Introduction
Thank you for choosing 848P Neo2-V Series (MS-7108 v1.x) ATX mainboard. The 848P Neo2-V
Series is based on Intel®848P & Intel®ICH5 chipsets for optimal system efficiency. Designed to
fit the advanced Intel®P4 Prescott 533MHz/800MHz processors in LGA775 package, the 848P
Neo2-V Series delivers a high performance and professional desktop platform solution.
Layout
848P

2
Specifications
CPU
zSupports Intel® Pentium 4 Prescott processors in LGA775 package.
zSupports up to Intel® Pentium 4 3XX, 5XX and 6XX Processor.
zSupports Intel®Hyper-Threading Technology.
(For the latest information about CPU, please visit
http://www.msi.com.tw/program/products/mainboard/mbd/pro_mbd_cpu_support.php)
Chipset
zIntel®848P chipset
- Supports FSB 800/533MHz.
- Supports AGP 8X interface.
- Supports DDR 400/333/266 memory interface.
zIntel®ICH5 chipset
- Hi-Speed USB (USB2.0) controller, 480Mb/sec, 8 ports.
- 2 Serial ATA/150 ports.
- 2 channel Ultra ATA 100 bus Master IDE controller.
- PCI Master V2.3, I/O APIC.
- Supports both ACPI and legacy APM power management.
Main Memory
zSupports two unbuffered DIMM of 2.5 Volt DDR SDRAM.
zSupports up to 2GB memory size without ECC.
zSupports Single channel DDR266/333/400 MHz.
Slots
zOne AGP slot supports 8x/4x at 1.5V (3.3V is not supported).
zFour 32-bit v2.3 Master PCI bus slots (support 3.3v/5v PCI bus interface).
On-Board IDE
zDual Ultra DMA 66/100 IDE controllers integrated in ICH5.
- Supports PIO, Bus Master operation modes.
- Can connect up to four Ultra ATA drives.
zSerial ATA/150 controller integrated in ICH5.
- Up to 150MB/sec transfer speeds.
- Can connect up to two Serial ATA drives.
On-Board Peripherals
zOn-Board Peripherals include:
- 1 floppy port supports 1 FDD with 360K, 720K, 1.2M, 1.44M and 2.88Mbytes
- 1 serial port on the rear panel
- 1 serial port with pinheader (through external cable)
- 1 parallel port supports SPP/EPP/ECP mode
- 8 USB 2.0 ports (Rear * 4/ Front * 4)
- 1 Line-In / Line-Out / Mic-In
- 1 RJ45 LAN jack (Optional)
Audio
zAC97 link controller integrated in Intel®848P chipset.
z5.1-channel audio codec Realtek ALC655.
- Compliance with AC97 v2.3 Spec.
- Meet PC2001 audio performance requirement.

3
LAN (Optional)
zRealtek®8100C
- Integrated Fast Ethernet MAC and PHY in one chip.
- Supports 10Mb/s, 100Mb/s.
- Compliance with PCI 2.2.
- Supports ACPI Power Management.
BIOS
zThe mainboard BIOS provides “Plug & Play” BIOS which detects the peripheral devices
and expansion cards of the board automatically.
zThe mainboard provides a Desktop Management Interface (DMI) function which records
your mainboard specifications.
Dimension
zATX Form Factor: 30.5 cm (L) x 17.5 cm (W).
Mounting
z6 mounting holes.

