MSI WIND TOP AC1900 User manual
Wind Top AC1900
All-in-One (AIO) PC
MS-A934 (V1.X) System
ii
iii
MS-A934
iv
v
MS-A934
Preface
▍
vi
Safety Instructions
Read the safety instructions carefully and thoroughly.
All cautions and warnings on the equipment or user’s manual should be
noted.
Keep the User’s Guide that comes with the package for future reference.
Keep this equipment away from humidity and high temperature.
Lay this equipment on a reliable at surface before setting it up.
Make sure that the power voltage is within its safety range and has
been adjusted properly to the value of 100~240V before connecting the
equipment to the power outlet. Do not disable the protective earth pin
from the plug. The equipment must be connected to an earthed mains
socket-outlet.
Always unplug the AC power cord before installing any add-on card or
module to the equipment.
Always disconnect the AC power cord or switch the wall socket o if
the equipment would be left unused for a certain time to achieve zero
energy consumption.
◙
◙
◙
The ventilator on the enclosure is used for air convection and to prevent the
equipment from overheating. Do not cover the ventilator.
Do not leave the equipment in an unconditioned environment with a storage
temperature above 60OC (140OF) or below 0OC (32OF), which may damage
the equipment.
NOTE: The maximum operating temperature is around 40OC. CAUTION:
Danger of explosion if battery is incorrectly replaced. Replace only with the
same or equivalent type recommended by the manufacturer.
The optical storage devices are classied as CLASS 1 LASER PRODUCT. Use of
controls or adjustments or performance of procedures other than those specied
is prohibited.
Do not touch the lens inside the drive.
1.
2.
Never pour any liquid into the opening that could damage or cause electri-
cal shock.
Place the power cord in a way that people are unlikely to step on it. Do not
place anything on the power cord.
When installing the coaxial cable to the TV Tuner, it is necessary to ensure
that the metal shield is reliably connected to protective earthing system of
the building.
Cable distribution system should be grounded (earthed) in accordance with
ANSI/NFPA 70, the National Electrical Code (NEC), in particular Section
820.93, Grounding of Outer Conductive Shield of a Coaxial Cable.
Always keep the strong magnetic or electrical objects away from the equip-
ment.
If any of the following situations arises, get the equipment checked by ser-
vice personnel:
The power cord or plug is damaged.
Liquid has penetrated into the equipment.
The equipment has been exposed to moisture.
The equipment does not work well or you can not get it work according
to user’s manual.
The equipment has dropped and damaged.
The equipment has obvious sign of breakage.
◙
◙
◙
◙
◙
◙
廢電池請回收
For better environmental protection, waste batteries should be collected
separately for recycling or special disposal.
vii
MS-A934
廢電池請回收
viii
ix
MS-A934
x
xi
MS-A934
xii
Chapter 1
Overview
This system is integrated in design, selecting a stylish appear-
ance with a mirror screen, which displays the simplicity of mod-
ern individualism and the comfort of home. With a touchscreen
display, awless audio/video capabilities, and intuitive user inter-
face, it blends technology with life, making computers easier and
more fun to use — suitable for the whole family.
1-2
Overview
▍
Packing contents
* Please contact us immediately if any of the items is damaged or missing.
* The picture is for your reference only and your packing contents may slightly vary
depending on the model you purchased.
Wind Top Series AC/DC Adapter AC Power Cord
User Manual &
Quick Guide
Driver/Utility Disk
Mouse (Optional)
Keyboard (Optional)
system overview
Front View
4
3
1
2
1Microphone
The built-in microphone can be used for video chatting online.
2Webcam
The built-in webcam with the microphone can be used for picture
taking, video recoding, online conferencing and any other interactive
applications.
3LCD Display
The 18.5-inch TFT LCD display is with an optimal resolution of 1366
X 768 and standard proportion of 16:9 widescreen.
4Stereo Speakers
The built-in stereo speakers deliver high quality sound blaster with
stereo system.
1-3
MS-A934
Packing contents
* Please contact us immediately if any of the items is damaged or missing.
* The picture is for your reference only and your packing contents may slightly vary
depending on the model you purchased.
Wind Top Series AC/DC Adapter AC Power Cord
User Manual &
Quick Guide
Driver/Utility Disk
LCD Display Wiper
Mouse (Optional)
Keyboard (Optional) Stylus (Optional)
system overview
Front View
4
3
1
2
1Microphone
The built-in microphone can be used for video chatting online.
2Webcam
The built-in webcam with the microphone can be used for picture
taking, video recoding, online conferencing and any other interactive
applications.
3LCD Display
The 18.5-inch TFT LCD display is with an optimal resolution of 1366
X 768 and standard proportion of 16:9 widescreen.
4Stereo Speakers
The built-in stereo speakers deliver high quality sound blaster with
stereo system.
1-4
Overview
▍
Rear View
Important
We suggest that you connect the AC/DC adapter to your AIO PC rst and then con-
nect the AC power cord to the socket-outlet for safety concerns.
1Ventilator
The ventilator on the enclosure is used for air convection and to pre-
vent the equipment from overheating. Do not cover the ventilator.
2Optical Disk Drive
A DVD Super-Multi drive is integrated for your home entertainment.
2
4
5
1
3
3Card Reader Drive
The built-in card reader may support various types of memory card,
such as SD (Secure Digital), MS (Memory Stick), MS Pro (Memory
Stick Pro) or MMC (Multi-Media Card) cards that usually used in de-
vices like digital cameras, MP3 players, mobile phones and PDAs.
Contact the local dealer for further information and please be noted
that the supported memory cards may vary without notice.
USB Port
The USB (Universal Serial Bus) port is provided for attaching USB
devices such as mouse, keyboard, printer, scanner, camera, PDA or
other USB-compatible devices.
