Moxa AirWorks AWK-6222 User’s Manual
Edition 2.0, August 2016
www.moxa.com/product
© 2016 Moxa Inc. All rights reserved.

Moxa AirWorks AWK-6222 User’s Manual
The software described in this manual is furnished under a license agreement and may be used only in accordance with
the terms of that agreement.
Copyright Notice
© 2016 Moxa Inc. All rights reserved.
Trademarks
The MOXA logo is a registered trademark of Moxa Inc.
All other trademarks or registered marks in this manual belong to their respective manufacturers.
Disclaimer
Information in this document is subject to change without notice and does not represent a commitment on the part of
Moxa.
Moxa provides this document as is, without warranty of any kind, either expressed or implied, including, but not limited
to, its particular purpose. Moxa reserves the right to make improvements and/or changes to this manual, or to the
products and/or the programs described in this manual, at any time.
Information provided in this manual is intended to be accurate and reliable. However, Moxa assumes no responsibility for
its use, or for any infringements on the rights of third parties that may result from its use.
This product might include unintentional technical or typographical errors. Changes are periodically made to the
information herein to correct such errors, and these changes are incorporated into new editions of the publication.
Technical Support Contact Information
www.moxa.com/support
Moxa Americas
Toll
-free: 1-888-669-2872
Tel:
[phone]
Fax:
[phone]
Moxa China (Shanghai office)
Toll
-free: 800-820-5036
Tel:
[phone]
Fax:
[phone]
Moxa Europe
Tel:
[phone]
Fax:
[phone]
Moxa Asia
-Pacific
Tel:
[phone]
Fax:
[phone]
Moxa
India
Tel:
[phone]
Fax:
[phone]

Table of Contents
1. Introduction...................................................................................................................................... 1-1
Overview ...........................................................................................................................................1-2
Package Checklist ...............................................................................................................................1-2
Product Features ................................................................................................................................1-2
Product Specifications .........................................................................................................................1-3
Functions...........................................................................................................................................1-5
LED Indicators ............................................................................................................................1-5
Reset Button...............................................................................................................................1-6
Relay (Digital Output) ..................................................................................................................1-6
2. Getting Started ................................................................................................................................. 2-1
First-time Installation and Configuration ................................................................................................2-2
Communication Testing .......................................................................................................................2-3
Function Guide Map ............................................................................................................................2-5
3. Web Console Configuration ............................................................................................................... 3-1
Configuration by Web Browser .............................................................................................................3-2
Overview ...........................................................................................................................................3-3
Basic Settings ....................................................................................................................................3-4
System Info Settings ...................................................................................................................3-4
Network Settings.........................................................................................................................3-4
Time Settings .............................................................................................................................3-5
Wireless Settings ................................................................................................................................3-7
Operation Mode ..........................................................................................................................3-7
Enabling Non-Redundant (Single RF) AP....................................................................................... 3-10
WLAN Security Settings ............................................................................................................. 3-13
Advanced Wireless Settings ........................................................................................................ 3-21
WLAN Certification Settings (for EAP-TLS in Redundant Client, Client or Slave mode only).................. 3-23
Advanced Settings ............................................................................................................................ 3-24
DHCP Server (for AP-Client operation mode’s AP mode only) .......................................................... 3-24
Packet Filters ............................................................................................................................ 3-26
RSTP Settings (for Master or Slave mode only) ............................................................................. 3-28
SNMP Agent ............................................................................................................................. 3-29
Storm Protection ....................................................................................................................... 3-31
Auto Warning Settings....................................................................................................................... 3-32
System Log .............................................................................................................................. 3-32
Syslog ..................................................................................................................................... 3-33
E-mail...................................................................................................................................... 3-34
Relay ....................................................................................................................................... 3-35
Trap ........................................................................................................................................ 3-36
Status ............................................................................................................................................. 3-38
Wireless Status ......................................................................................................................... 3-38
Associated Client List (for Redundant AP, AP, or Master Mode only) ................................................. 3-38
DHCP Client List (for AP mode only) ............................................................................................ 3-39
System Log .............................................................................................................................. 3-39
Relay Status ............................................................................................................................. 3-40
DI and Power Status.................................................................................................................. 3-40
Maintenance .................................................................................................................................... 3-40
Console Settings ....................................................................................................................... 3-41
Ping......................................................................................................................................... 3-41
Firmware Upgrade ..................................................................................................................... 3-41
Config Import Export ................................................................................................................. 3-42
Load Factory Default.................................................................................................................. 3-42
Password ................................................................................................................................. 3-43
Misc. Settings ........................................................................................................................... 3-43
Save Configuration ........................................................................................................................... 3-43
Restart ............................................................................................................................................ 3-44
Logout ............................................................................................................................................ 3-44
4. Software Installation/Configuration ................................................................................................. 4-1
Overview ...........................................................................................................................................4-2
Wireless Search Utility.........................................................................................................................4-2
Installing Wireless Search Utility ...................................................................................................4-2
Configuring the Wireless Search Utility...........................................................................................4-5
5. Other Console Configurations............................................................................................................ 5-1
RS-232 Console Configuration (115200, None, 8, 1, VT100) ....................................................................5-2
Configuration by Telnet and SSH Consoles .............................................................................................5-4
Configuration by Web Browser with HTTPS/SSL ......................................................................................5-5
Disabling Telnet and Browser Access .....................................................................................................5-6

