MrHeater MHVFRD20LPBT Assembly instructions

MR. HEATER, INC., 4560 W. 160TH ST., CLEVELAND, OHIO 44135 · 800-251-0001
WARNING: If the information in this manual is not followed exactly, a re or explosion may result causing
property damage, personal injury, or loss of life.
- Do not store or use gasoline or other ammable vapors and liquids in the vicinity of this or any other appliance.
- WHAT TO DO IF YOU SMELL GAS
• Shut o󰀨 gas supply
• Do not try to light any appliance
• Do not touch an electrical switch; do not use any phone in your building.
• Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instructions.
• If you cannot reach your gas supplier, call the re department.
- Installation and service must be performed by a qualied installer, service agency, or the gas supplier.
WARNING: This is an unvented gas-red heater. It uses air (oxygen) from the room in which it is installed.
Provisions for adequate combustion and ventilation air must be provided. Refer to Fresh Air for Combustion
and Ventilation section on page 4 of this manual.
WARNING: Improper installation, adjustment, alteration, service or maintenance can cause injury or property
damage. Refer to this manual for correct installation and operational procedures. For assistance or additional
information consult a qualied installer, service agency, or gas supplier.
2017 - CB
UNVENTED LP-GAS FIRED ROOM HEATER
OPERATING INSTRUCTIONS
AND OWNER’S MANUAL
READ INSTRUCTIONS CAREFULLY: Read and follow all instructions. Place instructions in a safe
place for future reference. Do not allow anyone who has not read these instructions to assemble,
light, adjust or operate the heater.
Blue Flame Heaters
MHVFBF20LPBT
(BLOWER INCLUDED)
MHVFBF20LPT
(BLOWER SOLD SEPARATE)
MHVFBF30LPBT
(BLOWER INCLUDED)
MHVFBF30TLPT
(BLOWER SOLD SEPARATE)
Plaque Heaters
MHVFRD20LPBT
(BLOWER INCLUDED)
MHVFRD20LPT
(BLOWER SOLD SEPARATE)
MHVFRD30LPBT
(BLOWER INCLUDED)
MHVFRD30LPT
(BLOWER SOLD SEPARATE)
INSTALLER: Leave this manual with the appliance. CONSUMER: Retain this manual for future reference.
This appliance may be installed in an aftermarket permanently manufactured (mobile) home, where not prohibited
by local codes. This appliance is only for use with the type of gas indicated on the rating plate. This appliance is not
convertible for use with any other gas.

2Installation Instructions and Owner’s Manual
Unvented LP-Gas Vent Free Room Heaters
CONTENTS
WARNINGS........................................................................2
SPECIFICATIONS.................................................................3
PRECAUTIONS....................................................................3
IGNITION SYSTEM BATTERY INSTALLATION .......................4
BLOWER FAN CONTROL SWITCH OPERATION ....................4
DETERMINING THE TYPE OF HEATER LOCATION SPACE .....5
INSTALLATION ...................................................................6
FASTENING HEATER TO WALL............................................ 7
FLOOR MOUNTING AWAY FROM WALL .............................8
CONNECTING TO GAS SUPPLY ...........................................8
OPERATING YOUR HEATER............................................... 10
CLEANING AND MAINTENANCE.......................................11
TROUBLESHOOTING ........................................................ 14
EXPLODED-VIEW PARTS DRAWING................................... 16
PARTS LIST....................................................................... 17
WARRANTY .................................................................... 20
CAUTION: Never connect heater directly
to the Propane supply. This heater requires
an external regulator (not supplied). Install
the external regulator between the heater and
Propane/LP supply.
The installer must supply an external
regulator. The external regulator will reduce
the incoming gas pressure to between 11
and 14 inches of water. If you do not reduce
incoming gas pressure heater regulator
damage could occur. Install external regulator
with the vent pointing down. Pointing the
vent down protects it from freezing rain or
sleet.
In order to provide the best service possible Mr. Heater is now giving you
more ways to get in touch with us:
WEBSITE: Mr. Heater’s full line of product are now at:
WWW.MRHEATER.COM
FACEBOOK: Find us on Facebook
TWITTER: Find us on twitter
YouTube: There are now informational videos on YouTube.
