MULTIQUIP Mikasa MT-86D Guide

© COPYRIGHT 2004, MULTIQUIP INC.
PARTS AND OPERATION MANUAL
OPERATION AND PARTS MANUAL
MULTIQUIP INC..
..
. PARTS DEPARTMENT:
18910 WILMINGTON AVE. 800-427-1244
CARSON, CALIFORNIA 90746 FAX: [phone]
310-537-3700
SERVICE DEPARTMENT/TECHNICAL ASSISTANCE:
800-421-1244 800-478-1244
FAX:[phone] FAX:[phone]
E-mail:[email protected] •www:multiquip.com
Atlanta • Boise • Dallas • Houston • Newark
Montreal, Canada • Manchester, UK
Rio De Janiero, Brazil • Guadalajara, Mexico
Revision #7 (09/02/04)
Tamping Rammer
Model
MT-86D
(YANMAR L40A-DRM ENGINE)

PAGE 2 — MT-86D — PARTS & OPERATION MANUAL — REV. #7 (09/02/04)

MT-86D — PARTS & OPERATION MANUAL — REV. #7 (09/02/04) — PAGE 3
HERE'S HOW TO GET HELP
PLEASE HAVE THE MODEL AND SERIAL
NUMBER
ON-HAND WHEN CALLING
MULTIQUIP’S MAIN PHONE NUMBERS
800-421-1244 FAX: [phone]
310-537-3700
PARTS DEPARTMENT
800-427-1244 FAX: [phone]
310-537-3700 FAX: [phone]
MAYCO PARTS
800-306-2926 FAX: [phone]
310-537-3700 FAX: [phone]
SERVICE DEPARTMENT
800-478-1244 FAX: [phone]
310-537-3700
MQ POWER SERVICE DEPARTMENT
800-835-2551 FAX: [phone]
310-537-3700
TECHNICAL ASSISTANCE
800-478-1244 FAX: [phone]
WARRANTY DEPARTMENT
800-421-1244, EXT. 279 FAX: [phone]
310-537-3700, EXT. 279

PAGE 4 — MT-86D — PARTS & OPERATION MANUAL — REV. #7 (09/02/04)
Specification and part
number are subject to
change without notice.
YANMAR L40A-DRM
ENGINE
Cylinder Block Assembly ................................... 30-31
Cylinder Head and Bonnet Assembly ............... 32-33
Crankshaft,Piston and Camshaft Assembly...... 34-35
Lub.,Oil Pump and Governor Assembly ............ 36-37
Cooling and Starting Assembly......................... 38-39
Fuel Injection Pump Assembly .......................... 40-41
Air Cleaner and Muffler Assembly .................... 42-43
Label and Gasket Set Assembly ....................... 44-45
Loose Parts Assembly ...................................... 46-47
Terms and Condition Of Sale —Parts ....................48
MIKASA MT-86D —
Tamping Rammer
Here's How To Get Help ............................................3
Table Of Contents .....................................................4
Parts Ordering Procedures .......................................5
Rules For safe Operation ..................................... 6-7
Operation and Safety Decals ....................................8
General Information ..................................................9
Specification ............................................................10
Controls and Components ......................................11
Operation .......................................................... 12-16
Troubleshooting Guide ............................................17
Explanation Of Codes In Remarks Column ............18
Suggested Spare Parts ...........................................19
Name Plate And Decals .................................... 20-21
Crankcase and Engine Assembly ..................... 22-24
Guide Cylinder and Foot Assembly .................. 26-27
Tank and Handle Assembly .............................. 28-29
NOTE
MT-86D — TABLE OF CONTENTS

