AWK-4131 User’s Manual
Edition 2.1, August 2016
www.moxa.com/product
© 2016 Moxa Inc. All rights reserved.

AWK-4131 User’s Manual
The software described in this manual is furnished under a license agreement and may be used only in accordance with
the terms of that agreement.
Copyright Notice
© 2016 Moxa Inc. All rights reserved.
Trademarks
The MOXA logo is a registered trademark of Moxa Inc.
All other trademarks or registered marks in this manual belong to their respective manufacturers.
Disclaimer
Information in this document is subject to change without notice and does not represent a commitment on the part of
Moxa.
Moxa provides this document as is, without warranty of any kind, either expressed or implied, including, but not limited
to, its particular purpose. Moxa reserves the right to make improvements and/or changes to this manual, or to the
products and/or the programs described in this manual, at any time.
Information provided in this manual is intended to be accurate and reliable. However, Moxa assumes no responsibility for
its use, or for any infringements on the rights of third parties that may result from its use.
This product might include unintentional technical or typographical errors. Changes are periodically made to the
information herein to correct such errors, and these changes are incorporated into new editions of the publication.
Technical Support Contact Information
www.moxa.com/support
Moxa Americas
Toll
-free: 1-888-669-2872
Tel:
[phone]
Fax:
[phone]
Moxa China (Shanghai office)
Toll
-free: 800-820-5036
Tel:
[phone]
Fax:
[phone]
Moxa Europe
Tel:
[phone]
Fax:
[phone]
Moxa Asia
-Pacific
Tel:
[phone]
Fax:
[phone]
Moxa India
Tel:
[phone]
Fax:
[phone]

Table of Contents
1. Introduction...................................................................................................................................... 1-1
Overview ...........................................................................................................................................1-2
Package Checklist ...............................................................................................................................1-2
Product Features ................................................................................................................................1-2
Product Specifications .........................................................................................................................1-3
Functional Design ...............................................................................................................................1-6
LAN Port ....................................................................................................................................1-6
Recommended SFP Accessories.....................................................................................................1-6
LED Indicators ............................................................................................................................1-7
Beeper .......................................................................................................................................1-8
Reset Button...............................................................................................................................1-8
Relay (Digital Output) ..................................................................................................................1-8
Communication Connections .........................................................................................................1-9
Ethernet M12 Plug ..................................................................................................................... 1-10
2. Getting Started ................................................................................................................................. 2-1
First-time Installation and Configuration ................................................................................................2-2
Communication Testing .......................................................................................................................2-3
How to Test One AWK-4131 .........................................................................................................2-3
How to Test Two or More AWK-4131 Units......................................................................................2-4
Function Map .....................................................................................................................................2-5
3. Web Console Configuration ............................................................................................................... 3-1
Web Browser Configuration..................................................................................................................3-2
Overview ...........................................................................................................................................3-3
Basic Settings ....................................................................................................................................3-4
System Info Settings ...................................................................................................................3-4
Network Settings.........................................................................................................................3-5
Time Settings .............................................................................................................................3-6
Wireless Settings ................................................................................................................................3-7
Operation Mode ..................................................................................................................................3-7
Basic Wireless Settings........................................................................................................................3-8
WLAN Security Settings ............................................................................................................. 3-10
Advanced Wireless Settings ........................................................................................................ 3-16
WLAN Certification Settings (for EAP-TLS in Client/Slave mode only) ............................................... 3-19
Advanced Settings ............................................................................................................................ 3-19
Using a Virtual LAN.................................................................................................................... 3-20
Configuring a Virtual LAN ........................................................................................................... 3-21
DHCP Server (for AP mode only) ................................................................................................. 3-22
Packet Filters ............................................................................................................................ 3-23
RSTP Settings (for Master or Slave mode only) ............................................................................. 3-25
SNMP Agent ............................................................................................................................. 3-27
Link Fault Pass-Through (for Client/Slave mode only) .................................................................... 3-29
Auto Warning Settings....................................................................................................................... 3-29
System Log .............................................................................................................................. 3-30
Syslog ..................................................................................................................................... 3-31
E-mail...................................................................................................................................... 3-32
Relay ....................................................................................................................................... 3-33
Trap ........................................................................................................................................ 3-33
Status ............................................................................................................................................. 3-35
Wireless Status ......................................................................................................................... 3-35
Associated Client List (for AP/Master mode only) ........................................................................... 3-35
DHCP Client List (for AP mode only) ............................................................................................ 3-36
System Log .............................................................................................................................. 3-36
Relay Status ............................................................................................................................. 3-37
DI and Power Status.................................................................................................................. 3-37
RSTP Status ............................................................................................................................. 3-37
Maintenance .................................................................................................................................... 3-38
Console Settings ....................................................................................................................... 3-38
Ping......................................................................................................................................... 3-38
Firmware Upgrade ..................................................................................................................... 3-39
Config Import Export ................................................................................................................. 3-39
Load Factory Default.................................................................................................................. 3-40
Password ................................................................................................................................. 3-40
Misc. Settings ........................................................................................................................... 3-40
Save Configuration ........................................................................................................................... 3-41
Restart ............................................................................................................................................ 3-41
Logout ............................................................................................................................................ 3-42
4. Software Installation/Configuration ................................................................................................. 4-1

