MSI AE1920 User manual
Wind Top AE1920
All-in-One (AIO) PC
MS-A923 (V1.X) System
G52-A9231XA
ii
MS-A923
iii
iv
MS-A923
v
vi
廢電池請回收
MS-A923
vii
廢電池請回收
viii
MS-A923
ix
x
MS-A923
xi
xii
Chapter 1
Overview
Wind Top AE1920 is integrated in design, selecting a stylish ap-
pearance with a mirror screen, which displays the simplicity of
modern individualism and the comfort of home. Furthermore, it
is accompanied with the best computer features, such as instant
message, low acoustics, energy saving, and 802.11 b/g/n wire-
less internet capability so you may roam freely in the realm of
cyberspace.
1-2
Overview
▍
Packing contents
* Please contact us immediately if any of the items is
damaged or missing.
* The illustrations are for reference only and your
packing contents may slightly vary depending on
the model you purchased.
Wind Top Series
User Manual &
Quick Guide
Driver/Utility Disk
Stylus (Optional)
Mouse (Optional)
Keyboard (Optional)
LCD Display Wiper
AC/DC Adapter
AC Power Cord
system overview
Front View
2
4
1
3
4
5
1Microphone
- The built-in microphone can be used for video chatting online.
2Webcam
- The built-in webcam with the microphone can be used for picture tak-
ing, video recoding, online conferencing and any other interactive ap-
plications.
3LCD Display
- The 18.5-inch TFT LCD display is with an optimal resolution of 1366
X 768 and standard proportion of 16:9 widescreen.
4Stereo Speakers
- The built-in stereo speakers deliver high quality sound blaster with
stereo system and Hi-Fi function supported.
5Power Indicator
- The power indicator illuminates in green when the AIO PC is on, il-
luminates in orange when the AIO PC is in sleep mode and turns o
when the AIO PC is o.
1-3
MS-A923
Packing contents
* Please contact us immediately if any of the items is
damaged or missing.
* The illustrations are for reference only and your
packing contents may slightly vary depending on
the model you purchased.
Wind Top Series
User Manual &
Quick Guide
Driver/Utility Disk
Stylus (Optional)
Mouse (Optional)
Keyboard (Optional)
LCD Display Wiper
AC/DC Adapter
AC Power Cord
system overview
Front View
2
4
1
3
4
5
1Microphone
- The built-in microphone can be used for video chatting online.
2Webcam
- The built-in webcam with the microphone can be used for picture tak-
ing, video recoding, online conferencing and any other interactive ap-
plications.
3LCD Display
- The 18.5-inch TFT LCD display is with an optimal resolution of 1366
X 768 and standard proportion of 16:9 widescreen.
4Stereo Speakers
- The built-in stereo speakers deliver high quality sound blaster with
stereo system and Hi-Fi function supported.
5Power Indicator
- The power indicator illuminates in green when the AIO PC is on, il-
luminates in orange when the AIO PC is in sleep mode and turns o
when the AIO PC is o.
1-4
Overview
▍
Rear View
Important
We suggest that you connect the AC/DC adapter to your AIO PC rst and then con-
nect the AC power cord to the socket-outlet for safety concerns.
1
1
1
1
2
3
5
4
1Ventilator
- The ventilator on the enclosure is used for air convection and to pre-
vent the equipment from overheating. Do not cover the ventilator.
2Optical Disk Drive
- A DVD Super-Multi drive is integrated for your home entertainment.
(Blu-ray is optional.)
3Card Reader Drive
- The built-in card reader may support various types of memory card,
such as XD (eXtreme Digital), SD (Secure Digital), SDHC (SD High
Capacity), MS (Memory Stick), MS Pro (Memory Stick Pro) or MMC
(Multi-Media Card) cards that usually used in devices like digital cam-
eras, MP3 players, mobile phones and PDAs. Contact the local dealer
for further information and please be noted that the supported memory
cards may vary without notice.