MT-86D — PARTS & OPERATION MANUAL — REV. #7 (09/02/04) — PAGE 5
PARTS ORDERING PROCEDURES
When ordering parts,
please supply the following information:
❒❒
❒❒
❒Dealer account number
❒❒
❒❒
❒Dealer name and address
❒❒
❒❒
❒Shipping address (if different than billing address)
❒❒
❒❒
❒Return fax number
❒❒
❒❒
❒Applicable model number
❒❒
❒❒
❒Quantity, part number and description of each part
❒❒
❒❒
❒Specify preferred method of shipment:
✓FedEx or UPS Ground
✓FedEx or UPS Second Day or Third Day
✓FedEx or UPS Next Day
✓Federal Express Priority One
✓DHL
✓Tr u c k
Here’s how to get help...
Please have the model and serial number on
hand when calling.
Parts Department
800-427-1244 Fax: [phone]
310-537-3700 Fax: [phone]
Mayco Parts
800-306-2926 Fax: [phone]
310-537-3700 Fax: [phone]
Service Department
800-478-1244 Fax: [phone]
310-537-3700
MQ Power Service Department
800-835-2551 Fax: [phone]
310-537-3700
Technical Assistance
800-478-1244 Fax: [phone]
Warranty Department
800-421-1244, Ext. 279 Fax: [phone]
310-537-3700, Ext. 279
Multiquip’s Main Phone Numbers
800-421-1244 Fax: [phone]
310-537-3700
Note:Unless otherwise indicated by customer, all
orders are treated as “Standard Orders”, and will
ship within 24 hours.We will make every effort to
ship “Air Shipments” the same day that the order is
received, if prior to 2PM west coast time. “Stock
Orders” must be so noted on fax or web forms.
Extra Discounts!
All parts orders which include complete part numbers
and are received by our automated web parts order
system, or by fax qualify for the following extra
discounts:
Ordered Standard Stock orders
via orders ($750 list and above)
Fax 3% 10%
Web 5% 10%
Special freight allowances
when you order 10 or more
line items via Web or Fax!**
FedEx Ground Service at no charge for freight
No other allowances on freight shipped by any other
carrier.
Place Your Parts Order Via Web or Fax
For Even More Savings!
NOTE:DISCOUNTSARESUBJECTTOCHANGE
MULTIQUIP INC.
18910 WILMINGTON AVENUE
POST OFFICE BOX 6254
CARSON, CALIFORNIA 90749
310-537-3700•800-421-1244
FAX:[phone]
E-MAIL: [email protected]
WWW: multiquip.com
Direct TOLL-FREE access
to our Parts Department:
Toll-free nationwide — 800-427-1244

PAGE 6 — MT-86D — PARTS & OPERATION MANUAL — REV. #7 (09/02/04)
CAUTION:
Failure to follow instructions in this manual
may lead to serious injury or even death! This
equipment is to be operated by trained and
qualified personnel only! This equipment is
for industrial use only.
The following safety guidelines should always be used when
operating the MT-86D Tamping Rammer:
GENERAL SAFETY
■ DO NOT operate or service this equipment before
reading this entire manual.
■ This equipment should not be operated by persons under 18
years of age.
■ NEVER operate this equipment without proper
protective clothing, shatterproof glasses,
steel-toed boots and other protective devices
required by the job.
■ NEVER operate this equipment when not
feeling well due to fatigue, illness or
taking medicine.
■ NEVER operate this equipment under the
influence or drugs or alcohol.
■ NEVER use accessories or attachments, which are not
recommended by Multiquip for this equipment. Damage to
the equipment and/or injury to user may result.
■ Manufacture does not assume responsibility for any accident
due to equipment modifications.
■ Whenever necessary, replace nameplate, operation and
safety decals when they become difficult read.
■ Always check the machine for loosened threads or bolts before
starting.
MT-86D — RULES FOR SAFE OPERATION
■ Always refuel in a well-ventilated area, away from sparks and
open flames.
■ Always use extreme caution when
working with flammable liquids. When
refueling, stop the engine and allow it
to cool. DO NOT smoke around or near
the machine. Fire or explosion could
result from fuel vapors, or if fuel is spilled
on a hot engine.
■ NEVER operate the rammer in an explosive atmosphere or
near combustible materials. An explosion or fire could result
causing severe
bodily harm or even death.
■ Topping-off to filler port is dangerous, as it tends to spill fuel.
■ NEVER touch the hot exhaust
manifold, muffler or cylinder. Allow
these parts to cool before servicing
engine or rammer.
■ The engine section of this rammer requires an adequate free
flow of cooling air. Never operate the rammer in any enclosed
or narrow area where free flow of the air is restricted. If the air
flow is restricted it will cause
serious damage to the
rammer or engine and may
cause injury to people.
Remember the rammer's
engine gives off DEADLY
carbon monoxide gas.
■ HighTemperatures – Allow the engine to cool before adding
fuel or performing service and maintenance functions. Contact
with
hot components can cause serious burns.