Overview ...........................................................................................................................................4-2
AWK Search Utility..............................................................................................................................4-2
Installing AWK Search Utility ........................................................................................................4-2
Configuring AWK Search Utility .....................................................................................................4-4
5. Other Console Configurations............................................................................................................ 5-1
RS-232 Console Configuration (115200, None, 8, 1, VT100) ....................................................................5-2
Configuration by Telnet and SSH Consoles .............................................................................................5-4
Configuration by Web Browser with HTTPS/SSL ......................................................................................5-4
Disabling Telnet and Browser Access .....................................................................................................5-5
6. References ........................................................................................................................................ 6-1
Beacon ..............................................................................................................................................6-2
DTIM.................................................................................................................................................6-2
Fragment...........................................................................................................................................6-2
RTS Threshold....................................................................................................................................6-2
STP and RSTP ....................................................................................................................................6-2
The STP/RSTP Concept ................................................................................................................6-2
Differences between RSTP and STP................................................................................................6-3
7. Supporting Information .................................................................................................................... 7-1
About This User’s Manual.....................................................................................................................7-2
DoC (Declaration of Conformity)...........................................................................................................7-3
Federal Communication Commission Interference Statement ............................................................7-3
R&TTE Compliance Statement.......................................................................................................7-3
Firmware Recovery .............................................................................................................................7-4
Technical Support Contact Information ..................................................................................................7-5

1
1. Introduction
Moxa’s AirWorks AWK-4131 enables wireless access to network resources. The AWK-4131 is rated to operate
at temperatures ranging from -40 to 75°C and is rugged enough for any harsh industrial environment.
The following topics are covered in this chapter:

Overview

Package Checklist

Product Features

Product Specifications

Functional Design
LAN Port
Recommended SFP Accessories
LED Indicators
Beeper
Reset Button
Relay (Digital Output)
Communication Connections
Ethernet M12 Plug

