MULTISPAN MFM 14DC User manual

MFM 14DC
DC MULTIFUNCTION METER
TECHNICAL SPECIFICATION
ENVIRONMENTAL CONDITION
Working Temperature
Storage Temperature
Relative Humidity
0 to 55°C
0 to 55°C
95 % RH Non-
Condensing
ACCURACY
96 (H) x 96 (W) x 54 (D) mm
92 (H) x 92 (W) mm
TERMINAL CONNECTION
IP-65 (Front side As per
IS/IEC 60529 : 2001)
Protection Level
Class 1.0 (Standard)
( As per Request )
96
92
92
96
Outline Dimension (mm) Panel Cutout
Dimension (mm)
MECHANICAL INSTALLATION
MFM 142DC
DC POWER METER
PRG
RESET
54
3
DIMENSION :
Size (mm)
Panel Cutout
100V to 270V AC
Approx 5VA @ 230V AC
AUXILIARY POWER SUPPLY :
DISPLAY & KEYS :
Display
Key
Power Supply
Burden
Direct voltage DC
Input Current
Shunt Selectable
0 to 1000V DC
Through external shunt
(-75mV To+75mV DC)
-999 - 9999 A DC
-999 - 9999 KW
6 Digit, 7 seg. 0.40" RED
4 Digit, 3 Line 7 seg. 0.40" RED
0.00 - 49.99 V DC 1 % OF 49.99V
1 % OF 199.9V
1 % OF 399.9V
1 % OF 1000 V
1 % OF FSD
50.0 - 199.9 V DC
200.0 - 399.9 V DC
400.0 - 1000 V DC
5 to 9999 Amp
CALCULATED PARAMETERS :
DC Voltage
DC Current
WATT
INPUT SPECIFICATION :
Voltage
Current
Parameter Range Accuracy
RESET, PRG, INC, DEC
0 - 999999 KWH
KWH
1 2 3 4 78910
56
20 19 18 17 14 13 12 11
16 15
LN
www.multispanindia.com
Voltage: 0 To 1000V DC
Current: -999 To 9999 Amp DC
(Through Shunt)
Input: -75 To 75mV
Accuracy: Class 1.0
Made in India
~
50/60 HZ
5VA
100
270V AC
GND +T DC +V DC
LOAD
SHUNT
+1000V DC
GND

To enter in parameter setting
To Reset the KWH Value
PRESS KEYFUNCTION
OPERATOR MODE
PARAMETER SETTING MODE
To set parameter value
To increment parameter value.
To decrement parameter value.
Set parameter to be save & exit.
Press
5 sec
PRG
RESET
PRG
PRG
DISPLAY INDICATION
DC POWER METER
KWH Value
DC Volt
DC Amp
DC Watt
KEY OPERATION
1. Prepare the panel cutout with proper dimensions as shown
above.
2. Fit the unit into the panel with the help of clamp given.
3. The equipment in its installed state must not come in close
proximity to any heating source, caustic vapors, oil steam,
or other unwanted process byproducts.
4. Use the specified size of crimp terminal (M3.5 screws) to
wire the terminal block. Tightening the screws on the
terminal block using the tightening torque of the range of
1.2 N.m.
5. Do not connect anything to unused terminals.
1. The equipment should be cleaned regularly to avoid
blockage of ventilating parts.
2. Clean the equipment with a clean soft cloth. Do not use
isopropyl alcohol or any other cleaning agent.
3. Fusible resistor must not be replaced by operator.
MAINTENANCE
MECHANICAL INSTALLATION
MAINTENANCE
Read complete instructions prior to installation
and operation of the unit.
WARNING : Risk of electric shock.
SAFETY PRECAUTION
!
Please read the "Safety Warnings" in the instruction
manual supplied with the instrument thoroughly and
completely for correct use. Failure to follow the safety rules
can cause fire, trouble, electrical shock, etc. Therefore, make
sure to operate the instrument on a correct power supply
and voltage rating marked on each instrument.
If all the equipment is not handled in a manner specified
by the manufacturer, it might impair the protection provided
by the equipment.
WARNING GUIDELINES
WARNING : Risk of electric shock.
1) To prevent the risk of electric shock, power supply to the
equipment must be kept OFF while doing the wiring
arrangement. Do not touch the terminals while power is
being supplied.
2) To reduce electro magnetic interference, use wire with
adequate rating and twists of the same of equal size shall
be made with shortest connection.
3. Cable used for connection to power source, must have a
cross section of 1mm or greater. These wires should have
insulations capacity made of at least 1.5kV.
4) A better anti-noise effect can be expected by using
standard power supply cable for the instrument.
1) Do not allow pieces of metal, wire clippings, or fine
metallic fillings from installation to enter the product or
else it may lead to a safety hazard that may in turn
endanger life or cause electrical shock to the operator.
2) Circuit breaker or mains switch must be installed
between power source and supply terminal to facilitate
power ‘ON’ or ‘OFF’ function. However this mains switch
or circuit breaker must be installed at convenient place
normally accessible to the operator.
INSTALLATION GUIDELINES
3) Use and store the instrument within the specified ambient
temperature and humidity ranges as mentioned in this
manual.

Press Key to Save & Exit
PRG
Press Key
PRG
Shunt Selectable
Range:
5 to 9999Amp
Press Key For 5 Sec.
To Enter in Parameter Setting
PRG
A M P
Password -
(10)
PARAMETER SETTING
KWH
YES/NO
To Reset KWH Press Key For 5 Sec
RESET
Press Key
PRG
To Reset KWH Press Key
PRG
Y E S
Password
(15)
KWH RESET
Note :- To Change Parameter Value
Press OR Key