SOCIAL MEDIA
WARNINGS
IMPORTANT: Read this owner’s manual carefully and completely before trying to assemble, operate, or
service this heater. Improper use of this heater can cause serious injury or death from burns, re, explosion,
electrical shock, and carbon monoxide poisoning.
WARNING: This appliance is equipped for propane
gas. Field conversion is not permitted.
WARNING: Do not use any accessory not
approved for use with this heater.
WARNING: Any change to this heater or its
controls can be dangerous.
• Do not place clothing or other ammable ma-
terial on or near the appliance.
• Due to high temperatures, heater should be
kept out of tra󰀩c and away from furniture and
draperies.
• Surface of heater becomes very hot when
running. Keep children and adults away
from hot surfaces to avoid burns or clothing
ignition. Heater will remain hot for a time
after shutdown. Allow heater surfaces to cool
before handling.
• Young children should be carefully supervised
when they are in the same room with heater.
• Make sure grille guard is in place before
running heater. If screen or grille guard is
removed for servicing it must be replaced prior
to operating the heater.
• Keep the appliance area clear and free from
combustible materials, gasoline, and other
ammable vapors and liquids.
• Children and adults should be alerted to the
hazard of high surface temperature and should
stay away to avoid burns or clothing ignition.
• Any safety screen or guard removed for
servicing an appliance must be replaced prior
to operating the heater

Installation Instructions and Owner’s Manual
Unvented LP-Gas Vent Free Room Heaters 3
the control system and any gas control which has
been underwater.
9. Operating heater above elevations of 4,500 feet
could cause pilot/ODS to shutdown heater.
10. Always run heater with control knob in a locked
position. Never set control knob between locked
positions. Poor combustion and higher levels of
carbon monoxide may result if control knob is left
between locked positions.
DANGER: Carbon monoxide poisoning may lead to
death.
Carbon Monoxide Poisoning:
Early signs of carbon monoxide poisoning resemble
the u, with headaches, dizziness, or nausea. If you
have these signs, the heater may not be working
properly. Get fresh air at once! Have heater serviced.
Some people are more a󰀨ected by carbon monoxide
than others. These include pregnant women, persons
with heart or lung disease or anemia, those under the
inuence of alcohol, and those at high altitudes.
Propane/LP Gas:
Propane/LP gas is odorless. An odor making agent is
added to propane/LP gas. The odor helps you detect
a Propane/LP gas leak. However the odor added to
propane/LP gas may be present even though no odor
exists. Make certain you read and understand all
warnings. Keep this manual for reference. It is your
guide to safe and proper operation of this heater.
PRECAUTIONS:
1. 20,000 BTU or 30,000 BTU may not be installed
in a bedroom or bathroom, or any place where a
strong wind would shut down the appliance.
2. This heater needs outside ventilation air to run
properly. The Oxygen Depletion Sensor (ODS)
safety shuto󰀨 system shuts down the heater if not
enough fresh air is available. See Fresh Air for
Combustion and Ventilation, pages 5 through 6.
WARNING: An unvented heater having an input
of more than 10,000 Btu/hr (2 931W) shall not be
installed in a bedroom or bathroom.
3. Keep all air openings in heater clear, free of debris
or any blockage. This will insure that enough air for
proper combustion enters the heater.
4. If heater shuts o󰀨, do not relight until you provide
fresh, outside air. If heater keeps shutting o󰀨, it
requires servicing.
5. Turn o󰀨 and unplug heater and let cool before
servicing. Only a qualied service person should
service and repair heater.
6. Do not run heater:
• Where ammable liquids or vapors are used or
stored
• During dusty conditions.
7. Before using furniture polish, wax, carpet cleaner
or similar products, turn heater o󰀨. If heated the
vapors from these products may create a white
powder residue within burner box or on adjacent
walls or furniture.