4
Rear Panel
The rear panel provides the following connectors:
Hardware Setup
This chapter tells you how to install the CPU, memory modules, and expansion cards, as well as
how to setup the jumpers on the mainboard. It also provides the instructions on connecting the
peripheral devices, such as the mouse, keyboard, etc. While doing the installation, be careful in
holding the components and follow the installation procedures.
Central Processing Unit: CPU Prescott processor. The mainboard uses a CPU socket
hem
PU, please visit board/mbd/pro_mbd_cpu_support.php
The mainboard supports Intel®Pentium 4
called LGA775. When you are installing the CPU, make sure to install the cooler to prevent
overheating. If you do not have the CPU cooler, contact your dealer to purchase and install t
before turning on the computer.
For the latest information about C
http://www.msi.com.tw/program/products/main
MSI Reminds You...
Overheating
Overheating will seriously damage the CPU and the system, always make sure the cooling fan
can work properly to protect the CPU from overheating.
Overclocking
This mainboard is designed to support overclocking. However, please make sure your
components are able to tolerate such abnormal setting, while doing overclocking. Any attempt to
operate beyond product specifications is not recommended. We do not guarantee the damages
or risks caused by inadequate operation or beyond product specifications.
Memory Speed/CPU FSB Support Matrix
Memory
FSB DDR 266 DDR 333 DDR 400
533 MHz OK OK N/A
800 MHz OK OK OK

5
LGA775 CPU and Cooler Installation（CPU Clip is optional）
When you are installing the CPU, make sure the CPU has a cooler attached on the top to prevent
overheating. If you do not have the cooler, contact your dealer to purchase and install them
before turning on the computer. Meanwhile, do not forget to apply some silicon heat transfer
compound on CPU before installing the cooler for better heat dispersion.
Follow the steps below to install the CPU & cooler correctly. Wrong installation will cause the
damage to your CPU & mainboard.
1. The CPU has a land side cover on the bottom to protect the CPU contact from damage.
Rotate it to make the pin 1 indicator (yellow triangle) in the left-bottom
corner. The availability of it depends on the CPU packing.
2. Take out the accompanying CPU Clip (shown in the right) and rotate it
for the same direction as the CPU (Pin 1 indicator is in the left-bottom
corner).
3. Use 2 hands to remove the land side cover (if any). Please note not to touch the pins.
4. Align the two pin 1 indicators (the triangles on the CPU & the CPU Clip), and use the CPU
Clip to clip the CPU up, pressing the clips on both sides to the center, as the arrows
shown.
5. The CPU has a plastic cap on it to protect the contact from damage. Before you have
installed the CPU, always cover it to protect the socket pin.
6. Remove the cap from lever hinge side. The pins of socket reveal.
7. Lift the load lever up and open the load plate.
8. Correctly align the triangle of CPU Clip with the CPU chamfer, and
the square on the CPU Clip to the hook of the socket.
9. Use your thumb and the middle fingers to push the clips to release
the CPU, then press down the CPU with your index finger to allow
the whole module to be installed onto the CPU socket.
10. The CPU is installed well on the CPU socket.
11. Visually inspect if the CPU is seated well into the socket, then
remove the CPU Clip with 2 fingers. Then cover the load plate onto
the package.
12. Press down the load lever lightly onto the load plate, and then secure the lever with the
hook under retention tab.
13. Align the holes on the mainboard with the cooler. Push down the cooler until its four clips
get wedged into the holes of the mainboard.
14. Press the four hooks down to fasten the cooler. Then rotate the locking switch (refer to the
correct direction marked on it) to lock the hooks.
15. Turn over the mainboard to confirm that the clip-ends are correctly
inserted.
Note: If you want to uninstall the CPU, align the 4 points (see Point 8 for
details) again and push the clip to lift up the CPU.