AWK-4131 Introduction
1-2
Overview
Moxa's new AWK-4131 3-in-1 industrial wireless Access Point meets the growing need for faster data
transmission speed and wider coverage by supporting IEEE 802.11n technology with a net data rate of up to
300 Mbps. The AWK-4131 combines two adjacent 20 MHz channels into a single 40 MHz channel to deliver a
potent combination of greater reliability and larger bandwidth. With wide operating temperatures ranging from
-40 to 75°C and dust-tight/weatherproof IP68-rated design, the AWK-4131 allows you to extend existing wired
networks to outdoor locations. The AWK-4131 can operate on either the 2.4 or 5 GHz bands and is
backward-compatible with the existing 802.11a/b/g deployments, which makes your wireless investments
future-proof.
Package Checklist
Moxa’s AWK-4131 is shipped with the following items. If any of these items is missing or damaged, please
contact your customer service representative for assistance.
•AWK-4131
•Two omni-directional antennas (5/2 dBi, N-type male, 2.4/5 GHz)
•Wall mounting kit
•Field-installable power plug
•Field-installable RJ45 plug
•Metal cap to cover M12 female DI/O connector
•Metal cap to cover RJ45 connector
•Documentation and software CD
•Quick installation guide (printed)
•Warranty card
NOTE
The above items come with the
AWK-4131 standard version. The package contents may vary in different
customized versions.
Product Features
•IEEE802.11a/b/g/n Compliant.
•Advanced Wireless Security:
64-bit and 128-bit WEP/WPA/WPA2.
SSID Hiding/IEEE 802.1X/RADIUS.
Packet access control & filtering.
•STP/RSTP support for redundancy of system networking.
•Long-distance transmission support.
•Turbo Roaming enables rapid handover (Client mode).
•ABC-01 for configuration import/export
•Customized antenna selection.
•RS-232 console management.
•2DI+1DO for on-site monitoring and warming.
•Operating temperature range from -40 to 75℃.
•Power input via PoE (Power over Ethernet) or redundant 24 VDC power inputs.
•Wall mounting ability.
•IP68-rated metal housing.
•Waterproof RJ45 connectors and M12 connectors.

AWK-4131 Introduction
1-3
Product Specifications
WLAN Interface
Standards:
IEEE 802.11a/b/g/n for Wireless LAN
IEEE 802.11i for Wireless Security
IEEE 802.3 for 10BaseT
IEEE802.3u 100BaseTX
IEEE 802.3ab for 1000BaseT
IEEE 802.3af for Power-over-Ethernet
IEEE 802.1D for Spanning Tree Protocol
IEEE 802.1w for Rapid STP
IEEE 802.1Q VLAN
Spread Spectrum and Modulation (typical):
• DSSS with DBPSK, DQPSK, CCK
• OFDM with BPSK, QPSK, 16QAM, 64QAM
• 802.11b: CCK @ 11/5.5 Mbps, DQPSK @ 2 Mbps,
DBPSK @ 11 Mbps
• 802.11a/g: 64QAM @ 54/48 Mbps, 16QAM @ 36/24 Mbps,
QPSK @ 18/12 Mbps, BPSK @ 9/6 Mbps
• 802.11n: 64QAM @ 300 Mbps to BPSK @ 6.5 Mbps (multiple rates supported)
Operating Channels (central frequency):
US:
2.412 to 2.462 GHz (11 channels)
5.18 to 5.24 GHz (4 channels)
EU:
2.412 to 2.472 GHz (13 channels)
5.18 to 5.24 GHz (4 channels)
JP:
2.412 to 2.472 GHz (13 channels, OFDM)
2.412 to 2.484 GHz (14 channels, DSSS)
5.18 to 5.24 GHz (4 channels for W52)
Security:
• SSID broadcast enable/disable
• Firewall for MAC/IP/Protocol/Port-based filtering
• 64-bit and 128-bit WEP encryption, WPA/WPA2-Personal and Enterprise (IEEE 802.1X/RADIUS, TKIP and
AES)
Transmission Rates:
802.11b: 1, 2, 5.5, 11 Mbps
802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n: 6.5 to 300 Mbps (multiple rates supported)

