MTD Yard Machines Y765 Manual

Item Part No. Description
20 791-182405 Switch Assembly
21 791-181862 Housing Screw
22 791-181345 Cover Screw
23 753-05023 Wire Lead
24 753-06169 Starter Housing Assembly (includes 20-23)
25 753-04466 Anti-Rotation Screw
26 753-05056 Clamp Assembly (includes 25)
27 753-05091 Shroud Extension and Stand (includes 22)
28 753-04324 Module Assembly
29 791-610311B Spark Plug
30 753-04619 Exhaust Gasket
31 753-04620 Muffler Mounting Bolt Assembly
32 753-05169 Muffler Assembly (includes 30 & 31)
33 791-182723 Cylinder Bolt
34 753-04182 Cylinder Gasket
* 753-1209 Piston Ring Set
* 753-04826 Short Block Assembly (includes 9, 29, 33 & 34)
* not shown
Item Part No. Description
1 753-04511 Air Cleaner Cover Assembly (includes 2 & 22)
2 791-180350B Air Cleaner Filter
3 791-180351 Carburetor Mounting Screws
4 791-180226 Wavey Washer
5 753-04418 Choke Lever Assembly
6 753-04419 Choke Lever & Plate (includes 5)
7 753-04408 Carburetor Assembly (includes 8 & 18)
8 791-610675 Carburetor Gasket
9 791-181860 Carb Mount Screw
10 791-683974B Primer and Hose Assembly
11 753-1196 Carburetor Mount Assembly (includes 9, 12 & 13)
12 791-684451 Reed Assembly
13 753-05487 O-Ring
14 791-612134 Rear Mounting Pad
15 791-182612 Fuel Cap Assembly
16 791-182767 Fuel Tank Assembly (includes 15)
17 791-145308 Front Mounting Pad
18 753-05240 Flywheel Assembly
19 791-610303 Square Nut Drive
REPLACEMENT PARTS - MODEL Y765
2-CYCLE GAS TRIMMER
PPN 41DD765G900
PARTS LIST PART NO. 769-04518 P00 6/09
123
7
11
4
6
5
10
12
13
34
17
33
14
15
19
18
20
24
23
27
31
28
32
8
30
29 22
25
26
9
22
21
16

REPLACEMENT PARTS - MODEL Y765
2-CYCLE GAS TRIMMER
PPN 41DD765G900
Issued 6/09
Item Part No. Description
1 753-04927 Throttle Housing Assembly (includes 2 & 3)
2 791-610314 Throttle Trigger Spring
3 791-181807 Throttle Trigger
4 753-04901 Throttle Cable
5 791-153064 D-Handle Assembly (includes 6)
6 791-181587 D-Handle Hardware
7 753-06164 Drive Shaft Housing Assembly (includes 8)
8 753-05211 Flexible Drive Shaft
9 753-06125 Shield Mounting Hardware
10 753-06123 Shield Assembly (includes 11)
11 753-06126 Blade Assembly
12 753-05698 Anti-Rotation Screw
13 753-06165 Gearbox Assembly (includes 14-18)
14 753-04284 Outer Spool Assembly (includes 15)
15 791-610660 Retainer
16 791-610317B Spring
17 753-1155 Inner Reel
18 791-153066B Bump Head Knob Assembly
Optional Acessories
* 791-153577B Spool & 0.080 in. (2.03 mm) Line Assembly
1
4
3
2
1
5
6
7
8
10
15
9
14
11
16
17
18
6
12
13
