MST XXX-D RTR User manual

※
SPECIFICATION ARE SUBJECT TO CHANGE WITHOUT NOTICE
www.rc-mst.com
EXPLODED
MANUAL
ON ROAD USE ONLY
FULL BALL BEARINGS
WHEELBASE :
WIDTH :
GEAR RATIO :
CASTER :
CAMBER :
STANDARD 257mm (adjustable)
STANDARD 190mm (adjustable)
1.89 (34T/18T)
8 degrees variableness
0 to -12 degrees
RTR
RTR
XXX-R
XXX-D
1
/
10
SCALE RC HIGH PERFORMANCE DRIFT CAR

2
XXX-D RTR
原廠電裝配線圖
FACTORY
ELECTRONIC
SETTING
Appreciate for your choice of XXX-D RTR! You will be impressed with its performance and beauty.
Please prepare additional parts as car battery, transmitter battery, and charger.
Please follow the process for assemble and setting of parts package.
If you have doubt or need assistance, please contact the purchased shop or hobby shop for help, many thanks!
首先感謝你購入 XXX-D RTR 這項產品，您將擁有一部兼具性能與美型的甩尾車。
在首次操作前，有以下幾項須要另行購置的物件；車用電池、遙控器用電池、充電器。
備妥上述物件後，請進行零件包安裝與設定。
如需其他協助，請向原購買店家，或遙控模型店詢問！謝謝！
XXX-D
RTR
Completed.
Switch on the ESC.
Trims the transmitter in neutral.
Switch on the transmitter.
Connector ESC and battery.
Loosen receiver antenna.
Install transmitter batteries.
1
2
3
4
5
6
7 完成
打開電子變速器電源
調整遙控器各微調器至中立點
打開遙控器電源
聯結車用電池與電子變速器
鬆開接收機天線
安裝遙控器電池
1
2
3
4
5
6
7
PLEASE FOLLOW BELOW
OPERATIONS BEFORE ASSEMBLING
THE PARTS PACKAGE.
請於安裝零件包之前,執行以下操作
※
遙控器&接收機功能說明請參閱詳細說明書。
Please refer to instruction of
transmitter & receiver performance.
※
請於空曠或安全無虞的場所，使用本項產品。
Please play this product in opening or safety area.
※
電子變速器功能說明請參閱詳細說明書。
Please refer to instruction of
ESC performance.
接收機
Receiver
轉向伺服機
Steering servo
電子變速器
ESC
馬達
540 Motor
Battery (not included)
電池 (需另購)
ST EP
1安裝前車輪
Attaching Front Tire
FRONT
CH. 1
CH. 2
電子變速器開關
ESC Switch
1
/
10
SCALE RC HIGH PERFORMANCE DRIFT CAR

3
XXX-D RTR
3
2
1
Sponge tape
泡棉膠
130017
ST EP
3貼上吸震泡棉
Pasting Sponges
電池的安裝方式會因為廠牌規格而有些微差異，電池的使用方式與保存方式，也會因電池的
種類而有所不同。
The assembly and conservation method may be different by specification of
battery.
※
請沿虛線剪開。
Please cut along
the dashed line.
※
建議安裝長140×寬48×高25.4mm尺寸以內的電池。
Recommened battery measurement L140×W48×H25.4mm (not exceed)
※
安裝設定完成後，請於安全場所使用本產品!
使用前請先開啟遙控器電源後再開啟車體電源!
使用後請反向操作關閉!
Please play in safe place after all setting finish.
Before playing, please switch on transmitter then on the car.
Please switch off reversely.
※
ST EP
4電池安裝
Attaching Battery
連接電池!
Connect to battery!
ST EP
2安裝後車輪
Attaching Rear Tire
REAR
Sponge
吸震泡棉
130034
20mm 20mm
110mm
請沿虛線剪開。
Please cut along
the dashed line.
※

EXPLODED
VIEW
Please add color remark for
( )
part number.
e.g.
210123
R for Red
(
210123
)
請增加顏色標示在
( )
編號
例
:
210123
R for
紅色
(
210123
)
Color 顏色 Red 紅
Remark 標示 R
XXX-D
RTR
1
/
10
SCALE RC HIGH PERFORMANCE DRIFT CAR
310054310006
110 061
210054
120001
210060
110 017
110 017
210145
310006
110 015
110 015
210055
310054
310054
110004
310051
310048
210063
W
210063
W
310048
210063
W
310051
210043
210043
12 0011
110 0 67
110 017
110004
210063
W
310055
210063
W
210055
310047
120001
210095
210040
210025
210030
110020
210040
120008
110 0 5 3
210095
120001
120017
310032
110 03 9
S
210040
820024
310033
310033
820024
210030
210095
210095
110008
210002
110 019
210029
210002
210056
210056
210030
210095
820024
210040
110 03 9
S
210056
210069
820024
210040
210056
110 0 5 3 210030
120001
110 0 47
210095
120001
110026
110002
210064
210064
310046
110026
210097
210041
110002
110003
110 076
210058
210063
W
210058 210031
110001
110002
210041
210100
130004
110 013
210057
210082
310008
130032
210071
210082
210057
130025
(
310053
)
820079
210144
-
2
820079
820013
110008
110008
210095
210095
110004
210042
210037
BK
210037
BK
210095
110008
310029
310054
110001
110002
310055
110 0 5 4
110 0 41
110 02 9
230002
210086
110 0 42
110026
210099
110005
210097
110 0 61
210084
210083
110005
110 075
110 0 42
230001
310055
110 0 5 4
110 0 41
110002
110001
210095
110 0 5 4
210100
210100
110 016
110 016
210095
110 0 5 4
210100
12 0011
210145
110003
210063
W
110 02 9
110 017
120001
110002
110 0 47
210095
110001
310055
110 0 48
210033
110 0 47
110026
110001
210002
210002
110002
110 016
210002
130005
210002
110005
110 019
210098
110026
110047
110 03 5
148021
(
210487
)
110 0 44
110 03 5
110002
120002
110 0 51
120002
210098
120002
210040
130021
130021
210041
120007
310031
210039
(
210219
)
110 0 46
820020
110 0 45
110 0 44
210025
210041
120007
110026
110047
210096
110 0 46 110 04 5
210042
310054
110026
110 03 5
210040
210069
210031
210003
110 012
110004
110 012
210003
Brushless
601007
Brushed
601010
600002
Brushless
601008
Brushed
601002
601003

XXX-D RTR
EXPLODED
VIEW
Please add color remark for
( )
part number.