6. References ........................................................................................................................................ 6-1
Beacon ..............................................................................................................................................6-2
DTIM.................................................................................................................................................6-2
Fragment...........................................................................................................................................6-2
RTS Threshold....................................................................................................................................6-2
STP and RSTP ....................................................................................................................................6-2
The STP/RSTP Concept ................................................................................................................6-2
Differences between RSTP and STP................................................................................................6-3
7. Support Information ......................................................................................................................... 7-1
About This User’s Manual.....................................................................................................................7-2
DoC (Declaration of Conformity)...........................................................................................................7-2
Federal Communication Commission Interference Statement ............................................................7-2
R&TTE Compliance Statement.......................................................................................................7-3
Firmware Recovery .............................................................................................................................7-3
Technical Support Contact Information..................................................................................................7-5

1
1. Introduction
Moxa AirWorks AWK-6222 with dual-RF wireless capability allows wireless users to access network resources
more reliably. The AWK-6222 is rated to operate at temperatures ranging from -40 to 75°C and is rugged
enough for any harsh industrial environment.
The following topics are covered in this chapter:

Overview

Package Checklist

Product Features

Product Specifications

Functions
LED Indicators
Reset Button
Relay (Digital Output)

AWK-6222 Introduction
1-2
Overview
The AWK-6222 outdoor dual-RF wireless AP/bridge/client provides a flexible solution for industrial applications
in a demanding environment. The AWK-6222 is rated to operate at temperatures ranging from -40 to 75°C,
and its dustproof and weatherproof design is IP68-rated, allowing you to extend existing wired networks to
outdoor locations. With two independent RF modules, the AWK-6222 supports a greater variety of wireless
configurations and applications. It can also increase the reliability of entire wireless network by enabling
redundant wireless connections. The AWK-6222 also has two redundant DC power inputs to increase the
reliability of the power supply, and can be powered via PoE.
Package Checklist
Moxa’s AWK-6222 ships with the following items. If any of these items is missing or damaged, please contact
your customer service representative for assistance.
•1 AWK-6222 wireless AP/bridge/client
•2 dual-band omni-directional antennas (5/2 dBi, N-type male, 2.4/5 GHz)
•Wall mounting kit (includes 2 supports)
•Field-installable power plug
•Field-installable RJ45 plug
•2 metal caps to cover RJ45 connectors
•Metal cap to cover M12-female DI/O connector
•2 metal caps to cover N-type connectors
•Transparent plastic sticks for field-installable plugs
•Documentation and software CD
•Quick installation guide (printed)
•Warranty card
NOTE
The items above come with the standard AWK
-
6222. The package contents may vary for customized versions.
Product Features
•IEEE802.11a/b/g compliant.
•Three-in-one design (AP/Bridge/Client).
•Dual-RF design for redundant wireless communication.
•Advanced Wireless Security:
64-bit and 128-bit WEP/WPA/WPA2
SSID Hiding/IEEE 802.1X/RADIUS
Packet access control & filtering
•STP/RSTP support for network redundancy.
•Long-distance transmission support.
•Turbo Roaming™ enables rapid handover (Client mode).
•Dedicated antenna selection.
•RS-232 console management.
•2DI+1DO for on-site monitoring and warming.
•-40 to 75°C operating temperature range (-T model).
•Redundant 24 VDC power inputs or IEEE802.3af Power over Ethernet.
•DIN-rail or wall mountable.

