MSR 255 User manual

User manual
MSR 255
Distributed by MicroDAQ.com, Ltd. www.MicroDAQ.com [phone]

Instructions
2
SetupReaderViewerOnline
Table of contents
User manual .....................................................1
Important notes regarding this user manual...........................5
Safety instructions and warnings ....................................6
Operating Instructions .............................................7
Overview ......................................................8
Controls.......................................................8
Turning the unit on / saving measurement parameters . . . . . . . . . . . . . . . . . . . . 9
Logger display / Logger operation ..................................10
Logger states .................................................10
Logger display and logger operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Indicator LED’s.................................................12
Maintenance ....................................................13
User checks...................................................13
Cleaning......................................................13
Charging the battery.............................................13
Specifications ...................................................14
Defining the axes ................................................14
Operating, transport and storage conditions .........................15
Troubleshooting .................................................15
Packing list .....................................................16
Disposal........................................................16
Declaration of conformity .........................................16
PC software ....................................................17
Setup ..........................................................25
Basic settings..................................................26
Prediction..................................................27
Reducing the volume of data ...................................28
Conditional recording of measurement parameters (limits). . . . . . . . . . . . . . 28
Setting the alarm limit.........................................28
LED behaviour ..............................................29
Transferring basic settings to several loggers . . . . . . . . . . . . . . . . . . . . . . . 29
User settings ..................................................30
Adjusting the channel properties . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Change basic parameter.......................................33
Calibrating the sensors .......................................34
Change display parameter .....................................35
Defining the logger display .....................................36
Formatting the memory ..........................................37
Reader .........................................................38
Viewer .........................................................39
Online..........................................................45
Utility programs .................................................47
CSV.........................................................48
Distributed by MicroDAQ.com, Ltd. www.MicroDAQ.com [phone]

Instructions
3
SetupReaderViewerOnline
Cutter........................................................49
Calc.........................................................50
Concat.......................................................53
Additional software for PCs........................................55
FreeMat ......................................................56
Address ........................................................57
Distributed by MicroDAQ.com, Ltd. www.MicroDAQ.com [phone]

Operating instructions
Utility programs
Additional software for PCs
PC software
Setup
Reader
Viewer
Online
SetupReaderViewerOnline Instructions
Distributed by MicroDAQ.com, Ltd. www.MicroDAQ.com [phone]

Instructions
5
ViewerOnline
Important notes regarding this user manual
In this manual notes of particular importance are presented as follows:
CAUTION
Indicates that equipment may suffer dam-
age or that data loss may occur should the
instructions not be followed correctly.
WARNING
Indicates that equipment may suffer dam-
age or that there is a risk of injury to the op-
erator or user should the instructions not be
followed correctly.
Conventions
Term / Symbol Description Example
Logger In this manual the term "logger"
is used to mean "MSR255“.
Commands, programs,
menu items, functions,
field names
Commands, programs, menu
items, functions, field names are
shown in bold.
Record
-> See page -> 5
• Reference to further
information
• Further information
SetupReader
Distributed by MicroDAQ.com, Ltd. www.MicroDAQ.com [phone]

Instructions
6
ViewerOnline
Safety instructions and warnings
WARNING
• Read the operating instructions carefully before using the logger or the logger
software. This will protect you personally and avoid damage to the unit.
• The logger is a unit for recording and displaying measurement parameters
and may not be used for safety-related applications.
• Before using the logger check the unit itself and all cables for visible signs of
damage and never operate a damaged logger. A damaged logger can endan-
ger operator safety! Should the logger not function perfectly or appear to be
damaged, send it to MSR Electronics GmbH for repair.
• Ensure that no fluids enter the logger's casing. Fluids cause corrosion
damage and short-circuits inside the logger.
• The logger must never be opened or modified. The manufacturer cannot be
held liable for damage resulting from use other than that for which the unit is
intended, or from improper operation of the unit.
• Never use a logger with a leaking battery. Should a battery leak be detect-
ed ensure that the electrolyte does not come into contact with the skin, the
eyes or the mouth. Should this occur, thoroughly rinse the affected area
with water for at least 15 minutes. Consult a doctor. Do not breathe in any
vapours emitted. Immediately clean the electrolyte from the logger using a
soft cloth and dispose of the cloth subsequently.
CAUTION
• Ensure the proper disposal of an obsolete logger, the USB connection cable
and the mains adapter ->17.
SetupReader
Distributed by MicroDAQ.com, Ltd. www.MicroDAQ.com [phone]

Instructions
Operating Instructions
Operating Instructions
MSR 255
Distributed by MicroDAQ.com, Ltd. www.MicroDAQ.com [phone]