e.g.
210123
R for Red
(
210123
)
請增加顏色標示在
( )
編號
例
:
210123
R for
紅色
(
210123
)
Color 顏色 Red 紅
Remark 標示 R
XXX-D
RTR
1
/
10
SCALE RC HIGH PERFORMANCE DRIFT CAR
310054310006
110 0 61
210054
120001
210060
110 017
110 017
210145
310006
110 015
110 015
210055
310054
310054
110004
310051
310048
210063
W
210063
W
310048
210063
W
310051
210043
210043
12 0011
110 0 67
110 017
110004
210063
W
310055
210063
W
210055
310047
120001
210095
210040
210025
210030
110020
210040
120008
110 0 5 3
210095
120001
120017
310032
110 03 9
S
210040
820024
310033
310033
820024
210030
210095
210095
110008
210002
110 019
210029
210002
210056
210056
210030
210095
820024
210040
110 03 9
S
210056
210069
820024
210040
210056
110 0 5 3 210030
120001
110 0 47
210095
120001
110026
110002
210064
210064
310046
110026
210097
210041
110002
110003
110 076
210058
210063
W
210058 210031
110001
110002
210041
210100
130004
110 013
210057
210082
310008
130032
210071
210082
210057
130025
(
310053
)
820079
210144
-
2
820079
820013
110008
110008
210095
210095
110004
210042
210037
BK
210037
BK
210095
110008
310029
310054
110001
110002
310055
110 0 5 4
110 0 41
110 02 9
230002
210086
110 0 42
110026
210099
110005
210097
110 0 61
210084
210083
110005
110 075
110 0 42
230001
310055
110 0 5 4
110 0 41
110002
110001
210095
110 0 5 4
210100
210100
110 016
110 016
210095
110 0 5 4
210100
12 0011
210145
110003
210063
W
110 02 9
110 017
120001
110002
110 0 47
210095
110001
310055
110 0 48
210033
110 0 47
110026
110001
210002
210002
110002
110 016
210002
130005
210002
110005
110 019
210098
110026
110047
110 03 5
148021
(
210487
)
110 0 44
110 03 5
110002
120002
110 0 51
120002
210098
120002
210040
130021
130021
210041
120007
310031
210039
(
210219
)
110 0 46
820020
110 0 45
110 0 44
210025
210041
120007
110026
110047
210096
110 0 46 110 04 5
210042
310054
110026
110 03 5
210040
210069
210031
210003
110 012
110004
110 012
210003
Brushless
601007
Brushed
601010
600002
Brushless
601008
Brushed
601002
601003

6
XXX-D RTR
4
.
8
Copper hex ball
×7
銅製外六角球頭
310055
5
.
8
ball connector
×4
球頭
210003
2
.
5×46
arm shaft
×4
擺臂插銷
310048
2
.
5×6
spacer
×2
鋼板
120008
2
.
5×20
arm shaft
×2
擺臂插銷
310046
4
.
8×4
.
5
copper ball connector
×11
銅製球頭螺絲
310054
Rail post
×2
軸承支柱
310029
2×9
.
8
pin
×8
插銷
110017
2×9
.
8
pin
×2
插銷
110046
2×11
.
8
pin
×4
插銷
110019
5×7×0
.
3
spacer
×1
墊片
820020
10×12×0
.
3
spacer
×6
墊片
820024
3×5×0
.
2
spacer
×2
墊片
820013
3×6×0
.
5
spacer
×6
墊片
110047
3×8×0
.
5
spacer
×1
墊片
110048
M
3×8
screw
×27
沉頭螺絲
110005
M
3×10
screw
×14
圓頭螺絲
110026
M
3×14
screw
×4
圓頭螺絲
110061
M
2×6
screw
×2
圓頭螺絲
110044
M
2×8
screw
×2
圓頭螺絲
(
半牙
)
110045
M
2
.
5×30
screw
×2
有頭螺絲
(
半牙
)
110053
M
3×8
screw
×19
圓頭螺絲
110002
M
1
.
6×4
screw
×4
有頭螺絲
110039
M
2×6
screw
×4
沉頭螺絲
110042
M
2
.
