MadgeTech HiTemp140-FPST-36 User manual

PRODUCT
USER GUIDE
HiTemp140-FP
High Temperature Data
Logger with Flexible RTD
Probe
To view the full MadgeTech product line,
visit our website at madgetech.com.
2Product Overview
2Installation Guide
2Device Operation
3Device Maintenance
4Need Help?
TABLE OF CONTENTS

Product User Guide | 2
HiTemp140-FP
PRODUCT USER GUIDE
Product Overview
Installation Guide
Installing the Software
Device Operation
The Software can be downloaded from the MadgeTech
website at madgetech.com. Follow the instructions
provided in the Installation Wizard.
The HiTemp140-FP is rated IP68 and is fully submersible.
IFC400 or IFC406 (sold separately) — Follow the
instructions provided in the Installation Wizard to install
the USB Interface Drivers. Drivers can also be downloaded
from the MadgeTech website at madgetech.com.
The HiTemp140-FP is a durable, user-friendly high
temperature data logger featuring a long, flexible
RTD probe with a narrow diameter and stainless steel
tip, making it ideal for use in steam sterilization and
lyophilization processes.
Commonly used for mapping, validation and monitoring of
high temperature surfaces, this stainless steel data logger
is available in several models. The flexible probe is coated
with PFA insulation and can withstand temperatures up to
+260 °C (+500 °F).
The HiTemp140-FP probe design is narrow and lightweight
making it ideal for placement within small vials, tubing,
test tube and other small diameter or delicate applications.
Because of the flexible probe, the risks of breakage (both
vial and probe) generally associated with stainless steel
probe loggers are diminished and the location and
placement of the probe is easy to manipulate.
The Trigger Settings feature of the HiTemp140-FP allows
users to configure high and low temperature thresholds
that when met or exceeded, will automatically start
or stop recording data to memory. This data logger is
capable of storing up to 32,256 date and time stamped
readings and features a non-volatile solid state
memory which retains data even if the battery becomes
discharged.
1. Place the logger into the docking station.
2. Highlight the data logger in the Connected Devices
list. Click Stop on the menu bar.
3. Once the data logger is stopped, with the logger
highlighted, click Download.
4. Downloading will offload and save all the recorded
data to the PC.
6. The status of the device will change to Running or
Waiting to Start, depending upon your start method.
7. Disconnect the data logger from the interface cable
and place it in the environment to measure.
1. Once the software is installed and running, plug the
interface cable into the docking station.
2. Connect the USB end of the interface cable into an
open USB port on the computer.
3. Place the data logger into the docking station.
4. The data logger will automatically appear under
Connected Devices within the software.
5. For most applications, select Custom Start from
the menu bar and choose the desired start method,
reading rate and other parameters appropriate for the
data logging application and click Start.
Water Resistance
Installing the Docking Station
Downloading Data from a Data Logger
Connecting and Starting the Data Logger
(Quick Start
applies the most recent custom start options, Batch
Start is used for managing multiple loggers at once,
Real Time Start stores the dataset as it records while
connected to the logger.)
Note: The device will stop recording data when the end of memory
is reached or the device is stopped. At this point the device cannot
be restarted until it has been re-armed by the computer.

Product User Guide | 3
HiTemp140-FP
PRODUCT USER GUIDE
Device Operation (cont’d)
Trigger Settings
Device Maintenance
O-Rings
Set Password Recalibration
Battery Replacement
To password protect the device so that others cannot
start, stop or reset the device:
1. In the Connected Devices panel, click the device
desired.
2. On the Device Tab, in the Information Group, click
Properties. Or, right-click the device and select
Properties in the context menu.
3. On the General Tab, click Set Password.
4. Enter and confirm the password in the box that
appears, then select OK.
The device can be programmed to only record based off
user configured trigger settings.
1. In the Connected Devices panel, click the device desired.
2. On the Device Tab, in the Information Group, click
Properties. Or, right-click the device and select
Properties in the context menu.
3. Select Trigger in the Properties window.
4. Trigger formats are available in Window or Two Point
Mode. Window mode allows a high and/or low trigger set
point, and a trigger sample count or “window” of time
recorded when set points are exceeded to be defined. Two
point allows for different Start and Stop setpoints to be
defined for both the high and low triggers.
Refer to the Trigger Settings - MadgeTech 4 Data Logger
Software video on madgetech.com for instructions on
how to configure Trigger Settings.
MadgeTech recommends annual recalibration. To send
devices back for calibration, visit madgetech.com.
O-ring maintenance is a key factor when properly
caring for the HiTemp140-FP. The O-rings ensure a tight
seal and prevent liquid from entering the inside of the
device. Please refer to the application note O-Rings 101:
Protecting Your Data, found at madgetech.com, for
information on how to prevent O-ring failure.
Materials: ER14250-SM
1. Unscrew the bottom of the logger and remove the
battery.
2. Place the new battery into the logger. Note the polarity
of the battery. It is important to insert the battery with
positive polarity pointing upward towards the probe.
Failure to do so could result in product inoperability or
potential explosion if exposed to high temperatures.
3. Screw the cover back onto the logger.
Note: This product is rated for use up to 140 °C
(284 °F). Please heed the battery warning. The
product will explode if exposed to temperatures
above 140 °C (284 °F).

HiTemp140-FP
NEED HELP?
HiTemp140-FPST-6
HiTemp140-FPST-12
HiTemp140-FPST-24
HiTemp140-FPST-36
HiTemp140-FPST-72
HiTemp140-FPST-6-KR
HiTemp140-FPST-36-KR
IFC400
IFC406
PN 902330-
00 PN
902312-00
PN 902364-
00 PN
902313-00
PN 902316-
00 PN
902339-00
PN 902336-
00 PN
900319-00
PN 900325-
00
PN 900097-
00
High Temperature Data Logger with a 6 inch Flexible Probe with Stainless Steel Tip
High Temperature Data Logger with a 12 inch Flexible Probe with Stainless Steel Tip
High Temperature Data Logger with a 24 inch Flexible Probe with Stainless Steel Tip
High Temperature Data Logger with a 36 inch Flexible Probe with Stainless Steel Tip
High Temperature Data Logger with a 72 inch Flexible Probe with Stainless Steel Tip
High Temperature Data Logger with Key Ring Bottom and 6 inch Flexible Probe with SS Tip
High Temperature Data Logger with Key Ring Bottom and 36 inch Flexible Probe with SS Tip
Docking Station with USB Cable
6 Port, Multiplexer Docking Station with USB Cable
Replacement Battery for the HiTemp140-FP
Ordering Information
Product Support & Troubleshooting:
MadgeTech 4 Software Support:
• Visit our Resources online at madgetech.com/resources.
• Contact our friendly Customer Support Team at [phone] or [e-mail].
• Refer to the built-in help section of the MadgeTech 4 Software.
• Download the MadgeTech 4 Software Manual at madgetech.com.
• Contact our friendly Customer Support Team at [phone] or [e-mail].
ER14250-SM
Formerly ER14250MR-145