MSI Reminds You...
1. Make sure your CPU cooler is firmly installed before turning on your system.
2. Check the information in PC Health Status of H/W Monitor in BIOS for the CPU
temperature.
3. Do not touch the CPU socket pins to avoid damage.
4. Whenever CPU is not installed, always protect your CPU socket pins with the plastic cap
covered to avoid damage.
5. Please note that the mating/unmating durability of the CPU is 20 cycles. Therefore, we
suggest you do not plug/unplug the CPU too often.
Memory
The mainboard provides two 184-pin unbuffered DDR 266 / DDR333 / DDR400 DDR SDRAM,
and supports the memory size up to 2GB. To operate properly, at least one DIMM module must
be installed. (For the updated supporting memory modules, please visit
http://www.msi.com.tw/program/products/mainboard/mbd/pro_mbd_trp_list.php )
Install at least one DIMM module on the slots. Memory modules can be installed on the slots in
any order. You can install either single- or double-sided modules to meet your own needs.
Installing DDR Modules
NotchVolt
1. The DDR DIMM has only one notch on the center of module. The module will only fit in the
right orientation.
2. Insert the DIMM memory module vertically into the DIMM slot. Then push it in until the
golden finger on the memory module is deeply inserted in the socket.
3. The plastic clip at each side of the DIMM slot will automatically close.
Power Supply
The mainboard supports ATX power supply for the power system. Before inserting the power
supply connector, always make sure that all components
are installed properly to ensure that no damage will be
caused. A 300W or above power supply is suggested.
ATX 24-Pin Power Connector: ATX1
This connector allows you to connect an ATX 24-pin
power supply. To connect the ATX 24-pin power supply,
make sure the plug of the power supply is inserted in the
proper orientation and the pins are aligned. Then push
down the power supply firmly into the connector.
6

You may use the 20-pin ATX power supply as you like. If you’d like to use the 20-pin ATX power
supply, please plug your power supply along with pin 1 & pin 13. There is also a foolproof design
on pin 11, 12, 23 & 24 to avoid wrong installation.
ATX 12V Power Connector: JPW1
This 12V power connector is used to provide power to the CPU.
Floppy Disk Drive Connector: FDD1
The mainboard provides a standard floppy disk drive connector that
supports 360K, 720K, 1.2M, 1.44M and 2.88M floppy disk types.
IDE Connector: IDE1/IDE2
The mainboard has dual Ultra DMA 66/100 controller that provides PIO mode 0~4, Bus
Master, and Ultra DMA 66/100 function. You can connect up to four hard disk drives,
CD-ROM, 120MB Floppy and other devices.
The first hard drive should always be connected to IDE1. IDE1 can connect a Master
and a Slave drive. You must configure second hard drive to Slave mode by setting the
jumper accordingly.
MSI Reminds You...
If you install two hard disks on one cable, you must configure the second drive to Slave mode by
setting its jumper. Refer to the hard disk documentation supplied by hard disk vendors for jumper
setting instructions.
Serial ATA Connectors controlled by Intel®ICH5: SATA1/SATA2
The mainboard provides dual high-speed Serial ATA interface ports. The ports
supper 1st generation Serial ATA data rates of 150MB/s and are fully compliant
with Serial ATA 1.0 specifications. Each Serial ATA connector can connect to 1 hard disk device.
MSI Reminds You...
Please do not fold the serial ATA cable in a 90-degree angle, which will cause the loss of data
during transmission.
CD-In Connector: JCD1
The connector is for CD-ROM audio connector.
Chassis Intrusion Switch Connector: JCI1
This connector is connected to a 2-pin chassis switch. JCI1 is
compliant with Intel®Front Panel I/O Connectivity Design Guide.
7