5×6
screw
×6
圓頭螺絲
110003
M
2×4
screw
×8
圓頭螺絲
110004
M
3×5
screw
×3
扁頭螺絲
110051
M
3×11
screw
×4
扁頭螺絲
110012
M
3×6
screw
×10
圓頭螺絲
110001
M
3×5
screw
×4
沉頭螺絲
110041
2×22
shaft
×2
插銷
310047
Coil spring
28
mm
(
gold
)
×4
避震彈簧
28
mm
(
金
)
210144
-
2
Cylinder cap
×4
避震器上蓋
210057
Rod guide cap
×4
避震器下蓋
210057
Damper retainer
×4
避震器彈簧座
820079
Oil seal
×4
避震器氣室
130004
Rod guide
(
BK
)
×4
避震器下蓋墊片
(
黑
)
210082
Piston
(
BK
)
×4
避震活塞
(
黑
)
210082
Damper adjuster
×4
避震器拉桿
820079
Damper O
-
ring P
3
×4
避震器
O
環
130025
E
-
clip
×8
E
形扣
110013
10
.
8×0
.
9
O
-
ring
×4
O
環
130032
Piston rod
×4
避震軸心
310008
M
3×12
screw
×4
圓頭螺絲
110029
Bevel gear
-
short shaft
×1
傘齒短軸
310031
Diff. spring
×1
滾差彈簧
310032
Steel ball
3
.
0×10
鋼珠
3
.
0
110020
Steel ball
1
.
5×8
鋼珠
1
.
5
120008
Wheel axle
×4
萬向接杯
310006
Steel CVA universal shaft
44×4
鋼製
CVA
傳動軸
44
310051
R
-
clip
×4
R
形扣
110016
M
4
Wheel nut
×4
輪框螺帽
110015
Damper cylinder
×4
避震筒身
210071
Spring retainer
×4
避震器調整環
310053
M
3×25
screw
×5
止付螺絲
110008
M
2
.
5×2
.
5
screw
×2
止付螺絲
110067
M
3×3
screw
×3
止付螺絲
110035
M
3×8
screw
×6
止付螺絲
110054
PARTS
M
3×25
screw
×2
圓頭螺絲
110076
3×7
screw
×1
自攻六角沉頭螺絲
3×7
110075
Diff. plate
×2
滾差壓板
310033
PARTS
XXX Adjuster & servo mount set
×2
XXX
拉桿頭
&
伺服機座
210095
×2
×5×2
×1×1
Joint set
×2
接杯組
210040
XXX lower beck
XXX
底盤
210099
XXX Upper deck & battery strap
XXX
二樓板
&
電池壓板組
210100
CS
-
R tire
×4
CS
-
R
甩尾胎
101024
XXX Eccentric motor mount set
XXX
偏心式馬達座組
210098
XXX Gear dust cover & brace
XXX
齒箱防塵殼
&
補強架
210097
XXX Front damper stay
XXX
前避震架
230001
XXX Rear damper stay
XXX
後避震架
230002

7
XXX-D RTR
PARTS
XXX Adjuster & servo mount set
×2
XXX
拉桿頭
&
伺服機座
210095
×2
×5×2
×1×1
Joint set
×2
接杯組
210040
XXX lower beck
XXX
底盤
210099
XXX Upper deck & battery strap
XXX
二樓板
&
電池壓板組
210100
CS
-
R tire
×4
CS
-
R
甩尾胎
101024
XXX Eccentric motor mount set
XXX
偏心式馬達座組
210098
XXX Gear dust cover & brace
XXX
齒箱防塵殼
&
補強架
210097
XXX Front damper stay
XXX
前避震架
230001
XXX Rear damper stay
XXX
後避震架
230002

8
XXX-D RTR
PARTS
HT Lower arm
HT
下擺臂
210054
6
.
2×2
Sponge
×2
泡棉
130021
10×15
Ball bearing
×8
培林
120001
8×14
Ball bearing
×2
培林
120007
5×11
Ball bearing
×4
培林
120011
5×8
Bearing
×2
軸承
120017
5×10
Ball bearing
×3
培林
120002
KPI Upright set
KPI
輪座組
210060
5
.
8×26
Reinforced adjuster set
強化拉桿頭組
210031
RM Bevel gear dust cover
×2
後置傘齒防塵殼
210030
XXX Alum. center one way RM
XXX
鋁合金中單組
RM
(
210487
)
Bevel gear box set
×2
傘齒座組
210041
Lower arm mount +
0
.
5×2
下擺臂座
+
0
.
5
210084
Lower arm mount
-
0
.
5×1
下擺臂座
-
0
.
5
210083
Lower arm mount +
2
.
5×1
下擺臂座
+
2
.
