mr. steam TEMPO/PLUS User manual

Sussman Lifestyle Group®
New York Corporate Office: 43-20 34th Street •Long Island City, NY 11101 •800.76.STEAM (800.767.8326) •fax: [phone]
West Coast Regional Office: 9410 S. La Cienega Blvd., Los Angeles CA 90301 •email: [email protected] •www.mrsteam.com
Owner's Manual
_____________
Installation Guide
_____________
Safety Information
_____________
User's Instructions
_____________
Care Tips
_____________
TEMPO™
IN-SHOWER
ELECTRONIC CONTROL
TEMPO/EXT™
ON/OFF SWITCH
FOR TEMPO AND
TEMPO/PLUS
TEMPO/PLUS™
IN-SHOWER
ELECTRONIC CONTROL
TEMPO/REMOTE™
WIRELESS REMOTE CONTROL
FOR TEMPO/PLUS
MrSteam
®
A Lifetime of Pleasure®

General Information & Care Tips . . . . . . . . . 2
Safety & Operating Information . . . . . . . . . 3
TEMPOTM & TEMPO/PLUSTM
Installation Instructions. . . . . . . . . . . . . . 4-5
TEMPOTM Operating Instructions . . . . . . . . 6
TEMPO/PLUSTM Operating Instructions . . 7-8
TEMPO/REMOTETM . . . . . . . . . . . . . . . . . . . . 9
Programming the Code . . . . . . . . . . . . . . 10
Using the Remote . . . . . . . . . . . . . . . . . . 11
Pausing the Unit . . . . . . . . . . . . . . . . . . . 11
Setting Program Values . . . . . . . . . . . . . . 12
Factory Settings & Battery Replacement
. . 13
Installing the Holder . . . . . . . . . . . . . . . . 14
TEMPO/EXTTM . . . . . . . . . . . . . . . . . . . . . . . 15
Using the TEMPO/EXT . . . . . . . . . . . . . . . 16
Installing the TEMPO/EXT control . . . . . . 17
Table of Contents
New York Corporate Office: 43-20 34th Street •Long Island City, NY 11101
800.76.STEAM (800.767.8326) •fax: [phone]
West Coast Regional Office: 9410 S. La Cienega Blvd., Los Angeles CA 90301
email: [e-mail] •www.mrsteam.com
_____________________________________________________________________________
SUSSMAN LIFESTYLE GROUP, MRSTEAM, AUTOFLUSH, STEAM@HOME, MRSAUNA, WARMATOWEL & Des., AROMAFLO,
A LIFETIME OF PLEASURE and STEAM ON DEMAND are registered trademarks of Sussman-Automatic Corporation
ALLEGRO, F1 PLUS, SAUNA/ONE, TEMPO, TEMPO/PLUS, TEMPO/REMOTE and TEMPO/EXT are trademarks of Sussman-Automatic Corporation.
_____________________________________________________________________________
© 2003 Sussman-Automatic Corporation PUR 100385 Rev. 5/03
TEMPOTM / TEMPO/PLUSTM / TEMPO/REMOTETM / TEMPO/EXTTM Owner’s Manual 1

