MSI MPG B760M EDGE TI WIFI User manual

MPG Series
Motherboard
MPG B760M EDGE TI WIFI
User Guide

2
Contents
Quick Start..................................................................................................................... 4
Specifications.............................................................................................................. 16
Special Features......................................................................................................... 20
Package Contents ...................................................................................................... 21
Back Panel Connectors ............................................................................................. 22
LAN Port LED Status Table .................................................................................. 23
Audio Jacks Connection ....................................................................................... 23
Installing Antennas............................................................................................... 25
Overview of Components........................................................................................... 26
CPU Socket ........................................................................................................... 27
DIMM Slots............................................................................................................ 28
PCI_E1~2: PCIe Expansion Slots.......................................................................... 29
SATA_A1~A2 & SATA_5~8: SATA 6Gb/s Connectors ........................................... 29
M2_1~3: M.2 Slots (Key M) ................................................................................... 30
JAUD1: Front Audio Connector ............................................................................ 36
JFP1, JFP2: Front Panel Connectors................................................................... 36
JCI1: Chassis Intrusion Connector....................................................................... 37
CPU_PWR1~2, ATX_PWR1: Power Connectors................................................... 38
JTBT_U4_1: USB4 Expansion Card Connector.................................................... 39
JTPM1: TPM Module Connector........................................................................... 39
JUSB4: USB 3.2 Gen 2 Type-C Front Panel Connector ....................................... 40
JUSB3: USB 3.2 Gen 1 Connector ........................................................................ 40
JUSB1~2: USB 2.0 Connectors............................................................................. 41
JDASH1 : Tuning Controller Connector ............................................................... 41
CPU_FAN1, PUMP_FAN1, SYS_FAN1~4: Fan Connectors.................................. 42
JBAT1: Clear CMOS (Reset BIOS) Jumper........................................................... 43
BAT1: CMOS Battery............................................................................................. 44
JRGB1: RGB LED Connector ................................................................................ 45
JARGB_V2_1~2: A-RAINBOW V2 (ARGB Gen2) LED Connectors ........................ 46
English

3
Onboard LEDs............................................................................................................. 48
EZ Debug LED....................................................................................................... 48
Installing OS, Drivers & MSI Center.......................................................................... 49
MSI Center............................................................................................................ 52
UEFI BIOS.................................................................................................................... 53
BIOS Setup............................................................................................................ 54
Resetting BIOS...................................................................................................... 55
Updating BIOS....................................................................................................... 55

4
Quick Start
Thank you for purchasing a new motherboard from MSI®. This Quick Start section
provides demonstration diagrams about how to install your computer. Some of the
installations also provide video demonstrations. Please link to the URL to watch it
with the web browser on your phone or tablet. You may have even link to the URL by
scanning the QR code.
Preparing Tools and Components
Intel® LGA1700 CPU LGA1700 CPU Fan
Graphics Card
SATA Hard Disk Drive
Phillips Screwdriver
Chassis
Power Supply Unit
A Package of Screws
Thermal Paste
DDR5 Memory

5
Safety Information
∙The components included in this package are prone to damage from electrostatic
discharge (ESD). Please adhere to the following instructions to ensure successful
computer assembly.
∙Ensure that all components are securely connected. Loose connections may cause
the computer to not recognize a component or fail to start.
∙Hold the motherboard by the edges to avoid touching sensitive components.
∙It is recommended to wear an electrostatic discharge (ESD) wrist strap when
handling the motherboard to prevent electrostatic damage. If an ESD wrist strap
is not available, discharge yourself of static electricity by touching another metal
object before handling the motherboard.
∙Store the motherboard in an electrostatic shielding container or on an anti-static
pad whenever the motherboard is not installed.
∙Before turning on the computer, ensure that there are no loose screws or metal
components on the motherboard or anywhere within the computer case.
∙Do not boot the computer before installation is completed. This could cause
permanent damage to the components as well as injury to the user.
∙If you need help during any installation step, please consult a certified computer
technician.
∙Always turn off the power supply and unplug the power cord from the power outlet
before installing or removing any computer component.
∙Keep this user guide for future reference.
∙Keep this motherboard away from humidity.
∙Make sure that your electrical outlet provides the same voltage as is indicated on
the PSU, before connecting the PSU to the electrical outlet.
∙Place the power cord such a way that people can not step on it. Do not place
anything over the power cord.
∙All cautions and warnings on the motherboard should be noted.
∙If any of the following situations arises, get the motherboard checked by service
personnel:
• Liquid has penetrated into the computer.
• The motherboard has been exposed to moisture.
• The motherboard does not work well or you can not get it work according to user
guide.
• The motherboard has been dropped and damaged.
• The motherboard has obvious sign of breakage.
∙Do not leave this motherboard in an environment above 60°C (140°F), it may damage
the motherboard.

