MPS EV6539B-F-00A User manual

EV6539B-F-00A
8V to 100V, Three-Phase Brushless
DC Motor Pre-Driver
Evaluation Board
EV6539B-F-00A Rev. 1.0 www.MonolithicPower.com 1
1/2/2019 MPS Proprietary Information. Patent Protected. Unauthorized Photocopy and Duplication Prohibited.
© 2019 MPS. All Rights Reserved.
DESCRIPTION
The EV6539B-F-00A is an evaluation board for
the MP6539BGF, a three-phase BLDC motor
pre-driver.
It operates from a supply voltage of up to 100V.
It is configured to drive 3 half bridges consisting
of 6 N-channel Power MOSFETs. The rotor
position information is provided by the Hall
sensors assembled in the motor and the driving
control signals are generated by the external
controller, such as MCU, FPGA, etc.
ELECTRICAL SPECIFICATIONS
Parameter Symbol Value Units
Input Voltage VIN 8 - 100 V
VDD Voltage VDD 8.5 - 14 V
Logic Power Supply VCC 3.3 or 5 V
FEATURES
Wide 8V to 100V Input Voltage Range
Support 100% Duty Cycle Operation
HS/LS Logic Input
OTP
Fault Indication Output
APPLICATIONS
3-Phase Brushless DC Motors and Permanent
Magnet Synchronous Motors
Power Drills
Impact Drivers
E-Bike
A
ll MPS parts are lead-free, halogen-free, and adhere to the RoHS
directive. For MPS green status, please visit the MPS website under quality
assurance. “MPS” and “The Future of Analog IC Technology” are
registered trademarks of Monolithic Power Systems, Inc.
EV6539B-F-00A EVALUATION BOARD
(L x W x H) 4.68” x 3.12” x 0.4”
(11.7cm x 7.8cm x 1cm)
Board Number MPS IC Number
EV6539B-F-00A MP6539BGF