8. Do not use heater if any part has been underwater.
Immediately call a qualied service technician to
inspect the room heater and to replace any part of
SPECIFICATIONS
**Operating heater above elevations of 4,500 feet could cause pilot/ODS to shutdown heater.**
MODEL MHVFRD20BT/
MHVFRD20T LP
MHVFRD30TB /
MHVFRD30T LP
MHVFBF20TB /
MHVFBF20T LP
MHVFBF30TB /
MHVFBF30T LP
BTU (Available) 18,000 30,000 20,000 30,000
Type of Gas LP-Gas Only LP-Gas Only LP-Gas Only LP-Gas Only
Ignition Battery ignitor (1-AA) Battery ignitor (1-AA) Battery ignitor (1-AA) Battery ignitor (1-AA)
Pressure Regulator Setting 10 Inches of Water 10 Inches of Water 10 Inches of Water 10 Inches of Water
Inlet Gas Pressure (Maximum) 14 Inches of Water 14 Inches of Water 14 Inches of Water 14 Inches of Water
Inlet Gas Pressure (Minimum) 11 Inches of Water 11 Inches of Water 11 Inches of Water 11 Inches of Water
Electrical Rating /Blower 120V, 60Hz , 1 120V, 60Hz , 1 120V, 60Hz , 1 120V, 60Hz , 1
Thermostatic Control Yes Yes Yes Yes
Clearances: inches (mm)
Top 36” (915cm) 36” (915cm) 36” (915cm) 36” (915cm)
Sides 10” (254cm) 10” (254cm) 10” (254cm) 10” (254cm)
Floor (min to top of carpet) 3” (76cm) 3” (76cm) 3” (76cm) 3” (76cm)
Fabric / ammable objects 36” (915cm) 36” (915cm) 36” (915cm) 36” (915cm)

4Installation Instructions and Owner’s Manual
Unvented LP-Gas Vent Free Room Heaters
Product Features
Figure 1
SAFETY DEVICE
This heater has a pilot with an Oxygen Depletion Sen-
sor (ODS) safety shut o󰀨 system. The ODS/pilot shuts
o󰀨 the heater if there is not enough fresh air.
IGNITION SYSTEM / BATTERY INSTALLATION
– The heater is equipped with an electronic manual
ignitor. This system requires no matches, or other
source to light heater, but does require one AA battery
to operate ignitor. (AA Battery included).
To install or replace battery unscrew the ignitor cap
(red button), insert battery positive (+) terminal up
and replace cap.
(AA Battery included)
THERMOSTATIC CONTROL
These heaters have a control valve with a thermostat
sensing bulb. This results in the greatest heater comfort
and may result in lower bills.
BLOWER FAN CONTROL SWITCH OPERATION
These heaters also include an electrical blower. The
blower switch has three positions: MANUAL, OFF and
AUTO. In AUTO, the blower will turn on and o󰀨 as the
heater cycles on and o󰀨. On MANUAL, the blower will run
continuously. To turn blower o󰀨, use the OFF position.
LOCAL CODES
Install and use heater with care.
Installation must conform to local codes or in the
absences of local codes, use the latest edition of
National Fuel Gas Code ANSI Z223.1/NFPA 54.
UNPACKING
1. Remove heater from carton.
2. Remove all protective packaging applied to
heater for shipment.
3. Check heater for any shipping damage. If
heater is damaged, promptly inform dealer
where you bought heater.
FRESH AIR FOR COMBUSTION AND
VENTILATION
WARNING: This heater shall not be installed in a
room or space unless the required volume of indoor
combustion air is provided by the method described in
the National Fuel Gas Code, ANSI Z223.1/NFPA 54.
Read the following instructions to insure proper fresh air
for this and other fuel-burning appliances in your home.
ESTABLISHING ADEQUATE VENTILATION
The following are excerpts from National Fuel Gas
Code, NFPA 54/ ANSI Z223.1, Section 5.3, Air for
Combustion and Ventilation. All spaces in homes fall
into one of the three following ventilation classications:
1. Unusually Tight Construction
2. Unconned Space
3. Conned Space
This heater must not be installed in a conned space
or unusually tight construction unless provisions are
provided for adequate combustion and ventilation air.
The information on pages 4 through 6 will help you
classify your space and provide adequate ventilation.
Unusually Tight Construction
If your home meets all of the three following criteria you
must provide additional fresh air. See Ventilation Air
from Outdoors, page 6.