6
Case stand-off notification
To prevent damage to the motherboard, any unnecessary mounting stand-off between
the motherboard circuits and the computer case is prohibited. The Case standoff keep
out zone signs will be marked on the backside of motherboard (as shown below) to
serve as a warning to user.
Avoid collision notification
Protective paint is printed around each screw hole to prevent parts from being
scratched.

7
Installing a Processor
⚽
∙https://youtu.be/KMf9oIDsGes
11
22
33
66
44
5577
88
99

8
Installing DDR5 memory
∙https://youtu.be/XiNmkDNZcZk
⚽
DIMMA2 DIMMA2
DIMMB2
DIMMA1
DIMMA2
DIMMB1
DIMMB2

9
HDD LED
RESET SW
Connecting the Front Panel Header
∙http://youtu.be/DPELIdVNZUI
JFP1
HDD LED HDD LED -
HDD LED +
POWER LED -
POWER LED +
POWER LED
RESET SW
POWER SW
POWER LED+
POWER LED-
HDD LED
⚽
1
2 10
9
Power LED
Reserved
Power Switch
JFP1
Reset SwitchHDD LED

10
Installing the Motherboard
11
∙https://youtu.be/wWI6Qt51Wnc
⚽
Torque:
3 kgf·cm*
*3 kgf·cm
= 0.3 N·m
= 2.6 lbf·in
BAT1
22

11
Connecting the Power Connectors
∙http://youtu.be/gkDYyR_83I4
ATX_PWR1
CPU_PWR1~2
⚽

12
Installing SATA Drives
∙http://youtu.be/RZsMpqxythc
11
2233
44
55
⚽

13
Installing a Graphics Card
∙http://youtu.be/mG0GZpr9w_A
⚽
11
22
33
44
55
66

14
Connecting Peripheral Devices

15
Power On
44
33
1122

16
Specifications
CPU
∙Supports 12th/ 13th Gen Intel® Core™ Processors,
Pentium® Gold and Celeron® Processors*
∙Processor socket LGA1700
* Please go to www.msi.com to get the newest support status as new processors
are released.
Chipset Intel® B760 Chipset
Memory
∙4x DDR5 memory slots, supporting up to 192GB*
∙Supports 1R 5600 MHz (by JEDEC & POR)
∙Max. overclocking frequency:
• 1DPC 1R Max speed up to 7800+ MHz
• 1DPC 2R Max speed up to 6400+ MHz
• 2DPC 1R Max speed up to 6000+ MHz
• 2DPC 2R Max speed up to 5600+ MHz
∙DIMM slots with single-sided latches
∙Supports Intel® XMP 3.0 OC
∙Supports Dual Controller Dual-Channel mode
∙Supports non-ECC, un-buffered memory
* Please refer to www.msi.com for more information on compatible memory.
Expansion Slots
∙1x PCIe x16 slot
• PCI_E1 slot (From CPU)
• Supports PCIe 5.0 x16
∙1x PCIe x4 slot
• PCIE_E2 slot (From B760 Chipset)
• Supports PCIe 3.0 x4
Onboard Graphics
∙1x HDMI™ 2.1 port with HDR, supporting a maximum
resolution of 4K 60Hz*/ **
∙1x DisplayPort 1.4 port with HBR3, supporting a maximum
resolution of 8K 60Hz*/ **
* Available only on processors featuring integrated graphics.
** Graphics specifications may vary depending on the CPU installed.
SATA Ports
∙6x SATA 6Gb/s ports
• SATA_5~8* (From B760 chipset)
• SATA_A1~A2 (From ASM1061)
* SATA_8 will be unavailable when installing M.2 SATA SSD in the M2_3 slot.
Continued on next column

17
Continued from previous column
M.2 SSD Slots
∙3x M.2 slots (Key M)
• M2_1 slot (From CPU)
• Supports up to PCIe 4.0 x4
• Supports 2242/ 2260/ 2280 storage devices
• M2_2 slot (From B760 chipset)
• Supports up to PCIe 4.0 x4
• Supports 2260/ 2280 storage devices
• M2_3* slot (From B760 chipset)
• Supports up to PCIe 4.0 x4
• Supports up to SATA 6Gb/s
• Supports 2280 storage devices
* SATA_8 will be unavailable when installing M.2 SATA SSD in the M2_3 slot.
RAID
∙Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA
storage devices*
* SATA_A1~A2 do not support RAID function.
Audio
Realtek® ALC897 Codec
∙7.1-Channel High Definition Audio
∙Supports S/PDIF output
LAN 1x Realtek® RTL8125 2.5Gbps LAN controller
Wi-Fi & Bluetooth®
Intel® Wi-Fi 6E
∙The Wireless module is pre-installed in the M.2 (Key-E)
slot
∙Supports MU-MIMO TX/RX, 2.4GHz/ 5GHz/ 6GHz*(160MHz)
up to 2.4Gbps
∙Supports 802.11 a/ b/ g/ n/ ac/ ax
∙Supports Bluetooth® 5.3**, FIPS, FISMA
* The usage of Wi-Fi 6GHz band relies on Windows 11 support and depends on
every country’s regulations.
** The Bluetooth version may be updated, please refer to the Wi-Fi chipset
vendor’s website for details.
Power Connectors ∙1x 24-pin ATX main power connector
∙2x 8-pin ATX 12V power connectors
Continued on next column