EV6539B-F-00A-8V TO 100V, THREE-PHASE BRUSHLESS DC MOTOR PRE-DRIVER EVALUATION BOARD
EV6539B-F-00A Rev. 1.0 www.MonolithicPower.com 2
1/2/2019 MPS Proprietary Information. Patent Protected. Unauthorized Photocopy and Duplication Prohibited.
© 2019 MPS. All Rights Reserved.
EVALUATION BOARD SCHEMATIC
GND
TP
TP31
TP
TP30
TP
TP29
10u F
C8
1
2
TS1
1
2
P3 SMAJ1 00A
1 2
D9
GND
GND
GND
VIN
100 uF/1 00V
C1 4
GND
TP14
TP7
LSC
nSLEEP
nFAULT
4.7k
R1
TP3
TP4
TP5
TP10
TP11
HSA
HSB
HSC
LSA
LSB
TP32
TP1
TP17
GND
TP27
GND
TP
TP28
12
D1
1K
R2
VCC3V3
FA ULT
+
+
-
-
Motor
Pow er
U
W
V
U
W
V
Motor
GNDVDD
Q7
AM7492N
Q4
AM7492N
22
R1 7
22
R1 6
GHA
BSTA
U
GLA
GHB
BSTB
V
GLB
GHC
BSTC
W
GLC
Q6
AM7492N
Q3
AM7492N
22
R1 5
22
R1 4
Q5
AM7492N
Q2
AM7492N
1uF 100 V
C1 5
1uF 100 V
C1 7
1uF 100 V
C1 6
GND
GND
GND
1
2
3
TS2
Header 3
1
2
3
P4
Header 3
GND
VIN
nSLEEP
VCC3V3
4.7k
R6
4.7k
R5
4.7K
R4
VCC3V3
R1 0
500 k
GND
DT
nFAULT
1nF
C2
GND GND GND
1nF
C3 1nF C4
1uF
C1 1
1uF
C9
U
V
W
nSLEEP
4.7k
R3
VCC3V3
1 2
JP2
GND
SLEEP
DEA D TIME
22
R1 2
1uF
C1 0
22
R1 3
D7 1N4148
D6 1N4148
D5 1N4148
D4 1N4148
D3 1N4148
D2 1N4148
TP6
nFAULT
HSA
HSB
HSC
LSA
LSB
LSC
HA
HB
HC
HSA
HSB
HSC
LSA
LSB
LSC
GND
VCC3V3
GND
1 2
JP3
1 2
JP4
1 2
JP5
1 2
JP1
TP2
VCC3V3
1uF
C1
GND
0
R9
12
D8
GND
10k
R2 1 VIN
1
2
3
4
5
P1
Header 5
1
2
3
4
5
6
7
P2
Header 7
0
R2 2
0
R2 3
0
R2 4
GND
100 nF
C7
VDDGND
GND
VIN 12
CSO
13
LDO 14
VREG 15
BSTA 16
SHA 17
GHA 18
GLA 19
BSTB 20
SHB 21
GHB 22
GLB 23
BSTC 24
SHC 25
GHC 26
GLC 27
LSS 28
PWMC/HC/LS C
1PWMB/HB/LS B
2PWMA/HA/LSA
3
ENC/nBRAKE/HSC
4ENB/P WM/HSB
5ENA/DIR/HSA
6
nFAULT
7
nSLEEP
8
OCREF
9
DT
10
GND
11
V
I
N
C
S
O
LD
O
VR
E
G
B
ST
A
S
H
A
G
H
A
GL
A
BS
T
B
S
H
B
G
H
B
GL
B
BS
T
C
S
HC
G
H
C
GL
C
L
S
S
PWM
C
/
HC
/L
S
C
P
W
MB
/
HB
/
L
S
B
P
W
MA
/
HA
/
L
S
A
EN
C/
nBRAKE
/
H
S
C
ENB/
P
W
M
/HSB
ENA
/
DIR
/
H
S
A
n
F
A
U
L
T
n
S
LEE
P
OC
RE
F
D
T
G
N
D
GND
29
U1
MP6 539 BGF

EV6539B-F-00A-8V TO 100V, THREE-PHASE BRUSHLESS DC MOTOR PRE-DRIVER EVALUATION BOARD
EV6539B-F-00A Rev. 1.0 www.MonolithicPower.com 3
1/2/2019 MPS Proprietary Information. Patent Protected. Unauthorized Photocopy and Duplication Prohibited.
© 2019 MPS. All Rights Reserved.
EV6539B-F-00A BILL OF MATERIALS
Qty RefDes Value Description Package Manufacturer Manufacturer P/N
1 C1 1µF
Ceramic Cap. 6.3V,
X5R 0603 Murata GRM188R60J105KA01D
3 C2, C3,
C4 1nF Ceramic Cap. 16V, X7R 0603 Wurth 885012206034
1 C7 100nF
Ceramic Cap. 25V,
X7R 0603 Wurth 885012206071
1 C8 10µF
Ceramic Cap. 25V,
X7R 1206 Murata GRM31CR71E106KA12
3 C9, C10,
C11 1µF Ceramic Cap. 25V, X7R 0603 Murata GRM188R71E105KA12D
1 C14 100µF
Electrolytic Cap.
100V DIP Jianghai CD263-100V100
3 C15,
C16, C17 1µF Ceramic Cap. 100V, X7R 1206 Murata GRM31CR72A105KA01L
5
R1, R3,
R4, R5,
R6
4.7k Film Resistor ,1% 0603 Yageo RC0603FR-074K7L
1 R2 1k Film Resistor ,1% 0603 Yageo RC0603FR-071KL
4 R9, R22,
R23, R24 0 Film Resistor ,1% 0603 Yageo RC0603FR-070RL
1 R10 500k Adjustable Resistor DIP 3266W-1-504LF
6
R12,
R13,
R14,
R15,
R16, R17
22Ohm Film Resistor ,1% 0603 Yageo RC0603FR-0722RL
1 R21 10k Film Resistor ,1% 0603 Yageo RC0603FR-0710KL
2 D1, D8 LED. 绿光 0805 佰鸿 BL-HGE35A-AV-TRB
6
D2, D3,
D4, D5,
D6, D7
Schottky Diode.
75V, 0.15A SOD-123 Diodes 1N4148W
1 D9 TVS. 100V, 2.5A SMA Diodes SMAJ100A
6
Q2, Q3,
Q4, Q5,
Q6, Q7
N-channel
MOSFET,
150V,6.2A,
Qg=23nC,
Ron=96mΩ
SOIC-
8PP Analog Power AM7492N
1 P1 5PIN. 2.54MM
1 P2 7PIN. 2.54MM
1 P3 2PIN. 2.54MM
1 P4 3PIN. 2.54MM

