MP-Man EB8 User manual

EB8
EN ITA DE
NL FR
5 Languages
EB8

FULLY CHARGE BATTERIES BEFORE FIRST USE-Batteries should be fully charged immediately when
they are received and immediately after each use for the recommended charge times(see below).
- Li-lon (Lithium lon) batteries 4-6 hours
We recommend that you consult a bicycle specialist if you have doubts or concerns as to your experience or ability
to properly assembly, repair, or maintain your bicycle.
Additional warning/cautions are in the assembly section of the manual
With proper care and maintenance your Electric Bicycle will provide ease of use and be fun to ride.
Below are points that will help you to maximize the enjoyment you to get from your new electric bicycle
FACTORS TO MAXMIZE THE RANGE OF YOUR ELECTRIC BICYCLE
-Riser input –the more the rider pedals the further the distance traveled. Continuous riding, as opposed to frequent
stopping and starting, will yield the greatest range possible
-Elevation Gain –the flatter the road the further the distance traveled
-Weather –cold weather can adversely affect the battery capacity
-Wind –traveling with a tailwind will increase distance traveled, traveling into a headwind will decrease distance
traveled
-Terrain –the smoother the terrain (roadways vs. fireroads, etc) the further the distance traveled
-Rider Weight –the lighter the rider, resulting in less drain on the batteries, the further distance traveled
-Bicycle Maintenance –a properly maintained bicycle will yield the greatest range possible
-Tire Maintenance –properly inflated tires have less rolling resistance and will be easier to pedal
-Batteries – properly charged and maintained batteries will yield the greatest range possible. Batteries stored in
cold areas(below 50 degrees Fahrenheit/10 degrees Celsius) will show reduced range. Batteries that have not
been kept in optimum condition will show reduce range and run time.
HELMETS
SAVE
LIVES!!!
-ALWAYS WEAR A PROPERLY FITTED HELMET WHEN YOU RIDE YOUR BICYCLE.
-CPSC RECORDS SHOW THAT ABOUT 35% OF BICYCLE RELATED DEATHS OCCUR
AFTER DARK.
-AVOID RIDING IN WET CONDITIONS.
-CPSC RECORDS SHOW THAT ABOUT 65% OF INJURIES HAPPEN TO CHILDREN
UNDER 15 YEARS OF AGE.
-RIDE ONLY WITH ADULT SUPERVISION
CORRECT FIT-MAKE SURE YOUR HELMET COVERS YOUR FOREHEAD.
INCORRECT FITTING. FOREHEAD IS EXPOSED AND VULNERABLE TO SERIOUS
INJURY. SERIOUS INJURY.
1 2

FOLDING ELECTRIC BIKE
1
23
4
5
29
28
26
25
22
23
21
19
18
17
16 15 14 13 12 11 10
6
7
8
9
24
1.Inner vertical pole
2.Folding stand
3.Brake handle
4.Outer vertical pole
5.Headlights
6.Fender
7.Front fork
8.Tire
9.Wheel
10.Frame
11.Crank
12.Pedal
13.Axis
14.Sensor
15.Chain
27
20
16.Disc brake
17.Wheel hub motor
18.Flywheel
19.Fender
20.Battery lock
21.Lithium battery
22.Sit pipe clamp
23.Saddle tube
24.Cushion
25.Controller
26.Folding machine
27.Charge socket
28.Vertical clamp
PART 1 EN................................................................ .....4
PART 2 ITA............................................................................28
PART 3 DE.............................................................................52
PART 4 NL.............................................................................76
PART 5 FR..............................................................................100
........
3 4