18
Continued from previous column
Internal USB
Connectors
∙1x USB 3.2 Gen 2 10Gbps Type-C front panel connector
(From B760 chipset)
∙1x USB 3.2 Gen 1 5Gbps connector (From B760 chipset)
• Support additional 2 USB 3.2 Gen 1 5Gbps ports
∙2x USB 2.0 Type-A connectors (From Hub-GL850G)
• Supports additional 4 USB 2.0 ports
Fan Connectors
∙1x 4-pin CPU fan connector
∙1x 4-pin water-pump fan connector
∙4x 4-pin system fan connectors
System Connectors
∙1x Front panel audio connector
∙2x System panel connectors
∙1x Chassis intrusion connector
∙1x TPM module connector
∙1x Tuning controller connector
∙1x USB4 expansion card connector (Supports RTD3)
Jumpers ∙1x Clear CMOS jumper
LED Features
∙1x 4-pin RGB LED connector
∙2x 3-pin A-RAINBOW V2 (ARGB Gen2) LED connectors
∙1x LED Demo connector
∙1x JPIPE_LED connector
∙4x EZ Debug LED
Continued on next column

19
Continued from previous column
Back Panel
Connectors
∙4x USB 2.0 Type-A ports (From B760 chipset)
∙1x DisplayPort
∙1x HDMI™ port
∙1x Clear CMOS button
∙1x 2.5Gbps LAN (RJ45) jack
∙3x USB 3.2 Gen 2 10Gbps Type-A ports (From GL3590 Hub)
∙1x USB 3.2 Gen 2x2 20Gbps Type-C port (From B760
chipset)
∙2x Wi-Fi antenna connectors
∙5x Audio jacks
∙1x Optical S/PDIF Out connector
I/O Controller NUVOTON NCT6687R Controller Chip
Hardware Monitor
∙CPU/ System/ Chipset temperature detection
∙CPU/ System/ Pump fan speed detection
∙CPU/ System/ Pump fan speed control
Form Factor ∙Micro-ATX Form Factor
∙9.6 in. x 9.6 in. (244 mm x 244 mm)
BIOS Features
∙1x 256 Mb flash
∙UEFI AMI BIOS
∙ACPI 6.4, SMBIOS 3.5
∙Multi-language
Software
∙Drivers
∙MSI Center
∙Intel® Extreme Tuning Utility
∙MSI APP Player (BlueStacks)
∙CPU-Z MSI GAMING
∙Norton 360
∙AID64 Extreme - MSI Edition

20
Special Features
MSI Center
• Gaming Mode
• Smart Priority
• Game Highlights
• Mystic Light
• Ambient Link
• Frozr AI Cooling
• User Scenario
• True Color
• Live Update
• Hardware Monitoring
• Super Charger
• Devices Speed Up
• Smart Image Finder
• MSI Companion
• System Diagnosis
Thermal Features
• Extended Heatsink Design
• M.2 Shield Frozr
• K7 MOSFET thermal pad / Extra
choke pad
• Fan headers (CPU *1 + PUMP *1 +
SYSTEM *4)
Performance
• Core Boost
• VRM Power Design (VCPU *12/ VGT
*1/ AUX *1)
• Dual CPU Power (2x 8 pin)
• OC Engine
• Memory Boost
• Lightning Gen 5 PCI-E
• Lightning Gen 4 M.2 Slot
• Front USB Type-C
• Server Grade PCB
• 2oz Copper thickened PCB
DIY Friendly
• PCI-E Steel Armor
• Pre-installed I/O Shield
• Screwless M.2 Shield Frozr
• EZ M.2 Clips
• EZ DEBUG LED
• EZ LED Control
• Flash BIOS Button
Audio
• Audio Boost
RGB Support
• Mystic Light Extension (RGB)
• Mystic Light Extension (A-RAINBOW
V2)
• Ambient Devices Support
BIOS
• Click BIOS 6
• CPU Cooler Tuning
