Green/Amber
Green On WLAN2 function is in client mode.
Blinking Green WLAN2’s data communication is running in Client mode
Amber On WLAN2 function is in AP/bridge mode.
Blinking Amber WLAN2’s data communication is running in AP/bridge
mode
Off WLAN2 is not in use.
TP Port (LAN1, LAN2) LED Indicators (Port Interface)
10M Yellow
On TP port’s 10 Mbps link is active.
Blinking Data is being transmitted at 10 Mbps
Off TP port’s 10 Mbps link is inactive.
100M Green
On TP port’s 100 Mbps link is active.
Blinking Data is being transmitted at 100 Mbps
Off TP port’s 100 Mbps link is inactive.

AWK-5222 Introduction
1-6
ATTENTION
When the LEDs for
STATE (Green), FAULT, WLAN1 and WLAN2 all light up simultaneously and blink at
one
-second intervals, it means the system failed to boot. This may be due to improper operation or issues
such as an unexpected shutdown during firmware update.
To recover the firmware, refer to “Firmware
Recovery
” in Chapter 6.
Beeper
The beeper signals that the system is ready with two short beeps.
Reset Button
The RESET button is located on the top panel of the AWK-5222. You can reboot the AWK-5222 or reset it to
factory default settings by pressing the RESET button with a pointed object such as an unfolded paper clip.
•System reboot:Hold the RESET button down for under 5 seconds and then release.
•Reset to factory default: Hold the RESET button down for over 5 seconds until the STATE LED starts
blinking green. Release the button to reset the AWK-5222.
Relay (Digital Output)
The AWK-5222 has one relay output, which consists of 2 terminal block contacts on the top panel, as shown
below. These relay contacts are used to forward system failure and user-configured events.
The two wires attached to the relay contacts form an open circuit when a user-configured event is triggered. If
a user-configured event does not occur, the relay circuit will remain closed. For safety reason, the relay circuit
is kept open when the AWK-5222 is not powered.
The AWK-5222’s relay status is summarized as follows:
Power Status Event Relay
Off – Open
On Yes Open
No Short

AWK-5222 Introduction
1-7
Antenna
If you need to improve the performance of the Main1 and Main2 antennas, you can connect additional antennas
to the side panel of the AWK-5222 using an antenna cable (Position A: AUX1 and Position B: AUX2). The default
antenna for the AWK-5222 is a 2 dBi, dual-band omni-directional antenna, RP-SMA (male).
Main1
Main2
Position A Position B

2
2. Getting Started
This chapter explains how to install Moxa’s AirWorks AWK-5222 for the first time, quickly set up your wireless
network, and test whether the connection is running well. The function guide helps you find the functions that
you need easily.
The following topics are covered in this chapter:

First-Time Installation and Configuration

Communication Testing

Function Map

AWK-5222 Getting Started
2-2
First-Time Installation and Configuration
Before installing the AWK-5222, make sure that all items in the Package Checklist are in the box. In addition,
you will need access to a notebook computer or PC equipped with an Ethernet port. The AWK-5222 has a
default IP address that you must use when connecting to the device for the first time.
Step 1: Select the power source.
The AWK-5222 can be powered by DC power input or PoE (Power over Ethernet).
NOTE
The
information technology equipment (ITE) power supply
unit is to be connected only to PoE networks without
routing
it to the outside plant.
Step 2: Connect the AWK-5222 to a notebook or PC.
Since the AWK-5222 supports MDI/MDI-X auto-sensing, you can use either a straight-through cable or
crossover cable to connect the AWK-5222 to a computer. If the LED indicator on AWK-5222’s LAN port lights up,
it means the connection is established.
Step 3: Set up the computer’s IP address.
Set an IP address on the same subnet as the AWK-5222. Since the AWK-5222’s default IP address is
192.168.127.253, and the subnet mask is 255.255.255.0, you should set the IP address of the computer to
192.168.127.xxx.
NOTE
After you select
Maintenance

Load Factory Default and click the Submit button, the AWK-
5222 will be
reset to factory default settings and the IP address will be also reset to
192.168.127.253.
Step 4: Use the web-based manager to configure AWK-5222
Open your computer’s web browser and type http://192.168.127.253 in the address field to access the
homepage of the web-based Network Manager. Before the homepage opens, you will need to enter the
username and password as shown in the following figure. For first-time configuration, enter the default
username and password and then click on the Login button:
NOTE
Default user name and password:
Username: admin
Password: root
For security reasons, we strongly recommend changing the default password. To do so, select
Maintenance

Password
, and then follow the on-screen instructions to change the password.