5
210086
Bumper
防撞泡棉
130020
HT Upper arm
HT
上擺臂
210058
HT rear lower arm & wheel hub
×2
HT
後下擺臂
&
輪座
210055
Body post extension mount
4
mm
車殼柱延伸座
4
mm
210029
PARTS
C PARTS
-
bumper set
C PARTS
-
防撞板組
210002
Spur gear
48
P
-
74
T
大直齒
48
P
-
74
T
210096
Brake calipers
(
red
)
煞車卡鉗 (紅)
210145
CR
Wheel hubs w
/
disc shape
碟型六角輪座組
210043
Gear holder steering rail set
齒座搖臂滑軌組
210042
Gear box cover set
齒箱上蓋組
210039
HT Gear box cover set
HT
齒箱上蓋組
210064
Servo horn set
(
long
)(
23
T
/
25
T
)
伺服機舵片組
(
長
)(
23
T
/
25
T
)
210033
Spool parts set
直軸配件組
210056
XXX Alum. propeller shaft
×1
鋁合金中傳軸
(
210219
)
Rail pulley spacer set
(
BK
)
滑軌滑輪墊片組
(
黑
)
210037
BK
Shaft bush & spacer set
(
white
)
襯套墊片組
(
白
)
210063
W
Bevel gear set
(
40
-
16
)
傘齒組
(
40
-
16
)
210025
Bevel gear set
(
34
-
18
)
傘齒組
(
34
-
18
)
210069

9
XXX-D RTR
PARTS
C PARTS
-
bumper set
C PARTS
-
防撞板組
210002
Spur gear
48
P
-
74
T
大直齒
48
P
-
74
T
210096
Brake calipers
(
red
)
煞車卡鉗 (紅)
210145
CR
Wheel hubs w
/
disc shape
碟型六角輪座組
210043
Gear holder steering rail set
齒座搖臂滑軌組
210042
Gear box cover set
齒箱上蓋組
210039
HT Gear box cover set
HT
齒箱上蓋組
210064
Servo horn set
(
long
)(
23
T
/
25
T
)
伺服機舵片組
(
長
)(
23
T
/
25
T
)
210033
Spool parts set
直軸配件組
210056
XXX Alum. propeller shaft
×1
鋁合金中傳軸
(
210219
)
Rail pulley spacer set
(
BK
)
滑軌滑輪墊片組
(
黑
)
210037
BK
Shaft bush & spacer set
(
white
)
襯套墊片組
(
白
)
210063
W
Bevel gear set
(
40
-
16
)
傘齒組
(
40
-
16
)
210025
Bevel gear set
(
34
-
18
)
傘齒組
(
34
-
18
)
210069

10
XXX-D RTR
Front rollcenter
Front lower arm
Front damper
Front wheel hubs Steering railCaster Rear wheel hubs
Front damper stay Front upright Rear upright
Length: mm
Spring: mm
Piston:
mm
Shock oil:
Piston hole:
Spring color:
Length: mm
Spring: mm
Piston:
mm
Shock oil:
Piston hole:
Spring color:
Rear rollcenter
Rear lower arm
Gear diff.
Diff. oil________
Ball diff.
Spool
Alum. one way
Ball diff.
Alum. spool
Alum. spool
Alum. center one way
Rear diff.
31 2 4 5 6
FRONT REAR
Tire:____________
______________
_
Wheel:_________
_______________
_
Offset:________________
Tire:_____________
_______________
Wheel:
_ _________
________________
_
Offset:
_
________________
Rear damper stay
Rear damper
16°
12°
Universal rail
Alum. rail
8°
Camber:
Toe-in:
Ride height: mm
mm
°
°
GROUND
mm
mm
mm
mm
Length Length
Camber:
Toe-in:
Ride height: mm
mm
GROUND
°
°
mm mm
mm
Gear diff.
Diff. oil________
Front diff.
1
1
2
3
4
2
3
4
mm
mm
Motor & ESC: ___________________________ Battery: _________________
Gear ratio: ( Spur: _____T / Pinion: _____T )×1.89 2.12 2.50 =
________
CS ratio: front ( 2.12 2.5 3.08 3.82) / rear ( 1.89 2.12 2.5) = _______
E
E
C
A
E
E
E
C
C
C
A
A
A8°
12°
16°
CASTER UPPER ARM
0
0 0
0
0
21 3 4 5
XXX-D
RTR
ATE :
TRACK :GRIP
:
SURFACE :NOTE
:
SETUP SHEET
1
/
10
SCALE RC HIGH PERFORMANCE DRIFT CAR
5
+3 -3
5
0
0
0
5
6
0
#
300 # 300
62 62
28 283 3
o
1
12
.
o
1
12
.
o
1
12
.
o
1
12
.
gold gold
0
Suspension mount
.
+05 . -05
.
