MUHLER MSC-1500 User manual

EN: STEAM MOP 12IN1 | Instruction Manual
BG: ПАРОЧИСТАЧКА 12 В 1 | Инструкця за работа
RO: APARAT DE CURĂȚAT CU ABUR 12 ÎN 1 | Instrucțiuni de utilizare
GR: ΑΤΜΟΚΑΘΑΡΙΣΤΉΣ 12 ΣΕ 1 | Εγχειρίδιο λειτουργιών
EN: Please read the instructions manual before using the appliance for the rst time and save it for future reference. / BG: Моля, прочетете
инструкцията за употреба преди да използвате уреда за пръв път и я запазете за бъдещи справки. / RO: Vă rugăm să citiți instrucțiunile
de utilizare înainte de a folosi aparatul pentru prima dată și păstrați-le pentru referințe viitoare. / GR: Παρακαλώ, διαβάστε το εγχειρίδιο
οδηγιών πριν χρησιµοποιήσετε τ η συσκευή για πρώτη φορά και φυλάξτε το για μελλοντική αναφορά.
Model: MSC-1500
1500W
220-240V, 50-60Hz

3
EN: STEAM MOP 12IN1 | Instruction Manual
IMPORTANT SAFETY INSTRUCTION
Please read all instructions carefully and save it for future reference.
When using electrical appliances, basic safety precautions should always be
followed:
1.Check that the voltage indicated on the rating plate corresponds with
that of the local network before connecting the appliance to the mains
power supply.
2.This appliance is not intended for use by persons (including children)
who are not mentally able, physically capable, experienced or do not
understand the product.They should be given supervision and instruction
for use of the appliance by a person responsible for their safety.
3.Do not steam direct at people, animals, electrical appliances, or electrical
outlets.
4.Keep the appliance and its cord out of reach of children.
5.This appliance must not be used by children.
WARNING: Danger of scalding. Please use caution when using the steam
cleaner.The steam emitted from the openings is very hot.
6.Do not immerse the appliance in water.
7.Do not leave the appliance unattended while connected to the mains
power supply.
8.Do not leave the appliance connected to an electrical outlet when not in
use.
9.Never pull the power cord to disconnect the appliance from the socket
outlet.Take out the plug by pull it out form the socket outlet.
10. Keep the appliance cord away from heat sources and sharp edges.
11. Do not use the appliance with wet hands.
12. Do not pull or carry the appliance by the cord, pull the cord around
sharp corners or expose the cord to heated surfaces.
13. Do not use this appliance on leather, wax polished furniture or oors,
synthetic fabrics, velvet or other delicate, steam sensitive materials.
14. Do not use the appliance on any unsealed hard oor surfaces.

4
EN: STEAM MOP 12IN1 | Instruction Manual
Note: Surfaces treated with wax and some non-wax oors may lose their
sheen due to the heat and steam action. It is recommended to test an
isolated surface area before proceeding.
15. Never add de-scaling, aromatic, alcoholic or detergent products into
the steam mop as this may cause damage and doing so will void your
warranty.
This appliance gets very hot during use. Please pay attention when using it.
Note: Always wear suitable shoes when using this appliance and when
changing the accessories; do not wear slippers or open-toed footwear.
16. The microber cleaning pad must be installed correctly before use.
17. This appliance contains no user serviceable parts. All repairs should
be carried out by a qualied engineer; improper repairs may place the
user at serious risk of harm.
18. This appliance is intended for household use only. It should not be
used for commercial purposes.
19. Never leave the steam mop on a oor area stationary whilst on for
longer than 15 seconds.
20. Leaving the mop in this position may cause a buildup of a pale
residue on the surface.
21. To increase the life of your appliance, it is recommended that you
lter the water using the jug and lter included or use de-mineralized
water.
22. If using to clean hobs and ovens, you must not direct the steam
towards any electrical connections.
23. Ensure the device is disconnected from the mains before cleaning.
24. Please ensure hobs and ovens are fully cooled before attempting to
clean.
25. Do not use this appliance for any purpose other than it is intended
for.
26. Never force the steam unit onto the mop head as this could
potentially damage the steam mop.

5
EN: STEAM MOP 12IN1 | Instruction Manual
27. Do not use the appliance after a malfunction or if it has been
dropped or damaged in any way.
28. If the supply cord or plug is damaged, it must be replaced by a
qualied engineer in order to avoid a hazard.
DESCRIPTION OF THE APPLIANCE
1. Handle 8. Cup 15. Scraper tool
2. Up cord hook 9. Funnel 16. Angled nozzle
3. Down cord hook 10. Carpet glider 17. Brush tool
4. Power switch 11. Microber cloth 18. Steamer shelf
5.Water tank cover 12. Accessory adaptor 19. Vertical ironing and clothes
disinfection attachment
6.Variable steam control 13. Metal brush tool 20. Steamer brush
7.Triangle mop head 14. Nylon brush tool 21. Squeegee attachment

6
EN: STEAM MOP 12IN1 | Instruction Manual
TECHNICAL CHARACTERISTICS
Model MSC-1500
RatedVoltage 220-240V
Rated Frequency 50/60Hz
Output Power 1500W
Class Class I
Waterproof Level IPX4
WaterTank Capacity 400ml
BEFORE USE
1. Remove the appliance from the box.
2. Remove any packaging from the product.
3. Place the packaging inside the box and either store or dispose of safety.
FUTURES
1. Steam cleaning freshens carpets and cleans tiles, vinyl, and hardwood oors.
2. Quick start.
3. Lightweight.
4. Transparent tank allows monitoring of water level.
ASSEMBLY
ATTACHING THE HANDLE
1. Slide the handle into the extension tube until it locks into position.
2. Slide the extension tube with the handle installed in to the steam mop body until it locks into place.
3. The handle can be removed from the steam mop body for easy storage by pressing the handle tube button.
ATTACHING THE STEAM HEAD
1. Slide the button end of the steam mop body onto the triangle mop head until the triangle mop head spindle locks into
place.
2. Hold both parts of the unit and gently push the clip into the handle.This will lock the two parts into position.
WARNING: Never force the steam mop body onto the triangle mop head, as this could
potentially damage the steam mop. Always attach the triangle mop head using both hands,
ensuring it locks into place correctly.
The triangle steam head can be removed from the main body by pressing the button on the
triangle steam head spindle.
ATTACHING A MICROFIBER CLOTH
Position the microber cloth onto the triangle steam head and secure it.

7
EN: STEAM MOP 12IN1 | Instruction Manual
ATTACHING THE CARPET GLIDER
Position the microber cloth into the triangle steam head and place the carpet glider over and around the microber cloth.To
remove, simply pull the carpet glider o.
INSTRUCTIONS FOR USE
FILLINGTHEWATER TANK
Open the water tank cap by unscrewing in an anticlockwise direction; ll the tank with 400ml of water.
FILLINGTHETANK DURING USE
Turn o the switch and open the tank and pour in the water. Seal the tank and turn on to activate the steam.
WARNING: Never place de-scaling, aromatic, alcoholic or detergent products in the steam mop
tank, this will cause damage to the appliance and void your warranty.
USING THE STEAM MOP
1. Plug the appliance into the mains power supply and switch on.The indicator lights on switch will illuminate red.
2. It will take approximately 25 seconds for the appliance to preheat, the appliance is ready for use.
3. Steam will run continuously until turn o or the unit runs out of water.
4. A full tank will supply approximately 20 minutes of steam. If the water tank is empty, the pump will be little pumping
noise and shake, switch must be turn o immediately and rell the water tank following the instructions above.
5. Control the steam using the variable steam control knob. Turn the control clockwise to increase the steam or anticlockwise
to reduce it.
USING AS A HANDHELD STEAMER
1. Press the handle tube button to remove the handle from the steam mop body.
2. Install the accessory adaptor at the top of the steam mop body until it locks into position.
3. Choose the required accessories and install by aligning the arrow indicators and turning clockwise.
4. Allow the water to heat up as above then adjust steam button to get ideal steam for dierent oor surfaces.
ACCESSORIES
Accessory Suggested Use
Squeegee Attachment/Accessory/Adaptor Shower screens, mirrors, and glass.
Remove creases from sofa, tablecloths etc.
metal and large nylon BrushTools
WARNING: be careful of metal brush to scratch the surface
Ovens, hobs, showers, bath tubs, tiles, toys, refrigerators,
etc.
Angled Nozzle Stove tops, taps, sinks, hard to reach areas etc.
BrushTool Cleaning grout lines, sanded or non-sanded.
ScraperTool Scraping baked on food, grime, and grease. Removing residue or other dierent substances from
surfaces such as hobs and ovens.

8
EN: STEAM MOP 12IN1 | Instruction Manual
Steamer Cloth Steaming sofa, tablecloths etc.
Microber Cloth For general cleaning of hard oors and carpets.
CLEANING AND MAINTENANCE
1. 1. Ensure the appliance is unplugged from the mains supply and has cooled suciently before cleaning.
2. 2. Drain any remaining water from the tank and clean after every use.
3. 3. Clean the accessories in warm, soapy water and leave to dry.
DECALCIFY THE WATER TANK INTERIOR
To clean calcium deposits that build up inside the water tank, add one or two tablespoons of white vinegar to a full tank and
then shake.
NOTE: Do not turn the steamer on!
REMOVING LIMESCALE
1. If the appliance begins to produce steam more slowly than usual or stops producing steam, you may need to remove
limescale.
2. Limescale can develop over time on the metal parts of the appliance and greatly aect its performance. It is recommended
to remove limescale on a moment basis or after every 25-50 usages.
3. The frequency of removal depends on the hardness of your tap water and how often you use your steamer. If you live in an
especially hard water area, you may need to use de-mineralized water.
USING A CLEANING SOLUTION
1. Prepare a solution of 1/3 white vinegar and 2/3 tap water and add to the water tank.
2. Secure and position the unit to ensure any steam released is aimed away from the oor or surrounding objects and
surfaces.
3. Plug the appliance into the mains power supply and turn on; allow the unit to produce steam until all the solution is used.
4. Repeat the above procedures as often as necessary then ll the tank with fresh water and rinse.
5. Fill the tank to the max. level with fresh water, twitch on and release steam through the system until the water tank is
empty.
WARNING:Do not leave the steamer unattended during the limescale removal process and/or
during use.
NOTE:Perform a test on a suitable isolated surface after limescale removal to ensure there is no
debris left in the unit.
NOTE: Due to the mature of UK water suppliers, some areas of the country experience large
amounts of limescale build-up. If you live in one of these areas you may need to decalcify the
unit more often.
CLEANING BLOCKED ACCESSORIES

9
EN: STEAM MOP 12IN1 | Instruction Manual
Due to the high mineral water content in certain areas, you may notice less steam from the accessories; this may be caused by
calcium build-up inside the nozzle.
CLEANING CALCIUM BUILDUP
1. It is recommended to use the vinegar solution inside the aected accessory then ll the water tank with water according to
the directions and run a continuous jet of steam through the aected accessory for several minutes to clear the pathway.
2. Aim the appliance at a neutral surface or cleaning cloth to ensure do debris is emitted.
CLEANING THE MICROFIBRE CLOTHS
1. The microber cloths are machine washable on a warm setting; always use a mild detergent.
2. For best results, lay at to dry.
NOTE: Never use bleach or fabric softener when cleaning the microber cloths.
STORAGE
1. After use, turn the appliance o and unplug from the mains power supply.
2. Remove the water tank and empty out any residual water, then clean the outer surface with a dry cloth.
3. Remove the cleaning pad and wash ready for the next use.
4. Store the appliance in a dry area out of reach of children.
TROUBLESHOOTING
Problem Possible Reason Possible Solution
Reduced Steam or No Steam.
Water tank may be empty.
Steam nozzle may be blocked.
There is no power to the unit.
The steam button wasn’t pressed.
Steam control knob is set to min.
Fill the water tank.
Clean the steam nozzle.
Ensure the appliance is plugged in.
Press the steam button.
Turn the steam control knob clockwise
to Max.
UnitWill NotTurn On.
Blown fuse or breaker.
Power cord not plugged in.
Internal fuse is blown.
Handle is not inserted correctly.
Replace the fuse or reset breaker.
Plug the cord into a working circuit.
Contact customer services.
Check that the handle is rmly
connected to the steam mop body.

10
BG: ПАРОЧИСТАЧКА 12 В 1 | Инструкця за работа
ВАЖНИ ИНСТРУКЦИИ ЗА БЕЗОПАСНОСТ
Внимателно прочетете тези инструкции и ги запазете за бъдещи
справки.
Когато използвате електрически уреди, винаги трябва да следвате
основните предпазни мерки:
1.Преди да включите уреда към главното електрозахранване,
проверете дали напрежението, посочено на фабричната табелка,
съответства на това на местната електрическа мрежа.
2.Този уред не е предназначен за употреба от лица (включително
деца), които имат психични или физически затруднения, които
нямат достатъчно опит в работата с електрически уреди или не
разбират начина на употреба на този продукт. Те трябва да бъдат
наблюдавани и инструктирани относно употребата на уреда от
лицето, отговорно за тяхната безопасност.
3.Не насочвайте парата към хора, животни, електрически уреди или
електрически контакти.
4.Уредът и неговият захранващ кабел трябва да са на недостъпно за
деца място.
5.Този уред не трябва да се използва от деца.
ПРЕДУПРЕЖДЕНИЕ: Риск от попарване. Внимавайте, когато
използвате парочистачката. Парата, излизаща от отворите, е много
гореща.
6.Не потапяйте уреда във вода.
7.Не оставяйте уреда без наблюдение, докато е включен в
електрическата мрежа.
8.Когато не използвате уреда, не го оставяйте включен в електрически
контакт.
9.Никога не дърпайте захранващия кабел, за да изключите уреда от
стенния контакт. Издърпайте щепсела, за да го извадите от контакта.
10. Пазете захранващия кабел на уреда от източници на топлина
или остри ръбове.
11. Не използвайте уреда с мокри ръце.