AWK-4131 Introduction
1-4
TX Transmit Power:
2.4GHz
802.11b:
•Typ. 18±1.5 dBm @ 1 to 11 Mbps
802.11g:
•Typ. 18±1.5 dBm @ 6 to 24 Mbps
•Typ. 17±1.5 dBm @ 36 to 48 Mbps
•Typ. 15±1.5 dBm @ 54 Mbps
802.11n:
•MCS15 20 MHz: Typ. 14 dBm (± 1.5 dBm)
•MCS15 40 MHz: Typ. 13 dBm (± -1.5 dBm)
5GHz
802.11a:
•Typ. 17±1.5 dBm @ 6 to 24 Mbps
•Typ. 16±1.5 dBm @ 36 to 48 Mbps
•Typ. 14±1.5 dBm @ 54 Mbps
802.11n:
•MCS15 20 MHz: Typ. 13 dBm (± 1.5 dBm)
•MCS15 40 MHz: Typ. 12 dBm (± 1.5 dBm)
RX Sensitivity:
2.4GHz
802.11b:
•-92 dBm @ 1 Mbps
•-90 dBm @ 2 Mbps
•-88 dBm @ 5.5 Mbps
•-84 dBm @ 11 Mbps
802.11g:
•-87 dBm @ 6 Mbps
•-86 dBm @ 9 Mbps
•-85 dBm @ 12 Mbps
•-82 dBm @ 18 Mbps
•-80 dBm @ 24 Mbps
•-76 dBm @ 36 Mbps
•-72 dBm @ 48 Mbps
•-70 dBm @ 54 Mbps
802.11n:
•-68 dBm @ MCS15 40 MHz
•-70 dBm @ MCS7 40 MHz
•-69 dBm @ MCS15 20 MHz,
•-71 dBm @ MCS7 20 MHz
802.11a:
•-87 dBm @ 6 Mbps
•-86 dBm @ 9 Mbps
•-85 dBm @ 12 Mbps
•-82 dBm @ 18 Mbps
•-80 dBm @ 24 Mbps
•-76 dBm @ 36 Mbps
•-72 dBm @ 48 Mbps
•-70 dBm @ 54 Mbps
802.11n:
•-68 dBm @ MCS15 40 MHz
•-70 dBm @ MCS7 40 MHz
•-69 dBm @ MCS15 20 MHz
•-71 dBm @ MCS7 20 MHz

AWK-4131 Introduction
1-5
Protocol Support
General Protocols: Proxy ARP, DNS, HTTP, HTTPS, IP, ICMP, SNTP, TCP, UDP, RADIUS, SNMP, PPPoE, DHCP
,
STP/RSTP (IEEE 802.1D/w), LLDP
AP-only Protocols: ARP, BOOTP, DHCP, dynamic VLAN-Tags for 802.1X-Clients
Interface
Default Antennas: 2 dual-band omni-directional antennas, 5 dBi at 2.4 GHz, 2 dBi at 5 GHz, N-type (male)
Connector for External Antennas: N-type (female)
LAN Ports: 1, 10/100/1000BaseT(X), auto negotiation speed (M12 female type)
Fiber Ports: 1, 1000BaseSFP slot
Console Port: RS-232 (waterproof RJ45-type)
LED Indicators: PWR, FAULT, STATE, WLAN, LAN
Alarm Contact (digital output, M12 male connector):
1 relay output with current carrying capacity of 1
A @ 24 VDC
Digital Inputs (M12 connector): 2 electrically isolated inputs
• +13 to +30 V for state “1”
• +3 to -30 V for state “0”
• Max. input current: 8 mA
Physical Characteristics
Housing: Metal, IP68 protection
Weight: 1.8 kg
Dimensions: 224 x 147.7 x 64.5 mm (8.82 x 5.82 x 2.54 in)
Installation: Wall mounting (standard), DIN-Rail mounting (optional), pole mounting (optional)
Environmental Limits
Operating Temperature: -40 to 75°C (-40 to 167°F)
Storage Temperature: -40 to 85°C (-40 to 185°F)
Ambient Relative Humidity: 5% to 100% (non-condensing)
Power Requirements
Input Voltage: 12 to 48 VDC, redundant dual DC power inputs or 48 VDC Power-over-
Ethernet (IEEE 802.3af
compliant)
Connector: M12 connector with A-coding
Reverse Polarity Protection: Present
Standards and Certifications
Safety: UL 60950-1, EN 60950-1
Hazardous Location: UL/cUL Class I Division 2, ATEX Zone 2
EMC: EN 301 489-1/17, FCC Part 15 Subpart B Class B, EN 55022/55024
Radio: EN 300 328, EN 301 893, TELEC
Note: Please check Moxa’s website for the most up-to-date certification status.
Warranty
Warranty Period: 5 years
Details: See www.moxa.com/warranty
ATTENTION
For EXPLOSION
-PROOF application, model AWK-3131 are designed and certified to meet ATEX shall be
mounted in a suitable enclosure rate to at least IP54 and Pollution Degree 2 as defined in EN60529 and used
within its rated electrical and environmental ratings.

