MrHeater Heatstar MH85FAV Assembly instructions

70056 Rev. G 03/10
MR HEATER, INC., 4560 W. 160TH ST., CLEVELAND, OHIO 44135 • 216-916-3000
— Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any
other appliance.
— An LP cylinder not connected for use shall not be stored in the vicinity of this or any other appli-
ance.
— WHAT TO DO IF YOU SMELL GAS
•Do not try to light appliance.
•
•Shut off gas to appliance.
— Service must be performed by a qualified service agency.
Adequate combustion and ventilation air must be provided. Refer to page 3.
READ INSTRUCTIONS CAREFULLY:
Read and follow all instructions. Place
instructions in a safe place for future
reference. Do not allow anyone who has
not read these instructions to assemble,
light, adjust or operate the heater.
MH55FAV, MH60FAV, MH85FAV,
MH125FAV
PA55FAV, PA85FAV, PA125FAV
MODEL
MODEL
OPERATING INSTRUCTIONS AND OWNER’S MANUAL
MR. HEATER HEATSTAR
HS55FAV, HS85FAV, HS125FAV
FORCED AIR PROPANE
CONSTRUCTION HEATER
WARNING: If the information in this manual is not followed exactly, a fire or
explosion may result causing property damage, personal injury or loss of life.
LANGUAGES
ENGLISH
Pages E1 — E10
SPANISH
Pages S1 — S11
FRENCH
Pages F1 — F11
For model serial numbers,
see page E10.

E-2 Operating Instructions and Owner’s ManualMr. Heater, Inc.| Forced Air Propane Construction Heater
SPECIFICATIONS
Type of Gas:................For use with Propane Only
Gas Supply Pressure
to regulator .............Max.: Bottle Pressure
to regulator .............Min.: 5 psig (34.5 kPa)
regulator out ..........27.5" W.C. (6.84 kPa)
Electrical Input:...........115V, 60 Hz, 1Ø, 3a
Min. Operating Voltage: 100V
Ignition:......................Direct Spark
Primary
Flame Control: ..........Thermocouple Operated Gas Valve
High Temperature
Control: ....................240°F (116°C)
Min. Ambient Temp. Rating 0°F (-17.8°C)
CONTENTS
HEATER SPECIFICATIONS..........................................................E-2
WARNINGS..............................................................................E-2
OPERATING PRECAUTIONS ......................................................E-3
SAFETY PRECAUTIONS.............................................................E-4
ODOR FADE WARNING............................................................E-5
OPERATING INSTRUCTIONS .....................................................E-6
SERVICING...............................................................................E-6
SIZE AND CAPACITY OF PROPANE CYLINDERS REQUIRED ........E-7
WIRING DIAGRAMS.................................................................E-8
55FAV PARTS............................................................................E-9
60FAV PARTS ...........................................................................E-9
85FAV PARTS............................................................................E-9
125FAV PARTS ..........................................................................E-9
WARRANTY ........................................................................... E-11
WARNING: FIRE, BURN, INHALATION, AND
EXPLOSION HAZARD. KEEP SOLID COMBUSTIBLES,
SUCH AS BUILDING MATERIALS, PAPER OR
CARDBOARD, A SAFE DISTANCE AWAY FROM THE
HEATER AS RECOMMENDED BY THE INSTRUCTIONS
NEVER USE THE HEATER IN SPACES WHICH DO
OR MAY CONTAIN VOLATILE OR AIRBORNE
COMBUSTIBLES, OR PRODUCTS SUCH AS GASOLINE,
SOLVENTS, PAINT THINNER, DUST PARTICLES OR
UNKNOWN CHEMICALS.
WARNING:COMBUSTION BY-PRODUCTS PRO-
DUCED WHEN USING THIS PRODUCT CONTAIN
CARBON MONOXIDE, A CHEMICAL KNOWN TO THE
STATE OF CALIFORNIA TO CAUSE CANCER AND BIRTH
DEFECTS (OR OTHER REPRODUCTIVE HARM).