GENERAL WARNING
BEFORE YOU RIDE
ABOUT THIS MANUAL
It is important for you to understand your new bicycle. By reading this manual before you go out on your first ride, you’ll know how
to get better performance, comfort, and enjoyment from your new bicycle.
It is also important that your first ride on your new bicycle is taken in a controlled environment , away from cars, obstacles, and
other cyclists.
Bicycling can be a hazardous activity even under the best of circumstances. Proper maintenance of your bicycle is your
responsibility as it helps reduce the risk of injury. This manual contains many “Warning ” and “Caution” concerning the
consequences of failure to maintain or inspect your bicycle. Many of the warnings and cautions say “you may lose control and fall”.
Because any fall can result in serious injury or even death, we do not repeat the warning of possible injury or death wherever the
risk of falling is mentioned.
Warning: this product might be limited to use on private road(check the regulations in force in the territory of use).
We recommend using suitable protective equipment.
A SPECIAL NOTE FOR PARENT
It is a tragic fact that most bicycle accidents involve children. As a parent or guardian, you bear the responsibility for the
activities and safety of your minor child. Among these responsibilities are to make sure that the bicycle which your child is riding
is properly fitted to the child; that is in good repair and safe operating condition; that you and your child have learned,
understand and obey not only the applicable local motor vehicle, bicycle, and traffic laws, but also the common sense rules of
safe and responsible bicycling. As a parent, you should read this manual before letting your child ride the bicycle.
Please make sure that your child always wears an ANSI,ASTM,SNELL approved bicycle helmet when riding.
Your new bicycle was partially assembled in the factory and then partially disassembled for shipping. You may have
purchased the bicycle already fully assembled and ready to ride OR in the shipping carton in the partially disassembled
form. The following instructions will enable you to prepare your bicycle for years of enjoyable cycling. For more details
on inspection, lubrication, maintenance and adjustment of any area please refer to the relevant sections in this manual.
If you have questions about your ability to properly assemble this unit, please consult a qualified bicycle service
specialist before riding. If you need replacement parts or have questions pertaining to assembly of your bicycle,
call the service line direct at:
Typical Tools Required:
-
- 2.5mm,3mm,4mm,5mm,6mm & 8mm Allen keys
- Adjustable wrench or a 8mm, 9mm,10mm,13mm,14,
15mm & 17mm open/box end wrenches
- A pair of pliers with cable cutting ability
(Note: those tools are not included in the box, users
need to prepare them themselves.)
Phillips head screw driver
5 6

-Dimension:20*1.95(inch)
7 8

9 10

How to charging the battery inside the frame and pull out the battery
Before using the charger locate the voltage selector switch (Li-lon) on the back of the charger. Select either
115 Volts or 230 Volts depending on the country you reside in. Using the wrong Voltage setting will
permanently damage the charger and/or electrical components on the hybrid electric bicycle.
1.Use the matching charger,insert the round plug into E-bike first
2.Then insert the charger plug into electrical socket
3.Under Charging, the right situation is Red Light on (attention: during the charging, if the green light on means wrong,
while when the battery charged full, the green light on.)
4.Under the frame,there is another hole for lock and unlock the battery,if you want pull out the battery,use the key to unclock it,
then you can pull the battery out.
Notes:
1.The battery is removable: the battery can be charged inside of the e-bike frame and can be also pulled out to charge separately.
2.Anti-theft system of the battery: there is hole under the frame, where we can use the key to lock it, which can keep the battery
from stealing.
3. LG battery, the core inside is produced by LG, and imported from Korea. We have the certificate to prove it.
11 12

TC470X Instruction
Display Panel Description: This model has 2 buttons, 8 LED lights
Location & Features:
Top left Button
Lower left Button
Top left LED
4 Middle LED
Lower left“LOW MID HIGH” LED、 、
Function:
1 Power On/Off、
On : Press “Power Button”, display works; Press the
Power Button for 3-5 seconds, Display off work.
2 On/Off the headlight、
When the display power on, press again the “Power Button” , then headlight on.
LED indicator On/Off means Headlight On/Off.
3 Mode:、
Press “Mode” Button, can adjust PAS LEVEL ,, press “Mode” Button for 3-5 seconds,
Mode change to 6KM/H. Mode change indicator On/Off & PAS LEVEL as follows:
LOW On; MED, HIGH Off
MED ON;LOW, HIGH OFF
HIGH ON;LOW, MED OFF
L M H All on 、 、
4、Battery Power indicator: No operation, automatic display, full battery power to low
battery power was showed by the LED indicator from 4 lights to 1 light.
When the battery is under voltage, only the left most LED will Flash.
PAS LEVEL 1
PAS LEVEL 2
PAS LEVEL 3
Mode change to 6KM/H
Mode Change Indicator
Battery Power Indicator
Headlight Indicator
Mode Change
Power/headlight button
Name:
13 14

SHIMANO 7-Gear Thumb Shifter and Flywheel
The flywheel is 7 gears,we can change the speed by using the thumb shifter.
15 16