+05 . +25
＊ FORMULA
計算公式
終傳比
大直齒
馬達齒
Spur gear teeth
Gear ratio
Pinion gear teeth ×=
()
大傘齒
小傘齒
Diff. ring gear
Diff. pinion gear
SPUR GEAR
大直齒
PINION GEAR
馬達齒
CS RATIO
後齒箱
1:1.12 1:1.32 1:1.63 1:2.02
1:1 1:1.18 1:1.45 1:1.80
1:1 1:1.23 1:1.53
FRO N T G E A R B O X
前齒箱
二次減速比
210034
210069
210034
210025
PARTS CODE
210025 210035 210036
1:1.19 1:1.40 1:1.73 1:2.15
210362
REAR GEAR BOX
2nd REDUCTION RATE
34T
/
18T
<
1.89
>
36T
/
17T
<
2.12
>
40T
/
16T
<
2.50
>
32T
/
18T
<
1.78
>
2.12
36T
/
17 T
2.50
40T
/
16 T
3.08
40T
/
13 T
3.82
42T
/
11 T
GEAR RATIO
(
For
48
P Spur Gear
)
FINAL DRIVE
32T
/
18T
<
1.78
>
7.74
7.31
6.92
6.58
6.26
5.98
5.72
5.48
5.06
5.26
6.74
6.40
6.10
5.82
5.57
5.33
5.12
4.92
5.93
5.66
5.41
5.19
4.98
4.79
5.26
5.04
4.84
4.65
68T
17T
18T
19T
20T
21T
22T
23T
24T
25T
26T
70T 72T 74T
FINAL DRIVE 34T
/
18T
<
1.89
>
8.22
7.77
7.36
6.99
6.66
6.35
6.08
5.82
5.38
5.59
7.16
6.80
6.48
6.18
5.91
5.67
5.44
5.23
6.30
6.01
5.75
5.51
5.29
5.09
5.58
5.35
5.14
4.94
68T
17T
18T
19T
20T
21T
22T
23T
24T
25T
26T
70T 72T 74T
FINAL DRIVE 36T
/
17T
<
2.12
>
9.22
8.71
8.25
7.84
7.46
7.12
6.81
6.53
6.03
6.27
8.02
7.62
7.26
6.93
6.63
6.35
6.10
5.86
7.06
6.74
6.45
6.18
5.93
5.70
6.26
6.00
5.76
5.54
68T
17T
18T
19T
20T
21T
22T
23T
24T
25T
26T
70T 72T 74T
FINAL DRIVE 40T
/
16T
<
2.50
>
10.88
10.28
9.74
9.25
8.81
8.41
8.04
7.71
7.12
7.40
9.47
9.00
8.57
8.18
7.83
7.50
7.20
6.92
8.33
7.95
7.61
7.29
7.00
6.73
7.39
7.08
6.80
6.54
68T
17T
18T
19T
20T
21T
22T
23T
24T
25T
26T
70T 72T 74T
GEAR RATIO
& CS RATIO
XXX-D
RTR
1
/
10
SCALE RC HIGH PERFORMANCE DRIFT CAR

11
XXX-D RTR
＊ FORMULA
計算公式
終傳比
大直齒
馬達齒
Spur gear teeth
Gear ratio
Pinion gear teeth ×=
()
大傘齒
小傘齒
Diff. ring gear
Diff. pinion gear
SPUR GEAR
大直齒
PINION GEAR
馬達齒
CS RATIO
後齒箱
1:1.12 1:1.32 1:1.63 1:2.02
1:1 1:1.18 1:1.45 1:1.80
1:1 1:1.23 1:1.53
FRO N T G E A R B O X
前齒箱
二次減速比
210034
210069
210034
210025
PARTS CODE
210025 210035 210036
1:1.19 1:1.40 1:1.73 1:2.15
210362
REAR GEAR BOX
2nd REDUCTION RATE
34T
/
18T
<
1.89
>
36T
/
17T
<
2.12
>
40T
/
16T
<
2.50
>
32T
/
18T
<
1.78
>
2.12
36T
/
17 T
2.50
40T
/
16 T
3.08
40T
/
13 T
3.82
42T
/
11 T
GEAR RATIO
(
For
48
P Spur Gear
)
FINAL DRIVE
32T
/
18T
<
1.78
>
7.74
7.31
6.92
6.58
6.26
5.98
5.72
5.48
5.06
5.26
6.74
6.40
6.10
5.82
5.57
5.33
5.12
4.92
5.93
5.66
5.41
5.19
4.98
4.79
5.26
5.04
4.84
4.65
68T
17T
18T
19T
20T
21T
22T
23T
24T
25T
26T
70T 72T 74T
FINAL DRIVE 34T
/
18T
<
1.89
>
8.22
7.77
7.36
6.99
6.66
6.35
6.08
5.82
5.38
5.59
7.16
6.80
6.48
6.18
5.91
5.67
5.44
5.23
6.30
6.01
5.75
5.51
5.29
5.09
5.58
5.35
5.14
4.94
68T
17T
18T
19T
20T
21T
22T
23T
24T
25T
26T
70T 72T 74T
FINAL DRIVE 36T
/
17T
<
2.12
>
9.22
8.71
8.25
7.84
7.46
7.12
6.81
6.53
6.03
6.27
8.02
7.62
7.26
6.93
6.63
6.35
6.10
5.86
7.06
6.74
6.45
6.18
5.93
5.70
6.26
6.00
5.76
5.54
68T
17T
18T
19T
20T
21T
22T
23T
24T
25T
26T
70T 72T 74T
FINAL DRIVE 40T
/
16T
<
2.50
>
10.88
10.28
9.74
9.25
8.81
8.41
8.04
7.71
7.12
7.40
9.47
9.00
8.57
8.18
7.83
7.50
7.20
6.92
8.33
7.95
7.61
7.29
7.00
6.73
7.39
7.08
6.80
6.54
68T
17T
18T
19T
20T
21T
22T
23T
24T
25T
26T
70T 72T 74T
GEAR RATIO
& CS RATIO
XXX-D
RTR
1
/
10
SCALE RC HIGH PERFORMANCE DRIFT CAR

026100
PARTS CODE
110001
110002
110003
110004
110005
110008
110012
110013
110015
110016
110017
110019
110020
110026
110029
110035
110039
S
110041
110042
110044
110045
Round head screw M
3
X
6
(
10
)
Round head screw M
3
X
8
(
10
)
Round head screw M
2
.
5
X
6
(
6
)
Round head screw M
2
X
4
(
6
)
Countersunk screw M
3
X
8
(
10
)
Set screw M
3
X
25
(
6
)
Flat head screw M
3
X
11
(
10
)
E
-
clip
2
.
0
(
10
)
Flange nut M
4
(
4
)
R
-
clip
6
.
0
(
10
)
Shaft
2
X
9
.