4Stand
- Use this stand to position your system on a at and stable surface.
5Cable Routing Hole
- Route the cables through the cable routing hole to avoid cable spa-
ghetti when connecting devices.
6Power Jack
- The AC/DC adapter converts AC power to DC power for this jack.
Power supplied through this jack supplies power to the PC. To prevent
damage to the PC, always use the supplied AC/DC adapter.
7USB Port
- The USB (Universal Serial Bus) port is provided for attaching USB
devices such as mouse, keyboard, printer, scanner, camera, PDA or
other USB-compatible devices.
9876
10
1-5
MS-A923
Rear View
Important
We suggest that you connect the AC/DC adapter to your AIO PC rst and then con-
nect the AC power cord to the socket-outlet for safety concerns.
1
9876
1
1
1
2
3
5
4
10
1Ventilator
- The ventilator on the enclosure is used for air convection and to pre-
vent the equipment from overheating. Do not cover the ventilator.
2Optical Disk Drive
- A DVD Super-Multi drive is integrated for your home entertainment.
(Blu-ray is optional.)
3Card Reader Drive
- The built-in card reader may support various types of memory card,
such as XD (eXtreme Digital), SD (Secure Digital), SDHC (SD High
Capacity), MS (Memory Stick), MS Pro (Memory Stick Pro) or MMC
(Multi-Media Card) cards that usually used in devices like digital cam-
eras, MP3 players, mobile phones and PDAs. Contact the local dealer
for further information and please be noted that the supported memory
cards may vary without notice.
4Stand
- Use this stand to position your system on a at and stable surface.
5Cable Routing Hole
- Route the cables through the cable routing hole to avoid cable spa-
ghetti when connecting devices.
6Power Jack
- The AC/DC adapter converts AC power to DC power for this jack.
Power supplied through this jack supplies power to the PC. To prevent
damage to the PC, always use the supplied AC/DC adapter.
7USB Port
- The USB (Universal Serial Bus) port is provided for attaching USB
devices such as mouse, keyboard, printer, scanner, camera, PDA or
other USB-compatible devices.
1-6
Overview
▍
8RJ-45 LAN Jack
- The standard RJ-45 LAN jack is provided for connection to the Local
Area Network (LAN). You can connect a network cable to it.
Yellow Green/ Orange
LED Color LED State Condition
Left Yellow O LAN link is not established.
On (steady state) LAN link is established.
On (brighter & pulsing) The computer is communicating with
another computer on the LAN.
Right Green O 10 Mbit/sec data rate is selected.
On 100 Mbit/sec data rate is selected.
Orange On 1000 Mbit/sec data rate is selected.
9Microphone Jack (Pink)
- This connector is provided for microphones.
10 Headphone Jack (Green)
- This connector is provided for headphones or speakers.
Side View
1
2
3
4
5
6
1Optical Disk Drive
- A DVD Super-Multi drive is integrated for your home entertainment.
(Blu-ray is optional.)
2Eject Button
- Press the eject button to open the optical disk drive.
3Eject Hole
- Insert a thin, straight object (such as a paper clip) into the eject hole to
open the optical disk drive manually if the eject button does not work.
4Card Reader Drive
- The built-in card reader may support various types of memory card,
such as XD (eXtreme Digital), SD (Secure Digital), SDHC (SD High
Capacity), MS (Memory Stick), MS Pro (Memory Stick Pro) or MMC
(Multi-Media Card) cards that usually used in devices like digital cam-
eras, MP3 players, mobile phones and PDAs. Contact the local dealer
for further information and please be noted that the supported memory
cards may vary without notice.
7
8
9
10
1-7
MS-A923
8RJ-45 LAN Jack
- The standard RJ-45 LAN jack is provided for connection to the Local
Area Network (LAN). You can connect a network cable to it.
Yellow Green/ Orange
LED Color LED State Condition
Left Yellow O LAN link is not established.
On (steady state) LAN link is established.
On (brighter & pulsing) The computer is communicating with
another computer on the LAN.
