MULTIQUIP MVC-90H Guide

OPERATION AND PARTS MANUAL
THIS MANUAL MUST ACCOMPANYTHE EQUIPMENT AT ALL TIMES.
SERIES
MODEL MVC-90H
ONE-WAY PLATE COMPACTOR
(HONDA GASOLINE ENGINE)
Revision #3 (01/10/11)
www.discount-equipment.com
Discount-Equipment.com

Discount-Equipment.com is your online resource for commercial and industrial
quality parts and equipment sales.
Locations:
Florida (West Palm Beach): 561-964-4949
Outside Florida TOLL FREE: 877-690-3101
Need parts? Check out our website at www.discount-equipment.com
Can’t find what you need?
Click on this link: http://www.discount-equipment.com/category/5443-parts/ and fill out
the request form.
Please have the machine model and serial number available in order to help us get
you the correct parts. One of our experienced staff members will get back to you with
a quote for the right part that your machine needs.
We sell worldwide for the brands: Genie, Terex, JLG, MultiQuip, Mayco, Toro/Stone,
Diamond Products, Magnum, Airman, Mustang, Power Blanket, Nifty Lift, Atlas Copco,
Chicago Pneumatic, Allmand Brothers, Essick, Miller Spreader, Skyjack, Lull, Skytrak,
Tsurumi, Husquvarna/Target, Whiteman-Concrete/Mortar, Stow-Concrete/Mortar, Baldor,
Wacker, Sakai, Snorkel, Upright, Mi-T-M, Sullair, Neal, Basic, Dynapac, MBW, Weber,
Bartell, Bennar Newman, Haulotte, Ditch Runner, Blaw-Knox, Himoinsa, Best, Buddy,
Crown, Edco, Wyco, Bomag, Laymor, Terremite, Barreto, EZ Trench, Takeuchi, Basic, Bil-
Jax, Curtis, Gehl, Heli, Honda, ICS/PowerGrit, Puckett, Waldon, ASV, IHI, Partner, Imer,
Clipper, MMD, Koshin, Rice, Gorman Rupp, CH&E, Cat Pumps, Comet, General Pump,
Giant,AMida, Coleman, NAC, Gradall, Square Shooter, Kent, Stanley, Tamco, Toku, Hatz,
Kohler, Robin, Wisconsin, Northrock, Oztec, Toker TK, Rol-Air, Small Line, Wanco, Yanmar
Discount-Equipment.com

PAGE 2 — MVC-90H PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV. #3 (01/10/11)
l
PROPOSITION 65 WARNING
Discount-Equipment.com

PAGE 4 — MVC-90H PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV. #3 (01/10/11)
l
TABLE OF CONTENTS
MULTIQUIP MVC-90H
PLATE COMPACTOR
Proposition 65 Warning ..............................................2
Table Of Contents ......................................................4
Parts Ordering Procedures ........................................5
Safety Information ................................................ 6-10
Dimensions ............................................................. 12
Specifications .......................................................... 13
General Information ................................................ 14
Components (Plate Compactor) ............................. 15
Components (Honda Engine) ................................. 16
Inspection ........................................................... 17-18
Start-Up Procedure ................................................. 19
Shut-down Procedure ............................................. 20
Operation ................................................................ 21
Maintenance ...................................................... 22-24
Preparation For Long Term Storage ....................... 25
Troubleshooting (Engine) ................................... 26-27
Troubleshooting (Compactor) ................................. 28
Explanation Of Codes In Remarks Column ............ 30
Suggested Spare Parts ........................................... 31
NOTE Specification and part number
are subject to change without
notice.
COMPONENT DRAWINGS
Name Plate and Decals ..................................... 32-33
Body Assembly .................................................. 34-37
Vibrator Assembly .............................................. 38-39
Clutch Assembly (Old Type) ............................... 40-41
Clutch Assembly (New Type) ............................. 42-43
HONDA GX160K1QMX2/
GX160U1QMX2
GASOLINE ENGINE
Air Cleaner (Dual) Assembly ............................. 44-45
Camshaft Assembly .......................................... 46-47
Carburetor Assembly ........................................ 48-49
Control Assembly .............................................. 50-51
Crankcase Cover Assembly .............................. 52-53
Crankshaft Assembly ........................................ 54-55
Cylinder Barrel Assembly .................................. 56-57
Cylinder Head Assembly ................................... 58-59
Fan Cover Assembly ......................................... 60-61
Flywheel Assembly ........................................... 62-63
Fuel Tank Assembly .......................................... 64-65
Ignition Coil Assembly ....................................... 66-67
Muffler Assembly .............................................. 68-69
Piston Assembly ................................................ 70-71
Recoil Starter Assembly.................................... 72-73
Gasket Kit Assembly ......................................... 74-75
Label Assembly ................................................. 76-77
Terms and Conditions Of Sale — Parts .................. 78
Discount-Equipment.com

