MST LSD-01 GYRO User manual

27
26
11.3
SPECIFICATIONS
Dimension: 26x27x11.3mm
Weight: 7.0g(0.285 oz) with plastic Case
4.8g(0.169 oz) w/o plastic Case
Power Supply: 4.8-6.0 Volts
Current Drain: 10mA(4.8V)
Gain Adjustment: single rate.non-remote
Operating Temperature: -5°C to +60°C
Applicable R/C System: GWS. Futaba. JR.
Airtronics. Sanwa.
Hitec. Multiplex.
1. Confirm servo and mechanical transmission system substantially correct
and unhindered, such as servo neutral.
2. Disconnect the servo to be compensated from the receiver and plug the
connector from the gyro.
3. Insert the servo connector to the gyro port.
4. Turn on the transmitter and then receiver. You should see Bi-color LED
lights on LSD-01, or please double check each line group function.
5. Bi-color LED lit shows the gyro is in neutral, no need to adjust it
additionally. If just one color bright, it represents gyro and servo are not
both located in neutral. Please rotate the gyro neutral knob (SETUP ADJ)
by insulated screwdriver carefully till both two colors lit.
6. Now you are able to operate it. To make the car operational performance
closer to your personal qualities, you can adjust gyro sensitivity finer.
Clockwise rotate the gain knob (+) to increase the gyro controlled servo
swing angle to make the rear relatively stable and reduce the flexibility.
Counterclockwise rotate to reduce the gyro controlled servo stability to
rear but increase the swing flexibility. (Please adjust according to your
personal requirements and proficiency.)
7. LSD-01 is connected between receiver and servo, so you can change the
servo rotate direction easily by transmitter reserving switch. To opposite
the upper and lower direction of gyro location can change the reaction
direction as well.
INTRODUCTION
LSD-01 Gyro
GYRO
LSD-01
Please read this instruction carefully before any
operation of your gyro.
Setup
Adjustment
Power & Offset LED
Rotation Axis
To Servo
Gain Value
Adjustment
To Receiver
The ultra-light weight and incredible compact size, simple and easy for
installation and adjustment are characteristic of this gyro. Install “receiver
→LSD-01 →servo” sequentially to finish installation. A unique red and green
LED indicator system simplifies gyro setup and gyro direction indication to
let user adjust the servo deviation easily and quickly. User can adjust the
servo sensitivity without changing the neutral.
Even novice can install and operate it easily.
Bi-color LED
(Power & offset LED)
Setup Adjustment
Servo
Gain Value Adjustment
Receiver For CH.1
LSD-01 Gyro
INSTALLATION

小巧和輕量是LSD-01最基本的特色，LSD-01真正與眾不同的特點，在
於其再簡單不過的安裝步驟和調整程序，以使用者立場的思考模式所設計的
LSD-01，也就是依 [接收機→LSD-01→伺服機] 的方向，將各配件依序連接，
即完成安裝步驟；而其調整則更是簡單，LSD-01內建的雙色LED，可以清
楚地瞭解伺服機的偏向，而快速調整至中立點；而靈敏度的增減，則不影響
中立點。
所以在安裝設定LSD-01的過程中，即使是初學者第一次使用，也能立
刻上手。
雙色LED
(電源及設定顯示LED)
伺服機
中立調整鈕
靈敏度調整鈕
接收機 接CH.1
1. 請先在尚未接上陀螺儀時，確認伺服機與各機械傳動部份均正確而無阻
礙，如伺服機的中立點。
2. 在接收機電源關閉情況下，將LSD-01的插頭插上接收機。
3. 將伺服機插頭插上LSD-01的插座而牢固無虞。
4. 請先開啟發射機電源，再開啟接收機電源，這時應可看到LSD-01上的雙
色LED亮起，否則請再次檢查各線組。
5. 雙色LED初次亮起時，如雙色LED都已亮著，則陀螺儀已在中立點位置，
您可以省掉調整中立點的時間；如只亮一色LED，是代表陀螺儀和伺服
機兩者並未同時都位在中立點，請小心旋轉陀螺儀上的中立調整鈕
(SETUP ADJ請用絕緣一字起子)，直到雙色LED同時亮著，就表示已經
調整到中立點的位置了。
6. 調整了中立點后，其實您已經可以進行操作了，但是為了讓車體的操作
性能更加接近您個人的操控特質，您可以就陀螺儀的靈敏度，做更細微
的調整，此處的調整須由轉動增益鈕(+)來達成，順時針旋轉增益鈕(+)
會增加陀螺儀控制伺服機的擺動角度，結果車尾將會顯得比較穩定，但
也因而降低靈活度，反之逆時針調整增益鈕則減少了陀螺儀控制伺服機的
擺動角度，則將降低車尾的穩定性，相對變得靈活。(請依照您個人的需
求和操控的熟練度來加以調整)
7. 由於LSD-01是串接在接收機和伺服機之間，所以只要藉由發射機上的正
反轉開關，就可以輕易的改變伺服機的轉動方向；或者在固定的時，將其
上下反個方向固定，也可改變反應的方向。
簡 介
安裝說明
進行LSD-01的安裝設定前，請先詳細閱讀以下使用說明。
雙色LED
(電源及設定顯示LED)
接收機
中立調整鈕
靈敏度調整鈕
伺服機
旋轉軸向
27
26
11.3
規 格
外型尺寸：26.0x27.0x11 .3mm
重量：7.0g(0.285 oz) 含外殼
4.8g(0.169 oz) 不含外殼
工作電壓：4.8-6.0 Volts
消耗電流：10mA(4.8V)
單段式靈敏度增益調整
適用溫度：-5°C to +60°C
適用遙控系統：GWS. Futaba. JR.
Airtronics. Sanwa.
Hitec. Multiplex.
LSD-01 Gyro
LSD-01 Gyro
GYRO
陀螺儀
LSD-01