GENERAL HAZARD WARNING:
FAILURE TO COMPLY WITH THE PRECAUTIONS AND
INSTRUCTIONS PROVIDED WITH THIS HEATER, CAN
RESULT IN DEATH, SERIOUS BODILY INJURY AND
PROPERTY LOSS OR DAMAGE FROM HAZARDS OF FIRE,
EXPLOSION, BURN, ASPHYXIATION, CARBON MONOX-
IDE POISONING, AND/OR ELECTRICAL SHOCK.
ONLY PERSONS WHO CAN UNDERSTAND AND FOLLOW
THE INSTRUCTIONS SHOULD USE OR SERVICE THIS
HEATER.
IF YOU NEED ASSISTANCE OR HEATER INFORMATION
SUCH AS AN INSTRUCTIONS MANUAL, LABELS, ETC.
CONTACT THE MANUFACTURER.
WARNING: NOT FOR HOME OR RECREATIONAL
VEHICLE USE
WARNING: YOUR SAFETY IS IMPORTANT TO
YOU AND TO OTHERS, SO PLEASE READ THESE
INSTRUCTIONS BEFORE YOU OPERATE THIS HEATER.
The State of California requires the following warning:

E-3 Operating Instructions and Owner’s ManualMr. Heater, Inc.| Forced Air Propane Construction Heater
OPERATING PRECAUTIONS
is primarily temporary heating of buildings under construction,
alteration or repair.
Propane is heavier than air. If propane leaks from a connection or
air, forming a potentially explosive mixture. Obviously, propane
leaks should be avoided, so set up the propane supply with
utmost care. Read enclosed Odor Fade and Propane Sheet for
additional information about detecting propane leaks. Leak check
new connections or reconnections with a soap and water solution
and follow all connection instructions herein. Also, ask your
propane dealer for advice on the propane application and supply
installation and ask him to check it if there are any questions.
heater in accordance with ANSI Z83.7a/CGA 2.14a-2007. Check
about your applications. Other standards govern the use of fuel
gases and heat producing products in specific applications. Your
local authority can advise you about these.
Direct-Fired means that all of the combustion products enter the
heated space. Even though this heater operates very close to 100
percent combustion efficiency, it still produces small amounts of
carbon monoxide. Carbon monoxide (called CO) is toxic. We can
tolerate small amounts but not a lot. CO can build up in a heated
space and failure to provide adequate ventilation could result in
death. The symptoms of inadequate ventilation are:
•headache
•dizziness
•burning eyes and nose
•nausea
•dry mouth or sore throat
So, be sure to follow advice about ventilation in these operating
instructions.
Forced Air means that a blower or fan pushes the air through the
parts removed or missing. Likewise, safety systems must not be
circumvented or modified in order to operate the heater.
When the heater is to be operated in the presence of other people
the user is responsible for properly acquainting those present
with the safety precautions and instructions, and of the hazards
involved.
SPECIFICATIONS
Model: 55FAV 60FAV 85FAV 125FAV
Rating: 30,000 - 55,000 Btu/Hr 30,000 - 65,000 Btu/Hr 50,000 - 85,000 Btu/Hr 75,000 - 125,000 Btu/Hr
(8.8 - 16.1 kW) (8.8 - 19.0 kW) (14.6 – 25.0 kW) (21.9 – 36.6 kW)
Fuel Consumption: 1.4-2.5 #/hr 1.4 - 3.0 #/hr 2.3 – 3.9 #/hr 3.5 – 5.8 #/hr
(.64-1.1 kg/hr) (0.64 - 1.36 kg/hr) (1.04 – 1.77 kg/hr) (1.59 – 2.63 kg/hr)
Fuel Ori¯ce Port No.: 18 18 18 18
Fuel Ori¯ce Port Size: 0.0196" 0.0247" 0.0236” 0.0295"
(0.50mm) (0.52mm) (0.60mm) (0.75mm)
Heated Air Output: 300 cfm 300 cfm 300 cfm 350 cfm
(8.49 cmm) (8.49 cmm) (8.49 cmm) (9.91 cmm)
Average Air Temp. Rise: 200°F (111°C) 200°F (111°C) 200°F (111°C) 400°F (232°C)

E-4 Operating Instructions and Owner’s ManualMr. Heater, Inc.| Forced Air Propane Construction Heater
Figure 2
MINIMUM CLEARANCE: From normal combustible material
Clearance 55, 60, 85, 125 Forced Air
From floor....................................0 ft
From outlet..................................6 ft
From sides ...................................2 ft
From top......................................3 ft
Locate 10 ft. from canvas or plastic tarpaulins or similar
coverings and secure them to prevent flapping or movement
due to wind action.