PAGE 6 — MVC-90H PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV. #3 (01/10/11)
l
SAFETY INFORMATION
Do not operate or service the equipment before reading
the entire manual. Safety precautions should be followed
at all times when operating this equipment.
Failure to read and understand the safety
messages and operating instructions could
result in injury to yourself and others.
SAFETY MESSAGES
The four safety messages shown below will inform you
about potential hazards that could injure you or others.The
safety messages specifically address the level of exposure
to the operator and are preceded by one of four words:
DANGER, WARNING, CAUTION or NOTICE.
SAFETY SYMBOLS
DANGER
Indicates a hazardous situation which, if not avoided,
WILL result in DEATH or SERIOUS INJURY.
WARNING
Indicates a hazardous situation which, if not avoided,
COULD result in DEATH or SERIOUS INJURY.
CAUTION
Indicates a hazardous situation which, if not avoided,
COULD result in MINOR or MODERATE INJURY.
NOTICE
Addresses practices not related to personal injury.
Potential hazards associated with the operation of this
equipment will be referenced with hazard symbols which
may appear throughout this manual in conjunction with
safety messages.
Discount-Equipment.com

MVC-90H PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV. #3 (01/10/11)— PAGE 7
SAFETY INFORMATION
GENERAL SAFETY
CAUTION
NEVER operate this equipment without proper protective
clothing, shatterproof glasses, respiratory protection,
hearing protection, steel-toed boots and other protective
devices required by the job or city and state regulations.
NEVER operate this equipment when not
feeling well due to fatigue, illness or when
under medication.
NEVER operate this equipment under the influence of
drugs or alcohol.
ALWAYS check the equipment for loosened threads or
bolts before starting.
DO NOT use the equipment for any purpose other than
its intended purposes or applications.
ALWAYS clear the work area of any debris, tools, etc.
that would constitute a hazard while the equipment is
in operation.
NOTICE
This equipment should only be operated by trained and
qualified personnel 18 years of age and older.
Whenever necessary, replace nameplate, operation and
safety decals when they become difficult read.
Manufacturer does not assume responsibility for any
accident due to equipment modifications. Unauthorized
equipment modification will void all warranties.
NEVER use accessories or attachments that are not
recommended by Multiquip for this equipment. Damage
to the equipment and/or injury to user may result.
ALWAYS know the location of the nearest
fire extinguisher.
ALWAYS know the location of the nearest
first aid kit.
ALWAYS know the location of the nearest phone or keep
a phone on the job site. Also, know the phone numbers
of the nearest ambulance, doctor and fire department.
This information will be invaluable in the case of an
emergency.
Discount-Equipment.com

PAGE 8 — MVC-90H PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV. #3 (01/10/11)
l
SAFETY INFORMATION
COMPACTOR SAFETY
DANGER
NEVER operate the equipment in an explosive
atmosphere or near combustible materials.An
explosion or fire could result causing severe
bodily harm or even death.
WARNING
NEVER disconnect any emergency or safety devices.
These devices are intended for operator safety.
Disconnection of these devices can cause severe injury,
bodily harm or even death.Disconnection of any of these
devices will void all warranties.
CAUTION
NEVER lubricate components or attempt service on a
running machine.
NOTICE
ALWAYS keep the machine in proper running condition.
Fix damage to machine and replace any broken parts
immediately.
ALWAYS store equipment properly when it is not being
used. Equipment should be stored in a clean, dry location
out of the reach of children and unauthorized personnel.
ENGINE SAFETY
DANGER
The engine fuel exhaust gases contain poisonous carbon
monoxide. This gas is colorless and odorless, and can
cause death if inhaled.
The engine of this equipment requires an adequate
free flow of cooling air. NEVER operate this equipment
in any enclosed or narrow
area where free flow of the
air is restricted. If the air
flow is restricted it will cause
injury to people and property
and serious damage to the
equipment or engine.
WARNING
DO NOT place hands or fingers inside engine
compartment when engine is running.
NEVER operate the engine with heat shields or
guards removed.
Keep fingers, hands hair and clothing away
from all moving parts to prevent injury.
DO NOT remove the radiator cap while the
engine is hot. High pressure boiling water will gush out
of the radiator and severely scald any persons in the
general area of the compactor.
DO NOT remove the coolant drain plug
while the engine is hot. Hot coolant will
gush out of the coolant tank and severely
scald any persons in the general area of
the compactor.
DO NOT remove the engine oil drain plug while the
engine is hot. Hot oil will gush out of the oil tank and
severely scald any persons in the general area of the
compactor.
CAUTION
NEVER touch the hot exhaust manifold,
muffler or cylinder. Allow these parts to cool
before servicing equipment.
NOTICE
NEVER run engine without an air filter or with a dirty air
filter. Severe engine damage may occur. Service air filte
r
frequently to prevent engine malfunction.
NEVER tamper with the factory settings
of the engine or engine governor. Damage
to the engine or equipment can result
if operating in speed ranges above the
maximum allowable.
NEVER tip the engine to extreme angles during lifting as
it may cause oil to gravitate into the cylinder head, making
the engine start difficult.
Discount-Equipment.com

MVC-90H PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV. #3 (01/10/11)— PAGE 9
SAFETY INFORMATION
FUEL SAFETY
DANGER
DO NOT add fuel to equipment if it is placed inside truck
bed with plastic liner. Possibility exists of explosion or
fire due to static electricity.
DO NOT start the engine near spilled fuel or combustible
fluids. Diesel fuel is extremely flammable and its vapors
can cause an explosion if ignited.
ALWAYS refuel in a well-ventilated area, away from
sparks and open flames.
ALWAYS use extreme caution when working with
flammable liquids.
DO NOT fill the fuel tank while the engine is running
or hot.
DO NOT overfill tank, since spilled fuel could ignite if it
comes into contact with hot engine parts or sparks from
the ignition system.
Store fuel in appropriate containers, in well-ventilated
areas and away from sparks and flames.
NEVER use fuel as a cleaning agent.
DO NOT smoke around or near the
equipment. Fire or explosion could result
from fuel vapors or if fuel is spilled on a
hot engine.
FUEL
FUEL
BATTERY SAFETY (ELECTRIC START ONLY)
DANGER
DO NOTdrop the battery. There is a possibility that the
battery will explode.
DO NOT expose the battery to open flames,
sparks, cigarettes, etc.The battery contains
combustible gases and liquids. If these
gases and liquids come into contact with a
flame or spark, an explosion could occur.
WARNING
ALWAYS wear safety glasses when
handling the battery to avoid eye irritation.
The battery contains acids that can cause
injury to the eyes and skin.
Use well-insulated gloves when picking up
the battery.
ALWAYS keep the battery charged. If the battery is not
charged, combustible gas will build up.
DO NOT charge battery if frozen. Battery can explode.
When frozen, warm the battery to at least 61°F (16°C).
ALWAYS recharge the battery in a well-ventilated
environment to avoid the risk of a dangerous concentration
of combustible gases.
If the battery liquid (dilute sulfuric acid)
comes into contact with clothing or skin,
rinse skin or clothing immediately with
plenty of water.
If the battery liquid (dilute sulfuric acid) comes into
contact with eyes, rinse eyes immediately with plenty
of water and contact the nearest doctor or hospital to
seek medical attention.
CAUTION
ALWAYS disconnect the NEGATIVE battery terminal
before performing service on the equipment.
ALWAYS keep battery cables in good working condition.
Repair or replace all worn cables.
Discount-Equipment.com

