MSI NX6600GT-VT2D128E Diamond User manual

Hardware Installation
Follow the steps to install the VGA card :
1. Remove the computer case.
2. Locate the PCI Express slot on your mainboard.
Warning: Inserting the VGA card into a wrong
slot (e.g. AGP slot) may damage your card (refer
to your mainboard manual for more Information).
3. Put the card directly over the slot
and press one end of the card into the slot first.
Gently but firmly press the other end until it is
fully seated in the slot.
4. Secure the card with a bracket screw.
5. Install all other cards and devices and connect
all the cables, and then install the case.
6. Connect the monitor. Now, you are ready to
install the software on your computer.
below
PCI Express
Software Installation
(for )
Windows XP/ 2000
R
ITM TM nstalling MSI Live Update 3
To install the driver of the VGA card to your computer running
CD
Windows XP or 2000,
please follow the steps below:
1. Turn on the computer.
2. Insert the into the CD-ROM drive. The Autorun program will start the Setup
program, and show the setup screen as follows:
R
TM
MSI Live Update 3 is a useful utility for you to upgrade your MSI mainboard and
VGA card. Thanks to the powerful capacity of this utility, you can conveniently
download and automatically update the BIOS and the drivers on-line, without spending
much time in searching many Web sites to find the BIOS or drivers you want.
Installing from the CD-Title
1. Insert the CD into the CD-ROM drive, and start the Setup program.
2. Click the Utility tab on the setup screen.
3. Click the MSI Live Update 3 . Follow the on-screen instructions to complete the
installation.
Installing from the MSI Web Site
1. Make connection to MSI's website at http://www.msi.com.tw
2. Select /Support/Live Update 3/ on the upper part of the MSI's homepage to enter
the setup page.
TM TM
TM TM
TM
Tip : If, on your computer, the
Autorun program does not execute
automatically, please 1) enable the
CD-ROM drive Auto-detect function
from Control Panel; or 2) find and
run the setup.exe file manually from
the CD.
3. Click nVIDIA VGA Drivers. Follow the on-screen instructions to complete the
installation.
4. After finishing the installation, restart the computer as instructed.
UTM TM sing MSI Live VGA Driver Update
MSI Live VGA Driver Update
This service enables you to update the latest VGA driver for your VGA card.
1. To update the MSI Live VGA Driver , click Live VGA Driver item on the left
column of the main page.
TM TM
TM TM TM
2. This utility will start checking your platform and the information on the VGA card, and
display the information in a list.
3. Click the graph button on the bottom to connect MSI Live Update Series Server.
Then, it will automatically connect the Internet and compare the version of the driver
in the database.
4. It may take several minutes to detect the required drivers. Please wait while
proceeding detection.
5. Click the InstallShield Wizard button on the right side of the table to download and
update the driver. All actions will proceed automatically.
6. Follow the on-screen instructions to complete the updating procedure.
The page ofthe MSI Live Update 3
TM TM
3. TM Click the InstallShield Wizard button to have the program of MSI Live
TM TM
Update 3 with MSI Live monitor downloaded and installed on your system
automatically, or click here (manual) to download and install the program manually.
4. Follow the on-screen instructions to complete the installation.
NVIDIA Digital Vibrance Control 3.0
On-chip video processor
64-bit floating pointtexture filtering andblending
Microsoft DirectX 9.0 Shader Model3.0 support
OpenGL 1.5 support
NVIDIA SLI multi-GPU ready
Superscalar GPU architecture
256-bit memory interfacewith advanced memorycontrol
Dual single-link DVIsupport
Innovative 0.13 micronprocess technology
Operating Systems SupportWindows XP / 2000
Power supply of350 (and up)watt is highly recommended for system stability
Memory Interface: 128-bit
Memory Bandwidth (GB/sec.):16.0
Fill Rate (billiontexels/sec.): 4.0
Vertices/sec. (Million):375
Pixels per clock(peak): 8
RAMDACs (Mhz): 400
TM
TM
R
RR
R
R
R

Getting Started
System Requirements
Card Features
Please check out the following items to make sure that you get the complete product:
VGA card
CDs
- Drivers and documentation on CD
- Applications on CD
Consult your dealer immediately if anything is missing or damaged.