AWK-5222 Getting Started
2-3
NOTE
Clicking on
Submit will apply your changes and refresh the web page. The string “(Updated)
” and a blinking
reminder will
appear on the upper-right corner of web page as shown below:
To make the changes effective, click
Restart and then Save and Restart after you change the settings.
The
AWK
-5222 will take about 30 seconds to complete the restart process.
Step 5: Select the operation mode for the AWK-5222.
By default, the AWK-5222’s operation mode is set to Wireless redundancy. You can change the setting in
Wireless Settings

Operation mode if you would like to use the Wireless bridge or AP-Client mode
instead. Detailed information about configuring the AWK-5222’s operation can be found in Chapter 3.
Step 6: Test communications.
In the following sections we will describe two test methods that can be used to ensure that a network
connection has been established.
Communication Testing
After installation, you can run a sample test to make sure the AWK-5222 and wireless connection are
functioning normally. Two testing methods are explained in the following sections. Use the first method if you
are using only one AWK-5222 device, and use the second method if you are using two or more AWK-5222s.
Testing Method for one AWK-5222
If you are only using one AWK-5222, you will need a second notebook computer equipped with a WLAN card.
Configure the WLAN card to connect to the AWK-5222 (NOTE: the default SSID is MOXA_1), and change the
IP address of the second notebook (B) so that it is on the same subnet as the first notebook (A) that is
connected to the AWK-5222.
After configuring the WLAN card, establish a wireless connection with the AWK-5222 and open a DOS window
on Notebook B. At the prompt, type:
ping <IP address of notebook A>
and then press Enter (see the figure below). A “Reply from IP address …” response means the communication
was successful. A “Request timed out.” response means the communication failed. In this case, check the
configuration to make sure the connections are correct.

AWK-5222 Getting Started
2-4
Testing Method for two or more AWK-5222s
If you have two or more AWK-5222s, you will need a second notebook computer (B) equipped with an Ethernet
port. Use the default settings for the first AWK-5222 connected to notebook A and change the second or third
AWK-5222 connected to notebook B to Client mode. Then, configure the notebooks and AWK-5222s properly.
After setting up the testing environment, open a DOS window on notebook B. At the prompt, type
ping <IP address of notebook A>
and then press Enter. A “Reply from IP address …” response means the communication was successful. A
“Request timed out” response means the communication failed. In this case, recheck the configuration to make
sure the connections are correct.

AWK-5222 Getting Started
2-5
Function Map
The management functions are categorized in a tree and shown in the left field of the web-based management
console. You can efficiently locate the function you need with the following guiding map.
A quick overview of the AWK-5222’s status
Basic settings for administering the AWK-5222
Essential settings related to establishing a
wireless network
Advanced features to support additional network
management and secure wired and wireless
communication
* These advanced functions are all optional.
Application-oriented device management functions
to set up events, traps, and reactions via relay
warning, e-mail and SNMP notification
* These functions are all optional.
Real-time status information to monitor wired/wireless
network performance, advanced services, and device
management functions
Functions to maintain the AWK-5222 and
diagnose the network
On-demand functions to support the operations of
web-based console management

3
3. Web Console Configuration
In this chapter, we explain each item in the web-based configuration and management tool. Moxa’s
easy-to-use functions will help you set up your AWK-5222 as well as establish and maintain your wireless
network easily.
The following topics are covered in this chapter:

Configuration by Web Browser

Overview

Basic Settings
System Info Settings
Network Settings
Time Settings

Wireless Settings
Operation Mode
WLAN1/WLAN2
Enabling Non-Redundant (Single RF) AP
WLAN Security Settings
Advanced Wireless Settings
WLAN Certification Settings (for EAP-TLS in
Redundant Client, Client or Slave mode only)

Advanced Settings
DHCP Server (for AP-Client
operation mode’s
AP mode only)
Packet Filters
RSTP Settings (for Master or
Slave mode only)
SNMP Agent
Storm Protection

Auto Warning Settings
System Log
Syslog
E-mail
Relay
Trap

Status
Wireless Status
Associated Client List (for Red
undant AP, AP,
or Master mode only)
DHCP Client List (for AP mode only)
System Log
Relay Status
DI and Power Status

Maintenance
Console Settings
Ping
Firmware Upgrade
Config Import Export
Load Factory Default
Password
Misc. Settings

Save Configuration

Restart

Logout

AWK-5222 Web Console Configuration
3-2
Configuration by Web Browser
Moxa AWK-5222’s web browser interface provides a convenient way to modify its configuration and access the
built-in monitoring and network administration functions. The recommended web browser is Microsoft®
Internet Explorer 5.5 or higher with JVM (Java Virtual Machine) installed.
NOTE
To use the AWK
-
5222’s management and monitoring functions from a PC host connected to the same LAN as
the AWK
-5222, you must make sure that the PC host and AWK-5222
are on the same logical subnet. Similarly,
if the AWK
-
5222 is configured for other VLAN settings, you must make sure your PC host is on the management
VLAN.
The Moxa AWK
-5222’s default IP is 192.168.127.253.
To access the AWK-5222’s web-based console management:
1. Open your web browser (e.g. Internet Explorer) and type the AWK-5222’s IP address in the address field.
Then press Enter to establish the connection.
2. In the web console login page, enter the password (the default Username is admin and the Password is
root, provided a new password has not been set) and then click Login to continue.
You may need to wait a few moments for the web page to download onto your computer. The model name and
IP address of your AWK-5222 are both shown on the title of the web page. This information can help you
identify multiple AWK-5222s.
You can use the menu tree on the left panel of the web console to open the function pages to access each of
AWK-5222’s functions.

AWK-5222 Web Console Configuration
3-3
In the following paragraphs, we will go through each of the AWK-5222’s management functions in detail. You
can also get a quick overview of these functions in the “Function Guiding Map” section of Chapter 2.
NOTE
The model name of the AWK
-5222 is shown as AWK-5222-XX where XX indicates the country code. T
he country
code represents the AWK
-5222 version and which bandwidth it uses. We use AWK-5222-US
as an example in
the following figures. The country code of model name on the screen may vary if you are using a different
version (band) AWK
-5222.
NOTE
For
security reasons, you will need to log back into the AWK-5222 after the 5-minute time-out.
Overview
The Overview page summarizes the AWK-5222’s current status. The information is categorized into several
groups: System info, Device info, and 802.11 info.

AWK-5222 Web Console Configuration
3-4
Basic Settings
The Basic Settings group includes the most commonly used settings required by administrators to maintain and
control the AWK-5222.
System Info Settings
The System Info items, especially Device name and Device description, are displayed and included on the
Overview page, SNMP information, and alarm emails. Setting System Info items makes it easier to identify
the different AWK-5222s connected to your network.
Device name
Setting Description Factory Default
Max. 31 Characters This option is useful for specifying the role or application of
different AWK-5222 units.
AWK-5222_<Serial
No. of this
AWK-5222>
Device location
Setting Description Factory Default
Max. 31 Characters To specify the location of different AWK-5222 units. None
Device description
Setting Description Factory Default
Max. 31 Characters Use this space to record more detailed description of AWK-5222 None
Device name
Setting Description Factory Default
Max. 31 Characters To provide information about whom to contact in order to
resolve problems. Use this space to
record contact information
of the person responsible for maintaining this AWK-5222.
None
Network Settings
The Network Settings configuration allows you to modify the usual TCP/IP network parameters. An explanation
of each configuration item is given below.