SAFETY PRECAUTIONS
1. Check the heater thoroughly for damage. DO NOT operate a
damaged heater.
2. DO NOT modify the heater or operate a heater which has
been modified from its original condition.
3. Use only propane gas.
4. Use only VAPOR WITHDRAWAL propane supply. If there is any
question about vapor withdrawal, ask your propane dealer.
5. Mount the propane cylinders vertically (shutoff valve up).
Secure them from falling or being knocked over and protect
them from damage.
6. Locate propane containers at least (USA) 7 ft. (2.13m),
(Canada) 10 ft. (3m) from the heater and do not direct
exhaust toward containers.
7. IMPORTANT Use only the hose and regulator assembly
provided with the heater. Match the color stripe on the
hangtag attached to the hose assembly with the color on
the label located near the propane inlet fitting on the heater.
Inspect hose assembly before each use of the heater. If there
is excessive abrasion or wear, or hose is cut, replace with hose
assembly listed on parts list before using heater.
8. For indoor use only. Area must be well ventilated. Figure 1.
(also see "Operating Precautions").
9. If at any time gas odor is detected, IMMEDIATELY
DISCONTINUE operation until the source of gas has been
located and corrected. Read enclosed Odor fade and Propane
Sheet for additional information about detecting propane
leaks.
10. Install the heater such that is is not directly exposed to water
spray, rain and/or dripping water.
11. Maintain minimum clearance from normal combustible
material (like paper). Figure 2.
12. Due to the high surface and exhaust temperatures, adults and
children must observe clearances to avoid burns or clothing
ignition.
13. Operate only on a stable, level surface.
14. Do not use with duct work. Do not restrict inlet or exit.
15.
connection and grounding must comply with National
Electrical Code - ANSI/NFPA 70 (USA) and CSA C22.1 Canadian
Electrical Code, Part 1 (Canada).
16. Use only a properly grounded 3-prong receptacle or extension
cord.
17. Do not move, handle or service while hot or burning.
18. Do not adjust the heater combustion tube elevation while
heater is running or hot. Adjustments to elevation should
only be made after the heater has cooled to touch.
19. Use only in accordance with local codes or, in the absence of
local codes, with the Standard for the Storage and Handling
Natural Gas and Propane Installation Code.
Figure 1
VENTILATION: Minimum openings required
Opening Opening
Heater near floor near ceiling
Forced air (55, 60)................ 1 ft2..........................1 ft2
Forced air (85, 125) .............. 2 ft2..........................2 ft2

E-5 Operating Instructions and Owner’s ManualMr. Heater, Inc.| Forced Air Propane Construction Heater
ODOR FADE WARNING
WARNING
Asphyxiation Hazard
•Do not use this heater for heating human living
quarters.
•Do not use in unventilated areas.
•
not be obstructed.
•Proper ventilation air must be provided to
support the combustion air requirements of the
heater being used.
•
manual, heater data plate, or contact the factory
to determine combustion air ventilation
requirements of the heater.
•Lack of proper ventilation air will lead to
improper combustion.
•Improper combustion can lead to carbon
monoxide poisoning leading to serious injury or
death. Symptom of carbon monoxide poisoning
can include headaches, dizziness and difficulty
in breathing.
FUEL GAS ODOR
LP gas and natural gas have man-made odorants added
specifically for detection of fuel gas leaks.
If a gas leak occurs you should be able to smell the fuel
gas. Since Propane (LP) is heavier than air you should
smell for the gas odor low to the floor. ANY GAS ODOR
IS YOUR SIGNAL TO GO INTO IMMEDIATE ACTION!
•Do not take any action that could ignite the fuel gas. Do
not operate any electrical switches. Do not disconnect
any power supply or extension cords. Do not light
matches or any other source of flame. Do not use your
telephone.