Headphone Jack
This connector is provided for headphones or speakers.
Microphone Jack
This connector is provided for microphones.
4Stand
Use this stand to position your system on a at and stable surface.
5Cable Routing Hole
Route the cables through the cable routing hole to avoid cable spa-
ghetti when connecting devices.
1-5
MS-A934
Rear View
Important
We suggest that you connect the AC/DC adapter to your AIO PC rst and then con-
nect the AC power cord to the socket-outlet for safety concerns.
1Ventilator
The ventilator on the enclosure is used for air convection and to pre-
vent the equipment from overheating. Do not cover the ventilator.
2Optical Disk Drive
A DVD Super-Multi drive is integrated for your home entertainment.
(Blu-ray is optional.)
2
4
5
1
3
3Card Reader Drive
The built-in card reader may support various types of memory card,
such as SD (Secure Digital), MS (Memory Stick), MS Pro (Memory
Stick Pro) or MMC (Multi-Media Card) cards that usually used in de-
vices like digital cameras, MP3 players, mobile phones and PDAs.
Contact the local dealer for further information and please be noted
that the supported memory cards may vary without notice.
USB Port
The USB (Universal Serial Bus) port is provided for attaching USB
devices such as mouse, keyboard, printer, scanner, camera, PDA or
other USB-compatible devices.
Headphone Jack
This connector is provided for headphones or speakers.
Microphone Jack
This connector is provided for microphones.
4Stand
Use this stand to position your system on a at and stable surface.
5Cable Routing Hole
Route the cables through the cable routing hole to avoid cable spa-
ghetti when connecting devices.
1-6
Overview
▍
Left and Right View
1Optical Disk Drive
A DVD Super-Multi drive is integrated for your home entertainment.
2Eject Button
Press the eject button to open the optical disk drive.
3Eject Hole
Insert a thin, straight object (such as a paper clip) into the eject hole
to open the optical disk drive manually if the eject button does not
work.
4Card Reader Drive
The built-in card reader may support various types of memory card,
such as SD (Secure Digital), MS (Memory Stick), MS Pro (Memory
Stick Pro) or MMC (Multi-Media Card) cards that usually used in de-
vices like digital cameras, MP3 players, mobile phones and PDAs.
Contact the local dealer for further information and please be noted
that the supported memory cards may vary without notice.
5USB Port
The USB (Universal Serial Bus) port is provided for attaching USB
devices such as mouse, keyboard, printer, scanner, camera, PDA or
other USB-compatible devices.
6Headphone Jack
This connector is provided for headphones or speakers.
Microphone Jack
This connector is provided for microphones.
7Stand
Use this stand to position your system on a at and stable surface.
8Ventilator
The ventilator on the enclosure is used for air convection and to pre-
vent the equipment from overheating. Do not cover the ventilator.
5
4
1
3
2
7
68
8
1-7
MS-A934
Left and Right View
1Optical Disk Drive
A DVD Super-Multi drive is integrated for your home entertainment.
(Blu-ray is optional.)
2Eject Button
Press the eject button to open the optical disk drive.
3Eject Hole
Insert a thin, straight object (such as a paper clip) into the eject hole
to open the optical disk drive manually if the eject button does not
work.
4Card Reader Drive
The built-in card reader may support various types of memory card,
such as SD (Secure Digital), MS (Memory Stick), MS Pro (Memory
Stick Pro) or MMC (Multi-Media Card) cards that usually used in de-
vices like digital cameras, MP3 players, mobile phones and PDAs.
Contact the local dealer for further information and please be noted
that the supported memory cards may vary without notice.
5USB Port
The USB (Universal Serial Bus) port is provided for attaching USB
devices such as mouse, keyboard, printer, scanner, camera, PDA or
other USB-compatible devices.
6Headphone Jack
This connector is provided for headphones or speakers.
Microphone Jack
This connector is provided for microphones.
7Stand
Use this stand to position your system on a at and stable surface.
8Ventilator
The ventilator on the enclosure is used for air convection and to pre-
vent the equipment from overheating. Do not cover the ventilator.
5
4
1
3
2
7
68
8
1-8
Overview
▍
Top and Bottom View
1Ventilator
The ventilator on the enclosure is used for air convection and to pre-
vent the equipment from overheating. Do not cover the ventilator.
2Drive Activity LED
The drive activity LED is on when data is read from or written to the
hard disk drive (HDD) or optical disk drive (ODD).
3Power LED
The power LED glows when the system is turned on and goes o
when the system is shut down. In terms of power saving, the LED
blinks in S3 (Suspend to RAM) mode and goes o in S4 (Suspend
to Disk) mode.
1 4
97
5
8 110
2 3 6
This manual suits for next models
1
Table of contents
Other MSI Desktop manuals
MSI
MSI MEGA 180 MS-6265 User manual
MSI
MSI Codex B913 User manual
MSI
MSI MPC 400 User manual
MSI
MSI Cubi 5 10M 008BEU User manual
MSI
MSI Creator B929 User manual
MSI
MSI Trident B924 User manual
MSI
MSI PRO DP130 User manual
MSI
MSI Hetis H61 Ultra User manual
MSI
MSI Cubi N 021BEU User manual
MSI
MSI Trident B936 User manual
MSI
MSI AE270 Series User manual
MSI
MSI MS-A622 User manual
MSI
MSI Pro24 2M User manual
MSI
MSI Wind Box DE500 User manual
MSI
MSI 005EU User manual
MSI
MSI MEGA 180 User manual
MSI
MSI Wind Top AP2021 Series User manual
MSI
MSI Hetis 945 User manual
MSI
MSI Trident B922 User manual
MSI
MSI AXIS 945GM - Axis - 945GM User manual