AWK-6222 Introduction
1-3
•IP68 protected high-strength metal housing.
Product Specifications
WLAN Interface
Standards:
IEEE 802.11a/b/g for Wireless LAN
IEEE 802.11i for Wireless Security
IEEE 802.3 for 10BaseT(X)
IEEE 802.3u for 100BaseT(X)
IEEE 802.3af for Power
-over-Ethernet
IEEE 802.
1D for Spanning Tree Protocol
IEEE 802.1w for Rapid STP
IEEE 802.1Q for VLAN
Spread Spectrum and Modulation (typical):
• DSSS with DBPSK, DQPSK, CCK
• OFDM with BPSK, QPSK, 16QAM, 64QAM
• 802.11b: CCK @ 11/5.5 Mbps, DQPSK @ 2 Mbps,
DBPSK @ 11 Mbps
• 8
02.11a/g: 64QAM @ 54/48 Mbps, 16QAM @ 36/24 Mbps,
QPSK @ 18/12 Mbps, BPSK @ 9/6 Mbps
Operating Channels (central frequency):
US:
2.412 to 2.462 GHz (11 channels)
5.18 to 5.24 GHz (4 channels)
EU:
2.412 to 2.472 GHz (13 channels)
5.18 to 5.24 GHz (4
channels)
JP:
2.412 to 2.472 GHz (13 channels, OFDM)
2.412 to 2.484 GHz (14 channels, DSSS)
5.18 to 5.24 GHz (4 channels for W52)
Security:
• SSID broadcast enable/disable
• Firewall for MAC/IP/Protocol/Port
-based filtering
• 64
-bit and 128-bit WEP encryption, WPA/WPA2 Personal and Enterprise (IEEE 802.1X/RADIUS, TKIP, and
AES)
Transmission Rates:
802.11b: 1, 2, 5.5, 11
Mbps
802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54
Mbps
TX Transmit Power:
802.11b:
Typ. 23±1.5 dBm @ 1 to 11 Mbps
802.11g:
Typ. 20±1.5 dBm @ 6 to 24 Mbps, Typ. 19±1.5 dBm @ 36 Mbps, Typ. 18±1.5 dBm @ 48 Mbps, Typ. 17±1.5
dBm @ 54 Mbps
802.11a:
Typ. 18±1.5 dBm @ 6 to 24 Mbps, Typ. 16±1.5 dBm @ 36 to 48 Mbps, Typ. 15±1.5 dBm @ 54 Mbps