•Get everyone out of the building and away from the area
immediately.
•Close all propane (LP) gas tank or cylinder fuel supply
valves, or the main fuel supply valve located at the meter
if you use natural gas.
•Propane (LP) gas is heavier than air and may settle in low
areas. When you have reason to suspect a propane leak,
keep out of all low areas.
•Use your neighbor’s phone and call your fuel gas supplier
-enter the building or
area.
•Stay out of the building and away from the area until
declared safe by the firefighters and your fuel gas
supplier.
•FINALLY, let the fuel gas service person and the
the building and area before you return. Properly trained
service people must repair any leaks, check for further
leakages, and then relight the appliance for you.
ODOR FADING - NO ODOR DETECTED
•Some people cannot smell well. Some people cannot
smell the odor of the man-made chemical added to
propane (LP) or natural gas. You must determine if you
can smell the odorant in these fuel gases.
•Learn to recognize the odor of propane (LP) gas and
natural gas. Local propane (LP) gas dealers will be more
than happy to give you a scratch and sniff pamphlet. Use
it to become familiar with the fuel gas odor.
•Smoking can decrease your ability to smell. Being
around an odor for a period of time can affect your
sensitivity to that particular odor. Odors present in animal
•The odorant in propane (LP) gas and natural gas
is colorless and the intensity of its odor can fade
under some circumstances.
•If there is an underground leak, the movement of gas
through the soil can filter the odorant.
•Propane (LP) gas odor may differ in intensity at different
levels. Since Propane (LP) gas is heavier than air, there
may be more odor at lower levels.
•Always be sensitive to the slightest gas odor. If you
continue to detect any gas odor, no matter how small,
treat it as a serious leak. Immediately go into action as
discussed previously.
ATTENTION - CRITICAL POINTS TO
REMEMBER!
•Propane (LP) gas has a distinctive odor. Learn to
recognize these odors. (Reference Fuel Gas Odor and
Odor Fading sections above.
•Even If you are not property trained in the service and
repair of the heater, ALWAYS be consciously aware of the
odors of propane (LP) gas and natural gas.
•If you have not been properly trained in repair and
service of propane (LP) gas then do not attempt to
light heater, perform service or repairs, or make any
adjustments to the heater on the propane (LP) gas fuel
system.
•A periodic sniff test around the heater or at the heater’s
joints; i.e. hose, connections, etc., is a good safety
practice under any conditions. If you smell even a small
amount of gas, CONTACT YOUR FUEL GAS SUPPLIER
IMMEDIATELY. DO NOT WAIT!

E-6 Operating Instructions and Owner’s ManualMr. Heater, Inc.| Forced Air Propane Construction Heater
MAINTENANCE AND STORAGE
1. The heater should be inspected before each use, and at least
annually by a qualified person.
2. Before each use, check the soft "O" ring seal at the bullnose
damaged, replace it with part number 73786.
3. Turn off the gas at the LP-gas supply cylinder(s) when the
heater is not in use.
4. When the heater is to be stored indoors, the connection
between the LP-gas supply cylinder(s) and the heater must
be disconnected and the cylinder(s) removed from the heater
and stored out of doors and in accordance with Chapter 5 of
the standard for Storage and Handling of Lique¯ed Petroleum
Gases ANSI/NFPA 58 and CSA B149.1, Natural Gas and
Propane Installation Code.
SERVICING
A hazardous condition may result if a heater is used that has been
properly:
•
•
•There is no strong disagreeable odor, eye burning or other
physical discomfort.
•There is no smoke or soot internal or external to the heater.
•There are no unplanned or unexplained shut downs of the
heater.
The parts lists and wiring diagram show the heater as it was
constructed. Do not use a heater which is different from that
shown. In this regard, use only the hose, regulator and cylinder
IMPORTANT Match the color stripe on the hangtag attached to
the hose assembly with the color on the label located near the
propane inlet fitting on the heater. Do not use alternates. For this
If there is any uncertainty about the regulator setting, have it
checked.
A heater which is not working right must be repaired, but only by a
trained, experienced service person.
In-warranty products will be repaired with no charge for either parts
or labor. Please include a brief statement indicating date, place of
purchase, the nature of the problem and proof of purchase.
