MULTISPAN EPM-13N User manual

PowerSupply
Frequency
ActivePower
(KW)
ActivePower
(KWh)
Operating
Temperature
Wiring
System
Relative
Humidity
230VAC,50Hz,Approx4VA
45To65Hz
0000-9999KW
0-999999KWH
0°CTo50°C
3Ph-4W
Upto95%RHNonCondensing
Model
Size(mm)
Display
PanelCutout
VoltageInput
CurrentInput
96(H)X96(W)X50(D)mm
92X92mm
EPM-13N
Protection
Level

(Asperrequest)
IP-65(Frontside)AsperIS/IEC60529:2001
www.multispanindia.com
Page-1
EPM-13N
OPERATINGMANUAL
3PHASEENERGYMETER
EPM-13N
TechnicalSpecification
KWH
KW
EPM 13N
INTG
CT
SET
. 
.
UPPER:7Seg,6digit,0.56,REDLEDdisplayforKWH
LOWER:7Seg,4digit,0.36,REDLEDdisplayforKW
0.1AmpTo5AmpACdirectorC.T
Selectableupto4000/5ratio
50To500VACP-PCATIII
30To300VACP-NCATIII
12347 8 9
12
1314
10
11
5
1617181920
6
15
S1 S1 S1 S2S2S2
RY
B
VRVYVBN
System : 3 Ph-4W
Accuracy Class: 1.0
Range
Current: 0.1 To 5A AC, CAT III
Voltage(P-P) : 50-500V AC, CAT III
(P-N) : 30-300V AC, CAT III
230V AC
50Hz, 4VA
LN
!
CONNECTIONDIAGRAM:

www.multispanindia.com
Page-2
1)PressKey.
2)Nowwithoutreleasingthekeyswitch
ontheinstrument.
3)SelectrequiredCTprimarywithandkey.
4)TosavetheCTRatioswitchOffinstrumentpowersupply.

PowerManagement

BuildingManagementSystem

QualityControlSystem

PlantMaintence

EnergyAudit

ControlPanels

Gensets

PowerDistributionSwitchboards

1)PressKeyfor10seconds.
2)ThenreleaseandpressresetkeyagintoresetKWHitwillshowdonemessage.
CT
SET
EPM-13N
CTPRIMARYSELECTION:
RESETTINGkWh.
APPLICATION:

All safety related codifications, symbols and instructions that appear in this operating manual
or on the equipment must be strictly followed to ensure the safety of the operating personnel as
well as the instrument.
If all the equipment is not handled in a manner specified by the manufacturer, it might impair the
protection provided by the equipment .
=> Read complete instructions prior to installation and operation of the unit.
WARNING : Risk of electric shock.
3) Cable used for connection to power source, must have a cross section of 1mm or greater. These wires
should have insulations capacity made of at least 1.5kV.
2) To reduce electro magnetic interference, use wire with adequate rating and twists of the same of
equal size shall be made with shortest connection.
1) To prevent the risk of electric shock power supply to the equipment must be kept OFF while doing the
wiring arrangement. Do not touch the terminals while power is being supplied.
4) A better anti-noise effect can be expected by using standard power supply cable for
the instrument.
1) This equipment, being built-in-type, normally becomes a part of main control panel and in such case the
terminals do not remain accessible to the end user after installation and internal wiring.
2) Do not allow pieces of metal, wire clippings, or fine metallic fillings from installation to enter the product
or else it may lead to a safety hazard that may in turn endanger life or cause electrical shock to the operator.
3) Circuit breaker or mains switch must be installed between power source and supply terminal to
facilitate power ‘ON’ or ‘OFF’ function. However this mains switch or circuit breaker must be
installed at convenient place normally accessible to the operator.
4) Use and store the instrument within the specified ambient temperature and humidity ranges as
mentioned in this manual.
Warning Guidelines
Installation Guidelines
Mechanical Installation
Maintenance
Safety Precautions
1) Prepare the panel cutout with proper dimensions as show above.
2) Fit the unit into the panel with the help of clamp given.
3) The equipment in its installed state must not come in close proximity to any heating source,
caustic vapors, oils steam, or other unwanted process by products.
4) Use the specified size of crimp terminal (M3.5 screws) to wire the terminal block. Tightening the
screws on the terminal block using the tightening torque of the range of 1.2 N.m.
5) Do not connect anything to unused terminals.
1) The equipment should be cleaned regularly to avoid blockage of ventilating parts.
2) Clean the equipment with a clean soft cloth. Do not use isopropyl alcohol or any other cleaning agent.
3) Fusible resistor must not be replaced by operator.
2
A
B
C
D
MODEL A
96mm 96mm 92mm 92mm 3mm 50mm
BC
D E F
DIMENSIONS
136mm - 5.35 inches
120mm - 4.72 inches
E
F
www.multispanindia.com
Page - 3
EPM-13N
KWH
KW
EPM 13N
INTG
CT
SET
. 
.

www.multispanindia.com
Page-4EPM-13N
Note:
Product improvement and upgrade is a constant procedure. So for more updated operating information and Support,
Please contact our Helpline: 9978 991474/76/82 or Email at Ver:12-2017ser[email protected]