AWK-6222 Introduction
1-4
RX Sensitivity:
802.11b:
-
97 dBm @ 1 Mbps, -94 dBm @ 2 Mbps, -92 dBm @ 5.5 Mbps, -90 dBm @ 11 Mbps
802.11g:
-
93 dBm @ 6 Mbps, -91 dBm @ 9 Mbps, -90 dBm @ 12 Mbps, -88 dBm @ 18 Mbps, -84 dBm @ 24 Mbps, -
80
dBm @ 36 Mbps,
-76 dBm @ 48 Mbps, -74 dBm @ 54 Mbps
802.11a:
-
90 dBm @ 6 Mbps, -89 dBm @ 9 Mbps, -89 dBm @ 12 Mbps, -85 dBm @ 18 Mbps, -83 dBm @ 24 Mbps, -
79
dBm @ 36 Mbps,
-75 dBm @ 48 Mbps, -74 dBm @ 54 Mbps
Protocol Support
General Protocols:
Proxy ARP, DNS, HTTP, HTTPS, IP, ICMP, SNTP, TCP, UDP, RADIUS, SNMP, PPPoE, DHCP
AP
-only Protocols: ARP, BOOTP, DHCP, STP/RSTP (IEEE 802.1D/w)
Interface
Default Antennas:
2 dual-band omni-directional antennas, 5 dBi at 2.4 GHz, 2 dBi at 5 GHz, N-
type (male)
Connector for External Antennas:
N-type (female)
RJ45 Ports:
2, 10/100BaseT(X), auto negotiation speed, F/H duplex mode, and auto MDI/MDI-
X connection
Console Port:
RS-232 (waterproof RJ45-type)
Reset:
Present
LED Indicators:
PWR, FAULT, STATE, WLAN1, WLAN2, LAN1, LAN2
Alarm Contact (digital output, M12 female
connector):
1 relay output with current carrying capacity of 1
A @ 24 VDC
Digital Inputs (M12 female connector):
2 electrically isolated inputs
• +13 to +30 V for state “1”
• +3 to
-30 V for state “0”
• Max. input current: 8 mA
Physical Characteristics
Housing:
Metal, IP68 protection
Weight:
1.8 kg
Dimensions:
224 x 148 x 67 mm (8.82 x 5.82 x 2.62 in)
Installation:
Wall mounting (standard), DIN-rail mounting (optional), pole mounting (optional)
Environmental Limits
Operating Temperature:
-40 to 75°C (-40 to 167°F)
Storage Temperature:
-40 to 85°C (-40 to 185°F)
Ambient Relative Humidity:
5% to 100% (non-condensing)
Power Requirements
Input Voltage:
12 to 48 VDC, redundant dual DC power inputs or 48 VDC Power-over-
Ethernet (IEEE 802.3af
compliant)
Connector:
M12 male connector with A-coding
Power Consumption:
12 to 48 VDC, 1.066 to 0.312 A
Reverse Polarity Protection:
Present
Standards and
Certifications
Safety:
UL 60950-1, EN 60950-1
Hazardous Location:
UL/cUL Class I Division 2, ATEX Zone 2
EMC:
EN 301 489-1/17, FCC Part 15 Subpart B, EN 55022/55024
Radio:
EN 300 328, EN 301 893, TELEC, FCC ID SLE-WAPA003
Note: Please check Moxa’s web
site for the most up-to-date certification status.
MTBF
(mean time between failures)
Time:
284,072 hrs
Warranty
Warranty Period:
5 years
Details:
See www.moxa.com/warranty

AWK-6222 Introduction
1-5
ATTENTION
The AWK
-6222 is NOT a portable mobile device and should be located at least 20cm away from the human
body. The AWK
-6222 is NOT designed for the general consumer. A well-
trained technician is required to safely
deploy AWK
-6222s and establish a wireless network.
Patent http://www.moxa.com/doc/operations/Moxa_Patent_Marking.pdf
Functions
LED Indicators
The LEDs on the front panel help you to quickly identity the status and wireless settings of the AWK-6222. The
following table gives a summary:
LED Color State Description
PWR Green On Power is being supplied (from power input 1 or 2, or PoE)
Off Power is not being supplied.
FAULT Red
On Relay output is triggered by an event.
Blinking (slow
at 1-second
intervals)
Cannot get an IP address from the DHCP server.
Blinking (fast
at 0.5-second
intervals)
IP address conflict.
Off Normal status.
STATE Green/Red
Green System startup is complete and the system is in operation.
Green
(blinking at
1-second
intervals)
The Wireless Search Utility has located the AWK.
Red Booting or Error condition.
WLAN 1/
WLAN 2 Green/Amber
Green On WLAN is functioning in client/slave mode.
Green Blinking WLAN’s is transmitting data in client/slave mode.
Amber On WLAN is functioning in AP/bridge/master mode.
Amber
Blinking
WLAN’s is transmitting data in AP/bridge/master mode.
Off WLAN is not in use or not working properly.
LAN 1/
LAN 2 Yellow/Green
Yellow On LAN port’s 10 Mbps link is active.
Yellow Blinking Data is being transmitted at 10 Mbps.
Yellow Off LAN port’s 10 Mbps link is inactive.
Green On LAN port’s 100 Mbps link is active.
Green Blinking Data is being transmitted at 100 Mbps.
ATTENTION
When the LEDs for
STATE (Green), FAULT, WLAN1, and WLAN2 all light up simultaneously and blink at
one
-second intervals, it means that the system failed to boot. This may be due to an improper operation or
issue
s such as an unexpected shutdown during a firmware update. To recover the firmware, refer to “
Firmware
Recovery
” in Chapter 6.