Out-of-warrranty products will be repaired with a charge for parts
and labor.
HEATER ELEVATION ADJUSTMENT
This heater is equipped with an elevation adjustment panel
located at the exhaust end of the control box.
1. Do not adjust the heater combustion tube elevation while
heater is running or hot. Adjustments to elevation should
only be made after the heater has cooled to touch.
2. To adjust the heater combustion tube elevation, turn the
adjustment screw knob counterclockwise and lift the
combustion tube to desired position.
OPERATING INSTRUCTIONS
PREPARING FOR OPERATION
1. Check the heater for possible shipping damage. If any is
found, immediately notify the factory.
2. Follow all of the "Precautions".
3. Connect the POL fitting of hose and regulator assembly to the
propane cylinder by rotating the POL nut counterclockwise into
the propane cylinder's valve outlet and securely tighten with a
wrench.
4. Connect the hose to the heater by rotating the hose fitting
clockwise.
5. Securely tighten all gas connections.
6. Open the cylinder's gas valve and check all gas connections
with a soap and water solution. DO NOT USE A FLAME.
7. Connect power cord to well-grounded 115V, 60 Hz, 1Ø source
of power.
8. When using an extension cord, make certain that it is a 3-wire
(grounded) cord of proper wire size.
START
1. Before heater ignition, always allow heater fan (blower) to run
for 20 seconds to purge fuel.
2. Slowly open the main valve at propane cylinder.
3. Depress the fuel valve button to light the heater.
4. After the heater lights, keep the gas valve button depressed
for 15 seconds then release and the heater will continue to
operate.
5. Adjust burn rate by setting control knob to desired level.
6.
a) Igniter sparks continually.
7. No thermostat usable with these units.
STOP
1. Securely close valve on the propane cylinder.
2. Continue to operate heater until all fuel in the hose has
burned.
3. Unplug the power cord.
RESTART AFTER SAFETY SHUTDOWN
1. Securely close valve at propane cylinder. Unplug heater.
2. Wait 5 minutes.
3. Restart following "Start" procedure.

E-7 Operating Instructions and Owner’s ManualMr. Heater, Inc.| Forced Air Propane Construction Heater
SIZE AND CAPACITY OF PROPANE
CYLINDERS REQUIRED
The charts below show the approximate size of the cylinder
required for these heaters. To use the chart:
1. Select the lowest air temperature expected (at the bottom of the
chart).
2. Move straight up to time of operation desired (left side of chart).
3. Read the cylinder size required.
All heaters should have:
full cylinders
good air circulation
no frost on cylinders
MAXIMUM OPERATING TIME - HOURS
MAXIMUM OPERATING TIME - HOURS
MAXIMUM OPERATING TIME - HOURS
55,000 BTU/HR (16.1 kW)
85,000 BTU/HR (33.4 kW)
125,000 BTU/HR (49.1 kW)
AIR TEMPERATURE - oF (oC)
AIR TEMPERATURE - oF (oC)
AIR TEMPERATURE - oF (oC)
Use liquid with-
drawal
and a vaporizer

E-8 Operating Instructions and Owner’s ManualMr. Heater, Inc.| Forced Air Propane Construction Heater
Color Length From To
Yellow 18" (406mm) High Limit Ignition Control Temp. Terminal
Yellow 18" (406mm) High Limit Ignition Control Temp Terminal
WIRING CHART (Wire: Type AWG 150oC or equivalent (Type SF2-200, **SGI-250oC))
WIRING DIAGRAMS
HIGH LIMIT
SWITCH
MOTOR
THERMOCOUPLE
TO WIRE
IGNITION CONTROL
TEMP
MOTOR
VAC INPUT
HV TRANS
GND
SCREW
G
W
BLINE CORD
O**
G
SPARK PLUG
Y
B
Y
B
VAC INPUT
MOTOR
TEMP
HV TRANS
IGNITION
CONTROL
TO WIRE
TO WIRE
115V
60HZ
TO JUNCTION
SPARK
PLUG HIGH LIMIT
SWITCH
GND
SCREW
TEMP
MOTOR
VAC INPUT
MOTOR
B
W
COLOR CODE LEGEND
B BLACK
W WHITE
G GREEN
R RED
Y YEL
O ORG
FEMALE CONN.