EV6539B-F-00A-8V TO 100V, THREE-PHASE BRUSHLESS DC MOTOR PRE-DRIVER EVALUATION BOARD
EV6539B-F-00A Rev. 1.0 www.MonolithicPower.com 4
1/2/2019 MPS Proprietary Information. Patent Protected. Unauthorized Photocopy and Duplication Prohibited.
© 2019 MPS. All Rights Reserved.
EV6539B-F-00A BILL OF MATERIALS
Qty RefDes Value Description Package Manufacturer Manufacturer P/N
1 TS1 Header, 2-Pin
1 TS2 Header, 3-Pin Wurth 691216510003
5
JP1, JP2,
JP3, JP4,
JP5
2PIN. 2.54MM
1 JP1 Short Jumper
18
HSA,
HSB,
HSC,
LSA, LSB,
LSC,
VCC,VDD,
VIN, FLT,
SLP, U, V,
W, GND,
GND,
GND,
GND
1.0 公针
11
DT, VDD,
BSTA,
BSTB,
BSTC,
GLA,
GLB,
GLC,
GHA,
GHB,
GHC
Test Points
1 U1 3-Phase BLDC
Motor Pre-Driver
TSSOP-28 EP
(9.7mmx6.4mm) MPS MP6539BGF

EV6539B-F-00A-8V TO 100V, THREE-PHASE BRUSHLESS DC MOTOR PRE-DRIVER EVALUATION BOARD
EV6539B-F-00A Rev. 1.0 www.MonolithicPower.com 5
1/2/2019 MPS Proprietary Information. Patent Protected. Unauthorized Photocopy and Duplication Prohibited.
© 2019 MPS. All Rights Reserved.
PRINTED CIRCUIT BOARD LAYOUT
Figure 1: Top Silk Layer Figure 2: Top Layer
Figure 3: Bottom Layer

EV6539B-F-00A-8V TO 100V, THREE-PHASE BRUSHLESS DC MOTOR PRE-DRIVER EVALUATION BOARD
NOTICE: The information in this document is subject to change without notice. Users should warrant and guarantee that third
party Intellectual Property rights are not infringed upon when integrating MPS products into any application. MPS will not
assume any legal responsibility for any said applications.
EV6539B-F-00A Rev. 1.0 www.MonolithicPower.com 6
1/2/2019 MPS Proprietary Information. Patent Protected. Unauthorized Photocopy and Duplication Prohibited.
© 2019 MPS. All Rights Reserved.
QUICK START GUIDE
1. Attach the input voltage (8V ≤V
IN
≤100V) and input ground to the VIN and GND connectors
respectively.
2. Attach the VDD voltage (8.5V ≤V
DD
≤14V) and VDD ground to the VDD and GND connectors
respectively.
3. Attach a 3.3V or 5V constant voltage to the VCC terminal of the P1 connector.
4. Attach the driving control signals generated by the external controller to the P2 connector.