8
(
10
)
Shaft
2
X
11
.
8
(
5
)
Steel ball
3
.
0
(
13
)
Round head screw M
3
X
10
(
10
)
Round head screw M
3
X
12
(
6
)
Set screw M
3
X
3
(
6
)
Cap screw M
1
.
6
X
4
(
10
)
Countersunk screw M
3
X
5
(
10
)
Countersunk screw M
2
X
6
(
6
)
Round head screw M
2
X
6
(
6
)
Round head screw M
2
X
8
(
partial thread
) (
6
)
110046
110047
110048
110051
110053
110054
110061
110067
110075
110076
120001
120002
120007
120008
120011
120017
130004
130007
130017
130020
130021
130025
Shaft
2
X
9
.
8
(
8
)
Spacer
3
X
6
X
0
.
5
(
8
)
Spacer
3
X
8
X
0
.
5
(
8
)
Flat head screw M
3
X
5
(
5
)
Cap screw M
2
.
5
X
30
(
2
)
Set screw M
3
X
8
(
10
)
Round head screw M
3
X
14
(
6
)
Set screw M
2
.
5
X
2
.
5
(
6
)
Tapping flat head screw
3
X
7
(
10
)
Round head screw M
3
X
25
(
6
)
Ball bearing
10
X
15
(
4
)
Ball bearing
5
X
10
(
4
)
Ball bearing
8
X
14
(
2
)
Thrust bearing
2
.
5
X
6
Ball bearing
5
X
11
(
4
)
Bearing
5
X
8
(
4
)
Oil seal
(
4
)
Antenna pipe
(
2
)
Inner sponge
(
8
)
Bumper
(
B
)
Sponge
6
.
5
X
2
(
10
)
O
-
ring P
4
(
red
) (
8
)
130032
130034
130035
130036
148021
210002
210003
210025
210029
210030
210031
210033
210037
210039
210040
210041
210042
210043
210054
210055
210056
210057
Damper cap O
-
ring
(
10
)
Sponge
20
X
80
X
1
(
4
)
L Wrench set
(
1
.
5
&
2
.
0
&
2
.
5
)
Tools
MST
48
P Pinion gear
21
T
C PARTS
-
bumper set
D PARTS
-
ball connector
Bevel gear set
40
-
16
Body post extension mount
4
mm
RM Bevel gear dust cover
Reinforced adjuster set
5
.
8
X
26
Servo horn set
(
long
) (
23
T
/
25
T
)
Rail pulley spacer set
Gear box cover set
Joint set
Bevel gear box set
Gear holder steering rail set
Wheel hubs w
/
disc shape
HT Lower arm
HT Rear lower arm & wheel hub
Spool parts set
Damper cap set
210058
210060
210064
210069
210071
210082
210083
210084
210086
210095
210096
210097
210098
210099
210100
210145
210487
R
230001
230002
230011
SG
230012
SG
310006
HT Upper arm
KPI Upright set
HT Gear box cover set
Lightweight bevel gear set
34
-
18
Damper cylinder
(
2
)
Piston spacer set
Lower arm mount
-
0
.
5
Lower arm mount +
0
.
5
Lower arm mount +
2
.
5
XXX Adjuster & servo mount set
Spur gear
48
P
-
74
T
XXX Gear dust cover & brace
XXX Eccentric motor mount set
XXX Lower deck
XXX Upper deck & battery strap
Brake calipers
(
4
)
XXX Alum. center one way RM
(
red
)
XXX Front damper stay
XXX Rear damper stay
Silver grey
5
H wheel
(
+
1
) (
4
)
Silver grey TE wheel
(
+
1
) (
4
)
Wheel axle
(
2
)
310008
310029
310031
310032
310033
310046
310047
310048
310051
310053
R
310054
310055
820013
820020
820024
820079
210063
W
210144
-
2
210219
R
Piston rod
(
4
)
Rail post
(
2
)
Bevel gear
-
short arbor
Diff. screw & spring set
Diff. plate
(
2
)
Arm shaft
2
.
5
X
20
(
2
)
Arm shaft
2
.
0
X
22
(
2
)
Arm shaft
2
.
5
X
46
(
4
)
CVA Swing shaft
44
(
2
)
Spring retainer
(
red
) (
2
)
Copper ball connector
4
.
8
X
4
.
5
(
4
)
Copper hex ball
4
.
8
(
4
)
Spacer
3
X
5
X
0
.
2
(
8
)
Spacer
5
X
7
X
0
.
3
(
8
)
Spacer
10
X
12
X
0
.
3
(
8
)
Damper plastic maintenance set
(
2
)
Shaft bush & spacer set
(
white
)
Coil spring set
28
mm
(
medium
) (
gold
) (
2
)
XXX Alum. propeller shaft
(
red
)
OPTION PARTS CODE
210102
R
210115
R
210142
R
210143
210144
210145
R
210213
210215
Alum. one way unit
(
red
)
Alum. damper set
(
red
) (
4
)
Alum. bumper support
(
red
)
Alum. wheel hubs
6
mm
(
brake disc shaped
)
Coil spring set
28
mm
Brake calipers
(
red
) (
4
)
XXX Carbon front damper stay
3
.
5
XXX Carbon upper deck
2
.