8
Fan Power Connectors: CPUFAN1/PWRFAN1/SYSFAN1
The 4-pin CPUFAN1 (processor fan) and 3-pin PWRFAN1
(power supply fan) / SYSFAN1 (system fan) support
system cooling fan with +12V. CPUFAN1 can support
three or four pin head connector.
When connecting the wire to the connectors, always take note that the red wire is the positive
and should be connected to the +12V, the black wire is Ground and should be connected to GND.
If the mainboard has a System Hardware Monitor chipset on-board, you must use a specially
designed fan with speed sensor to take advantage of the CPU fan control.
MSI Reminds You...
Always consult the vendors for the proper CPU cooling fan.
Front Panel Connectors: JFP1/JFP2
HDD
LED
Power
LED
Power
LED
Speaker
Reset
Switch
P
ower
Switch
11
7
9
22
8
10
JFP1 JFP2
The mainboard provides two front panel connectors for
electrical connection to the front panel switches and
LEDs. JFP1 is compliant with Intel®Front Panel I/O
Connectivity Design Guide.
Front Panel Audio Connector: JAUD1
The front panel audio connector allows you to connect to
the front panel audio and is compliant with Intel®Front
Panel I/O Connectivity Design Guide.
MSI Reminds You...
If you do not want to connect to the front audio header, pins 5 & 6, 9 & 10 have
to be jumpered in order to have signal output directed to the rear audio ports.
Otherwise, the Line-Out connector on the back panel will not function.
Front USB Connector: JUSB1/JUSB2
The mainboard provides two standard USB 2.0 pin headers
JUSB1&JUSB2. USB2.0 technology increases data transfer rate
up to a maximum throughput of 480Mbps, which is 40 times fa
than USB 1.1, and is ideal for connecting high-speed USB
interface peripherals such as USB HDD, digital cameras, MP3
players, printers, modems and the like.
ster
MSI Reminds You...
Please note that the pins of VCC & GND must be connected correctly or it may cause some
damage

9
Serial Port Connector: JCOM1 (Optional)
The mainboard offers one 9-pin male DIN connector COM 1 (on the rear
panel), and one optional serial port JCOM1. Both are 16550A high speed
communication ports that send/receive 16 bytes FIFOs. You can attach a
serial mouse or other serial device directly to them.
PIN SIGNAL DESCRIPTION PIN SIGNAL DESCRIPTION
1
3
5
7
9
DCD
SOUT
GND
RTS
RI
Data Carry Detect
Receive Data Transmit
Data
Request To Send Ring
Indicate
2
4
6
8
10
SIN
DTR
DSR
CTS
X
Serial in or receive data
Serial out or transmit data
Data Set Ready
Clear To Send
X
Clear CMOS Jumper: JBAT1
There is a CMOS RAM on board that has a power supply from
external battery to keep the data of system configuration. With the
CMOS RAM, the system can automatically boot OS every time it is
turned on. If you want to clear the system configuration, use the
JBAT1 (Clear CMOS Jumper) to clear data. Follow the instructions
in the image to clear the data.
MSI Reminds You...
You can clear CMOS by shorting 2-3 pin while the system is off. Then return to 1-2 pin position.
Avoid clearing the CMOS while the system is on, which will damage the mainboard.
AGP (Accelerated Graphics Port) Slot
The AGP slot allows you to insert the AGP graphics
card. AGP is an interface specification designed for
the throughput demands of 3D graphics. It introduces a
66MHz, 32-bit channel for the graphics controller to directly access main memory. The slot
supports AGP card for 8x/4x at 1.5v (3.3v is not supported).
PCI (Peripheral Component Interconnect) Slots
The PCI slots allow you to insert the expansion cards
to meet your needs. When adding or removing
expansion cards, make sure that you unplug the
power supply first. Meanwhile, read the documentation for the expansion card to make any
necessary hardware or software settings for the expansion card, such as jumpers, switches or
BIOS configuration.
PCI Interrupt Request Routing
The IRQ, abbreviation of interrupt request line and pronounced I-R-Q, are hardware lines over
which devices can send interrupt signals to the microprocessor. The PCI IRQ pins are typically
connected to the PCI bus INT A# ~ INT D# pins as follows:
Order1 Order2 Order3 Order4
PCI Slot 1 INT B# INT C# INT D# INT A#
PCI Slot 2 INT C# INT D# INTA# INT B#
PCI Slot 3 INT D# INT A# INT B# INT C#
PCI Slot 4 INT B# INT C# INT D# INT A#

