MTD CC4165 Manual

21
25
27
29
3
30
31
28
22
35
36
38
26
37
40
42
41
43
17
20
45
44
1
46
39
7
6
5
4
3
89
10 711 12 13 14
16
15 14
2
34
23
24
32
33
33
18
19
3
REPLACEMENT PARTS - MODEL CC4165
4-CYCLE GAS TRIMMER
PARTS LIST PART NO. 769-03280 9/07

REPLACEMENT PARTS - MODEL CC4165
4-CYCLE GAS TRIMMER
Issued 9/07
Item Part No. Description
1 753-05449 Engine Cover
2 791-181345 Screw
3 753-05377 Screw
4 753-05209 Valve Cover
5 753-05210 Valve Cover Gasket
6 753-05438 Cylinder Assembly (includes 5, 7 & 40)
7 791-181003 Cylinder Screw
8 753-05247 Insulator Gasket
9 753-05248 Nut
10 753-05452 Insulator (includes 11)
11 753-05439 Carburetor Gasket
12 753-05440 Carburetor w/Primer
13 791-181751 Carburetor O-Ring
14 753-05441 Air Filter Cover Assembly (includes 16)
15 753-05253 Air Filter Mounting Screw
16 753-05442 Air Filter
17 753-05289 Fuel Cap
18 791-181930 Screw
19 791-182366 Clip Nut
20 753-05443 Fuel Tank Assembly (includes 17)
21 753-05444 Muffler Assembly (includes 22 & 23)
22 753-05244 Muffler Gasket
23 753-05246 Muffler Mounting Screw
24 753-05264 Lead Wire
25 753-05445 Starter Housing Assembly (includes 3, 19 & 26-29)
26 753-1202 Plate Screw
27 753-05260 Push Nut
28 791-613103 Rope
29 791-181079 Pull Handle
Item Part No. Description
30 753-05446 Clutch Cover Assembly (includes 31-33)
31 791-181345 Cover Screw
32 791-182519 Anti-Rotation Screw
33 753-04291 Clamping Screw Assembly
34 753-05447 Ignition Module Assembly
35 791-610303 Square Nut Drive
36 753-05240 Flywheel
37 791-181861 Shroud Screw
38 753-04919 Cam Bracket Assembly (includes 39)
39 791-181012 Cam Bracket Screw
40 791-182374 Cylinder Gasket
41 791-182377 Oil Pan (includes 42 & 43)
42 791-181018 Oil Pan Gasket
43 791-181020 Oil Pan Screw
44 791-182378 Dipstick Assembly (includes 45)
45 791-182290 O-Ring
46 753-05458 Piston Assembly
* 791-180852B Spark Plug
* 753-05459 Shortblock Assembly (includes 3-7 & 34-46)

Item Part No. Description
1 753-04234 Throttle Housing Assembly (includes 2-4)
2 753-04119 Throttle Trigger
3 791-182690 Throttle Trigger Spring
4 791-182405 Switch
5 753-05266 Throttle Cable Assembly
6 753-05186 Upper Drive Shaft Housing Assembly
7 791-180869 Deluxe D-Handle Assembly (includes 8-10)
8 791-181070 Screw
9 791-182167 Deluxe D-Handle
10 791-182168 Bottom Clamp
11 753-05184 Flexible Drive Shaft
12 791-145569 Anti-Rotation Screw
13 753-05183 Gear Box Assembly (includes 17-21)
14 791-180547 Shield Mounting Hardware
15 791-180548 Shield Assembly (includes 16)
16 791-682061 Blade Assembly
17 791-153619 Outer Spool Assembly (includes 18)
18 791-610660 Retainer
19 791-610317B Spring
20 753-1155 Inner Reel
21 791-153066B Bump Head Knob Assembly
Optional Accessories
* 791-180120 Replacement Line, 0.095 Diameter
* 753-1156 Reel and Line Assembly
* Items Not Shown
1
1
9
7
8
10
6
3
2
13
11
15
17
18
12
14
16
21
19
20
5
4
14
REPLACEMENT PARTS - MODEL CC4165
4-CYCLE GAS TRIMMER
Issued 9/07