Instructions
8
Overview
The logger is a miniaturised universal datalogger for measuring and recording dif-
ferent physical measurement parameters.
For further information, see data sheets.
The Logger PC program enables users to customise the way in which the log-
ger measures and records data according to their requirements. The integrated
clock (RTC) allows data from as many loggers as required to be synchronised and
merged into a single data record.
USB connection cable CD with PC
software
Controls
Mains adapterMSR 255
Indicator LED’s
Blue: Record indicator ->29
Red: Alarm indicator ->28
Yellow: Battery charge indicator ->12
Light sensor
Display
Analogue connections, see delivery for terminal assignment
USB PC-Interface
Push button T1 / T2
Power supply
connector
Distributed by MicroDAQ.com, Ltd. www.MicroDAQ.com [phone]

Instructions
9
Turning the unit on / saving measurement parameters
The storage properties of the logger are determined using the Setup program*.
Control of measurement parameter storage can be either time activated, value
activated or by pushing the push button.
See also chapter „Logger display / Logger operation“ on page 10.
*Setup is an PC program (see below).
Distributed by MicroDAQ.com, Ltd. www.MicroDAQ.com [phone]

10
Instructions
Off (Factory defaults)
(No data recording, display not available)
Display not available
Logger display / Logger operation
When the logger is turned off 1 the display cannot be activated using the T1 or
T2 keys. The display and keys are activated by connecting the logger to a USB
port or charger 2. The display is operated using keys T1 and T2 (see the dia-
gram "Display and operation").
Logger states
1
2
Idle state
In the idle state the de-
vice is waiting for start-
up information from the
PC (setup).
The display turns off
automatically. It can be
switched on by means
of T1 or T2.
Record mode
Data is recording or the
device is waiting for start-
up (immediate start, pro-
grammed start time, start
on key press, external
start signal)
Recording mode is not
exited upon ‘stop on key
press’* (menu 0, T2).
(*Only possible if acti-
vated in setup)
The standard display
appears that was se-
lected under Setup
> General. This may
show a single chan-
nel or a multiple dis-
play of 4 measure-
ment parameters.
Display available
(See next page for operation)
Exit record
mode
Recording has
been stopped
from the PC or
the recording
period has ter-
minated or the
memory is full
(ring memory
deactivated).
Exit idle state
PC setup
Entry of start
info
Exit Off: Connect logger to USB port or
charger
Distributed by MicroDAQ.com, Ltd. www.MicroDAQ.com [phone]

Instructions
11
Logger display and logger operation
Menu 0
Record control
State: on/stop by
KEY
Channel
indication 0 Logger name,
model, version, se-
rial number
Channel
indication 1
Channel
indication 13
Menu 2
Select channel..
Menu 3
show info..
Menu 4
Show last se-
lected view..
Record stop?
Recording is
stopped.
Timeout TimeoutTimeoutTimeout
Menu 1
Select predefined
groups..
Group indication 1
Group indication 2
Group indication 3
Group indication 4
T1 T1 T1 T1
T1
Last group
indication or
channel indication
Display turned off
through timeout
Timeout
Channel
indication 14
T1
T1
T1
T1
T1
T1
T1
T1
T1
T1
T1
T1 T2
T2 T2
T2
T2
T2
T2
T2
T2
T2
T2
T2
T2
T2
T2
T2
*
*
*For defining group indication and channel indication see „Defining the logger
display“ on page 36.
Distributed by MicroDAQ.com, Ltd. www.MicroDAQ.com [phone]

Instructions
12
Indicator LED’s
Information displayed
LED Meaning
Red Alarm limit reached
Blue Define the behaviour of the blue LED via Setup > Ba-
sic settings. See the section Setup, LED behaviour.
Meaning of the yellow lamp during charging
LED Meaning
yellow
continuously
Charging in progress
yellow off • Fully charged
• No connection to PC
• PC turned off
• Power supply not connected
yellow flashes Fully charged
The battery is recharged for a short time, e.g. during
an online measurement or data recording
Distributed by MicroDAQ.com, Ltd. www.MicroDAQ.com [phone]

Instructions
13
Maintenance
User checks
• Check the logger before each use.
• Before using the logger check for visible signs of damage.
• Check the functions of the logger.
• Never use a logger that is damaged or not functioning perfectly. Never use
damaged accessories.
• Ensure that the battery is sufficiently charged for the required period of use.
Should the logger not function perfectly or should damage become apparent
send the unit to MSR Electronics GmbH for repair. Repairs may only be carried
out by MSR Electronics GmbH or an authorised dealer. Defective or damaged
components may only be replaced with manufacturer’s original parts.
Cleaning
CAUTION
• Ensure that no fluids enter the logger's casing.
Fluids will cause corrosion damage and short
circuits.
• Never use corrosive or abrasive cleaning agents or polishes.
• Cleaning agents containing additives such as alcohol will cause the case to
become matt and/or brittle.
• Clean the logger when necessary.
• Always disconnect the logger from the PC or the power supply before clean-
ing.
• Use a cleaning agent suitable for plastic or a cloth dampened with water and
soap.
Charging the battery
Before first use: The battery is not fully charged on delivery and should
be charged before using the logger for the first time.
Charge the logger • Before each use
• At least every six months
Procedure:
• Connect the logger to the power supply or via USB connection cable to the PC
or an external USB mains adapter.
Notes:
• The meaning of the yellow warning light during charging is described on page 12.
• Charging an exhausted battery takes approx. 5 hours using the mains adapter.
Charging is also possible via the USB port with the backlight turned off (ap-
prox. 28 hours).
• Recorded data is non-volatile and remains in the unit’s memory even when the
battery is exhausted.
• Never store the logger with a discharged battery. See ->15 (storage conditions).
Distributed by MicroDAQ.com, Ltd. www.MicroDAQ.com [phone]