BIOS Setup
Power on the computer and the system will start POST (Power On Self Test) process. When the
message below appears on the screen, press <DEL> key to enter Setup.
DEL: Setup
If the message disappears before you respond and you still wish to enter Setup, restart the
system by turning it OFF and On or pressing the RESET button. You may also restart the system
by simultaneously pressing <Ctrl>, <Alt>, and <Delete> keys.
Main Page
Standard CMOS Features
Use this menu for basic system configurations, such as time, date etc.
Advanced BIOS Features
Use this menu to setup the items of Award special enhanced features.
Advanced Chipset Features
Use this menu to change the values in the chipset registers and optimize your system
performance.
Integrated Peripherals
Use this menu to specify your settings for integrated peripherals.
Power Management Setup
Use this menu to specify your settings for power management.
PnP/PCI Configurations
This entry appears if your system supports PnP/PCI.
H/W Monitor
This entry shows your PC health status.
Frequency/Voltage Control
Use this menu to specify your settings for frequency/voltage control.
Load BIOS Defaults
Use this menu to load the BIOS default values that are factory settings for system operations.
BIOS Setting Password
Use this menu to set password.
Save & Exit Setup
Save changes to CMOS and exit setup.
Exit Without Saving
Abandon all changes and exit setup.
10

11
Frequency/Voltage Control
CPU Clock Ratio
This item allows you to adjust the CPU ratio. It might be locked by CPU hardware and this item
will be hided.
Auto Detect PCI Clk
This item is used to auto detect the PCI slots. When set to [Enabled], the system will remove
(turn off) clocks from empty PCI slots to minimize the electromagnetic interference (EMI).
Settings: [Enabled], [Disabled].
Spread Spectrum
When the motherboard’s clock generator pulses, the extreme values (spikes) of the pulses
creates EMI (Electromagnetic Interference). The Spread Spectrum function reduces the EMI
generated by modulating the pulses so that the spikes of the pulses are reduced to flatter curves.
If you do not have any EMI problem, leave the setting at [Disabled] for optimal system stability
and performance. But if you are plagued by EMI, select the desired range for EMI reduction.
Remember to disable Spread Spectrum function if you are overclocking, because even a slight
jitter can introduce a temporary boost in clock speed which may just cause your overclocked
processor to lock up.
CPU Clock
This item allows you to select the CPU Front Side Bus clock frequency (in MHz) and overclock
the processor by adjusting the FSB clock to a higher frequency.

12
Load BIOS Defaults
You can load the default values provided by the mainboard manufacturer for the stable
performance.
For the complete BIOS introduction and setup, please visit MSI website at http://www.msi.com.tw

13
Introduction
Félicitations, vous venez d’acquérir une carte mère ATX 848P Neo2-V Series (MS-7108 v1.x) La
848P Neo2-V Series est basée sur les Chipsets Intel®848P & Intel®ICH5 offrant un système très
performant. La carte fonctionne avec les processeurs Intel®P4 Prescott 533MHz/800MHz
(LGA775), est très performante et offre une solution adaptée tant aux professionnels qu’aux
particuliers.
Schéma
848P