AWK-4131 Introduction
1-6
ATTENTION
1. The AWK-4131 is NOT a portable mobile device and should be located at least 20 cm away from the
human body.
2. The AWK-4131 is NOT designed for the general public. To deploy AWK-4131 units and establish a
wireless network safely, a well-trained technician is required for installation.
Patent http://www.moxa.com/doc/operations/Moxa_Patent_Marking.pdf
Functional Design
LAN Port
The AWK-4131 comes standard with 1 combo Gigabit port (Ethernet M12 or Fiber SFP). The LAN LED will light
up when the 1st LAN cable is inserted.
ATTENTION
Do not use the PoE Injector. Instead, use an IEEE 802.3af or IEEE 802.3at compliant PSE (Power Sourcing
Equipment) for
the PoE (Power over Ethernet) device.
Recommended SFP Accessories
SFP-1G series
•SFP-1GSXLC:
Small form factor pluggable transceiver with 1000BaseSX, LC, 0.5 km, 0 to 60°C
•SFP-1GSXLC-T:
Small form factor pluggable transceiver with 1000BaseSX, LC, 0.5 km, -20 to 75°C
•SFP-1GLSXLC:
Small form factor pluggable transceiver with 1000BaseLSX, LC, 2 km, 0 to 60°C
•SFP-1GLSXLC-T:
Small form factor pluggable transceiver with 1000BaseLSX, LC, 2 km, -40 to 85°C
•SFP-1GLXLC:
Small form factor pluggable transceiver with 1000BaseLX, LC, 10 km, 0 to 60°C
•SFP-1GLXLC-T:
Small form factor pluggable transceiver with 1000BaseLX, LC, 10 km, -40 to 85°C
•SFP-1GLHLC:
Small form factor pluggable transceiver with 1000BaseLH, LC, 30 km, 0 to 60°C
M12 8-pin Ethernet
Port
SFP Fiber Port