UTM TM sing MSI Live VGA BIOS Update
G52-V2NNX42
May 2005
MICRO-STAR
INTERNATIONAL
nVIDIA GeForce NX6600GT
PCI Express interface
To install the VGA card, your computer system needs to meet the following requirements:
Intel Pentium 4/Celeron , AMD Athlon XP, Sampron or compatiblewith PCI Expressslot
256MB of systemmemory
Installation software requiresCD-ROM drive
Operation System Support:Windows XP /2000
Power supply of350 (and up)watt is highly recommended for system stability.
TM
RRR
128MB DDR/DDR3 memory
NVIDIA CineFX 3.0 engine
TM
TM
TM
TM
TM
TM
TM
64-bit texture filteringsupport delivers full-speed,high dynamic-range (HDR)lighting effects
Unmatched image qualitydelivered through new16x anisotropic filteringand rotated grid
antialiasing
4x shadow processingpower with NVIDIA UltraShadow II for next generation games
Infinite program lengthallows for anew class ofspecial effects
Hardware-accelerated MPEG andWMV9 decode deliverssmooth, artifact-free video
Dedicated video hardwarereduces CPU utilizationand improves overallsystem
performance
On-chip video encoderand motion estimationengine provides fast,high-quality encoding
from TV tuner
Programmable video engineensures compatibility withfuture video codecs
High-quality video scalingand filtering improvesplayback quality atany window size
PCI Express supportaccelerates video editingby speeding updata transfer rates
Integrated HDTV-outputbrings content fromyour desktop toyour high-definition TV
NVIDIA ForceWare software delivers unmatched features and rock-solid stability
High dynamic-range (HDR)rendering
NVIDIA UltraShadow II technology
NVIDIA Intellisample 3.0 technology
NVIDIA ForceWare Unified Driver Architecture (UDA)
NVIDIA nView multi-display technology
R
R
R
R
R
R
R
Fan Connector
Power Connector
SLI Interface
For reference only
NX6600GT-Diamond
nVIDIA GeForce NX6600GT inside!!!
PCI Express Interface
Note: The VGAcard shown here
may vary from the actual card.
For further information,please
visit MSI websiteat
www.msi.com.tw
I
n
t
e
r
a
r
t
n
a
S
-
t
i
o
o
r
n
c
i
a
l
M
TEL. [phone]
FAX. [phone]
http://www.msi.com.tw
* All trademarksused in this manual are the soleproperty of theirrespective owners.
VGA is atrademark of International Business Machines Corporation.
Pentium is a registered trademark of Intel Corporation.
Windows is a registered trademark of Microsoft Corporation.
RR
RR
Macrovision Corporation ProductNotice
This product incorporatescopyright protection technologythat is protectedby method claims of
certain U.S. patentsand other intellectualproperty rights ownedby Macrovision Corporation and
other right owners.Use of thiscopyright protection technologymust be authorized by Macrovision
Corporation, and isintended for homeand other limitedviewing uses only unless otherwise
authorized by MacrovisionCorporation. Reverse engineeringor disassembly isprohibited.
MICRO-STAR INT'L
MS-8994
MSI Live VGA BIOS Update
This service enablesyou to updatethe latest VGABIOS for yourVGA card.
1. To update your VGABIOS, click Live VGA BIOS item on theleft column of the main page.
TM TM
TM
TM
2. If your VGA card does not support the Live VGA BIOS function, you will receive a warning
message on thescreen.
TM
3. If your VGAcard do supportthe Live VGA BIOS function, please pay attention to themessage
shown on thescreen telling youthat in whatcircumstance flashing BIOS may fail to reboot.
4. Click Yes if you would like to try it at your own risk or No to return to the main page with
everything unchanged.
5. If you click Yes to continue, it will check the information and BIOS version of your VGA card,
and list themin a table.
TM TM
6. Click the graph button at thebottom to connectthe MSI Live Update 3 Server.
TM TM
7. The MSI Live VGA BIOS will automatically connect the Internet and search the supported
TM
BIOS in thedatabase of MSI .
8. If it has found one (or several) supported BIOS for your VGA card, click the InstallShield
Wizard button on the right side of the table to have the new BIOS downloaded and updated
automatically.
9. Follow the on-screen instructions to completethe updating procedure.
CoreCell 3D
TV_Out / Video_In
Connector (S&C)
HDTV-Output integrated
Dual DVI-I Ports
With
TM
CoreCell 3D
Technology