14
Spécificités
CPU
zSupporte les processeurs Intel® Pentium 4 Prescott (LGA775).
zSupportes les processeurs Intel® Pentium 4 3XX, 5XX et 6XX.
zSupporte la technologie.Intel®Hyper-Threading
(Pour les dernières mises à jours concernant les CPU, vous pouvez visiter :
http://www.msi.com.tw/program/products/mainboard/mbd/pro_mbd_cpu_support.php.)
Chipset
zChipset Intel®848P
- Supporte FSB 800/533MHz.
- Supporte l’interface AGP 8X.
- Supporte l’interface de mémoire DDR 400/333/266.
zChipset Intel®ICH5
- contrôleur Hi-Speed USB (USB2.0), 480Mb/sec, 8 ports.
- 2 ports Serial ATA/150.
- 2 contrôleurs IDE bus Master channel Ultra ATA 100.
- PCI Master V2.3, I/O APIC.
- Supporte à la fois l’ACPI et la gestion de l’alimentation (APM).
Mémoire Principale
zSupporte deux DIMM unbuffered de2.5 Volt DDR SDRAM.
zSupporte jusqu’à 2GB de mémoire non ECC.
zSupporte le seul canal DDR266/333/400 MHz.
Slots
zUn slot AGP supportant 8x/4x à 1.5V (le 3.3V n’est pas supporté).
zQuatre slots PCI bus Master 32-bit v2.3 (supporte l’ interface bus PCI 3.3v/5v).
IDE Intégré
zDeux contrôleurs IDE Ultra DMA 66/100 intégrés dans ICH5.
- Supporte les modes opératoires PIO, Bus Master.
- Possibilité de connecter jusqu’à quatre disques Ultra ATA.
zContrôleur Serial ATA/150 intégré dans ICH5.
- Vitesse de transfert jusqu’à 150MB/sec.
- Peut connecter jusqu’à deux disques Serial ATA.
Périphériques Intégrés
zPériphériques Intégrés Inclus:
- 1 port floppy supportant 1 FDD avec 360K, 720K, 1.2M, 1.44M et 2.88Mbytes
- 1 port série sur le panneau arrière
- 1 port série sur broches à travers un câble externe
- 1 port parallèle supportant les modes SPP/EPP/ECP
- 8 ports USB 2.0 (Arrière * 4/ Avant * 4)
- 1 Line-In / Line-Out / Mic-In
- 1 RJ45 LAN jack (Optionnel)
Audio
zContrôleur AC97 link integré dans le chipset Intel®848P.
z5.1 canaux audio codec Realtek ALC655.
- Compatible avec les Spec AC97 v2.3.
- Répond aux exigences audio PC2001.

15
LAN (Optionnel)
zRealtek®8100C
- Fast Ethernet MAC et PHY Integré dans une puce.
- Supporte 10Mb/s, 100Mb/s.
- Compatible avec PCI 2.2.
- Supporte l’ACPI Power Management.
BIOS
zLa carte procure un BIOS “Plug & Play” qui détecte automatiquement les cartes
d’extension ou les périphériques.
zLa carte offre une interface DMI (Desktop Management Interface) qui enregistre les
spécificités de la carte mère.
Dimension
zFormat ATX : 30.5 cm (L) x 17.5 cm (W).
Montage
z6 trous de montage.

16
Panneau Arrière
Le panneau arrière procure les connecteurs suivants:
Installation Matériel
Ce chapitre vous indique comment installer le processeur, barrettes de mémoire et cartes pourd’extension. Lors de l’installation des matériels, veuillez suivre les instructions de montage
éviter d’endommager quoi que ce soit.
Central Processing Unit: CPU entium 4 Prescott. Elle utilise le socket CPU LGA775. ,
pu_support.php)
La carte supporte les processeurs Intel P
Assurez-vous que vous possédez bien un ventilateur + dissipateur pour éviter la surchauffe. Si
vous ne savez pas quel ventilateur utiliser, veuillez contacter votre revendeur avant de mettre en
marche votre PC. (Pour une mise à jour sur les CPU, veuillez visiter
http://www.msi.com.tw/program/products/mainboard/mbd/pro_mbd_c
MSI Vous rappelle...
Surchauffe
Une surchauffe endommagera sérieusement le CPU et le système. Soyez toujours sur du bon
fonctionnement des ventilateurs et radiateurs pour protéger le CPU d’une surchauffe.
Overclocking
Cette carte mère a été créée pour supporter l’overclocking. Assurez vous que vos composants
sont capables de tolérer de tels réglages, avant d’overclocker le système. Tout essais au delà
des spécifications des produits n’est pas recommandé. Nous ne garantissons pas les
dommages causés par une mauvaise opération ou au delà des spécifications du produit.
Tableau de Support Vitesse Mémoire/CPU FSB
Mémoire
FSB DDR 266 DDR 333 DDR 400
533 MHz OK OK N/A
800 MHz OK OK OK