5
210221
R
210223
R
210227
R
210228
R
210230
R
210232
210234
R
210238
210257
R
XXX Alum. one way unit
(
RM
) (
red
)
XXX Alum. spool unit
(
red
)
XXX Alum. upper deck support
(
red
)
XXX Alum. connecter
(
red
)
XXX Alum. spur gear holder
(
red
)
XXX Alum. steering rail set
XXX Alum. gear box cover
(
red
)
Alum. propeller shaft joint
(
2
)
XXX
-
D PRO Alum. gear box
(
red
)
210261
210381
210282
210288
210323
R
210353
210354
R
210357
210379
XXX Carbon rear damper stay
(
widen
)
Car body post set
MST Diffuser
XXX Reinforced bevel diff. assembly
XXX Alum. gear box cover set
(
HT
-
F
) (
red
)
FXX Alum. ball diff.
HT Alum. rear upright
(
red
) (
2
)
XXX
-
HT Rear stabilizer set
Rear bumper
210399
R
210410
R
210416
R
210456
210457
R
820005
820029
R
820043
R
820044
R
XXX Alum. lightweight propeller shaft set
(
red
)
XXX Alum. slide rack steering set
(
red
)
FXX
/
XXX
-
D S Alum. lower arm mount set
(
red
)
XXX
-
D S Ball connector set
XXX
-
D S Turnbuckle shaft set
(
red
)
Steel CVD great angle universal shaft
44
(
2
)
KPI Alum. upright
(
red
) (
2
)
Alum. hex. wheel hubs
5
mm
(
red
) (
4
)
Alum. hex. wheel hubs
4
mm
(
red
) (
4
)
820046
R
820057
R
820060
R
820064
R
820076
R
820089
Alum. damper retainer
(
lower type
) (
4
) (
red
)
Adjustable alum. suspension mount
(
-
0
.
5
-
+
1
.
0
) (
red
)
HT Alum. front lower arm set
(
red
)
HT Alum. rear lower arm set
(
red
)
Alum. short servo mount set
(
red
)
Alum. adjustable shock upper end
(
4
)
110001
110002
110003
110004
110005
110008
110012
110013
110015
110016
110017
110019
110020
110026
110029
110035
110039
S
110041
110042
110044
110045
110046
六角半圓頭螺絲
M
3
X
6
(
10
)
六角半圓頭螺絲
M
3
X
8
(
10
)
六角半圓頭螺絲
M
2
.
5
X
6
(
6
)
六角半圓頭螺絲
M
2
X
4
(
6
)
六角沉頭螺絲
M
3
X
8
(
10
)
六角止付螺絲
M
3
X
25
(
6
)
十字扁頭螺絲
M
3
X
11
(
10
)
E
扣
2
.
0
(
10
)
凸緣螺帽
M
4
(
4
)
R
銷
6
.
0
(
10
)
插銷
2
X
9
.
8
(
10
)
插銷
2
X
11
.
8
(
5
)
差速鋼珠
3
.
0
(
13
)
六角半圓頭螺絲
M
3
X
10
(
10
)
六角半圓頭螺絲
M
3
X
12
(
6
)
六角止付螺絲
M
3
X
3
(
6
)
六角有頭螺絲
M
1
.
6
X
4
(
10
)
六角沉頭螺絲
M
3
X
5
(
10
)
六角沉頭螺絲
M
2
X
6
(
6
)
六角半圓頭螺絲
M
2
X
6
(
6
)
六角半圓頭螺絲
M
2
X
8
(
半牙
) (
6
)
插銷
2
X
9
.
8
(
剖溝
) (
8
)
110047
110048
110051
110053
110054
110061
110067
110075
110076
120001
120002
120007
120008
120011
120017
130004
130007
130017
130020
130021
130025
130032
墊片
3
X
6
X
0
.
5
(
8
)
墊片
3
X
8
X
0
.
5
(
8
)
十字扁頭螺絲
M
3
X
5
(
5
)
六角有頭螺絲
M
2
.
5
X
30
(
半牙
) (
2
)
六角止付螺絲
M
3
X
8
(
10
)
六角半圓頭螺絲
M
3
X
14
(
6
)
六角止付螺絲
M
2
.
5
X
2
.
5
(
6
)
自攻六角沉頭螺絲
3
X
7
(
10
)
六角半圓頭螺絲
M
3
X
25
(
6
)
培林
10
X
15
(
4
)
培林
5
X
10
(
4
)
培林
8
X
14
(
2
)
止推培林
2
.
5
X
6
培林
5
X
11
(
4
)
軸承
5
X
8
(
4
)
避震氣室
(
4
)
天線管
(
2
)
吸震泡棉
(
8
)
防撞泡棉
(
B
)
泡棉
6
.
5
X
2
(
10
)
O
環
P
4
(
紅
) (
8
)
避震上蓋
O
環
(
10
)
130034
130035
130036
148021
210002
210003
210025
210029
210030
210031
210033
210037
210039
210040
210041
210042
210043
210054
210055
210056
210057
210058
吸震泡棉
20
X
80
X
1
(
4
)
L
板手組
(
1
.
5
&
2
.
0
&
2
.
5
)
工具包
MST
48
P
馬達齒
21
T
C PARTS
-
防撞板組
D PARTS
傘齒組
40
-
16
車殼柱延伸座
4
mm
RM
傘齒防塵殼
強化拉桿頭組
5
.