Unusually tight construction is dened as construction
where:
a. Walls and ceilings exposed to the outside
atmosphere have a continuous water vapor retarder
with a rating of one perm (6 x 10-11 kg per pa-sec-m2)
or less with openings gasketed or sealed and
b. Weather stripping has been added on operable
windows and doors, and
c. Caulking or sealants are applied to areas such
as joints around windows and door frames,
between wall-ceiling joints, between wall panels, at
penetrations for plumbing, electrical, and gas lines,
and at other openings.
If your home does not meet all of the three criteria
above, see Determine the Type of Heater Location
Space, page 5.
Conned Space and Unconned Space
The National Fuel Gas Code, NFPA 54/ ANSI Z223.1
denes a conned space as a space whose volume is
less than 50 cubic feet per 1,000 Btu per hour (4.8 m3
per kW) of the aggregate input rating of all appliances
installed in that space, and an unconned space as a
space whose volume is not less than 50 cubic feet per
1,000 Btu per hour (4.8 m3 per kW) of the aggregate
input rating of all appliances installed in that space.
Rooms communicating directly with the space in which
the appliances are installed*, through openings not
furnished with doors, are considered a part of the
unconned space.
Ignitor Button
Control Knob
Grill
Front Panel
Burners
Heater
Cabinet
Fan Blower
Switch
(located on back
of heater)

Installation Instructions and Owner’s Manual
Unvented LP-Gas Vent Free Room Heaters 5
*Adjoining rooms are communication only if there
are door less passageways or ventilation grills
between them.
DETERMINING THE TYPE OF HEATER
LOCATION SPACE:
Use this method to determine if you have a conned or
unconned space.
Note: the space includes the room in which you
install heater plus any adjoining rooms with doorless
passageways or ventilation grills between the rooms.
1. Find the volume of the space by multiplying room
length x width x height.
Example: Space size 18ft (length) x 18ft. (width) x 8ft.
(height) = 2592
If additional ventilation to adjoining room is supplied
with grills or openings, add the volume of these rooms
to the total volume of the space.
2. Divide the space volume by 50 cubic feet to deter-
mine the maximum Btu/hr the space can support.
Example: 2592 cu.ft. (volume of space) / 50 cu.ft. =
51.8 or 51,800 (maximum Btu/hr the space
can support)
WARNING: If the area in which the heater may be
operated is smaller than dened as an unconned
space or if the building is of unusually tight
construction, provide adequate combustion and
ventilation air by the methods described in the
National Fuel Gas Code, NFPA 54/ ANSI Z223.1,
Section 5.3 or applicable local codes.
3. Add the Btu/hr of all the fuel-burning appliances
in the space such as, Vent–free heater, Gas water
heater, Gas furnace, Vented gas heater, Gas re-
place logs, and Other gas appliances*
*Do not include direct-vent gas appliances. Direct-
vent draws combustion air from the outdoors and
vents to the outdoors.
Example: Gas water heater 40,000 Btu/hr
Vent Free Heater + 20,000 Btu/hr
Total =60,000 Btu/hr
4. Compare the maximum Btu/hr the space can support
with the actual amount of Btu/hr used.
Example: 51,800 Btu/hr (maximum Btu/hr the
space can support)
60,000 Btu/hr (Actual amount of Btu/hr
used)
The space in the above example is a conned
space because the actual Btu/hr used is more than
the maximum Btu/hr the space can support.
You must provide additional fresh air. Your options
are as follows:
A. Rework worksheet, and the space of an adjoining
room. If the extra space provides an unconned
space, remove door to adjoining room or add
ventilation grills between the rooms. See Ventilation
Air From Inside Building (Figure 2).
B. Vent room directly to the outdoors. See Ventilation
Air From Outdoors (Figure 3).
C. Install a lower Btu/hr heater if lower Btu/hr size
makes room unconned.
If actual Btu/hr used is less than the maximum Btu/
hr the space can support, the space is an uncon-
ned space. You will need no additional fresh air
ventilation.
VENTILATION AIR
Ventilation from Inside Building
This fresh air would come from an adjoining unconned
space. When ventilation to an adjoining unconned
space, you must provide two permanent openings:
one within 12” of the ceiling and one within 12” of
the oor on the wall connecting the two spaces (see
options 1 & 2 of g. 2). You can also remove door into
adjoining room (see option3, g 2). Follow the National
Fuel Gas Code NFPA 54/ ANSI Z223.1, Section 5.3,
Air for Combustion and Ventilation for required size of
ventilation grills or ducts.
