MULTISPAN AV-14DA User manual

AV 14DA

DC AMPERE METER
AV-14DA AV-24DA AV-34DA
96 X 96mm 72 X 72mm
OPERATING MANUAL
AV-14DA,24DA,34DA
Technical Specification
1 TO 9999
Power Supply
Protection Level
Operating Relative
(As per request)
Temperature Humidity
230V AC, 50 Hz, Approx 4VA
IP-65(Front side) AS per IS/IEC 60529:2001
0°C To 55°C Up to 95% RH Non Condensing
Model
Display
Size(HXWXD)
Panel Cutout
Input
Range
AV 14DA
96 X 96 X 50 mm
68 X 68 mm
92 X 92 mm 44 X 92 mm
72 X 72 X 85 mm 48 X 96 X 55 mm
4 Digit, Single Display
AV 24DA AV 34DA
75mV DC
AV 24DA

AV 34DA
48 X 96mm

NOTE : Every Time, When Instrument is turned on following parameter will be displayed.
(POWER ON)
(Process Value)



(Previously selected High range
value Display for 2 Second)
www.multispanindia.com
Page - 1
AV-14DA/24DA/34DA

(POWER ON)
(Enter“37” Password for parameter Setting)
(Decimal Point)
(High Range)








(Set by & key)
Press key
SET
Press key
SET
Press key
SET
Press key
SET
Press key
SET
Press key
SET
Press key
SET
Press key Save & Exit
SET
(Press & key to set digit value )
(Change by & key )
SET
Procedure for range selection
(Change by & key )
www.multispanindia.com
Page - 2
AV-14DA/24DA/34DA

1 8
2 9
310
11
12
4
5
613
714
AV-24DA
AV-34DA
L
N
!
230V AC
50Hz,4VA
12345678910
Range:
9999A DC CAT III
Selectable up to
75mV DC
Input
+
-
230V AC
50Hz,4VA
LN
!
-
+
Input
75mV DC
AV-14DA
Connection Diagram
12347 8 9 10
56
Range: Selectable up to
9999 Amp DC CAT III
Input
75mV DC
230V AC
50Hz,4VA
LN
!
+
-
www.multispanindia.com
Page - 3
AV-14DA/24DA/34DA

www.multispanindia.com
Page - 4
All safety related codifications, symbols and instructions that appear in this operating manual
or on the equipment must be strictly followed to ensure the safety of the operating personnel as
well as the instrument.
If all the equipment is not handled in a manner specified by the manufacturer, it might impair the
protection provided by the equipment .
=> Read complete instructions prior to installation and operation of the unit.
WARNING : Risk of electric shock.
3) Cable used for connection to power source, must have a cross section of 1mm or greater. These wires
should have insulations capacity made of at least 1.5kV.
2) To reduce electro magnetic interference, use wire with adequate rating and twists of the same of equal size shall
be made with shortest connection.
1) To prevent the risk of electric shock power supply to the equipment must be kept OFF while doing the wiring
arrangement. Do not touch the terminals while power is being supplied.
4) A better anti-noise effect can be expected by using standard power supply cable for the instrument.
1) This equipment, being built-in-type, normally becomes a part of main control panel and such in case the
terminals do not remain accessible to the end user after installation and internal wiring.
2) Do not allow pieces of metal, wire clippings, or fine metallic fillings from installation to enter the product
or else it may lead to a safety hazard that may in turn endanger life or cause electrical shock to the operator.
3) Circuit breaker or mains switch must be installed between power source and supply terminal to
facilitate power ‘ON’ or ‘OFF’ function. However this mains switch or circuit breaker must be
installed at convenient place normally accessible to the operator.
4) Use and store the instrument within the specified ambient temperature and humidity ranges as
mentioned in this manual.
Warning Guidelines
Safety Precautions
Installation Guidelines
Mechanical Installation
Maintenance
1) Prepare the panel cutout with proper dimensions as show above.
2) Fit the unit into the panel with the help of clamp given.
3) The equipment in its installed state must not come in close proximity to any heating source,
caustic vapors, oils steam, or other unwanted process by products.
4) Use the specified size of crimp terminal (M3.5 screws) to wire the terminal block. Tightening the
screws on the terminal block using the tightening torque of the range of 1.2 N.m.
5) Do not connect anything to unused terminals.
1) The equipment should be cleaned regularly to avoid blockage of ventilating parts.
2) Clean the equipment with a clean soft cloth. Do not use isopropyl alcohol or any other cleaning agent.
3) Fusible resistor must not be replaced by operator.
2
AV-14DA/24DA/34DA
AV 24DA

95mm - 3.75 inches
85mm - 3.34 inches
136mm - 5.35 inches
120mm - 4.72 inches
B
B
B
A
A
A
F
E
MODEL A
96mm 96mm 92mm 92mm 3mm 50mm
BC
D E F
DIMENSIONS
MODEL A
72mm 72mm 68mm 68mm 3mm 85mm
BC
D E F
DIMENSIONS
C
C
C
D
D
D
E
F
136mm - 5.35 inches
60mm - 2.36 inches
F
E
MODEL A
48mm 96mm 44mm 92mm 4.5mm 66mm
BC
D E F
DIMENSIONS
AV 14DA

AV 34DA