RING CONN.
CONNECTION DIAGRAM SCHEMATIC DIAGRAM
NOTE: If any original wiring as supplied with the heater, must be replaced, It must be replaced with
Type AWG 105° C wire or its equivalent, except as indicated (Type SF 2.200, **SGI-250° C)

E-9 Operating Instructions and Owner’s ManualMr. Heater, Inc.| Forced Air Propane Construction Heater
Forced Air Propane Construction Heater •Model #55FAV, 60FAV, 85FAV, 125FAV
REF. # ITEM# DESCRIPTION QTY.
55FAV 60FAV 85FAV 125FAV
1 21654 21654 21654 21671 Motor Grille Assy 1
2 21652 21652 21652 21551 Motor Assy 1
3 26086 26086 26086 27898 Fan 1
4 21729 21729 21729 21998 Outer Shell 1
21730 21730 21730 21999 Outer Shell - Model TS 1
5 28075 28075 28075 28075 Handle, plastic 1
6 28074 28074 28074 28074 Clip Handle Mounting, plastic 2
7 26121 26121 26121 27433 Ftg, Male Elbow 1
8 21082 --- --- 21083 Spark Plug 1
--- 28166 28167 --- Ignitor Electrode 1
9 21751 21751 21751 22003 High Limit Control Assy 1
10 --- --- 23036 23036 Bracket Thermocouple 1
11 --- --- 23787 23787 Spacer Thermocouple 1
12 21930 22008 22007 22002 Orifice Assy, LP 1
13 21651 21651 21651 22001 Middle Cylinder Assy 1
14 23037 23037 23037 23037 Spark Plug Nut (2-55FAV) 3
15 21931 22006 22009 22004 Flame Holder Assy 1
16 23038 23038 23038 23038 Orifice Nut Mtg 1
17 21941 21655 21655 21655 Fuel Tube Assy 1
18 26655 26655 26655 26655 Thermocouple 10" Lg w/JB. 1
19 23045 23045 23045 23045 Bracket Ignition / Relay 1
20 23276 23276 23276 23276 Ignition / Relay Module 1
21 26134 26134 26134 26134 Compression Block, Relay 1
22 27093 27093 27093 27093 Cover, Cup, Valve 1
23 25027 25027 25027 25027 Knob, Variable Rate 1
24 26079 26079 26079 26079 Spacer PC Standoff 3
26 27422 22010 22011 27418 Variable Rate Valve 1
28 26225 26225 26225 26227 Snap Bushing 1
29 26224 26224 26224 27158 Snap Bushing, 1/2 1
31 26127 26127 26127 26127 Ftg, Male Connector 1
REF. # ITEM# DESCRIPTION QTY.
55FAV 60FAV 85FAV 125FAV
32 27285 27285 27285 27285 Thermoelectric Valve 1
33 26223 26223 26223 26223 Strain Relief Bushing 1
34 21036 21036 21036 21036 Power Cord Assy 1
35 26433 26433 26433 26433 POL Excess Flow 1/4 MPT 1
36 26257 26257 26257 26257 Regulator 28" WC W/POL 1
37 26152 26152 26152 26152 Hose Assy, LP, 12' 1
* 26152-20 26152-20 26152-20 26152-20 Hose Ass'y, 20' (HS only) 1
* 21667 21667 21667 21667 Hose & Regulator Ass'y 1
38 24017 24019 24019 24019 Panel, Bottom 1
40 24020 24020 24022 24022 Control Box Assy 1
41 24023 24023 24025 24025 Elevation Plate 1
42 25026 25026 25026 25026 Elevation Knob 1
43 26656 26656 26656 26656 Thermocouple, connector 1
* 26189 --- --- --- Terminal “Y” 2
* 23676 23676 --- --- Brkt, Motor Mounting 1
* 26226 26226 --- --- Universal Bushing 1
* 70056 70056 70056 70056 Manual, Operating Instr 1
* 28733 28163 28724 28510 Label, Model 1
* 27783 28727 28784 28784 Label, Operating Instr. 1
* 26374 26374 26374 26374 Label, Electrical Grounding 1
* 27709 27709 27709 27709 Label, Fuel 1
* 27503 27503 27503 27503 Label, Wiring Diagram 1
* 26373 26373 26373 26373 Label, Fan Rotation 1
* 28203 28203 28203 28203 Label Hang Tag, LP 1
* 27704 27704 27704 27704 Label, Warning 1
* 26375 26375 26375 26375 Label Elevation Adjustment 1
* 26376 26376 26376 26376 Label Btu/hr Adjustment 1
* Not shown on exploded view

E-10 Operating Instructions and Owner’s ManualMr. Heater, Inc.| Forced Air Propane Construction Heater
WARNING: USE ONLY MANUFACTURER’S REPLACEMENT PARTS. USE OF
ANY OTHER PARTS COULD CAUSE INJURY OR DEATH. REPLACEMENT PARTS ARE
ONLY AVAILABLE DIRECT FROM THE FACTORY AND MUST BE INSTALLED BY A
QUALIFIED SERVICE AGENCY.