MT-86D — PARTS & OPERATION MANUAL — REV. #7 (09/02/04) — PAGE 7
MT-86D — RULES FOR SAFE OPERATION
■ NEVER Run engine without air filter. Severe engine may occur.
■ Always service air cleaner frequently to prevent carburetor
malfunction.
■ Always be sure the operator is familiar with proper safety
precautions and operations techniques before using rammer.
■ Always store equipment properly when it is not being used.
Equipment should be stored in a clean, dry location out of the
reach of children.
■ NEVER use accessories or attachments, which are not
recommended by Multiquip for this equipment. Damage to the
equipment and/or injury to user may result.
■ NEVER Run engine without air cleaner. Severe engine damage
may occur.
■ Always read, understand, and follow procedures in Operator’s
Manual before attempting to operate equipment.
■ Always be sure the operator is familiar with proper safety
precautions and operations techniques before using pump.
■ Always store equipment properly when it is not being used.
Equipment should be stored in a clean, dry location out of the
reach of children.
■ Refer to the ROBIN Engine Owner's Manual for engine
technical questions or information recommended by Multiquip
for this equipment. Damage to the equipment and/or injury to
user may result.
Transporting
■ Always shutdown engine before transporting.
■ Tighten fuel tank cap securely and close fuel cock to prevent
fuel from spilling.
■ Drain fuel when transporting rammer over long distances
or bad roads.
■ When placing the rammer inside a truck-bed for transport,
always tie-down the rammer.
Emergencies
■ Always know the location of the nearest fire extinguisher
and first aid kit . Know the location of the nearest telephone.
Also know the phone numbers of the nearest
ambulance ,
doctor and fire department . This information will be
invaluable in the case of an emergency.
Maintenance Safety
■ NEVER lubricate components or attempt service on a
running machine.
■ Always allow the machine a proper amount of time to cool
before servicing.
■ Keep the machinery in proper running condition.
■ Fix damage to the machine immediately and always replace
broken parts.
■ Dispose of hazardous waste properly. Examples of
potentially hazardous waste are used motor oil, fuel and
fuel filters.
■ DO NOT use food or plastic containers to dispose of
hazardous waste.

PAGE 8 — MT-86D — PARTS & OPERATION MANUAL — REV. #7 (09/02/04)
MT-86D — OPERATION AND SAFETY DECALS

MT-86D — PARTS & OPERATION MANUAL — REV. #7 (09/02/04) — PAGE 9
Definition of Tamping Rammer
The Mikasa MT-86D tamping rammer is a powerful compacting
tool capable of applying a tremendous force in consecutive
impacts to a soil surface. Its applications include soil compacting
for road, embankments and reservoirs as well as backfilling for
gas pipelines, water pipelines and cable installation work.
The impact force of the MT-86D levels and uniformly compacts
voids between soil particles to increase dry density.
Circular motion is converted to create impact force.The MT-86D
tamping rammer develops a powerful compacting force at the
foot of the rammer. To maintain optimum performance, proper
operation and service are essential.
Construction of Tamping Rammer
The Mikasa MT-86D Tamping Rammer is equipped with an Robin
air cooled, four cycle gasoline engine.Transmission of the power
takes place by increasing the engine speed to engage the
centrifugal clutch.
Rammer Gearbox and Spring Cylinder
The Mikasa MT-86D uses an oil bath lubrication system. Always
check the oil level through the oil level sight glass at the rear of
the tamper foot.
Controls
Before starting the MT-86D Tamping Rammer, identify and
understand the function of the controls, see Figure 1 on page 11.
MT-86D — GENERAL INFORMATION

PAGE 10 — MT-86D — PARTS & OPERATION MANUAL — REV. #7 (09/02/04)
MT-86D — SPECIFICATIONS
Specifications are general and are subject to change without notice. If
exact measurements are required, equipment should be weighed and
measured.
snoitacificepSremmaRD68-TM.1elbaTsnoitacificepSremmaRD68-TM.1elbaT snoitacificepSremmaRD68-TM.1elbaT snoitacificepSremmaRD68-TM.1elbaTsnoitacificepSremmaRD68-TM.1elbaT
LEDOM)cirtem(.S.UD68-TM
thgieHllarevO)mm000,1(.ni4.93
htdiWllarevO)mm014(ni1.61
htgneLrevO)mm027(ni3.82
eziSe
ohS)mm033(.ni31
etunim/swolB007
ecroFtcapmI)wolb/gk140,2(wolb/.sbl005,4
hctulClagufirtneCcitamotuA
thgieWgnit
arepO)gk29(.sbl202
snoitacificepSenignEDTSMRDA04-LramnaY.2elbaTsnoitacificepSenignEDTSMRDA04-LramnaY.2elbaT snoitacificepS
enignEDTSMRDA04-LramnaY.2elbaT snoitacificepSenignEDTSMRDA04-LramnaY.2elbaTsnoitacificepSenignEDTSMRDA0
4-LramnaY.2elbaT
LEDOMENIGNEDTSMRDA04-LramnaY
epyTenignEleseiDekortS4delooC-riA
tnemecalpsiDnotsiP)cc991(.ni.uc41.21
daoLoN,
deepSdenrevoG.xaMmpr003,3
metsySgnilooCdelooC-riA
metsySnoitacirbuL IPAliOgnitacirbubuLenignEleseiD
edarG"D
C"ro"CC"noitacifissalC
leuFleuFleseiDevitomotuA
metsySgnitratS nruteR-otuAhtiwretratSlioceR
eciveDnoisserp
moceD
NOTE