Figure 2.
Figure 3.
Ventilation
Gills into
Adjoining
Room -
Option 1
Ventilation Gills into
Adjoining Room - Option 2
12”
12”
Or remove
door into
Adjoining
Room -
Option 3
INLET
AIR
OUTLET
AIR
VENTILATION CRAWL SPACE
TO CRAWL
SPACE
TO ATTIC
VENTILATION AIR
VENTILATED
ATTIC
OUTLET AIR

6Installation Instructions and Owner’s Manual
Unvented LP-Gas Vent Free Room Heaters
*A CSA/AGA certied equipment shuto󰀨 valve with
1/8” NPT tap is an acceptable alternative to test gauge
connection. Purchase a CSA/AGA certied equipment
shuto󰀨 valve from your dealer.
LOCATING HEATER
This heater is designed to be mounted on the wall. The
heater can also be located on a non-combustible oor,
away from a wall by using the oor mounting stands
included with the heater. If installed on combustible
ooring such as carpeting, tile or other combustible
material other than wood ooring, the heater must be
placed on a wood panel the full width and depth of the
appliance.
For convenience and e󰀩ciency, install the heater:
• Where there is easy access for operation,
inspection, and service
• In the coldest part of the room.
• If planning to use fan, locate heater near an
electrical outlet.
CAUTION: If you install the heater in a home garage:
Heater pilot and burner must be at least 18 inches
above oor . Locate heater where moving vehicle will
not hit it.
CAUTION: This heater creates warm air currents.
These currents move heat to wall surfaces next to
heater. Installing heater next to vinyl or cloth wall
covering or operating heater where impurities (such
as tobacco smoke, aromatic candles, cleaning uids,
oil or kerosene lamps, etc.) are present in the air may
discolor walls.
WARNING: Never install the heater:
• In a bedroom (RD20LPT, RD30LPT, BF20LPT
or BF30LPT)
• In a recreational vehicle ·.
• Where curtains, furniture, clothing, or other
ammable objects are less than 36 inches from
the front, top, or sides of the heater.
• As a replace insert
• In high-tra󰀩c areas
• In windy or drafty areas
WARNING: Heater must be mounted to maintain
the minimum clearances shown in Figure 4. If
possible, provide greater clearances from the oor,
ceiling, and joining walls.
WARNING: Rework worksheet, adding the space
of the adjoining unconned space. The combined
space must have enough fresh air to supply all ap-
pliance in both spaces.
Ventilation from Outdoors
If necessary provide extra fresh air by using ventilation
grills or ducts. Connect these items directly to the
outdoors or spaces open to the outdoors. These
include attics* and crawl spaces. Follow the National
Fuel Gas Code NFPA 54/ ANSI Z223.1, Section 5.3,
Air for Combustion and Ventilation for required size of
ventilation grills or ducts.
*IMPORTANT: Do not provide openings for inlet or
outlet into attic. If attic has a thermostat-controlled
power vent, heated air entering the attic will activate
the power vent.
IMPORTANT: Vent-free heaters add moisture to
the air. Although this is benecial, installing heater
in rooms without enough ventilation air may cause
mildew to form from too much moisture. See Fresh Air
for Combustion and Ventilation, pages 5 through 6.
INSTALLATION
WARNING: Any change to this heater or its
controls can be dangerous.
NOTICE: This appliance is intended for supplemental
heating. Use this heater along with your primary heating
system. Do not install this heater as your primary heat
source. If you have a central heating system, you may
run system’s circulating blower while using heater. This
will help circulate the heat throughout the house. In the
event of a power outage, you can use this heater as
your primary heat source for the duration of the outage.
WARNING: A qualied service person must install
heater. Follow all local codes.
CHECK GAS TYPE
Use only LP-gas. If your gas supply is not LP-gas, do
not install heater. Call dealer where you bought heater
for proper type heater.