PAGE 10 — MVC-90H PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV. #3 (01/10/11)
l
SAFETY INFORMATION
TRANSPORTING SAFETY
CAUTION
NEVER allow any person or animal to stand underneath
the equipment while lifting.
NOTICE
Before lifting, make sure that the equipment parts (hook
and vibration insulator) are not damaged and screws are
not loose or missing.
Always make sure crane or lifitng device has been
properly secured to the lifting bail (hook) of the
equipment.
ALWAYS shutdown engine before transporting.
NEVER lift the equipment while the engine is running.
Tighten fuel tank cap securely and close fuel cock to
prevent fuel from spilling.
Use adequate lifting cable (wire or rope) of sufficient
strength.
Use one point suspension hook and lift straight
upwards.
DO NOT lift machine to unnecessary heights.
ALWAYS tie down equipment during transport by
securing the equipment with rope.
ENVIRONMENTAL SAFETY
NOTICE
Dispose of hazardous waste properly.
Examples of potentially hazardous waste
are used motor oil, fuel and fuel filters.
DO NOT use food or plastic containers to dispose of
hazardous waste.
DO NOT pour waste, oil or fuel directly onto the ground,
down a drain or into any water source.
Discount-Equipment.com

PAGE 12 — MVC-90H PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV. #3 (01/10/11)
l
Figure 1. MVC-90H Plate Compactor Dimensions
MVC-90H PLATE COMPACTOR — DIMENSIONS
SNOISNEMID.3ELBAT
retteLecnerefeR noitpircseD )mm(.nisnoisnemiD
A
)deyolpeDeldnaH(thgieH ).mm6.368(.ni43
B
htdiWlarevO ).mm335(.ni12
C
)ylnoetalP(htgneL ).mm485(.ni32
D
)deyolpeDeldnaH(htgneL ).mm912,1(.ni84
E
)dehctateDeldnaH(thgieH ).mm787(.ni13
Discount-Equipment.com

MVC-90H PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV. #3 (01/10/11)— PAGE 13
MVC-90H PLATE COMPACTOR — SPECIFICATIONS
ELBATSNOITACIFICEPSROTCAPMOC.1
ledoMH09-CVM
ecroFlagufirtneC)gk025,1(.sbl053,3
ycneuqerFnoitarbiV)zH39(mpv006,5
deepSdrawroFmumixaM)nim/m52(nim/tf28
)WxL(eziSetalP )mm005x065(ni6.91x22
thgieWgnitarepO)gk88(.sbl491
noitcapmoCfoaerAmumixaM )rh/m.qs647(rh/tf.qs630,8
gnitaRPH)WK2.4(PHB5.5
yticapaCknaTretaW)sretil3.5(.stq6.5
SNOITACIFICEPSENIGNE.2ELBAT
ekaMenignE ADNOH
ledoMenignE 2XMQ1U061XG/2XMQ1K061XG
epyTenignE enignEenilosaGtfahSlatnoziroH,VHO,rednilyCelgniS,ekorts-4,delooc-riA
tnemecalpsiD )cc361(ni.uc9.9
tuptuOmumixaM mpr006,3/.P.H5
yticapaCliO )sretil6.0(stnip3.1
epyTleuF dedaelnU
yticapaCknaTleuF )sretil6.3(snollag59.0
thgieWyrD )gk51(/.sbl1.33
dohteMlortnoCdeepS epyTthgiewylFlagufirtneC
dohteMgnitratS tratSlioceR
)HxWxL(snoisnemiD )mm533x263x403(ni2.31x4.41x0.21
Discount-Equipment.com

