Murdock A172UBL-VR Series User manual

A172UBL-VR Series
Barrier Free, Vandal Resistant & Resistance Button,
Universal Bi-Level, Wall Mounted Drinking Fountains
A172100S-UBL-VR / A172400S-UBL-VR
1.800.591.9360
Technical Assistance Fax: [phone]
TECHNICAL ASSISTANCE TOLL FREE TELEPHONE NUMBER:
COMPLIES WITH
7020-917-001 Date: 12/22/17
Test rating conditions are
compliant with ARI 1010.
Federal
Public Law
111-380
(No Lead) Member of
MURDOCK
15125 Proctor Ave.
City of Industry, CA
91746 U.S.A.
Phone [phone]
626-336-4561
Fax [phone]
www.murdockmfg.com
NOTES TO INSTALLER:
1. Please leave this documentation with the owner of the fixture when finished.
2. Please read this entire booklet before beginning the installation.
3. Check your installation for compliance with plumbing, electrical and other applicable codes.
LIMITED WARRANTY - UNITED STATES & CANADA
Murdock warrants that its products are free from defects in material or workmanship under normal use and
service for a period of one year from date of install or for 18 months after the date of shipment from the factory,
whichever comes first. The sealed refrigeration system is warranted for five years. Murdock’s liability under this
warranty shall be discharged solely by replacement or repair of defective material, provided Murdock is notified in
writing within one year from date of shipment, F.O.B. Industry, California.
This warranty does not cover installation or labor charges and does not apply to materials, which have been
damaged by other causes such as mishandling or improper care or abnormal use. The repair or replacement of the
defective materials shall constitute the sole remedy of the Buyer and the sole remedy of Murdock under this
warranty. Murdock shall not be liable under any circumstances for incidental, consequential or direct charges
caused by defects in the materials, or any delay in the repair or replacement thereof. This warranty is in lieu of all
other warranties expressed or implied. Product maintenance instructions are issued with each unit and disregard
or non-compliance with these instructions will constitute an abnormal use condition and void the warranty.
Stainless steel must be protected on job site during construction and must be properly maintained after the water
has been introduced into the water cooler or drinking fountain, or Murdock’s limited warranty is void.
LIMITED EXPORT WARRANTY - One year on parts only.
Murdock assumes no responsibility for use of void or
suspended data. © Copyright Murdock, City of
Industry, CA Member of Morris Group International.
Please visit www.murdockmfg.com for most
current specifications.
RATED FOR INDOOR
AND OUTDOOR USE
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAIN

NOTES:
1. Dimensions shown for ADA compliant installation. For Child ADA 2010 compliant parallel approach installation, decrease
height of (*) dimensions by 2-3/4".
2. Provide clear floor space as required. Adjust vertical dimensions as required to comply with federal, state, and local codes.
ROUGHING-IN AND DIMENSIONAL DRAWING
Prior to roughing consult with local, state, and federal codes for proper mounting height.
A172UBL-VR SERIES REFRIGERATED BI-LEVEL WALL MOUNTED DRINKING FOUNTAIN
Note: there are no mounting changes to be made for -SO models.
A172VR
Page 2 of 10
Revised: 12/22/17
7020-917-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
1-1/4" [32]
P-TRAP BY
OTHERS
13
8"
[35]
6"
[152]
12"
[305]
*33"
[838]
6"
[152]
217
8"
[556]
351
4"
[895]
C
185
8"
[473]
D193
8"
[492]
6"
[152]
133
8"
[340]
77
8"
[200]
41
4"
[108]
21
4"
[57]
77
8"
[200]
65
8"
[168]
65
8"
[168]
B
A
E
E
71
4"
[184]
23
4"
[70]
181
2"
[470]
A. 3/8" NCT Supply Inlet
B. Waste Outlet for 1-1/4" P-Trap, by others
C. Ø3/8" Hanger Bracket punching, 3 places
for Anchoring Hardware, by others
D. Ø1/4" punching, 2 places for Anchoring
Hardware, by others
E. Caulk for Outdoor Units (see page 5)
F. Electrical Service Rough(If Bottle Filler is
being used)
General Notes:
1. All dimensions are in inches [MM]
2. Allow 4 inches [102 MM] minimum clearance per side for
ventilation
*3. Dimensions shown are for recommended adult height. Adjust
vertical dimensions as necessary to comply with Federal,
State, & Local Codes
4. Stop Valve, P-Trap & Electrical Outlet not supplied
5. Important: Units must be attached to wall with appropriate wall
Anchor Screws
E
F
51
4"
[133]
165
8"
[422]
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAIN

A172UBL-VR SERIES REFRIGERATED BI-LEVEL WALL MOUNTED WATER COOLER
Note: Alternate Mounting. There are no mounting changes to be made for -SO models.
IMPORTANT:
1. Waste P-Trap, Water Supply Service Angle Stop Valve and 2” x 4” Electrical Plug-In Receptacle to be supplied by others in
accordance with local codes. A Metallic P-Trap (by others) must be used for the drain connection.
2. Provide 4” minimum clear space on fixture sides to allow for proper ventilation through Cabinet Louvers.
3. Water supply is 3/8” Outside Diameter Copper Tube. Waste is 1-1/4” Outside Diameter.
4. Completely flush supply lines of all foreign debris before connecting to fixture. Drinking Fountain designed to not affect taste,
odor, color, or sediment. Optional water filter (WF1) is available should any of these problems arise from the water supply.
5. If possible, limit exposure of the Drinking Fountain to direct sun light. The actual surface temperature of a Drinking Fountain in
direct sunlight on a 90°F day, the Drinking Fountain would be about 140°F.
6. Do NOT solder Copper Tube when inserted into the Coupler as damage to the O-Ring will result.
7. All burrs must be removed from outside of cut Tubes before inserting into Coupler or other components.
9. Warranty is voided if installation is not made following current Murdock Mfg. installation instructions and if components are
assembled to the fixture that is not approved by Murdock Mfg.
10. Fixture operates within water pressure range of 20 to 105 PSIG (138 to 724 kPa). Murdock Mfg. will not warranty fixtures
damaged when connected to supply lines with flow pressure lower than 20 PSIG (138 kPa) or higher than 105 PSIG (724
kPa). A pressure regulator must be furnished by others on supply line if inlet pressure is greater than 105 PSIG (724 kPa).
11. Per UPC 609.10- All building water supply systems in which quick acting valves are installed shall be provided with devices to
absorb the hammer caused by high pressure resulting from the quick closing of the valve. These pressure-absorbing devices
shall be approved mechanical devices. Water pressure-absorbing devices will be installed as close as possible to the quick
closing valve.
A172VR
Page 3 of 10
Revised: 12/22/17
7020-917-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
1-1/4" [32]
P-TRAP BY
OTHERS
13
8"
[35]
6"
[152] 12"
[305]
*33"
[838]
6"
[152]
A. 3/8" NCT SUPPLY INLET
B. WASTE OUTLET FOR 1-1/4"
P-TRAP BY OTHERS.
C. Ø3/8" HANGER BRACKET PUNCHING, 3 PLACES
FOR ANCHORING HARDWARE BY OTHERS.
D. Ø1/4" PUNCHING, 2 PLACES FOR ANCHORING
HARDWARE BY OTHERS.
E. CAULK FOR OUTDOOR UNITS
(SEE PAGE 5)
F. Electrical Service Rough(If Bottle
Filler is being used)
E
B
A
E
217
8"
[556]
351
4"
[896]
C
185
8"
[472]
D
193
8"
[491] 6"
[152]
133
8"
[340]
77
8"
[202]
41
4"
[108]
21
4"
[57]
77
8"
[202]
65
8"
[169]
65
8"
[169]
51
4"
[133]
165
8"
[422]
F
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAIN

INSTALLATION:
Choose configuration; Remove and reinstall Filler Plate, item 23 and reverse Drain Assembly if required for
alternate mounting configuration.
1. Mount Hanger Bracket to wall horizontally level as shown in Roughing-In and Dimensional Drawing. Note: Adjust height of
Bracket if Bubbler outlet height is required to vary from that shown. Hanger Bracket MUST be securely anchored to wall
with fasteners sufficient to support 3 times the weight of Drinking Fountain. If wall can not provide adequate support, order
and install optional fixture support carrier.
2. Remove the Bottom Cover from the Drinking Fountain and set aside in a safe place. Save the Screws in a secure location
for re-use in later stages of installation.
3. Hang the Drinking Fountain on the Hanger Brackets ensuring the Bracket Tabs engage AND seat in the slots in the back of
the Drinking Fountain. Verify Drinking Fountains are level, left to right AND front to back from bottom of unit. CAUTION:
The Bubbler stream may be adversely affected if units are not square and level. Bottom of units and Louvers should be
used as reference to verify unit is square and plumb.
4. Anchor the Drinking Fountain to the wall at the lower mounting points in each Back Panel. Shim lower mounting points to
level unit if necessary.
5. Thoroughly flush the 3/8” O.D. supply line and then connect Drinking Fountain to Water Supply Angle Stop Valve (by
others) with supplied 3/8” O.D. Copper Tube.
6. Use supplied Flexible Hose and Clamps to connect Waste Tailpiece from the upper unit to the Waste Tailpiece of lower unit
and then make up 1-1/4” O.D. P-Trap waste connection. Waste P-Trap by others.
7. For outdoor installation, see outdoor installation instructions (Page 5)
STANDARD WASTE CONFIGURATION ALTERNATE WASTE CONFIGURATION
ITEM 23
FILLER PLATE
ITEM 23
FILLER PLATE
A172VR
Page 4 of 10
Revised: 12/22/17
7020-917-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAIN

START UP:
1. Before connecting Power Supply and assembling Bottom Cover to Drinking Fountain, but after thoroughly flushing the
supply line and connecting it to the fixture, turn on building water supply and check all connections for leaks.
2. Air within the Drinking Fountain system or the structure supply piping will cause an irregular Bubbler outlet stream until
purged out by incoming water. Covering the Bubbler with a clean cup (or similar object) is recommended when first
activating Drinking Fountain to prevent excessive splashing. Depress the Pushbutton until steady water stream is
achieved.
3. If water flow requires adjustment, insert a Slotted Narrow Blade Screwdriver through the hole centered on the Pushbutton
to the flow regulator. Turning clockwise will increase flow and turning counterclockwise will decrease flow.
4. Recheck all water and drain connections with water flowing through system.
5. Assemble Bottom Cover to Drinking Fountain with Screws furnished.
A172VR
Page 5 of 10
Revised: 12/22/17
7020-917-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
OUTDOOR INSTALLATION INSTRUCTIONS:
1. Caulk all around the Basins where it contacts the wall and where Aprons contact the wall as shown, to prevent rain water
from leaking into the Cabinet. DO NOT CAULK THE REMOVABLE ACCESS COVER. Add 1/4” thick piece of soft Rubber
Weather Strip (provided by installer) between the units as shown.
STANDARD CONFIGURATION
ALTERNATIVE CONFIGURATION
CAULKING
WEATHER STRIP
WEATHER STRIP
(BETWEEN UPPER
AND LOWER UNITS)
CAULKING
WEATHER STRIP
(BETWEEN UPPER
AND LOWER UNITS)
CAULKING
WEATHER STRIP
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAIN

TROUBLE SHOOTING:
IMPORTANT: BEFORE MAKING ANY OF THE REPAIRS LISTED, MAKE SURE THE WATER COOLER IS
DISCONNECTED FROM THE ELECTRICAL SUPPLY AND THE WATER SUPPLY VALVE IS SHUT OFF.
1. Adjustments
a. Cartridge – The water flow can be adjusted through the Pushbutton using a Straight Blade Screwdriver and turning
clockwise to increase flow and counterclockwise to decrease flow.
b. Bubbler Stream – Bubbler can be rotated slightly to direct the stream backwards or forwards. Adjust the stream to
minimize splashing. Splashing may occur from Bubbler stream if the unit is not level. Shim lower mounting points, if
necessary, to level Drinking Fountain.
2. Restricted Or No Water Flow
a. Ensure Water Supply Service Stop Valve is fully open.
b. Verify minimum 20 (138 kPa) psig supply line flow pressure.
c. Check for twists or kinks in Bubbler Tubing.
d. Check the Water Inlet Strainer. Sediment from the main supply can get trapped in the Screen along with installation
materials such as Pipe Dope and Flux. The screen should be cleaned and checked on a regular basis and replace if
needed.
NOTE: STRAINER SCREEN MUST BE IN PLACE FOR WATER TO FLOW.
e. The Cartridge Valve located in the Water Control Assembly or Bubbler can also become clogged with foreign
material. The Cartridge Valve can only be replaced and not repaired.
f. Check flow adjustment. See start up note #3.
3. Water Drip Or Will Not Shut Off:
a. Remove Pushbutton (See pg.7 for details). Adjust flow regulator to the highest setting using a Flat Head Screwdriver
and turning clockwise. Check if water drip continues, if it is no longer dripping turn Screwdriver counter-clockwise
until you have desired flow rate. Assure that retaining nut is tighten to valve assembly, 25 in-lb (2825 mNm) torque is
required. If issue still continues after adjusting flow and tightening Retainer Nut, replacement of the Flow Regulator
Cartridge will be required.
CLEANING & MAINTENANCE GUIDE:
1. Motors have lifetime lubrication and do not require scheduled maintenance.
2. Periodically remove Access Panels and clean out In-Line Strainer.
3. Do NOT use harsh chemicals, abrasive or petroleum based cleaners. Use of these will void the Murdock Mfg. warranty.
4. Exterior Panels can be cleaned using mild household detergents or warm, soapy water. Extra care must be used cleaning
chrome plated items and mirror finished stainless steel. They can scratch easily and should only be cleaned using a clean,
soft cloth and mild soap with water or a mild glass cleaner.
WINTERIZING INSTRUCTIONS:
Important: The water in all the Water Tubing, Valve Body and Y-Strainer (if equipped) MUST be expelled from both Drinking
Fountains on a Bi-Level Unit to prevent freezing.
1. Shut off the water supply.
2. Disconnect the water supply to the Inlet Tube or Y-Strainer (if equipped).
3. Connect compressed air [30 to 85 PSI] to the Inlet Tube or Y-Strainer (if equipped).
4. Let the Drinking Fountain pressurize with air, then blow air thru the supply line while depressing the Pushbutton on the
upper unit of a Bi-Lever Drinking Fountain until water stops flowing out of the Bubbler and all water has been removed.
5. Add RV Anti-Freeze to the P-Trap.
6. Use a protective cover to prevent fresh water from diluting the Anti-Freeze in the waste drains.
7. It is recommended that a bleeder valve be added just above the gate valve to assist in future winter shut-down procedures.
IMPORTANT : ASSUREZ-VOUS QUE LA FONTAINE D'EAU POTABLE RÉFRIGÉRÉE SOIT DÉBRANCHÉE DE LA PRISE
DE COURANT MURALE ET QUE LE ROBINET D'ALIMENTATION D'EAU SOIT FRMÉ AVANT D'EFFECTUER LES
RÉPARATIONS NÉCESSAIRES.
A172VR
Page 6 of 10
Revised: 12/22/17
7020-917-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAIN

CARTRIDGE REPLACEMENT/ STRAINER MAINTENANCE
Note: Use the -VR maintenance tool to perform the following:
1. Strainer plug 4 must be removed before Cartridge replacement and Strainer
maintenance (no need to turn the water off at the Angle Stop). Some residual water will drain
during Plug removal.
2. Clean Strainer 4 as needed using clean water.
3. Cartridge replacement - Rotate and remove -VR Pushbutton Escutcheon 6 to release Pushbutton 7 and Springs 8 9 to
access Cartridge.
4. Remove Cartridge Retaining Nut 10 . Remove and replace Cartridge 2 . When replacing Cartridge be sure to align the
Inlet and Outlet Ports on the Cartridge with the Ports in the Valve Body.
5. Install item 10 using Maintenance Tool 5 (Becareful not to over tighten)
6. Install Button Assembly items 6 7 8 9 using Maintenance Tool 5 . Insure Springs are installed in Button correctly.
7. Reinstall Strainer 4 and Plug 3 using Maintenance Tool 5 .
NOTE: STRAINER FILTER SCREEN
MUST BE IN PLACE FOR
WATER TO FLOW.
ITEM PART NUMBER DESCRIPTION
1 7003-095-001 VALVE ASSEMBLY
2 7000-060-000 FLOW REGULATOR CARTRIDGE(0.5 GPM)
3 7003-097-001 O-RING &STRAINER PLUG
4 7003-864-000 STRAINER FILTER SCREEN
5 7003-194-199 (-VR) MAINTENANCE TOOL
6 7003-197-199 (-VR) PUSHBUTTON ESCUTCHEON, CHROME
7 7003-196-199 (-VR) PUSHBUTTON, CHROME
8 7003-195-000 (-VR) PUSHBUTTON OVERTRAVEL SPRING
9 7003-193-000 (-VR) PUSHBUTTON RETURN SPRING
10 7000-052-000 RETAINING NUT
2
4
3
1
5
5
6
7
8
9
10
A172VR
Page 7 of 10
Revised: 12/22/17
7020-917-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAIN

A172.8VR
Page 8 of 10
Revised: 12/22/17
7020-917-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
PUSH-IN FITTING INSTALLATION
NOTE: FITTINGS AND TUBE SHOULD BE KEPT
CLEAN, BAGGED AND UNDAMAGED PRIOR TO
INSTALLATION.
2. Pull on the fitted Tubing to ensure it is secure. Tube
should not come free from the Fitting. Water test the
connection assembly prior to leaving the site to ensure
there are no leaks.
DISCONNECTING THE TUBE:
To disconnect the Tube from the Fitting, ensure that the
water line is depressurized. Push Collet square towards
the Push-In Fitting Body and hold. While holding the Collet
in, pull on the PE Tubing to remove from the Push-In
Fitting.
TO CUT TUBE:
Cut to fit length of 1/4” PE Tubing and remove any
burrs or sharp edges. Ensure that the outside diameter
is free from score marks. Tube ends should be square.
INSERTING THE TUBE:
1. Firmly and fully insert the Tubing End into the Push-In
Fitting up to the Tube Stop located approximately ½”
deep.
COLLET
COLLET
O-RING
O-RING
TUBE STOP
COLLET
COLLET
COLLET
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAIN

WATER COOLER PARTS BREAKDOWN DRAWING:
NOTE: See page 11 for table of part numbers corresponding to drawing below.
A172VR
Page 9 of 10
Revised: 12/22/17
7020-917-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
NOTE:
30 Flow Restrictor Only Available
With Low Flow Flex Bubbler.
Universal Maintenance Tool
-Button Removal
-Cartridge Retaining Nut
-Strainer Plug
-Removal of P.E. Tubing from
Push-in Fittings
33
3
2
4
5
6
8
9
7
10
11
29
13
15 24
12
25
27
31
32
1
29
29
30
29
4
28
6
29
15"
15"
15"
27"
26
VANDAL RESISTANT BUTTON
& VALVE BREAKDOWN
SCALE x 1-1/2"
21
22
23
20
19
17
16
15
14
18
17
19
33
34"
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAIN

Repairs must be made with Acorn Engineering parts only. Please order through your local representative or
distributor. The phone number to locate your local representative is 1.800.591.9360.
COOLER PARTS BREAKDOWN TABLE
NOTE: See previous page for fixture drawing corresponding to table of parts below.
A172VR
Page 10 of 10
Revised: 12/22/17
7020-917-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
ITEM #
PART NUMBER DESCRIPTION
7003-001-199 BASIN TOP
7003-161-199 BF12 BASIN TOP WITH LESS HOLE FOR BF11/12
7003-161-299 BF12 BASIN TOP WITH HOLE FOR BF11/12
7000-099-002 LOW-FLOW FLEXIBLE BUBBLER ASSEMBLY
7000-012-001 STAINLESS STEEL BUBBLER ASSEMBLY
3 0124-032-000 #8 x 3/4" LG PHIL FLAT HD SELF TAPPING SCREW
4 7000-006-000 FLAT DRAIN GASKET
5 7003-182-000 DRAIN ADAPTER
6 7003-184-000 7/8" SPRING HOSE CLAMP
7 7003-181-000 1-1/4" DIAMETER DRAIN TUBE
8 7003-183-199 DRAIN HOSE
9 7003-003-199 BACK PANEL
10 7003-007-199 SUPPORT STRUT
7003-817-020 LEFT COVER - GRANITE
7003-823-299 LEFT COVER - STAINLESS STEEL
7003-818-020 RIGHT COVER - GRANITE
7003-824-299 RIGHT COVER - STAINLESS STEEL
7003-212-020 APRON ASSEMBLY - GRANITE
7003-211-002 APRON ASSEMBLY - STAINLESS STEEL
14 7003-197-199 (-VR) PUSHBUTTON ESCUTCHEON, CHROME
15 7003-196-199 (-VR) PUSHBUTTON, CHROME
16 7003-195-000 (-VR) PUSHBUTTON OVERTRAVEL SPRING
17 0161-062-000 #6-32 x 1/2" S/S PHIL FLAT HEAD SCREW
18 7003-193-000 (-VR) PUSHBUTTON RETURN SPRING
19 0124-055-000 #8 x 3/4" PHILLIPS ROUND HEAD SS SM SCREW
20 7003-198-199 (-VR) PUSHBUTTONN MOUNTING SLEEVE
21 7003-200-000 AUTO-STOP CONDENSATION GASKET, LOWER
22 7003-199-000 AUTO-STOP CONDENSATION GASKET, UPPER
23 7003-095-001 VALVE ASSEMBLY
24 0124-031-000 #8 x 3/8" LNG SLOTTED HEX WASHER HD SCREW
25 1895-121-000 SUPPLY INLET CONNECTION
26 1895-710-000 1/4" OD PUSH-IN "TEE" CONNECTION
7003-819-020 FILLER PLATE - GRANITE
7003-825-199 FILLER PLATE - STAINLESS STEEL
28 0124-050-000 #8 x 3/8" LG PHILLIPS PAN HEAD SCREW
29 2169-000-000 1/4" O.D. TUBING
30 7003-093-001 FLOW RESTRICTOR - LOW-FLOW BUBBLER ONLY
31 7003-014-199 HANGER BRACKET
32 0124-056-000 #8 x 3/8" LG PHILLIP PAN HEAD SHEET METALSCREW
33 7003-194-199 (-VR) MAINTENANCE TOOL
1
11
12
13
27
2
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAIN
