MTD Y28VP Manual

Item Part No. Description
22 791-181079 Pull Handle
23 791-182661 Rope
24 791-181862 Housing Screw
25 791-181345 Cover Screw
26 791-181936 Wire Lead
27 753-05992 Starter Housing Assembly (includes 22-25)
28 791-182441 Switch
29 753-05091 Shroud Extension and Stand (includes 25)
30 753-04109 Module Assembly
31 791-610311B Spark Plug
32 753-04619 Exhaust Gasket
33 753-04620 Muffler Mounting Bolt
34 753-05169 Muffler Assembly (includes 32 & 33)
35 753-04367 Piston & Rod Assembly
36 791-182723 Cylinder Bolt
37 753-04182 Cylinder Gasket
38 753-04814 Cylinder Assembly (includes 36 & 37)
39 791-153597 Clamp Assembly
40 791-145569 Screw
* 753-1209 Piston Ring Set
* 753-04826 Short Block Assembly
(includes Crankcase, 9, 32 & 35-38)
* not shown
Item Part No. Description
1 753-04511 Air Cleaner Cover Assembly (includes 2 & 25)
2 791-180350B Air Cleaner Filter
3 791-180351 Carburetor Mounting Screws
4 791-180226 Wavey Washer
5 753-04418 Choke Lever Assembly
6 753-04419 Choke Lever & Plate (includes 5)
7 753-04408 Carburetor Assembly (includes 8 & 17)
8 791-610675 Carburetor Gasket
9 791-181860 Carb Mount Screw
10 791-683974B Primer and Hose Assembly
11 753-1196 Carburetor Mount Assembly (includes 9, 12 & 13)
12 791-684451 Reed Assembly
13 753-05487 O-Ring
14 791-612134 Rear Mounting Pad
15 791-182612 Fuel Cap Assembly
16 791-181086 Fuel Return Line
17 791-682039 Fuel Line Assembly
18 753-04306 Fuel Tank Assembly (includes 15-17)
19 791-145308 Front Mounting Pad
20 753-05240 Flywheel Assembly
21 791-610303 Square Nut Drive
1
2
37
11
4
6
5
10
12
13
38
37
19
36
16
14
15
18
17
20
21
25
26
27
29
34
33 23
8
35
32
22
30
9
25
31
REPLACEMENT PARTS - MODEL Y28VP
2-CYCLE GAS ENGINE
PPN 41ADYVPG900
PARTS LIST PART NO. 769-04253 Isssued 8/08
24
39
40
28

REPLACEMENT PARTS - MODEL Y28VP
2-CYCLE GAS TRIMMER
PPN 41ADYVPG900
Item Part No. Description
1 753-04927 Throttle Housing and Trigger Assembly
(includes 2-4)
2 791-610314 Throttle Trigger Spring
3 791-181807 Throttle Trigger
4 753-04917 Throttle Housing Screws
5 753-04901 Throttle Cable
6 753-04280 Flexible Drive Shaft
7 753-04921 Drive Shaft Housing
8 791-153064 D-Handle Assembly (includes 9)
9 791-181587 D-Handle Hardware
10 753-04282 Guard Mounting Hardware
11 753-04283 Guard
12 791-180553 Blade Assembly
13 753-04284 Outer Reel w/Retainer
14 791-610317B Spring
15 753-1155 Inner Reel
16 791-153066B Bump Knob
* 753-04281 Drive Shaft Housing Assembly
(includes 6, 7 & 13)
Optional Accessories
* 791-153577B Inner Reel and Line
* 791-682075B Shoulder Strap Assembly
* Items Not Shown
1
5
6
1
4
3
2
9
9
8
7
10
12
12
11
10
14
15
16
13
Issued 8/08