PAGE 14 — MVC-90H PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV. #3 (01/10/11)
l
MVC-90H PLATE COMPACTOR — GENERAL INFORMATION
Definition of Plate Compactor
The Mikasa MVC-90H is a walk behind, plate compactor
designed for the compaction of sand, mixed soils and
asphalt. This plate compactor is a powerful compacting tool
capable of applying a tremendous force in consecutive high
frequency vibrations to a soil surface. Its applications include
compacting for road, embankments and reservoirs as well
as backfilling for gas pipelines, water pipelines and cable
installation work.
The MVC-90H has a heavy-duty steel base plate with closed
design. It is ribbed for extra strength. The tubular steel roll
bar cage protects engine components and provides a lifting
point.
The MVC-90H also has a reversible, shock-mounted handle.
Vibratory Plate
The vibratory plate of the compactor produce low amplitude
high frequency vibrations, designed to compact granular soils
and asphalt.
The resulting vibrations cause forward motion. The engine
and handle are vibration isolated from the vibrating plate.
The double-V belt drive assures less downtine and superior
drive characteristics. Unit can still operate if one belt breaks.
WaterTank
The compactor has a built-in water tank which helps provent
damage and adds to long life. Brass water valve eliminates
rust and corrosion problems.
Frequency/Speed
The compactor's vibrating plate has a frequency range
between 5,800 vpm (vibrations per minute). The forward
and reverse travel speed of the compactor is approximately
82 ft./minute (25 meters/minute).
Engine
The Mikasa MVC-90H Plate Compactor is equipped with a
Honda GX160K1QMX2/GX160U1QMX2 air cooled, 4-cycle
gasoline engine. The engine drives an eccentric weight at a
high speed to develop a compaction force.
Controls
Before starting the MVC-90H Plate Compactor identify and
understand the function of the controls and components.
Discount-Equipment.com

MVC-90H PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV. #3 (01/10/11)— PAGE 15
MVC-90H PLATE COMPACTOR — COMPONENTS (PLATE COMPACTOR)
Figure 3. MVC-90H Plate Compactor Components
Figure 3 shows the location of the components and general
maintenance parts. The function of each component is
described below:
1. Fuel Tank Cap – Remove this cap to add fuel.
2. Lifting Bale – When lifting of the compactor is required
either by forklift, crane etc., tie a rope or chain around
this lifting point.
3. Handle Bar – When operating the compactor use this
handle bar to manuever the compactor.
4. Gasoline Engine – This plate compactor uses a Honda
GX160K1QMX2/GX160U1QMX2 engine. Refer to the
Honda owner's manual for engine information and
related topics.
5. Belt Cover – Remove this cover to gain acess to the
V-belts. NEVER run the compactor without the V-belt
cover. If the V-belt cover is not installed, the possibility
exist that your hand may get caught between the V-
belt and clutch, thus causing serious injury and bodily
harm.
6. Vibrating Plate – A flat, open plate made of durable
cast iron construction used in the compacting of soil.
7. Vibration Case – Encloses the eccentric, gears and
counter weights.
8. Water Tube (Sprinkler) – Supplies water to the soil via
a splash plate.
9. Water Shut-Off Valve – Turn this valve downward to let
water flow from the water tank to the water tube.
10. Water Tank – Holds 5.6 quarts of water, built-in.
11. Water Tank Cap – Remove this cap to add water to the
water tank.
Discount-Equipment.com

PAGE 16 — MVC-90H PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV. #3 (01/10/11)
l
MVC-90H PLATE COMPACTOR — COMPONENTS (HONDA ENGINE)
Figure 4. Honda GX160K1QMX2 Engine Controls & Components
The engine (Figure 4) must be checked for proper lubrication
and filled with fuel prior to operation. Refer to the
manufacturer's Engine manual for instructions & details of
operation and servicing.
1. Fuel Filler Cap – Remove this cap to add unleaded
gasoline to the fuel tank. Make sure cap is tightened
securely. DO NOT over fill.
WARNING
Operating the engine without an
air filter, with a damaged air filter,
or a filter in need of replacement
will allow dirt to enter the engine,
causing rapid engine wear.
NOTE
CAUTION - Fueling The Engine
Adding fuel to the tank should be done only when the
engine is stopped and has had an opportunity to cool down.
In the event of a fuel spill, DO NOT attempt
to start the engine until the fuel residue has
been completely wiped up, and the area
surrounding the engine is dry.
2. Throttle Lever – Used to adjust engine RPM speed (lever
advanced forward SLOW, lever back toward operator
FAST).
3. Engine ON/OFF Switch – ON position permits engine
starting, OFF position stops engine operations.
4. Recoil Starter (pull rope) – Manual-starting method. Pull
the starter grip until resistance is felt, then pull briskly
and smoothly.
5. Fuel Valve Lever – OPEN to let fuel flow, CLOSE to
stop the flow of fuel.
Engine components can generate extreme
heat.To prevent burns, DO NOT touch these
areas while the engine is running or
immediately after operating. NEVER operate
the engine with the muffler removed.
CAUTION - Burn Hazard
10. Fuel Tank – Holds unleaded gasoline. For additional
information refer to engine owner's manual.
8. Spark Plug – Provides spark to the ignition system.
Set spark plug gap to 0.6 - 0.7 mm (0.028 - 0.031 inch)
for HONDA engine, and 0.5 - 0.6 mm (0.020 - 0.024
inch) for ROBIN engine. Clean spark plug once a week.
9. Muffler – Used to reduce noise and emissions.
6. Choke Lever – Used in the starting of a cold engine,
or in cold weather conditions. The choke enriches the
fuel mixture.
7. Air Cleaner – Prevents dirt and other debris from
entering the fuel system. Remove wing-nut on top of
air filter cannister to gain access to filter element.
Discount-Equipment.com