PARTS ORDERING INFORMATION:
PURCHASING: Accessories may be purchased at any Mr. Heater local dealer or direct
from the factory
FOR INFORMATION REGARDING SERVICE
Please call Toll-Free 800-251-0001 • www.mrheater.com
Please include the model number, date of purchase, and description of problem in all
communication.
LIMITED WARRANTY
The company warrants this product to be free from imperfections in material or workmanship,
under normal and proper use in accordance with instructions of The Company, for a period of
one year from the date of delivery to the buyer. The Company, at its option, will repair or replace
products returned by the buyer to the factory, transportation prepaid within said one year period
and found by the Company to have imperfections in material or workmanship.
If a part is damaged or missing, call our Technical Support Department at 800-251-0001.
Address any Warranty Claims to the Service Department, Mr. Heater, Inc., 4560 W. 160TH ST.,
CLEVELAND, OHIO 44135. Include your name, address and telephone number and include
details concerning the claim. Also, supply us with the purchase date and the name and address
of the dealer from whom you purchased our product.
The foregoing is the full extent of the responsibility of the Company. There are no other
and there is no warranty of merchantability. In no event shall the Company be liable for delay
caused by imperfections, for consequential damages, or for any charges of the expense of
any nature incurred without its written consent. The cost of repair or replacement shall be the
exclusive remedy for any breach of warranty. There is no warranty against infringement of the
like and no implied warranty arising from course of dealing or usage of trade. This warranty
will not apply to any product which has been repaired or altered outside of the factory in any
respect which in our judgment affects its condition or operation.
Some states do not allow the exclusion or limitation of incidental or consequential damages, so
rights, and you may have other rights which vary from state to state.
MR. HEATER, INC., 4560 W. 160TH ST., CLEVELAND, OHIO 44135 • 216-916-3000
Mr. Heater is a registered trademark of Mr. Heater, Inc.
© 2010, Mr. Heater. All rights reserved
Mr. Heater, Inc. reserves the right to make changes at any time, without notice or obli-
gation, in colors, specifications, accessories, materials and models.
READ INSTRUCTIONS CAREFULLY:
Read and follow all instructions. Place
instructions in a safe place for future
reference. Do not allow anyone who has
not read these instructions to assemble,
light, adjust or operate the heater.
MH55FAV, MH60FAV, MH85FAV,
MH125FAV
PA55FAV, PA85FAV, PA125FAV
MODEL
MODEL
OPERATING INSTRUCTIONS AND OWNER’S MANUAL
MR. HEATER HEATSTAR
HS55FAV, HS85FAV, HS125FAV
Model Starting Serial
Number
MH55FAV LN-2700550001001
MH60FAV LN-2281600001001
MH85FAV LN-2282850001001
MH125FAV LN-2701250001001
HS55FAV LN-1700550001001
HS85FAV LN-1700850001001
HS125FAV LN-1701250001001
PA55FAV LN-2220240001001
PA125FAV LN-2220450001001
70056 Rev. G 03/10
®
ANSI Z83.7b/CSA 2.14b-2009
