multicomp MC011333 User manual

www.element14.com
www.farnell.com
www.newark.com
Page <1> V1.023/01/19
Universal Power Bank
Features
• High Capacity, High Quality Li-Ion Cell
• Charge / Discharge Cycle Life Around 500 Times.
• Built-In Automatic Micro Controller
• Built-in Smart Power Management Controller with Power Conversion Efciency more than 88%
• Plug & Play with USB Output Port
• Intelligent Display of LED to Indicate the Charging Status & Power Levels
• Automatically Detect the Current Required by the Devices
• Ideal for most digital devices with DC5V input such as iPad, iPhone, Smart Phone, MP3, MP4,
Tablet PC and GPS
• Japanese Seiko High Efcient Protection IC for the Cell, System Design with Over Charge, Over
Discharge, Over Current and Short Circuit Protection to Guarantee the Safety of Usage
• Certied by CE, and FCC Safety Requirement
Specications
Capacity : 11,200mAh
Battery : Li-Ion
Dimensions : 110mm × 73mm × 24mm
USB Port
No. of Port : 2 Port
Input Port : Micro USB - 5V DC / 500 ~ 2000mA
Output Port : USB - 5.1V DC / 2.1A (Each Port)
Power / Capacity Indicator
<30%
30% ~ 80%
Output LED
>80%
Required Environment
Operating Temperature : 0°C - 35°C
Operating Relative : 5% ~ 95% RH
Storage Temperature : -10°C - 60°C
Accessories
USB Cable Line - 1PC

www.element14.com
www.farnell.com
www.newark.com
Page <2> V1.023/01/19
Universal Power Bank
Operation Instruction
# How to Recharge Power Bank
• Use power sources with output DC 5V over 500mA. The power sources can be USB port of computer, AC/DC USB
adapter and power adaptor with micro USB connector
• Connect the power sources with power bank
• In 5 seconds after connection, one power level LED ashes to indicate the power bank is charged properly. After fully
charged, 3 LEDs turn to solid light.
• You can press the on/off button to check the battery capacity remaining. The LED lights up according to the power level.
All lights off means no power
# How to Charge your Digital Device
• Use the original cable or the attached USB cable with correct connector
• Connect the power bank with your digital device
• Press on/off button to start charging; the power indicator will light up for proper charging
• After fully charge, remove the cable and press the on/off button to turn off the power bank
Charging Status Indication
• Power Indicator: the power LED lights up to indicate power bank is functioning well
• Power Capacity Indicator: The power capacity LEDs light up according to the possess power capacity. All lights off means
it runs out of power
• If 3 Power capacity LEDs ash, it indicates the power sources are not proper for charging, try other power sources
• The power bank can charge two devices simultaneous. However, when one device draws certain amount power 2A ~ 2.1A,
such as iPad, you may not able to use both USB port. If output current is over 3A, it may deactivate the power bank and all
the lights off. If this occurs, just disconnect your digital devices and charge the power bank to reset it

www.element14.com
www.farnell.com
www.newark.com
Page <3> V1.023/01/19
Universal Power Bank
Important Notice : This data sheet and its contents (the “Information”) belong to the members of the Premier Farnell group of companies (the “Group”) or are licensed to it. No licence is granted
for the use of it other than for information purposes in connection with the products to which it relates. No licence of any intellectual property rights is granted. The Information is subject to change
without notice and replaces all data sheets previously supplied. The Information supplied is believed to be accurate but the Group assumes no responsibility for its accuracy or completeness, any
error in or omission from it or for any use made of it. Users of this data sheet should check for themselves the Information and the suitability of the products for their purpose and not make any
assumptions based on information included or omitted. Liability for loss or damage resulting from any reliance on the Information or use of it (including liability resulting from negligence or where the
Group was aware of the possibility of such loss or damage arising) is excluded. This will not operate to limit or restrict the Group’s liability for death or personal injury resulting from its negligence.
Multicomp is the registered trademark of the Group. © Premier Farnell Limited 2016.
Part Number Table
Description Part Number
Universal Power Bank, 11,200mAh, 2Port, 5.1V/2.1A MC011333
Problems and Solutions
# Unable to Charge the Power Bank
The charging equipment is not correct, please use correct power equipment
Make sure the power source with output DC 5V / 500 ~ 2000mA
Conrm the charging equipment connected to the Micro USB correctly
The charging equipment may not work. Please try other proper equipment
# Unable to Charge your Digital Device
• The power bank is not compatible with your digital device. Make sure your device supports charging with input 5V power
• Check the connection.
• The USB cable or connector may be damaged. Please replace with new ones.
• The remaining power of power bank is too low to charge the device. Please charge the power bank rst.
Caution
• Before initial use, fully charge to activate the battery
• Keep away from res and water
• Avoid impact
• Do not disassemble the product