AWK-6222 Introduction
1-6
Reset Button
The RESET button is located on the bottom panel of the AWK-6222. You can reboot the AWK-6222 or reset it
to factory default settings by pressing the RESET button with a pointed object such as an unfolded paper clip.
•System reboot: Hold the RESET button down for less than 5 seconds and then release.
•Reset to factory default: Hold the RESET button down for over 5 seconds until the STATE LED starts
blinking green. Release the button to reset the AWK-6222.
NOTE
Each time the system is turned on the reset button
can be disabled for 60 seconds.
S
TEP 1:Remove the reset button cover.
STEP 2
:Using a pointed object, press and hold the
reset button
.
Relay (Digital Output)
The AWK-6222 has one relay output, which consists of the 2 contacts for the 8-pin M12 connector on the
bottom panel, as shown below. These relay contacts forward system failure and user-configured events.
The two wires attached to the relay contacts form an open circuit when a user-configured event is triggered. If
a user-configured event does not occur, the relay circuit will remain closed. For safety reasons, the relay circuit
is kept open when the AWK-6222 is not powered.
The AWK-6222’s relay status is shown below:
Power Status Event Relay
Off – Open
On Yes Open
No Short

AWK-6222 Introduction
1-7
Digital Inputs and Relay-out Pin Assignment (8-pin M12 connector)
PIN 1 2 3 4 5 6 7 8
Function DOUT_I DOUT_O DI0+ DI0- DI1+ DI1- reserved reserved

2
2. Getting Started
This chapter explains how to install Moxa’s AirWorks AWK-6222 for the first time, quickly set up your wireless
network, and test whether the connection is running properly. The function guide helps you find the functions
that you need easily.
The following topics are covered in this chapter:

First-time Installation and Configuration

Communication Testing

Function Guide Map

AWK-6222 Getting Started
2-2
First-time Installation and Configuration
Before installing the AWK-6222, make sure that all items in the Package Checklist are in the box. In addition,
you will need access to a notebook computer or PC equipped with an Ethernet port. The AWK-6222 has a
default IP address that you must use when connecting to the device for the first time.
Step 1: Select the power source.
The AWK-6222 can be powered by DC power input or PoE (Power over Ethernet).
NOTE
The information technology equipment (ITE) power supply unit is to be connected only to PoE networks without
routing it to the outside plant.
Step 2: Connect the AWK-6222 to a notebook or PC.
Since the AWK-6222 supports MDI/MDI-X auto-sensing, you can use either a straight-through cable or
crossover cable to connect the AWK-6222 to a computer. If the LED indicator on the AWK-6222’s LAN port
lights up, it means the connection is established.
Step 3: Set up the computer’s IP address.
Set an IP address on the same subnet as the AWK-6222. Since the AWK-6222’s default IP address is
192.168.127.253, and the subnet mask is 255.255.255.0, you should set the IP address of the computer to
192.168.127.xxx.
NOTE
After yo
u select Maintenance

