SMSFinder™
Turnkey SMS Server
Model SF100-G
Quick Start Guide

Copyright and Technical Support
2
SMSFinder™
Turnkey SMS Server
SF100-G
Quick Start Guide
82100360L Rev. A
Copyright © 2008 by Multi-Tech Systems, Inc. All rights reserved. This publication
may not be reproduced, in whole or in part, without prior written permission from
Multi-Tech Systems, Inc. Multi-Tech Systems, Inc. makes no representations or
warranty with respect to the contents hereof and specifically disclaims any implied
warranties of merchantability or fitness for any particular purpose. Furthermore,
Multi-Tech Systems, Inc. reserves the right to revise this publication and to make
changes from time to time in the content hereof without obligation of Multi-Tech
Systems, Inc. to notify any person or organization of such revisions or changes.
Revision Date Description
A 01/25/08 Initial release.
Trademarks
Multi-Tech and the Multi-Tech logo are registered trademarks of Multi-Tech
Systems, Inc. SMSFinder is a trademark of Multi-Tech Systems, Inc.
World Headquarters
Multi-Tech Systems, Inc.
2205 Woodale Drive
Mounds View, Minnesota 55112 U.S.A.
[phone] or [phone]
U.S. Fax [phone]
www.multitech.com
Technical Support
Country Email Phone
Europe, Middle East, Africa [email protected] [phone]
U.S., Canada, all others suppor[email protected] 800-972-2439 or
763-717-5863

SMSFinder
3
Introduction
This guide shows you how to set up your SMSFinder and how to send a
short message. For detailed information, product specifications, and
more, see the User Guide, available on the SMSFinder CD and the
Multi-Tech Web site.
Safety Warnings
Ethernet Port Caution
The Ethernet port is not designed to be connected to a Public
Telecommunications Network.
Handling Precautions
All devices must be handled with certain precautions to avoid damage
due to the accumulation of static charge. Although input protection
circuitry has been incorporated into the devices to minimize the effect of
this static build up, proper precautions should be taken to avoid
exposure to electrostatic discharge during handling and mounting.
Caution: Maintain a separation distance of at least 20 cm (8
inches) between the transmitter’s antenna and the body of the
user or nearby persons. The modem is not designed for, nor
intended to be, used in applications within 20 cm (8 inches) of the
body of the user.
Ship Kit Contents
The SMSFinder ship kit contains the following items:
•One SMSFinder
•Power Supply
•RJ-45 Ethernet Cable
•Cellular Antenna (not included with all models)
•A set of four self-adhesive plastic feet
•The Quick Start Guide
•One SMSFinder CD which contains the SMSFinder documentation
in Acrobat format and a link to the Adobe Web site from which you
can download Acrobat Reader.

Multi-Tech Systems, Inc. Quick Start Guide
4
Cabling Your SMSFinder
1. Turn the power off on the PCs and the SMSFinder.
2. Plug one end of a RJ-45 cable into the LAN port on the SMSFinder
and the other end into the Ethernet port on a network-connected
PC.
3. Connect the provided power supply cable to the 9 volt power port
on the back of the SMSFinder, and plug the other end into an AC
power outlet.
4. Attach the cellular antenna.
•Be sure to locate this appliance where there is wireless
coverage.
•The antenna must be attached in order for the SMSFinder to be
operational.

SMSFinder
5
Front Panel
Front Panel LEDs and Other Features
LEDs Description
Power Lights when power is being supplied to the SMSFinder.
Status When functioning normally, the LED blinks. The LED is a
solid light when the SMSFinder is booting up, saving the
configuration, restarting, or updating the firmware.
LAN
10/100 Lights when a successful connection to the 100BaseT LAN is established. Off when connected at 10BaseT.
LAN
LNK/ACT Lights when the LAN port has a valid Ethernet connection. Blinks when it is receiving or transmitting data.
Modem TD Transmit Data. This LED blinks when the modem is
transmitting data to your wireless carrier.
RD Receive Data. This LED blinks when the modem is
receiving data from your wireless carrier.
CD Carrier Detect. This LED lights when the modem
detects a valid carrier signal from a wireless carrier.
TR (Data) Terminal Ready. This LED lights when the
modem is trying to establish a wireless connection.
LS Link Status. This LED flashes when the network
registration is OK.
If the network registration is invalid, the LED will be
On/Off.
Signal Indicates the wireless signal strength. See the Signal
Strength Chart on the next page.
SIM Location of the SIM card.

Multi-Tech Systems, Inc. Quick Start Guide
6
Install the SIM Card
A SIM (Subscriber Identity Module) card is required in order for the
SMSFinder to operate on a GPRS network. To install the SIM card:
1. Use a small screwdriver to remove the screw closest to the outside
edge of the SMSFinder. Then swing the SIM slot cover up and over
to the left.
2. Insert the SIM card into the SIM card slot. The following graphic
illustrates the correct SIM card orientation.
Establish a TCP/IP Connection
The following directions establish a TCP/IP connection at the
workstation so the PC can communicate with the SMSFinder. The
following directions were written using a Windows 2000+ / XP operating
system.
Setting a Fixed IP Address
1. Make the SMSFinder connections as described on the previous two
pages.
2. Click Start | Settings | Control Panel. Double-click the Network
Connections icon.
3. The Network Connections screen displays. Right-click Local
Area Connection and choose Properties from the drop down list.

SMSFinder
7
4. The Local Area Connection Properties dialog box displays.
•Select Internet Protocol (TCP/IP).
•Click the Properties button. The Internet Protocol (TCP/IP)
Properties screen displays.

Multi-Tech Systems, Inc. Quick Start Guide
8
5. On the Internet Protocol (TCP/IP) Properties screen complete the
following:
Important: If this screen opens and displays your current IP
configuration, we suggest you record this information for future
reference (i.e., after the SMSFinder is configured, you may wish to
return this PC to its original settings).
•To set a Fixed IP Address for the workstation, select Use the
following IP address.
∗Enter the workstation IP Address. Example: 192.168.2.x.
Note: The xin the address stands for numbers 101 and up.
∗Enter the workstation Subnet Mask. Example: 255.255.255.0
∗Enter the workstation Default Gateway. Ex: 192.168.2.2
Note: The workstation settings must be in the same subnet
range as the SMSFinder.
The default factory settings for the SMSFinder are:
IP Address: 192.168.2.1; Subnet Mask: 255.255.255.0;
Default Gateway: 192.168.2.2
•Select Use the following DNS server addresses.
∗Enter the IP Address of the Preferred DNS Server. Ex:
205.171.3.65
∗Click OK.
•Close the Local Area Properties screen by clicking OK.
•Close the Control Panel.
•Repeat these steps for each PC on your network.

SMSFinder
9
Obtain and Activate a Wireless
Account
Before you can use the cellular feature, you must obtain a wireless
account through a service provider and then activate the account.
Please see the wireless account Activation Notices located on the
SMSFinder CD. Choose the one for your wireless network provider and
follow the directions to activate your account.
Important Note About Service Provider Fees
Your provider will charge you for your data usage. Please check with
your provider to make sure you are aware of the charges.
If you plan to use the router for large amounts of data transfers, Multi-
Tech recommends an unlimited data plan with your account. Multi-Tech
will not be responsible for any charges relating to your cellular bill.
Direct Communication to the Cellular Modem
You may want to communicate directly to the cellular modem to activate
the modem, verify network registration, and/or troubleshooting your
connection. To do this:
1. Open a PC's command window by clicking the Start button and
selecting Run.
2. Type CMD to open the command window. Click OK.
3. When the command window opens, type IPCONFIG.
4. Type Telnet 192.168.2.1 5000 (Note: 5000 is the port number).
AT commands can be used to check network registration status. See the
User Guide.
See the GPRS AT Commands Reference Guide and the GPRS-F4
Reference Guide for AT commands.