2TEMPOTM / TEMPO/PLUSTM / TEMPO/REMOTETM / TEMPO/EXTTM Owner’s Manual
Safety & Operating InformationGeneral Information
TEMPOTM / TEMPO/PLUSTM / TEMPO/REMOTETM / TEMPO/EXTTM Owner’s Manual 3
Do not install or use any TEMPO/PLUS, TEMPO, TEMPO/EXT or TEMPO/REMOTE controls without read-
ing and understanding the MrSteam steam generator Installation and Operation Manual (part number
101289 Revision number 6.2/03 or higher). Failure to read and understand these instructions may
result in an inoperative or hazardous installation.
A peel and stick warning is provided with the MrSteam steam generator Installation and Operation
Manual. MrSteam strongly recommends that this warning be read and posted in a conspicuous loca-
tion near the steambath.
Install the TEMPO or TEMPO/PLUS controls according to installation instructions. Failure to install
according to instructions will result in an inoperative control or hazardous overheating or inadequate
heating of the steamroom.
If a TEMPO or TEMPO/PLUS control is installed outside the steam room a Remote Temperature Probe
(Part Number MSTS) must be installed inside the steam room per installation instructions supplied with
the Remote Temperature Probe. Failure to install according to instructions will result in an inoperative
control and overheating of the steamroom.
Do not route any TEMPO/PLUS, TEMPO, TEMPO/EXT control wiring inside conduit together with
power lines or close to hot water or steam piping. Doing so may result in an inoperative or hazardous
installation.
Do not alter or modify any TEMPO/PLUS, TEMPO, TEMPO/EXT or TEMPO/REMOTE controls. Doing so
may result in an inoperative or hazardous installation.
IMPORTANT NOTES
:
If a TEMPO/PLUS control is to be used with a TEMPO/REMOTE control the TEMPO/PLUS must be in
located for "direct line of sight" operation with the TEMPO/REMOTE control.
See the TEMPO/REMOTE operating instructions before installation of the TEMPO/PLUS control.
Turn off all power to the steam generator until all connections are completed. Failure to do so may
result in in an inoperative control.
Do not operate any Tempo/Plus, Tempo, Tempo/Ext or Tempo/Remote controls with any steam genera-
tor system that is not a MrSteam Tempo compatible steam generator including MrSteam residential
steam generators with serial numbers lower than 355500, or any other brand of steam generator.
Doing so may result in an inoperative installation.
This document contains important safety, operation and maintenance information. Leave this docu-
ment with the homeowner. Do not discard this document.
Discontinue use of the steam generator or control if the steam generator is damaged or otherwise not
functioning properly. Doing so may result in an inoperative or hazardous installation
For additional information contact a MrSteam Technical Service representative:
New York Corporate Office: 1 800 76 STEAM
West Coast Regional Office:1 800 72 STEAM.
Additional product and Installation information is available
at the MrSteam web site: www.mrsteam.com.
As you follow these instructions, you will notice warning and caution
symbols. This blocked information is important for the safe and effi-
cient installation and operation of this generator. These are types of
potential hazards that may occur during installation and operation:
WARNING
!
!
WARNING
!
CAUTION
states a hazard may cause serious injury
or death if precautions are not followed.
signals a situation where minor injury or product
damage may occur if you do not follow instructions.
IMPORTANT NOTE
:
This highlights information that is especially
relevant to a problem-free installation.
Care Tips for All Controls
1. Use only mild soap and water on a soft cloth to
clean the control.
2. Do not use any abrasive cleansers
3. If the decorative cover is damaged on the
TEMPO™or TEMPO/PLUS™call MrSteam
technical service for replacement parts.
!
CAUTION

Installation Instructions for TEMPO™& TEMPO/PLUS™
4TEMPOTM / TEMPO/PLUSTM / TEMPO/REMOTETM / TEMPO/EXTTM Owner’s Manual
Installation Instructions for TEMPO™& TEMPO/PLUS™
TEMPOTM / TEMPO/PLUSTM / TEMPO/REMOTETM / TEMPO/EXTTM Owner’s Manual 5
Step 1
Determine the desired installation location of the con-
trol. The TEMPO and TEMPO/PLUS controls are
designed to be installed inside or outside the steam
room as a matter of personal preference.
If the control is installed inside the steamroom the
control must be located:
• 4-5 feet above the floor.
• away from the steamhead and not exposed to
direct steam emission
The control cable length is 30 feet. Insure that
the control and/or steam generator are located
accordingly. Contact a MrSteam technical service
representative if a longer cable is required.
If the control is installed outside the steam room
a Remote Temperature Probe Part Number MSTS
must be installed inside the steam room.
IMPORTANT NOTE
:
See installation
instructions supplied with the Temperature Probe
before rough-in or installation of the control.
Step 2
Make a one-inch diameter hole in the desired control
location (Diagram 1). Do not oversize or undersize the
hole.
Step 3
Route the control cable (provided with the control)
from the wall cutout to the steam generator. Locate
the end with the white connector at the steam gener-
ator. Connect the 5/8" square white connector to the
steam generator connector 'A' as shown in Diagram 2.
NOTE: The connector is keyed and will only connect in
one orientation. Locate the end of the control cable
with the red connector at the wall cutout (as shown in
Diagram 3).
IMPORTANT NOTE : Do not strain, staple,
pinch or otherwise damage the control cable.
Route cable as required to permit replacement.
STEP 4
Firmly connect the red connector to the back of
the control as shown in diagram 3. Provide
power and test the control to verify correct
connections. Test per the instructions on page 4.
Proceed with installation with verification of
proper control function.
IMPORTANT NOTE
:
Verify the steam
generator is installed according to instructions
before turning power on.
STEP 5
Remove & discard peel-off paper to expose
adhesive liner as shown in diagram 3.
STEP 6
Run a bead of silicone (provided) as shown to
the
C shaped groove as shown in diagram 4.
IMPORTANT NOTE
:
Do not apply excessive
amounts of silicone. Do not apply silicone to any
other parts of the control including the adhesive
gasket.
STEP 7
Insure the mounting surface is clean and dry as
required for good adhesion. Apply silicone into
the hole in the wall as required to create a mois-
ture seal.
Hold the control with the LED display in the (12)
o'clock position and press the control against the
wall until the adhesive sticks and holds firmly as
shown in diagram 5.
IMPORTANT NOTE : Two registration
marks are provided to facilitate level installation.
The marks are located at the (3) and (6) o'clock
positions on the back side of the control. Use a
level as required.
Mr
S
team
Diagram 3
Diagram 4
Diagram 5
Diagram 1
Diagram 2
BOX CONTENTS:
Tempo or
Tempo/Plus Control
Control Cable (30 ft.)
Steam Head
Tube of Silicon Sealant
Owner's Manual
SILICONE