Right Green O 10 Mbit/sec data rate is selected.
On 100 Mbit/sec data rate is selected.
Orange On 1000 Mbit/sec data rate is selected.
9Microphone Jack (Pink)
- This connector is provided for microphones.
10 Headphone Jack (Green)
- This connector is provided for headphones or speakers.
Side View
1Optical Disk Drive
- A DVD Super-Multi drive is integrated for your home entertainment.
(Blu-ray is optional.)
2Eject Button
- Press the eject button to open the optical disk drive.
3Eject Hole
- Insert a thin, straight object (such as a paper clip) into the eject hole to
open the optical disk drive manually if the eject button does not work.
4Card Reader Drive
- The built-in card reader may support various types of memory card,
such as XD (eXtreme Digital), SD (Secure Digital), SDHC (SD High
Capacity), MS (Memory Stick), MS Pro (Memory Stick Pro) or MMC
(Multi-Media Card) cards that usually used in devices like digital cam-
eras, MP3 players, mobile phones and PDAs. Contact the local dealer
for further information and please be noted that the supported memory
cards may vary without notice.
1
2
3
4
5
6
7
8
9
10
1-8
Overview
▍
mainboard sPecifications
Processor
Intel® Atom™ Dual-Core Processor D510 (Optional)
CPU Frequency 1.6 GHz
Chipset
Intel® NM10 Express Chipset
Memory
2 DDR2 667MHz SO-DIMM slots (Optional)
2 DDR3 1066MHz SO-DIMM slots (Optional)
Supports the maximum of 4GB
LAN
Gigabit Fast Ethernet by Realtek® RTL8111C GbE controller
Audio
Chip integrated by Realtek® ALC888
Compliant with Azalia 1.0 spec
Integrated Graphics
ATI® M92-XT, M2 package size, DDR3, 512GB VRAM (Optional)
ATI® Park-LP, M2 package size, DDR3, 512MB VRAM (Optional)
Realtek® RTD2482D-GR multi-function display controller
Form Factor
210 mm (W) X 197 mm (H)
■
■
■
■
■
■
■
■
■
■
■
■
■
5USB Ports
- The USB (Universal Serial Bus) port is provided for attaching USB
devices such as mouse, keyboard, printer, scanner, camera, PDA or
other USB-compatible devices.
6Ventilator
- The ventilator on the enclosure is used for air convection and to pre-
vent the equipment from overheating. Do not cover the ventilator.
7Power Button
- Press the power button to turn the system on and o.
8MENU Button
- Press this button to view the OSD menu or enter into the sub menu.
9Right Button
- This button indicates the cursor movement or OSD manual selection
in incremental values.
Left Button
- This button indicates the cursor movement or OSD manual selection
in decremental values.
10 AUTO Button
- Press this button to view the video mode menu or exit the submenu.
This manual suits for next models
3
Table of contents
Other MSI Desktop manuals
MSI
MSI AP1622E User manual
MSI
MSI Nightblade X2 User manual
MSI
MSI Infinite A 8RC-265EU User manual
MSI
MSI AP2021 Series User manual
MSI
MSI MAG Codex X5 User manual
MSI
MSI 10TD-889IT User manual
MSI
MSI HETISG41 - Hetis G41 - DTS User manual
MSI
MSI Adora24 Series User manual
MSI
MSI Claw User manual
MSI
MSI Pro 22XT AM 021EU User manual
MSI
MSI 11M-218EU User manual
MSI
MSI Crystal 945 User manual
MSI
MSI Aegis 3 User manual
MSI
MSI Midas 915GM User manual
MSI
MSI Cubi N 8 GL 001BEU User manual
MSI
MSI Nightblade Series User manual
MSI
MSI AE2040 User manual
MSI
MSI CRYSTAL A410 - Crystal - A410 User manual
MSI
MSI Cubi 5 10M 419EU User manual
MSI
MSI MS-B096 User manual