Multi-Tech Systems, Inc. Quick Start Guide
10
Start the SMSFinder
Open a Web Browser
1. Be sure that the SMSFinder is cabled and that the power is
connected.
2. Then open a Web browser.
3. Type the default gateway address line: http://192.168.2.1
4. Press Enter.
Login
The Login screen for the SMSFinder Web Interface displays.
•Type admin (admin is the default user name) in the user name
box.
•Type admin in the password box.
•Click Login.
Note: The User name and Password entries are case-sensitive
(both must be typed in lower-case). The password can be up to
12 characters. Later, you will want to change the password from
the default (admin) to something else (see the User Guide). If
Windows displays the AutoComplete screen, you may want to
click No to tell Windows OS to not remember the password for
security reasons.

SMSFinder
11
Web Interface Opens
This is the Home screen from which you can access all setup functions.
Note: Only the top portion of the Home screen is shown here.
See the User Guide for how to use the SMSFinder Web Interface.
Check to See if the SIM Card Is
Installed Correctly and Activated
This following procedure will verify that the SIM is installed correctly and
that it is activated.
1. Power up the SMSFinder. Wait until the Status LED and the LS
LED are blinking before continuing. Make sure all setup procedures
and connections have been made. See Chapter 2.
2. Open the Web browser, enter the IP address, and login to the
SMSFinder. See Chapter 3.
3. Go to the Network Setup > Cellular Modem screen.
•Enter the phone number of your SIM card. Example:
6126361654.

Multi-Tech Systems, Inc. Quick Start Guide
12
•Click the Save button.
•Click Save & Restart under the Menu Bar. Select Save.
Note: You do not have to restart the SMSFinder.
4. Send a text message to yourself. Do this on the SMS Services >
Send SMS screen.
•To – Enter Phone Numbers – Enter the SIM phone and click
Add. The phone number displays in the box to the right.
•SMS Text – Enter an SMS Text message. The format
add;SF100 is a trigger message word that tells the SMSFinder
to add the phone number and name to the address book. Notice
the use of the semicolon in this message.
•Click Send.The following message displays: Your request is
being processed.
•Click OK.
5. Check the Outbox and you will see that the message was sent.

SMSFinder
13
6. Check the Inbox and you will see that the message was received.
This verifies that the cellular modem is functioning.
Note: Sometimes you may have to refresh this screen and wait
several minutes for the cellular provider to deliver the message.
7. Go to the SMS Services > Address Book. You will see the trigger
SMS text message was processed and the name and phone
number were added to the address book.
Note: The phone number is entered with a "+1" in front of it. This
indicates the phone number was entered into the address book
using a trigger message.
Create a Broadcast Message for
Future Use
In this example a school wants to be prepared to send a message that
school is closed for the day. The Administrator creates a Trigger
Message word Snow and the following Broadcast Message:
School is closed today.
This example assumes that a Group called Parents has been created
and that SF100 stands for the Administrator's cell phone number.

Multi-Tech Systems, Inc. Quick Start Guide
14
1. Go to the Triggers > Add a Broadcast Trigger screen.
•Enter Snow in the Trigger Message word box. Trigger message
words or codes are not case-sensitive.
•Enter the Broadcast Message. In this case the message is
School is closed today.
•Select the Group that will receive this message. In this case the
group is Parents.
•Check the Authenticate box to indicate that this message can
be sent by an authenticated user only.
•The Authentic User selected to trigger this message is SF100,
the Administrator's cell phone.
Note: All phone numbers for Authenticated Users must be
preceded by a "1" in the address book so the SMSFinder can
match the phone number of the received SMS trigger message
with the phone number in the Authenticated User list.
•Click Save. The following screen displays the Broadcast
Message saved for future use.

SMSFinder
15
2. To trigger the broadcasting of this message to the Parent group,
the administrator sends the SMS text message word Snow from his
cell phone to the SMSFinder. When the SMSFinder receives this
message, it compares the Administrator's cell phone number with
the Authentication List and if they match, it broadcasts the message
to everyone in the Parent group.

82100360L