MVC-90H PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV. #3 (01/10/11)— PAGE 17
MVC-90H PLATE COMPACTOR — INSPECTION
3. Insert and remove the dipstick without screwing it into
the filler neck. Check the oil level shown on the dipstick.
4. If the oil level is low (Figure 6), fill to the edge of the oil
filler hole with the recommended oil type (Table 4).
Maximum oil capacity is 400 cc.
Figure 6. Engine Oil Dipstick
epyTliO.4elbaT
nosaeS erutarepmeT epyTliO
remmuS rehgiHroC°52 03-W01EAS
llaF/gnirpS C°01~C°52 02/03-W01EAS
retniW rewoLroC°0 01-W01EAS
The Oil Alert system will
automatically stop the engine
before the engine falls below
safe limits. Always be sure to
check the engine oil level prior
to starting the engine.
NOTE
CAUTION - General Safety Precautions
ALWAYS wear approved eye and hearing
protection before operating the
compactor.
NEVER operate the compactor in a
confined area or enclosed area structure
that does not provide ample free flow of
air .
Before Starting:
Figure 5. Engine Oil Dipstick
■ Read safety instructions at the
beginning of manual.
■ Remove dirt and dust, particularly
in the engine cooling air inlet,
carburetor and air cleaner.
■ Check the air filter for dirt and dust. If air filter is dirty,
clean or replace the air filter with a new one as required.
■ Check carburetor for external dirt and dust. Clean with
dry compressed air.
■ Check fastening nuts and bolts for tightness.
■ Check the Engine Oil level.
■ Check the Fuel level.
■ Check the V-belt tension and wear.
■ Check the Vibrator Oil level.
Engine Oil Check
1. To check the engine oil level, place the plate compactor
on secure level ground with the engine stopped.
2. Remove the filler cap/dipstick from the engine oil filler
hole (Figure 5) and wipe it clean.
Discount-Equipment.com

PAGE 18 — MVC-90H PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV. #3 (01/10/11)
l
Fuel Check:
1. Remove the gasoline cap located on top of fuel tank.
2. Visually inspect to see if the fuel level is low. If fuel is low,
replenish with unleaded fuel.
3. When refueling, be sure to use a strainer for filtration. DO
NOT top-off fuel. Wipe up any spilled fuel immediately!
V-Belt Check
1. To check the V-belt tension, remove the three bolts that
secure the belt cover to the frame as shown in Figure 8.
Figure 8.V-Belt Cover Removal
3. A loose V-belt will decrease the power transmission
output, causing reduced compaction and premature wear
of the belt.
4. If the V-belt becomes worn or loose, replace it .
Figure 9. V-Belt Tension
CAUTION - Checking and Replacing the V-Belt
NEVER attempt to check the V-belt
with the engine running. Severe in-
jury can occur if your hand gets
caught between the V-belt and the
clutch. Always use safety gloves.
2. The V-belt tension is proper if the V-belt bends 10 to 15
mm (Figure 9) when depressed with finger at midway
between the clutch and vibration pulley shafts.
MVC-90H PLATE COMPACTOR — INSPECTION
Figure 7. Vibrator Oil Plug
Vibrator Oil Check
1. Place the plate compactor horizontally on a flat surface.
Make sure the compactor is level when checking the oil
in the vibrator assembly.
2. Check vibrator oil level by removing the plug (vibrator
oil gauge) as shown in Figure 7. The oil level should be
up to the oil plug. The vibrator holds 140 cc (approxi-
mately 4 oz).
NOTE When adding or replacing oil, re-
place using only SAE 10W-30
motor oil.
Gasoline is extremely flammable, and its
vapors can cause an explosion if ignited.
DO NOT start the engine near spilled fuel
or combustible fluids.
DO NOT fill the fuel tank while the engine is running or
hot. DO NOT overfill tank, since spilled fuel could ignite if
it comes into contact with hot engine parts or sparks from
the ignition system. Store fuel in approved containers, in
well-ventilated areas and away from sparks and flames.
WARNING - Explosive Fuel
Discount-Equipment.com