Instructions
14
Specifications
See data sheets
Defining the axes
-Y
-Z
Z
Y
-X
X
Distributed by MicroDAQ.com, Ltd. www.MicroDAQ.com [phone]

Instructions
15
Operating, transport and storage conditions
• Protect the logger from excessive exposure to the sun and other sources of
heat. Avoid heavy impacts.
• Do not place heavy objects on top of the logger.
• Only store the logger in a dry, dust-free environment.
Operating conditions:
Temperature: -20°C to +65 °C
Pressure: 500 mbar to 2500 mbar absolute
Humidity: 10-95 % relative humidity, non-condensing
Avoid contact with water and humidity
Optimal storage and transportation conditions:
Temperature: 5 °C bis 45 °C (ideal storage condition for the battery)
Humidity: 10-95 % relative humidity, non-condensing
Avoid contact with water and humidity
Battery charge level: Never store the logger with a discharged battery.
The ideal charge level is a 2/3 charge
(see „Charging the battery“ on page 13)
Troubleshooting
Problem Possible cause Possible solution
The temperature
increases con-
tinuously when
the logger is
connected to the
mains adapter or
the PC
The battery warms up
because charging com-
mences.
When making temperature
measurements disconnect
the logger from mains adapter
or the PC.
The PC programs
do not recognise
the connected
logger
The COM port driver is not
installed correctly.
Observe the manufacturer’s
installation instructions.
http://www.ftdichip.com/
Distributed by MicroDAQ.com, Ltd. www.MicroDAQ.com [phone]

Instructions
16
• MSR 255
• CD including:
• User manual
• Logger PC software
• Logger USB connection cable
• Mains adapter
• Terminal assignment
Disposal
Take the logger and the mains adapter to a municipal waste disposal
centre or return it to MSR Electronics GmbH The logger and the mains
adapter must not be disposed of in normal domestic waste.
Packing list
Declaration of conformity
Distributed by MicroDAQ.com, Ltd. www.MicroDAQ.com [phone]

Setup
Online
Viewer
Reader
PC software
17
SetupReaderViewerOnline
Distributed by MicroDAQ.com, Ltd. www.MicroDAQ.com [phone]

18
SetupReaderViewerOnline
Overview
External processing of logger data is carried out using the PC programs Setup,
Reader, Viewer and Online. The PC programs can be used for all logger types.
The Setup enables the properties of the logger to be customised to user’s re-
quirements.
The Reader allows the user to transfer measurement parameters to a Windows
PC. The Viewer is used to display data graphically or in table form or to export it
as a text file (*.csv).
With the help of Online (and the built-in display) users can view measurement
parameters and curves “live” on a PC.
Installation of the PC software on a PC
For installation you will require Windows administrator rights.
Insert the CD containing the PC software into the computer’s CD-ROM drive. The
installation procedure starts automatically*.
Completing installation
Initial installation: Select
Install USB driver.
Click on Finish.
The logger symbol appears on screen.
If the PC is not set up for automatic installation, proceed as follows:
1. Click Start > Run
2. Click Find > Look in: (set to CD drive).
3. Select the file Install_MSR.exe and Open.
4. In the Run dialog box click OK.
5. The installation process will begin.
6. Follow the instructions and select: Run Program now.
7. During the initial installation select Install USB driver. See above, Complet-
ing installation.
PC software
* The program "Inno Setup" for installing the logger PC programs was written by Jordan Russell (www.jrsoftware.org, copyright Jordan
Russell).
Distributed by MicroDAQ.com, Ltd. www.MicroDAQ.com [phone]

19
SetupReaderViewerOnline
Version number of CD
Version numbers of PC programs
Logger program window
Starting the logger Software
The logger software may be started by clicking on the logger symbol or via
Start > Programs > MSR (folder) > MSR. The logger program window appears:
Distributed by MicroDAQ.com, Ltd. www.MicroDAQ.com [phone]

20
SetupReaderViewerOnline
Uninstalling
The software is uninstalled via the computer’s operating system (Programs >
MSR > Uninstall MSR).
System Requirements
• Windows 2000 / XP / Vista / 7
• USB port
Distributed by MicroDAQ.com, Ltd. www.MicroDAQ.com [phone]
