1. Unscrew cap from the H-11199 Relubricating Tool.

2. Remove shaft from body and turn handle counter-clockwise to retract shaft until “O” ring and piston are

withdrawn into cap.

3. Insert a stick of Mueller Grease (H-853) into the body.

4. Replace and tighten cap.

5. Turn handle clockwise to force grease out of the nozzle opening.

6. Be sure the Luboseal®Stop is in either the FULLY OPEN or FULLY CLOSED position. This aligns the vertical

groove in the key with the grease port recess.

7. Remove the grease plug by using the hex wrench on Relubricating Tool handle. Screw tool nozzle into grease plug

threads as far as possible.

8. Turn the handle clockwise, forcing the grease into the vertical groove in the key. If immediate resistance is

encountered, probably the groove in the key is not aligned with the grease port. Turn the key slightly in either

direction until the grease begins to ow.

Relubricating Instructions

H-11199 Relubricating Tool

(continued)

Relubricating Instructions (continued)

• The amount of grease required to relubricate a Luboseal®Stop depends upon how hard the stop turns and how much

grease must be replaced. The table below shows the number of complete revolutions of the handle required to fully

relubricate each size of Luboseal®Stop. The table is based on the assumption that the stop has excessive port leakage

and that considerable grease has been dissipated.

• NOTICE: Do not over lubricate. If the condition of the

stop is not too bad, not as many turns of the handle

will be required as is indicated in the table. The service

technician, after a few trials, should be able to tell by

the feel of the handle whether or not the stop is lled

with grease. Be sure to use MUELLER GREASE

STICKS. They are made especially for MUELLER

STOPS.

9. Replace grease plug and tighten, using hex wrench on

Relubricating Tool handle.

By deviating from the above listed instructions, you will void any product warranty and release Mueller Co. and its afliated entities from any and all liability

associated with the installation or use of this product. For details on the product’s warranty, terms, and conditions, please visit www.muellergas.com.

Phone: (800) 798-3131

Form 9664 05/16

Size of Stop Revolutions of Handle to Fill Stop

3/4” 6

1” 7-1/2”

1-1/4” 10

1-1/2” 13-1/2”

2” 16

2-1/2” 25-1/2”