THIS INSTALLATION REQUIRES:
Before installing heater, make sure you have the items
listed below:
• Piping (check local codes)
• Sealant (resistant to LP_Gas)
• Equipment shuto󰀨 valve*
• Ground joint union
• Test gauge connection*
• Sediment trap
• Tee joint
• Pipe wrench

Installation Instructions and Owner’s Manual
Unvented LP-Gas Vent Free Room Heaters 7
Figure 4
FASTENING HEATER TO WALL
Mounting Bracket
The mounting bracket in located on the back panel of
heater (see gure 5). It has been taped there for ship-
ping. Remove mounting bracket from back panel.
Figure 5
Removing Front Panel of Heater
1. Remove (4) screws total there are (2) screws
on either side of the heater (Figure 6).
2. Pull the front panel and back panel apart.
(2) Screws
(2) Screws
Figure 6
Attaching Mounting Bracket to Wall
Use holes on each end of mounting bracket to attach
bracket to wall. These holes are 16 inches apart. Attach
mounting bracket to wall in one of two following ways.
1. Attach to wall studs
2. Attach to wall anchor
Attaching to Wall Stud:
This way is the best providing the strongest mounting in
wood frame houses.
Attaching to Wall Anchor:
This way allows you to attach mounting bracket to hol-
low walls (wall areas between studs) or to solid walls
(concrete or masonry).
Decide which way best suits your needs. Either method
will provide a secure hold for the mounting bracket.
1. Tape mounting bracket to wall where heater
will be located. Make sure mounting bracket is
level. For wall stud mounting locate one end of
the mounting bracket over a wall stud.
WARNING: Maintain minimum clearances shown in
gure 7. If you can, provide greater clearances from
the oor and joining wall.
2. Mark screw locations on wall (see gure 7).
3. Remove tape and mount bracket from wall.
Figure 7
Attaching to Wall Stud:
For attaching mounting bracket to wall studs
1. Drill holes at marked locations using 9/64” drill
bit.
2. Place mounting bracket onto wall. Line up
holes on each end of bracket with hole drilled in
wall.
3. Insert mounting screws through bracket and
into wall studs.
4. Tighten screws until mounting bracket is rmly
fastened to wall studs.
Attaching to Wall using Anchor:
For attaching mounting bracket to hollow walls (wall areas
between studs) or solid walls (concrete or masonry)
Note: Wall anchors, mounting screws, and spacer
are in hardware package. The hardware package is
provided with heater.
1. Drill holes at marked locations using 5/16” drill
bit. For solid walls (concrete or masonry), drill
at least 1” deep.
Adjoining Wall
18” Min.
SEE CLEARANCE
SPECIFICATIONS ON PG. 3
16” (Lg)
12-9/64” (Sm)
Mark mounting hole locations
and drill holes where indicated.
Allow for minimum clearances
Left
Side Right
Side
36” (915cm)
min. from ceiling
10”(254cm)
from sides
3” min. to top surface of carpet, tile
or other combustible material
Floor
Mounting
Bracket

8Installation Instructions and Owner’s Manual
Unvented LP-Gas Vent Free Room Heaters
2. Fold wall anchor as shown in gure 8 below.
Figure 8.
3. Insert wall anchor (wings rst) into hole. Tap
anchor ush to wall.
4. For thin walls (1/2” or less) insert red key into
wall anchor.
5. Place mounting bracket onto wall. Line up
holes on each end of bracket with wall anchors.
6. Insert mounting screws through bracket and
into wall anchors.
7. Tighten screws until mounting bracket is rmly
fastened to wall.
Placing Heater on Mounting Bracket
1. Locate two horizontal slots on back pane of
heater (see gure 9).
2. Place heater onto mounting bracket. Slide hori-
zontal slots onto stand-out tabs on mounting
bracket.
Figure 9.
Installing Bottom Mounting Screws
1. Locate two bottom mounting holes. These
holes are near bottom on back panel of heater
(see gure 10).
Figure 10
2. Mark screws locations on wall.
3. Remove heater from mounting bracket.
4. If installing bottom mounting screw into hollow
or solid wall, install wall anchors. Follow steps 1
through 4 under Attaching to Wall using Anchor.
Horizontal Slots
Mounting Bracket
mounted to wall
If installing bottom mounting screw into wall
stud, drill holes at marked locations using 9/64”
drill bit.