MVC-90H PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV. #3 (01/10/11)— PAGE 19
Figure 10. Fuel Valve Lever (ON Position)
Figure 11. Engine ON/Off Switch (ON Position)
4. Place the throttle lever (Figure 13) halfway between fast
and slow .
Figure 13. Throttle Lever (FAST Position)
5. Grasp the starter grip (Figure 14) and slowly pull it out.
The resistance becomes the hardest at a certain posi-
tion, corresponding the compression point. Rewind the
rope a little from that point and pull out sharply.
DO NOT pull the starter rope all the way to the end.
DO NOT release the starter rope after pulling. Allow it to
rewind as soon as possible.
MVC-90H PLATE COMPACTOR — START-UP PROCEDURE
The CLOSED position of the
choke lever enriches the fuel
mixture for starting a COLD
engine. The OPEN position
provides the correct fuel mixture
for normal operation after
starting, and for restarting a
warm engine.
2. Place the Engine ON/OFF switch (Figure 11) in the ON
position.
3. Place the Choke Lever (Figure 12) in the OPEN position.
Figure 12. Choke Lever (OPEN Position)
NOTE
Starting the Engine (Honda engine):
This section is intended to assist the operator with the initial
start-up of the compactor. It is extremely important that
this section be read carefully before attempting to use the
compactor in the field.
1. Place the fuel valve lever (Figure 10) in the ON position.
CAUTION - Using the Recoil Starter Rope
Figure 14. Recoil Starter Grip (Pull to Start)
6. If the engine has started, slowly return the choke lever
(Figure 11) to the CLOSED position. If the engine has not
started repeat steps 1 through 5.
7. Before the compactor is put into operation run the engine
for 3-5 minutes.
8. Check for abnormal engine noises or fuel leaks.
Discount-Equipment.com

PAGE 20 — MVC-90H PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV. #3 (01/10/11)
l
MVC-90H PLATE COMPACTOR — SHUT-DOWN PROCEDURE
NEVER stop the engine suddenly while working at high
speeds. This can damage your engine.
1. Place the
throttle lever (Figure 15) in SLOW position,
and listen for the engine speed to decrease.
Stopping the Engine
Figure 15. Throttle Lever (SLOW Position)
2. Place the Engine ON/OFF switch (Figure 16) in the OFF
position.
Figure 16. Engine ON/Off Switch (OFF Position)
3. Place the fuel valve lever (Figure 17) in the OFF
position.
Figure 17. Fuel Valve Lever (OFF Position)
CAUTION - Stopping the engine while working
Emergency Shutdown Proucedure:
1. Move the throttle lever quickly to the SLOW position
(Figure 15).
2. Place the engine ON/OFF switch in the OFF position
(Figure 16).
Discount-Equipment.com