AWK-4131 Introduction
1-7
•SFP-1GLHLC-T:
Small form factor pluggable transceiver with 1000BaseLH, LC, 30 km, -40 to 85°C
•SFP-1GLHXLC:
Small form factor pluggable transceiver with 1000BaseLHX, LC, 40 km, 0 to 60°C
•SFP-1GLHXLC-T:
Small form factor pluggable transceiver with 1000BaseLHX, LC, 40 km, -40 to 85°C
•SFP-1GZXLC:
Small form factor pluggable transceiver with 1000BaseZX, LC, 80 km, 0 to 60°C
•SFP-1GZXLC-T:
Small form factor pluggable transceiver with 1000BaseZX, LC, 80 km, -40 to 85°C
•SFP-1GEZXLC:
Small form factor pluggable transceiver with 1000BaseEZX, LC, 110 km, 0 to 60°C
•SFP-1GEZXLC-120:
Small form factor pluggable transceiver with 1000BaseEZX, LC, 120 km, 0 to 60°C
LED Indicators
The LEDs on the front panel of AWK-4131 allow you to identity the status and wireless settings quickly.
The LED for FAULT indicates the system failure and user-configured events. If the AWK-4131 cannot retrieve
the IP address from a DHCP server, the FAULT LED will blink at an interval of one second.
The following table is a summary for the wireless settings and LED displays. You can check the status of the
AWK-4131 by reading these LEDs. More information about “Basic Wireless Settings” is presented in Chapter 3.
LED Color State Description
Front Panel LED Indicators (System)
PWR Green On Power is being supplied (from power input 1 or 2, or PoE).
Off Power is not being supplied
FAULT Red
Blink
(slow)
Cannot get an IP address from the DHCP server (interval: 1 sec)
Blink
(fast)
IP address conflict (interval: 0.5 sec)
Off Error condition does not exist.
WLAN
Green
On WLAN functions is in Client/Slave mode.
Blink WLAN’s data communication is run in Client/Slave mode
Off WLAN is not in use or not working properly
Amber
On WLAN functions is in AP/Bridge mode.
Blink WLAN’s data communication is run in AP/Master mode
Off WLAN is not in use or not working properly.
LAN
Green
On LAN port’s 1000Mbps link is active.
Blink Data is being transmitted at 1000 Mbps
Off LAN port’s 1000Mbps link is inactive.
Amber
On LAN port’s 10/100Mbps link is active.
Blink Data is being transmitted at 10/100 Mbps
Off LAN port’s 10/100Mbps link is inactive.

AWK-4131 Introduction
1-8
ATTENTION
When the LEDs for STATE (Green), FAULT, and WLAN all light up simultaneously and blink at one
-second
intervals, it means the system failed to boot. This may be due to improper operation or uncontrollable issues,
such as an unexpected shutdown during firmware update. To recover the firmware, refer to “Firmware
Recovery” in Chapter 6.
Beeper
The beeper signals that the system is ready with two short beeps.
Reset Button
The RESET button is located on the bottom panel of the AWK-4131. You can reboot the AWK-4131 or reset it
to factory default settings by pressing the RESET button with a pointed object such as an unfolded paper clip.
•System reboot: Hold the RESET button down for under 5 seconds and then release.
•Reset to factory default: Hold the RESET button down for over 5 seconds until the STATE LED starts
blinking green. Release the button to reset the AWK-4131.
STEP 1:
Remove the reset button cover.
STEP 2: Using a pointed object, press and hold the
reset button.
Relay (Digital Output)
The AWK-4131 has one relay output, which consists of the 2 contacts for the 8-pin M12 connector on the
bottom panel, as shown below. These relay contacts forward system failure and user-configured events.
The two wires attached to the relay contacts form an open circuit when a user-configured event is triggered. If
a user-configured event does not occur, the relay circuit will remain closed. For safety reason, the relay circuit
is kept open when the AWK-4131 is not powered.
The AWK-4131’s relay status is summarized as follows:
Power Status Event Relay
Off --- Open
On Yes Open
No Short

AWK-4131 Introduction
1-9
Pin Signal
1 Relay
2
3 DI1 I1
4 DI1 COM_1
5 DI2 I2
6 DI2 COM_2
7 Reserved
8
Communication Connections
Connecting the Data Lines
10/100/1000BaseT(X) Ethernet Port Connection
The AWK-4131 has 10/100/1000BaseT(X) Ethernet ports (8-pin shielded M12 connector with A coding). The
10/100/1000BaseT(X) ports located on the AWK-4131’s bottom panel are used to connect to Ethernet-enabled
devices. Below we show pinouts for both MDI (NIC-type) ports and MDI-X (HUB/Switch-type) ports.
Pinouts for the 10/100/1000BaseT(X) M12 (8-pin) Port
ATTENTION
To ensure the IP6
8-rated connectivity, you must use a waterproof housing during any communication
activities. An IP6
8-rated field installable plug, which is attached in the AWK-4131’s accessory pack, may be
needed in this case. The installation
procedure is shown below:

AWK-4131 Introduction
1-10
Ethernet M12 Plug
Dimensions (unit: mm)
Installation
1. Refer to the pin assignment and solder wires with ;
2. Then assemble , , , and in order;
3. Test the plug to ensure the quality.
RS-232 Connection
The AWK-4131 has one RS-232 (8-pin RJ45) console port located on the bottom panel. Use either an
RJ45-to-DB9 or RJ45-to-DB25 cable to connect the Moxa AWK-4131’s console port to your PC’s COM port. You
may then use a console terminal program to access the AWK-4131 for console configuration.
Console Pinouts for 10
-pin or 8-pin RJ45
10-Pin Description 8-Pin
1 –
2 DSR 1
3 RTS 2
4 GND 3
5 TxD 4
6 RxD 5
7 DCD 6
8 CTS 7
9 DTR 8
10 – –
NOTE
1. The pin numbers for male DB9 and DB25 connectors, and hole numbers for female DB9 and DB25
connectors are labeled on the connector. However, the numbers are typically quite small, so you may
need to use a magnifying glass to see the numbers clearly.
2. The pin numbers for both 8-pin and 10-
pin RJ45 connectors (and ports) are typically not labeled on the
connector (or port). Refer to the Pinout diagram above to see how RJ45 pins are numbered.

2
2. Getting Started
In this chapter we explain how to install Moxa’s AirWorks AWK-4131 for the first time, and quickly set up your
wireless network and test whether the connection is operating properly. The Function Map discussed in the
third section provides a convenient means of determining which functions you need to use.
The following topics are covered in this chapter:

First-time Installation and Configuration

Communication Testing
How to Test One AWK-4131
How to Test Two or More AWK-4131 Units

Function Map

AWK-4131 Getting Started
2-2
First-time Installation and Configuration
Before installing the AWK-4131, make sure that all items in the Package Checklist are in the box. You will need
access to a notebook computer or PC equipped with an Ethernet port. The AWK-4131 has a default IP address
that must be used when connecting to the device for the first time.
•Step 1: Select the power source.
The AWK-4131 can be powered by a DC power input or PoE (Power over Ethernet). The AWK-4131 will use
whichever power source you choose.
•Step 2: Connect the AWK-4131 to a notebook or PC.
Since the AWK-4131 supports MDI/MDI-X auto-sensing, you can use either a straight-through cable or
crossover cable to connect the AWK-4131 to a computer. The LED indicator on the AWK-4131’s LAN port
will light up when a connection is established.
•Step 3: Set up the computer’s IP address.
Choose an IP address on the same subnet as the AWK-4131. Since the AWK-4131’s default IP address is
192.168.127.253, and the subnet mask is 255.255.255.0, you should set the IP address of the
computer to 192.168.127.xxx.
NOTE
After you
select Maintenance Load Factory Default and click the Submit button, the AWK-4131
will be
reset to
factory default settings and the IP address will be reset to 192.168.127.253.
•Step 4: Use the web-based manager to configure the AWK-4131
Open your computer’s web browser and type http://192.168.127.253 in the address field to access the
homepage of the web-based Network Manager. Before the homepage opens, you will need to enter the user
name and password as shown in the following figure. For first-time configuration, enter the default user
name and password and then click on the Login button:
NOTE
Default user name and password:
User Name: admin
Password: root
For security reasons, we strongly recommend changing the default password. To do so,
select
Maintenance

Password, and then follow the on-screen instructions to change the password.