MT-86D — PARTS & OPERATION MANUAL — REV. #7 (09/02/04) — PAGE 11
8. Foot– Laminated wood with tempered steel plate for
superior shock absorption.
9. Muffler– Used to reduce noise and emissions.
10. Engine Air Cleaner – Prevents dirt and other debris
from entering the engine.
11. Decompression Lever – Use in the starting of the
engine. Press lever to engage. After engine starts lever
will return to original position.
12. Fuel Filter – Located inside fuel tank. Prevents dirt and
debris from entering fuel system.
13. Recoil Starting Handle – Used when starting the engine.
Pull starter handle sharply and quickly, then return
starter handle to starter case before releasing.
14. Handle – To operate rammer GRIP handle assembly
firmly on both sides.
15. Bellows – Reservoir for oil bath.
Figure A shows the location of the controls and components
for the MT-86D Tamping Rammer. The functions of each
control is described below:
1. Fuel Tank/Cap – Remove this cap to add diesel fuel.
Use high grade automotive diesel fuel only.
2. Throttle Lever – Controls engine speed and the tamping
action of the rammer.
3. Engine Oil Dipstick – Indicates the level of the engine oil
Use CC class or higer grade motor oil.
4. Oil filter – Prevents dirt and other debris from entering the
engine.
5. Oil Bath Fill Plug – Open this plug to add oil to the oil
bath reservoir.
6. Oil Level Sight Glass – Indicates the level of oil in the oil
bath reservoir.
7. Drain Valve – Open this valve to remove oil from the
bellows.
MT-86D — CONTROLS AND COMPONENTS
Figure A. MT-86D Tamping Rammer

PAGE 12 — MT-86D — PARTS & OPERATION MANUAL — REV. #7 (09/02/04)
1. Definition of Tamping Rammer
The Mikasa MT-86D diesel rammer is a powerful compacting
tool capable of applying tremendous force in consecutive
impacts to a soil surface.The impact force of the MT-86D levels
and uniformly compacts voids between soil particles to increase
dry density. Its applications include soil compacting for road,
embankment and reservoirs as well as backfilling for gas
pipelines, water pipelines and cable installation work.
2. Construction of Tamping Rammer
The rammer is equipped with an air-cooled, four-stroke diesel
engine. Transmission of the power takes place by increasing
engine speed to engage a centrifugal clutch. Circular motion is
converted into vertical motion to create impact force.
3-2. Preparation Inspection:
Rammer Gearbox and Spring Cylinder. This unit uses an oil
bath lubrication system. Check oil level through oil level sight
glass at rear of tamper foot. If oil is not visible, add #10W-30
motor oil. Oil bath contains approx. 1.7 pt. (800cc) for MT-86D.
3-3. Engine:
Use only automobile diesel fuel (Fig. 1). Check the engine oil
before starting operation and fill the oil regularly (Fig. 2). For
checking the oil level, move the engine to vertical position and
check that the oil is level with the oil inlet (about 700cc).
3-4. Check all nuts, bolts and fasteners for tightness. Retighten
as necessary.
3-5. Clean dirt from the recoil starter and foot. Wipe entire unit
clean before operating.
3-6. Replace any missing or damaged Safety/Operation decals.
MT-86D — OPERATION
Fig. 1
Fig. 2