ON/OFF - Diagram 1
Press the ON/OFF key to start or stop the flow of steam.
Steam will begin to flow a few minutes after the control
is turned ON. The duration required for the steamroom
to reach steambathing temperatures depends on the
steamroom construction and steam generator specifica-
tions. Steam may continue to flow for a short time after
the control is turned OFF.
PAUSE feature - Diagram 2
If a pause in steam flow is desired press the PAUSE key.
The display will flash while the control is in the PAUSE
mode. The timer will continue to countdown while in the
PAUSE mode.
Setting the temperature - Diagram 3
The control is pre-set and will display the temperature
setting of 110F (default setting). Use the UP and DOWN
keys to change the temperature setting from 105 F to
120 F in one degree increments.
Set the steambathing temperature according to personal
preference, however it is highly recommended to begin
steambathing at a low temperature setting to gauge
comfort and safety levels.
Timer feature
When the control is turned ON a (60) minute time dura-
tion is initiated. The control will turn off after (60) min-
utes unless the control is turned off manually.
Memory feature
If the control is turned off manually before (60) minutes
then the default temperature of (110F) will be used the
next time the control is turned on. If the control times
out at (60) minutes (not manually turned off) then the
previous user temperature setting will be used when the
steambath is used again.
TEMPO/PLUS™Operating Instruction
TEMPOTM / TEMPO/PLUSTM / TEMPO/REMOTETM / TEMPO/EXTTM Owner’s Manual 7
ON/OFF - Diagram 1
Press the ON/OFF key to start or stop the flow of
steam.
Steam will begin to flow a few minutes after the
control is turned ON. The duration required for the
steamroom to reach steambathing temperatures
depends on the steamroom construction and steam
generator specifications. Steam will continue to
flow for a short time after the control is turned
OFF.
PAUSE feature - Diagram 2
If a pause in steam flow is desired press the PAUSE
key. The display will flash while the control is in
the PAUSE mode. The timer will continue to count-
down while in the PAUSE mode.
Setting the time duration - Diagram 3
Press TIME key to set or display the remaining
relaxation time.
The control is pre-set and will display a TIME set-
ting of 20 minutes (default setting).
With the TIME displayed, press the UP and DOWN
keys (diagram 4) to set the desired duration time
(2 - 60 minutes) in two minute increments.
Set the steambathing duration according to
personal preference, however it is highly recom-
mended to begin steambathing at a shorter
duration to gauge comfort and safety levels.
The control will turn off when the relaxation
period times out.
TEMPO™Operating Instruction
6TEMPOTM / TEMPO/PLUSTM / TEMPO/REMOTETM / TEMPO/EXTTM Owner’s Manual
The Tempo Control features programmable digital temperature
control, a fixed (60) minute duration, ON/OFF and PAUSE.
The Tempo/Plus Control features programmable digital
temperature control, programmable time duration,
ON/OFF and PAUSE and two personal settings storage.
Diagram 1
Diagram 2
Diagram 3
Diagram 1
Diagram 2
Diagram 3
Diagram 4