8
X
26
伺服機舵片組
-
長
(
23
T
/
25
T
)
滑軌滑輪墊片組
齒箱上蓋組
接杯組
傘齒座組
齒座搖臂滑軌組
碟型六角輪座組
HT
下擺臂
HT
後下擺臂
&
輪座
塑膠直軸配件組
避震器上下蓋組
HT
上擺臂
210060
210064
210069
210071
210082
210083
210084
210086
210095
210096
210097
210098
210099
210100
210145
210487
R
230001
230002
230011
SG
230012
SG
310006
310008
KPI
輪座組
HT
齒箱上蓋組
輕量化傘齒組
34
-
18
避震器筒身
(
2
)
避震器活塞墊片組
下擺臂座
-
0
.
5
下擺臂座
+
0
.
5
下擺臂座
+
2
.
5
XXX
拉桿
&
伺服機座
大齒盤
48
P
-
74
T
XXX
齒箱防塵殼
&
補強架
XXX
偏心式馬達座組
XXX
底盤
XXX
二樓板
&
電池壓板組
煞車卡鉗
(
4
)
XXX
鋁合金中單組
RM
(
紅
)
XXX
前避震架
XXX
後避震架
銀灰5
H
輪框
(
+
1
) (
4
)
銀灰
TE
輪框
(
+
1
) (
4
)
萬向接杯
(
2
)
避震軸心
(
4
)
310029
310031
310032
310033
310046
310047
310048
310051
310053
R
310054
310055
820013
820020
820024
820079
210063
W
210144
-
2
210219
R
滑軌支柱
(
2
)
傘齒短軸
滾差彈簧螺絲組
滾差壓板
(
2
)
擺臂插銷
2
.
5
X
20
(
2
)
擺臂插銷
2
.
0
X
22
(
2
)
擺臂插銷
2
.
5
X
46
(
4
)
CVA
傳動軸
44
(
2
)
避震器調整環
(
紅
) (
2
)
銅製內六角公球頭
4
.
8
X
4
.
5
(
4
)
銅製外六角球頭
4
.
8
(
4
)
墊片
3
X
5
X
0
.
2
(
8
)
墊片
5
X
7
X
0
.
3
(
8
)
墊片
10
X
12
X
0
.
3
(
8
)
避震膠件包
(
2
)
襯套墊片組
(
白
)
避震彈簧
28
mm
(
中
) (
金
) (
2
)
XXX
鋁合金中傳軸
(
紅
)
部品編號
210102
R
210115
R
210142
R
210143
210144
210145
R
210213
210215
210221
R
鋁合金前單向組
(
紅
)
鋁合金避震器組
(
紅
) (
4
)
鋁合金防撞板上蓋
(
紅
)
鋁合金六角輪座
6
mm
(
煞車碟型
)
避震彈簧組
28
mm
煞車卡鉗
(
電鍍紅
) (
4
)
XXX
碳纖維前避震架
3
.
5
XXX
碳纖維二樓板
2
.
5
XXX
鋁合金前單組
(
後置
) (
紅
)
210223
R
210227
R
210228
R
210230
R
210232
210234
R
210238
210257
R
210261
XXX
鋁合金直軸組
(
紅
)
XXX
鋁合金二樓板連結座
(
紅
)
XXX
鋁合金連結架
(
紅
)
XXX
鋁合金大齒盤座
(
紅
)
XXX
鋁合金大轉向滑軌組
XXX
鋁合金齒箱上蓋
(
紅
)
鋁合金中軸接杯
(
2
)
XXX
-
D PRO
鋁合金傘齒箱
(
紅
)
XXX
碳纖維後避震架
(
加寬
)
210381
210282
210288
210323
R
210353
210354
R
210357
210379
210399
R
車殼支柱組
MST
後擾流板
XXX
強化式傘齒總成組
XXX
鋁合金齒箱上蓋組
(
HT
-
F
) (
紅
)
FXX
鋁合金滾珠差速器
HT
鋁合金後輪座
(
紅
) (
2
)
XXX
-
HT
後防傾桿組
後防撞板
XXX
鋁合金輕量化中傳軸組
(
紅
)
210410
R
210416
R
210456
210457
R
820005
820029
R
820043
R
820044
R
820046
R
XXX
鋁合金轉向滑軌組
(
紅
)
FXX
/
XXX
-
D S
全車鋁合金下擺臂座
(
紅
)
XXX
-
D S
高順暢球頭組
XXX
-
D S
全車可調拉桿組
(
紅
)
鋼製大角度
CVD
傳動軸
44
(
2
)
KPI
鋁合金輪座
(
紅
) (
2
)
鋁合金六角輪座
5
mm
(
紅
) (
4
)
鋁合金六角輪座
4
mm
(
紅
) (
4
)
鋁合金彈簧座
(
降低型
) (
4
) (
紅
)
820057
R
820060
R
820064
R
820076
R
820089
可調式鋁合金擺臂座
(
-
0
.
5
-
+
1
.
0
) (
紅
)
HT
鋁合金前下擺臂組
(
紅
)
HT
鋁合金後下擺臂組
(
紅
)
鋁合金短伺服機座組
(
紅
)
鋁合金避震器可調上座
(
4
)
改裝品編號
www.rc-mst.com
EXPLODED
MANUAL
Please add color remark for
( )
part number.
e.g.
210123
R for Red
(
210123
)
請增加顏色標示在
( )
編號
例
:
210123
R for
紅色
(
210123
)
Color 顏色 Red 紅
Remark 標示 R
XXX-D
RTR
1
/
10
SCALE RC HIGH PERFORMANCE DRIFT CAR