5. Re-place heater onto mounting bracket.
6. Place spacers between bottom mounting holes
and wall anchor or drilled hole.
7. Hold spacer in place with one hand. With the
other hand, insert mounting screw through
bottom mounting hole and spacer. Place tip of
screw in opening of wall anchor or drilled hole.
8. Tighten both screws until heater is rmly
secured to wall. Do not over tighten.
Note: Do not re-place front panel at this time.
Replace front panel after making gas connections
and checking for leaks.
FLOOR MOUNTING AWAY FROM WALL:
Installing Support Feet (see gure 11)
Figure 11
1. Lay heater onto table on its back with bottom
edge overhanging table edge.
2. Securely attach feet to bottom of heater using
2 – self-tapping screws each.
Note: Feet should have long end going out the
front of heater, and the edge coinciding with side of
heater. If feet overhang side of the heater, switch
leg location.
3. Place heater on non-combustible surface (see
Locating Heater above) before proceeding
with gas connection. If this will be a permanent
location, heater may be locked into position
using anchoring holes in mounting feet.
Note: Use of oor mounting feet will require you to
use a 3/8 NPT street elbow to make gas connection.
CONNECTING TO GAS SUPPLY
WARNING: A qualied service person must connect
heater to gas supply. Follow all local codes.
WARNING: This appliance requires a 3/8” NPT
(National Pipe Thread) inlet connection to the
pressure regulator. Use of oor mounting feet will
require you to use a 3/8 NPT street elbow to make
gas connection.
Screw
hole
Screw
hole

Installation Instructions and Owner’s Manual
Unvented LP-Gas Vent Free Room Heaters 9
CAUTION: Never connect heater directly to the Propane
supply. This heater requires an external regulator (not
supplied). Install the external regulator between the
heater and Propane/LP supply.
IMPORTANT: The installer must supply an external
regulator. The external regulator will reduce the
incoming gas pressure to between 11 and 14
inches of water. If you do not reduce incoming gas
pressure heater regulator damage could occur.
Install external regulator with the vent pointing
down. Pointing the vent down protects it from
freezing rain or sleet.
CAUTION: Use only new black iron or steel pipe.
Internally-tinned copper tubing may be used in certain
areas. Check your local codes. Use pipe of larger
enough diameter to allow proper gas volume to heater.
If pipe is too small, undue loss of pressure will occur.
Installation must include an equipment shuto󰀨 valve,
union and plugged 1/8” NPT tap. Locate NPT tap within
reach of test gauge hookup. NPT tap must be upstream
from heater (see gure 12).
FIGURE 12
*A CSA/AGA certied equipment shuto󰀨 valve with
1/8” NPT tap is an acceptable alternative to test gauge
connection. Purchase the CSA/AGA certied equipment
shuto󰀨 valve from your dealer.
IMPORTANT: Install an equipment shuto󰀨 valve in an
accessible location. The equipment shuto󰀨 valve is for
turning on or shutting o󰀨 the gas to the appliance.
Apply pipe joint sealant lightly to male threads. This will
prevent excess sealant from going into pipe. Excess
sealant in pipe could result in clogged heater fuel train.
CAUTION: Use pipe joint sealant that is resistant to LP-Gas.
Install sediment trap in supply line as shown in gure
12. Locate sediment trap where it is within reach
for cleaning. A sediment trap traps moisture and
contaminants. This keeps them from going into heater.
If sediment trap is not installed or is installed improperly,
heater may not run correctly.
IMPORTANT: Hold pressure regulator with wrench
when connecting it to gas piping and/or ttings.
CHECKING GAS CONNECTIONS
WARNING: Test all gas piping and connections for
leaks after installing or servicing. Correct all leaks
at once.
WARNING: Never use an open ame to check for
a gas leak. Apply a mixture of liquid soap and water
to all joints. Bubbles forming show a leak. Correct
all leaks at once.
PRESSURE TESTING GAS SUPPLY PIPING
SYSTEM
Test pressure in Excess of ½ psig (3.5kPa)
1. Disconnect appliance with its appliance main
gas valve (control valve) and equipment shuto󰀨
valve from gas supply piping system. Pressures
in excess of ½ psig will damage heater
regulator.
2. Cap o󰀨 open end of gas pipe where equipment
shuto󰀨 valve was connected.