MrSteam
®
TEMPO/REMOTE™
Wireless Remote Control
TEMPOTM / TEMPO/PLUSTM / TEMPO/REMOTETM / TEMPO/EXTTM Owner’s Manual 9
TEMPO/PLUS™Operating Instruction
8TEMPOTM / TEMPO/PLUSTM / TEMPO/REMOTETM / TEMPO/EXTTM Owner’s Manual
Setting the temperature - Diagram 5
Press TEMP key to set the desired temperature or display
the temperature setting
The control is pre-set and will display a temperature setting
of 110F (default setting).
With the temperature displayed, press the UP and DOWN
keys (diagram 6) to set the desired temperature (105F to
120F) in one degree increments.
Set the steambathing temperature according to personal
preference, however it is highly recommended to begin
steambathing at a low temperature setting to gauge
comfort and safety levels.
Memory feature
If the control is turned off manually before it times out
then the default settings of (20) minutes and (110F) will be
used the next time the control is turned on. If the control
times out (not manually turned off) then the previous user
time and temperature settings will be used when the
steambath is used again.
PROG 1 and PROG 2 feature - Diagram 7
PROG 1 and PROG 2 keys program and store preferred
settings.
To program preferred settings: Press a PROG1 or PROG2
key. Enter the preferred time and temperature settings.
The TEMPO/PLUS will store these settings when the
PROG keys are selected.
To select PROG1 or PROG2 : Press ON then press PROG1
or PROG2. The steambath will begin to operate at the
programmed settings.
continued
Diagram 5
Diagram 6
Diagram 7
The TEMPO/REMOTE™Control operates all functions of the
TEMPO/PLUS™Control from a maximum distance of about 12 feet.
It is for use inside the steam room and requires a direct
line-of-sight with the TEMPO/PLUS™Control.
The TEMPO/REMOTE™does not operate with the TEMPO™Control.
To operate the TEMPO/REMOTE™simply point it at the
TEMPO/PLUS™Control and press the desired function.
BOX CONTENTS:
TEMPO/REMOTE Control
Control Holder
(2) Holder Screws
User's Manual

Using the TEMPO/REMOTE™
Pausing the Unit
TEMPOTM / TEMPO/PLUSTM / TEMPO/REMOTETM / TEMPO/EXTTM Owner’s Manual 11
To Control Your TEMPO/PLUS®with the Remote Control:
• Press SETUP key to set the mode.
Tur ning Unit ON/OFF
a. Press ON/OFF key to turn unit on.
b. Press ON/OFF key a second time
to turn unit off.
Setting Temperature Set Point
Turn on the TEMPO/PLUS control.
Press the TEMP UP or TEMP DOWN key.
Setting Duration Time
Press TIME UP or TIME DOWN key.
1. Press PAUSE key.
To Pause the Flow of Steam:
2. Press PAUSE key
a second time to
resume the flow
of steam.
NOTE: The Timer contin-
ues to count down while
in the PAUSE mode.
10 TEMPOTM / TEMPO/PLUSTM / TEMPO/REMOTETM / TEMPO/EXTTM Owner’s Manual
TimeTemp
Programming the Code
1. Press SETUP key.
The TEMPO/REMOTE control is supplied with two AAA batteries already
installed. If these batteries have been removed for more than (3) minutes
or are discharged then the TEMPO/REMOTE code must be re-entered.
2. Press and hold PROG 1
key. The indicator will
flash.
3. While holding PROG 1
key, press CODE key
for two seconds until
the indicator lights up.
Then release both
keys.
4. Enter the 5-digit
code (24332).
5. The indicator will shut off if
the code is correct and the
setting was successful. If not,
the indicator will flash twice.
Check the code and repeat
the programming process if
necessary.
6. The remote control will exit
programming mode if any
other keys but the numerical
ones (1, 2, 3, 4) are pressed.
Note:
Delays longer than 10
seconds between key
presses automatically
cancels programming
mode. The code for
your MrSteam®is 24332.