MT-86D — PARTS & OPERATION MANUAL — REV. #7 (09/02/04) — PAGE 13
MT-86D — OPERATION
Fig. 4
Fig. 5
4. Starting
4-1. Move the throttle lever to IDLE position. (Fig. 3)
Throttle lever is used only at three (STOP, IDLE
& OPERATION) positions. When moving the
lever from stop to idle position, depress button
on lever at same time it is moved.
In cold weather, the engine should be started
at operating position or between the idle and
operation position of the throttle lever. Use
caution as higher engine RPM may engage
clutch, when engine starts. Return throttle lever
from starting position to idle position when
engine starts.
4-2. Grip the recoil starter handle and pull it until you feel a
slight resistance. (Fig. 4)
4-3. Press the decompression lever to release decompression.
The decompression lever will return automatically when the
recoil starter is pulled. (Fig. 5)
4-4. Return the recoil starter, and pull the handle sharply and
quickly.Warm up the engine by running at low speed for three
to five minutes, while checking for fuel leakage or abnormal
sounds.
Do not pull the starter rope all the way to the
end and do not let the starter rope snap back
as damage may result.
Fig. 3

PAGE 14 — MT-86D — PARTS & OPERATION MANUAL — REV. #7 (09/02/04)
5. Operation
5-1. Move the throttle lever quickly from the IDLE to OPERATION
position to start tamping action. DO NOT move the throttle lever
slowly as this may cause damage to the clutch or spring box.
5-2.The tamping rammer is designed to tamp the ground 700
times per minute at an engine speed of 3,300 rpm. Increasing
the engine speed above the recommended rpm will not increase
the rammer effectiveness. Impact will actually decrease because
a resonance is created rather than a tamping effect, and damage
to the unit can result.
5-3.The rammer can be warmed by quickly moving the throttle
lever from the OPERATION to the IDLE position several times
until the rammer operates smoothly.
5-4. The tamping rammer is designed to travel forward while
tamping. To increase travel speed, pull back slightly on the
handle so that the rear of the foot contacts the soil first.
5-5. To stop tamping, quickly move the throttle lever from the
OPERATION to IDLE position. Do not move the lever slowly as
irregular action and damage may result.
6. Stopping the Engine
6-1. Move throttle lever quickly from idle to STOP while pressing
the throttle lever button. Run the engine for three minutes at idle
speed to allow for proper cool down. Following the above
procedures will prevent improper cylinder lubrication caused
by a overheated engine. (Fig. 6)
7. Service
CAUTION:
Flammable Liquid: When refueling, stop engine and allow it
to cool.. Do no smoke or allow work to be
performed in the immediate area. Fire or
explosion could result from flames or sparks,
or if fuel is spilled on a hot engine.
Moving Parts: Shut down the engine before
performing service or maintenance functions.
Contact with moving parts can cause serious injury.
HighTemperatures: Allow machine and engine to cool before
performing service or maintenance functions. Contact with hot
components can cause serious burns.
Fig. 6
Fig. 8
Fig. 7
MT-86D — OPERATION

MT-86D — PARTS & OPERATION MANUAL — REV. #7 (09/02/04) — PAGE 15
7-1. Daily
■ Thoroughly remove dirt and oil from the engine and control
area.
■ Clean or replaces air cleaner as necessary.
■ Check and retighten all fasteners as necessary.
■ Check spring box and bellows for oil leaks. Repair as
needed.
■ Remove element from pre-cleaner at the top of crankcase
(body side) and clean it by air.
7-2.WEEKLY (every 50 hours)
■ Remove the fuel filter cap and inspect for dirt in the fuel
tank. (Fig. 7)
7-3. Replacement of Lubricant (BODY)
■ Remove the drain plug at the rear of tamper foot and drain
the dirty oil. Refill with clean oil to the middle of the sight
glass. Oil bath contains approx. 1.7 pt. (800 cc) for MT-86D.
INITIAL OIL CHANGE:
Temperature Classification of Oil
20°C (+68°F) or over
CC class or higher
grade
SAE 30
10¨C (+14°F) to
0°C (+68°F) SAE 20
Below 10° (+14°F) SAE 10W-30
After 50 hours of operation
SECOND OIL CHANGE AND/OR LATER
Every 200 hours of operation
7-4. Replacement of Lubricant (ENGINE)
7-4-1. While the engine is still warm, remove the drain plug. For
quick discharging, it is advisable to take off the oil gauge. Replace
drain plug and refill engine crankcase. (Fig. 8)
7-4-2. Refer to the following chart, for oil types
Inferior quality engine oil and/or lack of oil may cause engine
trouble or shorten engine life.
7-4-3.The interval of oil replacement
INITIAL OIL CHANGE:
After 20 hours of operation
SECOND OIL CHANGE AND/OR LATER:
Every 100 hours of operation
Fig. 11
Fig. 9
Fig. 10
MT-86D — OPERATION