3. Pressurize supply piping system by either using
compressed air or opening main gas valve on
or near gas meter.
4. Check all connections and joints in gas supply
piping system. Apply mixture of liquid soap and
water to gas joints. Bubbles forming show a
leak.
5. Correct all leaks at once.
6. Depressurize and relieve pressure in supply
piping system.
7. Reconnect heater and equipment shuto󰀨 valve
to gas supply.
8. Reconnected ttings must be checked for leaks
in next section.
Test Pressure Equal To or Less Than ½ psig (3.5 kPa)
1. Close equipment shuto󰀨 valve (see gure 13).
2. Pressurize supply piping system by either using
compressed air or opening main gas valve on
or near gas meter.
3. Check all joints from the gas meter to
equipment shuto󰀨 valve (see gure 14). Apply
mixture of liquid soap and water to gas joints.
Bubbles forming show a leak.
4. Correct all leaks at once.
5. Depressurize and relieve pressure from supply
piping system.
Nipple
Tee Joint
Cap
Shutoff Valve
HEATER CABINET
Nipple
Nipple
Tee Joint
Ground Joint Union
3/8” NPT Pipe Nipple
Pressure
Regulator
Test Gauge
Connection
1/8” NPT Plug Tap
Reducer Bushing
to 1/8” NPT
Nipple
Sediment
Trap
3” minimum
Fuel line from
Regulated LP Tank
(11”W.C to 14” WC Pressure)

10 Installation Instructions and Owner’s Manual
Unvented LP-Gas Vent Free Room Heaters
Equipment
Shuto󰀨 Valve
Open
Closed
ELECTRICAL WIRING DIAGRAM:
If any original wiring as supplied with the heater must
be replaced, it must be replaced with type AWG 105oC
wire or its equivalent except as indicated.
WARNING: Electrical Grounding Instructions: This
heater is equipped with a three-prong (grounding)
plug for your protection against shock hazard and
should be plugged into a properly grounded three-
prong receptacle.
OPERATING YOUR HEATER
FOR YOUR SAFETY READ BEFORE LIGHTING
WARNING: If you do not follow these instructions
exactly, a re or explosion may result causing
property damage, personal injury or loss of life.
A. This appliance has a pilot which must be lighted
by pushing the ignitor button. When lighting the
pilot, follow these instructions exactly.
B. BEFORE LIGHTING smell all around the
appliance area for gas. Be sure to smell next to
the oor because some gas is heavier than air
and will settle on the oor.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use
any phone in your building.
• Immediately call your gas supplier from a
neighbor’s phone. Follow the gas supplier’s
instructions.
• If you can not reach your gas supplier, call the
re department.
C. Use only your hand to push in or turn the gas
control knob. Never use tools. If knob will not
push in or turn by hand, don’t try to repair it call
a qualied service technician or gas supplier.
Force or attempted repair may result in a re or
explosion.
Pressure Testing Heater Gas Connections:
1. The appliance and its appliance main gas valve
must be disconnected from the gas supply
piping system during any pressure testing of
that system at test pressures in excess of ½
psi (3.5 kPa). The appliance must be isolated
from the gas supply piping system by closing
its equipment shuto󰀨 valve during any pressure
testing of the gas supply piping system at test
pressures equal to or less than ½ psi (3.5 kPa).
2. Make sure control knob of heater is in OFF
position.
3. Open equipment shuto󰀨 valve (see gure 13).
4. Open main gas valve on or near gas meter.
5. Check all joints from equipment shuto󰀨 valve
to control valve (see gure 14). Apply mixture
of liquid soap and water to gas joints. Bubbles
forming show a leak.
6. Correct all leaks at once.
7. Light heater (see Operating Your Heater, pages
10 and 11. Check the rest of the internal joints
for leaks.
8. Turn o󰀨 heater (see To Turn OFF Gas to
Appliance, page 11.
9. Replace lower front panel.
Figure 13
Figure 14
Control Valve
Equipment
Shuto󰀨 Valve
To regulated propane
source
Caution: Label all wires prior to
disconnection when
servicing controls.
Wiring errors can cause
improper and dangerous
operation. Verify proper
operation after servicing.
Figure 15