TEMPOTM / TEMPO/PLUSTM / TEMPO/REMOTETM / TEMPO/EXTTM Owner’s Manual 13
12 TEMPOTM / TEMPO/PLUSTM / TEMPO/REMOTETM / TEMPO/EXTTM Owner’s Manual
Factory Settings & Battery Replacement
The only factory setting for your remote control is code 24332.
To replace the batteries of your remote control, proceed as follows:
Your remote control is powered by two AAA batteries.
NOTE: Before you start it's important to note that you have only 3 minutes to
change batteries if you want to retain codes recorded in the memory!
1. Unscrew and remove bottom cap.
Note: You can use a coin to unscrew cap.
2. Insert new batteries, making sure to
match plus (+) ends with the plus
markings on the battery case.
3. Replace cap ensuring that
waterproof gaskets (screws and
control) are correctly positioned.
After replacing batteries:
LED indicator will flash twice indicating that programmed
codes are still in memory.
If LED indicator flashes 3 times, it means that programmed
code settings have been erased and remote control has
reverted to factory settings.
Setting Program Values
To Set PROG 1 and PROG 2
TimeTemp
1. Press the program key to set
(PROG 1 or PROG 2).
2. Press TEMP UP or TEMP DOWN key
to set the desired temperature.
3. Press TIME UP or TIME DOWN key
to set the desired duration time.

Installing the TEMPO/REMOTE®Holder
TEMPOTM / TEMPO/PLUSTM / TEMPO/REMOTETM / TEMPO/EXTTM Owner’s Manual 15
14 TEMPOTM / TEMPO/PLUSTM / TEMPO/REMOTETM / TEMPO/EXTTM Owner’s Manual
A holder is provided with the TEMPO/REMOTE™Control as an optional convenience.
Mount the holder in a location away from direct steam emission.
Secure the holder to a wall so the TEMPO/REMOTE™is oriented in the upright
position as shown. Determine if the two screws provided are suitable for the
installation conditions.
Use alternate hardware or use with plastic anchors as required by installation
conditions.
Seal screw holes in the wall against moisture as required.
MrSteam
®
TEMPO/EXT™
The TEMPO/EXT®control can only
be used together with a
TEMPO or TEMPO/PLUS control
The TEMPO/EXT®control functions
as an external ON/OFF switch for the
TEMPO or TEMPO/PLUS control
TEMPO/REMOTE™
HOLDER
(2) SCREWS PROVIDED
BOX CONTENTS:
TEMPO/EXT Control
User's Manual

TEMPOTM / TEMPO/PLUSTM / TEMPO/REMOTETM / TEMPO/EXTTM Owner’s Manual 17
16 TEMPOTM / TEMPO/PLUSTM / TEMPO/REMOTETM / TEMPO/EXTTM Owner’s Manual
Installing the TEMPO/EXT Control
Diagram 1
The TEMPO/EXT™has a 30 foot cable with a
Plug & Play connector at one end and an
ON/OFF switch at the other end.
Contact a MrSteam technical service
representative if a longer cable is required.
STEP 1 - Diagram 2
Drill a 7/8 inch diameter hole in the wall.
Do not oversize or undersize the hole.
STEP 2 - Diagram 3
Remove the black nut from the switch and
cable as shown in diagram 3.
Route the cable from the wall to the steam
generator.
Do not strain, staple, pinch or otherwise
damage the control cable.
STEP 3 - Diagram 4
Remove and discard the peel-off paper from
the switch housing to expose the adhesive as
shown in diagram 4.
STEP 4 - Diagram 5
Apply silicone (provided with TEMPO or
TEMPO/PLUS control) to the hole in the wall
as required to create a moisture seal.
Apply silicone to the back of the switch as
required to seal grout lines or as required
for additional adhesion.
STEP 5
Push cable and switch housing into
the hole firmly.
STEP 6 - Diagram 6
Firmly connect the Plug & Play connector
to the steam generator connector "B".
NOTE: The connector is keyed and will only
connect in one orientation.
Diagram 1
Diagram 2
Diagram 3
Diagram 4
Diagram 5
Diagram 6
Mr
S
team
SWITCH 30' CABLE
PLUG &PLAY
CONNECTOR
Using the TEMPO/EXT®Control
• This TEMPO/EXT control functions
as an ON/OFF key of the TEMPO or
TEMPO/PLUS control of your system.
LED INDICATOR
will light up when
the generator is on.