17 18

19 20

21 22

23 24

25 26

BICICLETTA ELETTRICA PIEGHEVOLE
1
23
4
5
29
28
26
25
22
23
21
19
18
17
16 15 14 13 12 11 10
6
7
8
9
24
1.Tubo verticale
interno
2.Supporto
pieghevole
3.Freno
4.Tubo verticale
esterno
5.Fanale anteriore
6.Paraurti
7.Forcella
anteriore
8.Pneumatico
9.Ruota
10.Telaio
11.Pedivella
12.Pedale
13.Mozzo
14.Sensore
15.Catena
16.Freno a disco
17.Perno motore
della ruota
18.Pacco pignoni
19.Paraurti
20.Serratura
batteria
21.Batteria al litio
22.Morsetto
reggisella
23.Canotto
reggisella
24.Sellino
25.Controllo
26.Dispositivo
pieghevole
27.Presa per ricarica
28.Morsetto verticale
27
20
28
EB8

29 30

-Dimensioni:20x1,95(pollici)
31 32

33 34

Come ricaricare la batteria nel telaio e come estrarla.
Prima di usare il caricabatteria, individuare l’interruttore di selezione del voltaggio (solo per caricabatteria
Li-Ion) posto sul suo retro. Selezionare il voltaggio a seconda di quello disponibile nel paese in cui ci si trova,
scegliendo tra 115 V e 230 V. L’uso del voltaggio errato potrebbe danneggiare permanentemente il
caricabatteria e/o le parti elettriche della bicicletta ibrida.
1.Usare il caricabatteria apposito, prima inserendo la spina rotonda nella E-bike.
2.Collegare quindi il caricabatteria ad una presa elettrica.
3.La ricarica in corso è confermata dalla luce rossa accesa (se dovesse accendersi la luce verde significa che si è verificato un
errore o che la ricarica è stata completata).
4.La serratura della batteria è situata nel lato inferiore del telaio, e va aperta con l’apposita chiave se si desidera estrarre la batteria.
Note:
1. La batteria è rimovibile: può essere ricaricata direttamente nel telaio della bicicletta o estratta per essere ricaricata
separatamente.
2. Sistema antifurto della batteria: sul lato inferiore del telaio c’è un foro nel quale inserire la chiave per sbloccare la batteria
dal sistema di bloccaggio antifurto.
3. Batteria LG: il nucleo interno della batteria è prodotto da LG e importato dalla Corea, come comprovato dal certificato annesso.
35 36

Strumentazione TC470X
Descrizione del Pannello del Quadrante: questo modello ha due buttoni e otto LED.
Funzione e Posizione: Nome:
Tasto in alto a sinistra
Tasto in basso a sinistra
LED in alto a sinistra
Quattro LED centrali
LED “BASSO, CENTRALE, ALTO”
in basso a sinistra
Funzione:
1.Attivare / Disattivare
Attivare: premere il “Tasto di Alimentazione”, il quadrante si attiverà;
tenere premuto lo tesso tasto per 3~5 secondi per disattivare e
spegnere il quadrante.
2.Accendere / Spegnere il Fanale
Con il quadrante attivo, premere nuovamente il “Tasto Alimentazione” per
accendere il fanale.
L’indicatore LED “Attivo / Non Attivo” si riferisce al fanale.
3.Modalità:
Premere il tasto “Modalità” per regolare il livello della pedalata assistita, tenere premuto
il tasto “Modalità” per 3~5 secondi, la modalità cambierà a 6Km/h. L’indicatore di cambio
modalità Attivo / Disattivo e Livello Pedalata Assistita indica come segue:
BASSO Attivo; MEDIO, ALTO Spento Livello Pedalata Assistita 1
MEDIO Attivo; BASSO, ALTO Spento Livello Pedalata Assistita 2
ALTO Attivo; BASSO, MEDIO Spento Livello Pedalata Assistita 3
BASSO, MEDIO ALTO Attivi Modalità a 6Km/h
4.Indicatore Livello della Batteria: Non serve selezionarlo, viene mostrato automaticamente,
il livello della batteria, da massimo a basso ,è indicato dagli indicatori LED con da 4 a 1
LED acceso.
Quando la batteria è scarica il LED più a sinistra lampeggerà.
Indicatore Modalità
Indicatore Livello della Batteria
Indicatore Fanale
Cambia Modalità
Alimentazione / Fanale
37 38