Load Factory Default and click the Submit button, the AWK-6222 will
be
reset to
factory default settings and the IP address will also reset to 192.168.127.253.
Step 4: Use the web-based manager to configure AWK-6222
Open your computer’s web browser and type in http://192.168.127.253 in the address field to access the
homepage of the web-based Network Manager. Before the homepage opens, you will need to enter the
username and password as shown in the following figure. For first-time configuration, enter the default
username and password and then click on the Login button:

AWK-6222 Getting Started
2-3
NOTE
Default U
sername and Password:
Username: admin
Password: root
For security reasons, we strongly recommend changing the default password. T
o do so, select Maintenance

Password
, and then follow the on-screen instructions.
NOTE
Clicking on
Submit will apply your changes and refresh the web page. The string “(Updated)
” and a blinking
reminder will be displayed on the upper
-right corner of the page as shown below.
To make the changes effective, click
Restart and then Save and Restart after you change the settings.
The
AWK
-6222 will take about 30 seconds to complete its restart process.
Step 5: Select the operation mode
By default, the AWK-6222’s operation mode is set to Wireless redundancy. You can change the setting at
Wireless Settings

Operation mode if you would like to use Wireless bridge or AP-Client mode instead.
Detailed information about configuring the AWK-6222’s operation mode can be found in Chapter 3.
Step 6: Test communications.
In the following sections we will describe two test methods that can be used to ensure that a network
connection has been established.
Communication Testing
After installation, you can run a sample test to make sure the AWK-6222 and wireless connection are
functioning normally. Two testing methods are explained in the following sections. Use the first method if you
are using only one AWK-6222 device, and use the second method if you are using two or more AWK-6222s.
Testing Method for One AWK-6222 with AP-Client Operation Mode
If you are only using one AWK-6222, you will need a second notebook computer equipped with a WLAN card.
Configure the WLAN card to connect to the AWK-6222 (NOTE: the default SSID is MOXA_1), and change the
IP address of the second notebook (B) so that it is on the same subnet as the first notebook (A), which is
connected to the AWK-6222.

AWK-6222 Getting Started
2-4
After configuring the WLAN card, establish a wireless connection with the AWK-6222 and open a DOS window
on Notebook B. At the prompt, type
ping <IP address of notebook A>
and then press Enter (see the figure below). A “Reply from IP address …” response means the communication
was successful. A “Request timed out.” response means the communication failed. In this case, check the
configuration to make sure the connections are correct.
Testing Method for Two or More AWK-6222s with AP-Client Operation Mode
If you have two or more AWK-6222s, you will need a second notebook computer (B) equipped with an Ethernet
port. Use the default settings for the first AWK-6222 connected to notebook A and change the second or third
AWK-6222 connected to notebook B to Client mode. Then, configure the notebooks and AWK-6222s as
illustrated below:
After setting up the testing environment, open a DOS window on notebook B. At the prompt, type
ping <IP address of notebook A>
and then press Enter. A “Reply from IP address …” response means the communication was successful. A
“Request timed out” response means the communication failed. In this case, recheck the configuration to make
sure the connections are correct.

AWK-6222 Getting Started
2-5
Function Guide Map
The management functions are organized in a tree and shown in the left field of the web-based management
console. You can efficiently locate the function you need with the following guiding map.
A quick overview of the AWK-6222’s status
Basic settings for administering the AWK-6222
Essential settings related to establishing
a wireless network
Advanced features to support additional
network management and secure wired and
wireless communication
* These advanced functions are all optional.
Application-oriented device management
functions to set up events, traps, and
reactions via relay warning, e-mail and
SNMP notification
* These functions are all optional.
Real-time status information to monitor
wired/wireless network performance,
advanced services, and device
management functions
Functions to maintain the AWK-6222 and
diagnose the network
On-demand functions to support the
operations of web-based console management

3
3. Web Console Configuration
In this chapter, we explain each item in the web-based configuration and management tool. Moxa’s
easy-to-use management functions will help you set up your AWK-6222 as well as establish and maintain your
wireless network easily.
The following topics are covered in this chapter:

Configuration by Web Browser

Overview

Basic Settings
System Info Settings
Network Settings
Time Settings

Wireless Settings
Operation Mode
Enabling Non-Redundant (Single RF) AP
WLAN Security Settings
Advanced Wireless Settings
WLAN Certification Settings (for EAP-TLS in
Redundant Client, Client or Slave mode only)

Advanced Settings
DHCP Server (for AP-Client
operation mode’s
AP mode only)
Packet Filters
RSTP Settings (for Master or
Slave mode only)
SNMP Agent
Storm Protection

Auto Warning Settings
System Log
Syslog
E-mail
Relay
Trap

Status
Wireless Status
Associated Client List (for
Redundant AP, AP,
or Master Mode only)
DHCP Client List (for AP mode only)
System Log
Relay Status
DI and Power Status

Maintenance
Console Settings
Ping
Firmware Upgrade
Config Import Export
Load Factory Default
Password
Misc. Settings

Save Configuration

Restart

Logout

AWK-6222 Web Console Configuration
3-2
Configuration by Web Browser
Moxa AWK-6222’s web browser interface provides a convenient way to modify its configuration and access the
built-in monitoring and network administration functions. The recommended web browser is Microsoft®
Internet Explorer 5.5 or higher with JVM (Java Virtual Machine) installed.
NOTE
To use the AWK
-
6222’s management and monitoring functions from a PC host connected to the same LAN as
the AWK
-6222, you must make sure that the PC host and AWK-
6222 are on the same logical subnet. Similarly,
if the AWK
-6222 is co
nfigured for other VLAN settings, you must make sure your PC host is on the management
VLAN.
The Moxa AWK
-6222’s default IP is 192.168.127.253.
To access the AWK-5222’s web-based console management:
1. Open your web browser (e.g. Internet Explorer) and type the AWK-6222’s IP address in the address field.
Then press Enter to establish the connection.
2. In the web console login page, enter the password (the default Username is admin and the Password is
root if a new password has not been set.) and then click Login to continue.
You may need to wait a few moments for the web page to download onto your computer. The model name and
IP address of your AWK-6222 are both shown on the title of web page title. This information can help you
identify multiple AWK-6222s.
You can use the menu tree on the left panel of the window to open the function pages to access each of
AWK-6222’s functions.

AWK-6222 Web Console Configuration
3-3
In the following sections, we will review each of the AWK-6222’s management functions in detail. You can also
get a quick overview of these functions in the “Function Guide Map” section of Chapter 2.
ATTENTION
The model name of the AWK
-6222 is shown as AWK-6222-
XX where XX indicates the country code. The country
code represents the AWK
-6222 version and which bandwidth it uses. We use AWK-6222-US
as an example in
the following figures. The country code of model name on the screen may vary if you are using a different
version (band) AWK
-6222.
ATTENTION
For
security reasons, you will need to log back into the AWK-6222 after a 5-minute time-out.
Overview
The Overview page summarizes the AWK-6222’s current status. The information is categorized into several
groups: System info, Device info and 802.11 info.

AWK-6222 Web Console Configuration
3-4
Basic Settings
The Basic Settings group includes the most commonly used settings required by administrators to maintain and
control the AWK-6222.
System Info Settings
The System Info items, especially Device name and Device description, are displayed and included on the
Overview page, SNMP information, and alarm emails. Setting System Info items makes it easier to identify
the different AWK-6222s connected to your network.
Device name
Setting Description Factory Default
Max. 31 Characters This option is useful for specifying the role or application of
different AWK-6222 units.
AWK-6222_<Serial
No. of this
AWK-6222>
Device location
Setting Description Factory Default
Max. 31 Characters To specify the location of different AWK-6222 units. None
Device description
Setting Description Factory Default
Max. 31 Characters Use this space to record more detailed description of AWK-6222 None
Device contact information
Setting Description Factory Default
Max. 31 Characters To provide information about whom to contact in order to
resolve problems. Use this space to
record contact information
of the person responsible for maintaining this AWK-6222.
None
Network Settings
The Network Settings configuration allows you to modify the usual TCP/IP network parameters. An explanation
of each configuration item is given below.