MVC-90H PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV. #3 (01/10/11)— PAGE 21
MVC-90H PLATE COMPACTOR — OPERATION
Operation
1. Once the engine has started, move the engine throttle
lever quickly to the FAST position. With the throttle lever
in the fast position, the engine speed should be around
2,300 RPM, which engages the centrifugal clutch.
2. Firmly gasp the compactor's handle bar with both hands
as the compactor begins moving forward.
3. Slowly walk behind the compactor and be on the lookout
for any large objects or foreign matter that might cause
damage to the compactor or bodily injury.
Make sure to follow all safety rules referenced in the safety
section of this manual before operating compactor. Keep
work area clear of debris and other objects that could cause
damage to the compactor or bodily injury.
Operating the Compactor on High Moisture Content Soil
Compactor traveling speed may drop on soils which contain
clay, or other types of soil.Soil with high moisture content can
cause the compaction plate to "stick" to the ground (not lifting
up off the ground very fast or high).
To rectify this problem, consider the following:
 Check the bottom plate to see if clay or equivalent
material has been lodged in the plate mechanism. If so,
wash with water and remove.
 Remember the compactor does not work as efficiently
on clay or soils that have a high moisture content level.
 If the soil has a high moisture level, dry soil to
appropriate moisture content level or carry out
compaction twice.
Always move the throttle lever
quickly without hesitation.
Increasing the engine speed
slowly causes the clutch to slip
and can damage your clutch.
CAUTION - General Operation Safety
NOTE
Using the Compactor Sprinkler System
The MVC-90H is equipped with a watering system that can
be used to wet the ground during compaction to keep dust
levels down.
To operate the watering system, turn the water cock handle
to open the valve (Figure 18) and start the water flow.With the
compactor at full speed and the water cock fully open, the
water system will provide approximately 20 minutes of
sprinkling.
Figure 18. Water System
Whenever the compactor's vibra-
tion becomes weak or lost during
normal operation regardless of op-
eration hours, check the V-belt
and clutch immediately.
NOTE
Discount-Equipment.com

PAGE 22 — MVC-90H PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV. #3 (01/10/11)
l
Inspection and Maintenance Service Tables.
To make sure your plate compactor is always in good working
condition before using, carry out the maintenance inspection
in accordance with Tables 5 through 7.
These inspection intervals are for
operation under normal
conditions. Adjust your inspection
intervals based on the number
hours plate compactor is in use,
and particular working conditions.
MVC-90H PLATE COMPACTOR — MAINTENANCE
NOITCEPSNIENIGNE.6ELBAT
)launaMenignEetarepesees,sliatedroF(
metIkcehCnoitarepOfosruoH
egakaeLliOroleuF)yliaD(sruoH8yrevE
sdaerhTgninetsaF
ssenthgiT )yliaD(sruoH8yrevE
hsinelpeR/kcehC
liOenignE )yliaD(sruoH8yrevE
liOenignEecalpeR ,sruoh02tsriF
sruoh001yreveneht
ehtnaelC/kcehC
renaelCriA sruoh05yrevE
EUQROTGNINETHGIT.5ELBAT
retemaiD)mc/gk.ni(
lairetaM mm6 mm8 mm01 mm21 mm41 mm61 mm81 mm02
T4 07 051 003 005 057 001,1 004,1 000,2
T8-6 001 052 005 008 003,1 000,2 007,2 008,3
T11 051 004 008 002,1 000,2 009,2 002,4 006,5
*001
)mm6(
053~003
)mm8(
007~056
)mm01(
)munimulafositrap-retnuocesacnI(*
.wercsdna,tlobhcaenodekramsilairetamfoytilauqdnalairetaM
dednahthgirllaeraenihcamsihthtiwesunisdaerhT:etoN
Fuel piping and connections should
be replaced every 2 years.
Daily Service
 Check for leakage of fuel or oil.
 Remove soil and clean the bottom of compaction plate.
 Check engine oil.
 Check for loose screws including tightness. See Table 5
below (tightening torque ), for retightening:
H09-CVM.7ELBATNOITCEPSNIENIHCAM
METI FOSRUOH
NOITAREPO SKRAMER
straPdegamaDsruoh8yrevE erofeBkcehC
noitarepOyliaD
swercStsoLroesooLsruoh8yrevE erofeBkcehC
noitarepOyliaD
gnillortnoCfonoitcnuF
traPmetsyS sruoh8yrevE erofeBkcehC noitarepOyliaD
kcehCliOrotarbiVsruoh001yrevE
12egaPeeS
liOrotarbiV
tnemecalpeR sruoh003yrevE
kcehChctulC&tleb-Vsruoh002yrevE22egaPeeS
CAUTION - General Maintenance Safety
Maintenance
Inspection and other services should
always be carried
out on hard and level ground with the engine shutdown.
NOTE
NOTE
Discount-Equipment.com