AWK-4131 Getting Started
2-3
NOTE
After you click
Submit to apply changes the web page will refresh (Updated) will appear on the page
and a
blinking reminder will be shown on the upper
-right corner of the web page:
To
activate the changes click Restart and then Save and Restart
after you change the settings. About 30
seconds are needed for the
AWK-4131 to complete the reboot procedure.
•Step 5: Select the AWK-4131 operation mode.
By default, the AWK-4131’s operation mode is set to AP. You can change to Client mode in Wireless
Settings Basic Wireless Settings. Detailed information about configuring the AWK-4131’s operation
can be found in Chapter 3.
•Step 6: Test communications.
In the following sections we describe two test methods that can be used to ensure that a network
connection has been established.
Communication Testing
After installing the AWK-4131 you can run a sample test to make sure the AWK-4131 and wireless connection
are functioning normally. Two testing methods are described below. Use the first method if you are using only
one AWK-4131 device, and use the second method if you are using two or more AWK-4131 units.
How to Test One AWK-4131
If you are only using one AWK-4131, you will need a second notebook computer equipped with a WLAN card.
Configure the WLAN card to connect to the AWK-4131 (NOTE: the default SSID is MOXA), and change the IP
address of the second notebook (Notebook B) so that it is on the same subnet as the first notebook (Notebook
A), which is connected to the AWK-4131.
After configuring the WLAN card, establish a wireless connection with the AWK-4131 and open a DOS window
on Notebook B. At the prompt, type
ping <IP address of notebook A>
and then press Enter (see the figure below). A “Reply from IP address …” response means the communication
was successful. A “Request timed out.” response means the communication failed. In this case, recheck the
configuration to make sure the connections are correct.

AWK-4131 Getting Started
2-4
How to Test Two or More AWK-4131 Units
If you have two or more AWK-4131 units, you will need a second notebook computer (Notebook B) equipped
with an Ethernet port. Use the default settings for the first AWK-4131 connected to notebook A and change the
second or third AWK-4131 connected to notebook B to Client mode, and then configure the notebooks and
AWK-4131 units properly.
After setting up the testing environment, open a DOS window on notebook B. At the prompt, type:
ping <IP address of notebook A>
and then press Enter. A “Reply from IP address …” response means the communication was successful. A
“Request timed out” response means the communication failed. In this case, recheck the configuration to make
sure the connections are correct.

AWK-4131 Getting Started
2-5
Function Map
Basic settings for administering the AWK-4131
Essential settings related to establishing a
wireless network
Advanced features to support additional network
management and secure wired and wireless
communication
Note: These advanced functions are all optional.
Application-oriented device
management functions to set up
events, traps,
and reactions via relay
warning, e-mail, and SNMP
notification
Note: These functions are all optional.
Current status information for monitoring
wired/wireless network performance, advanced
services, and device management functions.
Functions for maintaining the AWK-4131, and
for diagnosing the network.
On-demand functions to support the web-
based
console management operation.
Quick overview of the AWK-4131’s status

3
3. Web Console Configuration
In this chapter, we explain all aspects of web-based console configuration. Moxa’s easy-to-use management
functions help you set up your AWK-4131 and make it easy to establish and maintain your wireless network.
The following topics are covered in this chapter:

Web Browser Configuration

Overview

Basic Settings
System Info Settings
Network Settings
Time Settings

Wireless Settings

Operation Mode

Basic Wireless Settings
WLAN Security Settings
Advanced Wireless Settings
WLAN Certification Settings (for EAP-TLS in
Client/Slave mode only)

Advanced Settings
Using a Virtual LAN
Configuring a Virtual LAN
DHCP Server (for AP mode only)
Packet Filters
RSTP Settings (for Master or Slave
mode only)
SNMP Agent
Link Fault Pass-Through (for Client/Slave
mode only)

Auto Warning Settings
System Log
Syslog
E-mail
Relay
Trap

Status
Wireless Status
Associated Client List (for AP/Master mode
only)
DHCP Client List (for AP mode only)
System Log
Relay Status
DI and Power Status
RSTP Status

Maintenance
Console Settings
Ping
Firmware Upgrade
Config Import Export
Load Factory Default
Password
Misc. Settings

Save Configuration

Restart

Logout