PAGE 16 — MT-86D — PARTS & OPERATION MANUAL — REV. #7 (09/02/04)
7-5. Cleaning the Air Cleaner
Cleaning the Air Cleaner (every 200-300 hours) (Fig. 9)
■ Remove element from pre-cleaner at the top of crankcase
(body side).
■ Wash the element (outside) in detergent solution.
■ Shake out excess moisture and dry the element.
■ Clean inside element with air from the inside of element.
7-6. Cleaning the Oil Filter
Drain oil filter every 100 hours of operation. Replace the oil filter
every 1,000 hours of operation. (Fig. 10)
7-7. Fuel Pipe & Oil Pipe
7-8. Transportation
Maintain upright position of rammer at all times. Transport
rammer in upright position. If machine must be laid down for
transportation, drain the diesel fuel first and lay machine with
muffler side down (Fig. 11)
The fuel filter is installed at the bottom of fuel tank. Should the
rammer be laid on its side, dirt from the fuel filter may contaminate
the injection nozzle, causing damage to the fuel pump.
7-9. Storage
■ When storing the rammer for long periods of time,
thoroughly drain all fuel from line.
■ Clean exterior of rammer with an oil moistened cloth. Cover
and store in a clean, dry place.
MT-86D — OPERATION
■ Check fuel line regularly for damage,
paying attention to clamps to assure
a tight fit.
■ Replace fuel line every two years to
maintain original performance.

MT-86D — PARTS & OPERATION MANUAL — REV. #7 (09/02/04) — PAGE 17
Engine
A. Difficult to start
1 No diesel fuel
2 Throttle lever at wrong position (Stop position)
3 Excess engine oil
4 Injection nozzle clogged
5 Recoil starter not pulled with enough speed.
6 Air cleaner clogged
7 Clutch failure
8 Fuel line clogged
B. Operation not satisfactory
1 Engine speed improperly set.
2 Clutch slips
3 Excess lubricant oil causing irregular jumping or
protective sleeve is heated.
4 Lack of lubricant oil causing irregular jumping.
5 Spring failure
6 Spring cylinder locked
MT-86D — TROUBLESHOOTING

PAGE 18 — MT-86D — PARTS & OPERATION MANUAL — REV. #7 (09/02/04)
How to read the marks and remarks used in this parts
book.
Items Found In the “Remarks” Column
Serial Numbers-Where indicated, this indicates a serial
number range (inclusive) where a particular part is used.
Model Number-Where indicated, this shows that the
corresponding part is utilized only with this specific model
number or model number variant.
Items Found In the “Items Number” Column
All parts with same symbol in the number column, *, #, +, %, or
>>
>>
> , belong to the same assembly or kit.
MT-86D —TEXPLANATION OF CODE IN REMARKS COLUMN
If more than one of the same
reference number is listed,
the last one listed indicates
newest (or latest) part
avaliable.
The contents of this catalog
are subject to change
without notice
.
NOTE
NOTE

MT-86D — PARTS & OPERATION MANUAL — REV. #7 (09/02/04) — PAGE 19
Part numbers on this
Suggested Spare Parts List
may super cede/replace the
P/N shown in the text pages
of this book.
MT-86D DIESEL RAMMER
1-3 UNITS
1 .... 956200040 ........... THROTTLE LEVER ASSY
1 .... 956108040 ........... THROTTLE WIRE
3 .... 371010060 ........... ELEMENT ASSY
2 .... 954405080 ........... STRAINER, FUEL TANK
3 .... 18325455120 ....... STRAINER ASSY, FUEL
1 .... 0430430015 ......... CAP, FUEL TANK
1 .... 16071001760 ....... CAP, W/LUB OIL GA.
2 .... 11425035070 ....... STRAINER, OIL LUB.
2 .... 16026076630 ....... ROPE, RECOIL STARTER
MT-86D —SUGGESTED SPARE PARTS
NOTE

PAGE 20 — MT-86D — PARTS & OPERATION MANUAL — REV. #7 (09/02/04)
MT-86D— NAME PLATE AND DECALS
NAME PLATE AND DECALS
