Murdock A172-SO Series Installation and operating instructions

A172-SO Series
Barrier Free, Sensor Operated,
Wall Mounted Drinking Fountain
1.800.591.9360
Technical Assistance Fax: [phone]
TECHNICAL ASSISTANCE TOLL FREE TELEPHONE NUMBER:
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAIN
COMPLIES WITH
7020-961-001 Date: 12/20/17
Test rating conditions are
compliant with ARI 1010.
Federal
Public Law
111-380
(No Lead) Member of
MURDOCK
15125 Proctor Ave.
City of Industry, CA
91746 U.S.A.
Phone [phone]
626-336-4561
Fax [phone]
www.murdockmfg.com
NOTES TO INSTALLER:
1. Please leave this documentation with the owner of the fixture when finished.
2. Please read this entire booklet before beginning the installation.
3. Check your installation for compliance with plumbing, electrical and other applicable codes.
LIMITED WARRANTY - UNITED STATES & CANADA
Murdock warrants that its products are free from defects in material or workmanship under normal use and
service for a period of one year from date of original shipment or for 18 months after the date of shipment from the
factory, whichever comes first. Murdock’s liability under this warranty shall be discharged solely by replacement
or repair of defective material, provided Murdock is notified in writing within one year from date of shipment,
F.O.B. Industry, California.
This warranty does not cover installation or labor charges and does not apply to materials, which have been
damaged by other causes such as mishandling or improper care or abnormal use. The repair or replacement of the
defective materials shall constitute the sole remedy of the Buyer and the sole remedy of Murdock under this
warranty. Murdock shall not be liable under any circumstances for incidental, consequential or direct charges
caused by defects in the materials, or any delay in the repair or replacement thereof. This warranty is in lieu of all
other warranties expressed or implied. Product maintenance instructions are issued with each unit and disregard
or non-compliance with these instructions will constitute an abnormal use condition and void the warranty.
Stainless steel must be protected on job site during construction and must be properly maintained after the water
has been introduced into the water cooler or drinking fountain, or Murdock’s limited warranty is void.
LIMITED EXPORT WARRANTY - One year on parts only.
Murdock assumes no responsibility for use of void or
suspended data. © Copyright Murdock, City of
Industry, CA Member of Morris Group International.
Please visit www.murdockmfg.com for most
current specifications.
OR
A174100F-SO
A172100F-SO

ROUGHING-IN AND DIMENSIONAL DRAWING
Prior to roughing consult with local, state, and federal codes for proper mounting height.
NOTES:
are for ADA frontal approach installation. For Child ADA compliant parallel approach installation, decrease height of
installation for spout to be 30” maximum above finished floor. Provide clear floor space as required. Adjust vertical
dimensions as required to comply with federal, state, and local codes.
Adjust vertical dimensions as required to comply with federal, state, and local codes. Dimensions indicated
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAIN
A172-SO
Page 2 of 10
Revised: 12/20/17
7020-961-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
1-1/4" [32]
P-TRAP BY
OTHERS
71
4"
[184]
23
4"
[70]
181
2"
[470]
13
8"
[35]
12"
[305]
*33"
[838]
6"
[152]
*217
8"
[556]
D
185
8"
[473]
E
*157
8"
[403]
77
8"
[200]
41
4"
[108]
21
4"
[57]
C51
4"
[133] *165
8"
65
8"
[168]
A. 3/8" NCT Supply Inlet
B. Waste Outlet for 1-1/4" P-Trap, by others
C. Electrical Service Rough
D. Ø3/8" Hanger Bracket punching, 3 places
for Anchoring Hardware, by others
E. Ø1/4" punching, 2 places for Anchoring
Hardware, by others
B
A
133
8"
[340]
371
8"
[943]
6"
[152]
General Notes:
1. All dimensions are in inches [MM]
2. Allow 4 inches [102 MM] minimum clearance per side for
ventilation
*3. Dimensions shown are for recommended adult height. Adjust
vertical dimensions as necessary to comply with Federal,
State, & Local Codes
4. Stop Valve, P-Trap & Electrical Outlet not supplied
5. Important: Units must be attached to wall with appropriate wall
Anchor Screws
MOUNTING CONFIGURATION
AS SHIPPED

IMPORTANT:
1. Water supply is 3/8” Outside Diameter Copper Tube. Waste is 1-1/4” Outside Diameter.
2. Completely flush supply lines of all foreign debris before connecting to fixture. Drinking Fountain designed to not
affect taste, odor, color, or sediment. Optional water filter (WF1) is available should any of these problems arise
from the water supply.
3. Do NOT solder Copper Tube when inserted into the Coupler as damage to the O-Ring will result.
4. All burrs must be removed from outside of cut tubes before inserting into Coupler or other components.
5. WARNING: Warranty is voided if installation is not made following current Murdock Mfg. installation instructions
and if components are assembled to the fixture that is not approved by Murdock Mfg.
6. Fixture operates within water pressure range of 20 to 105 PSIG (138 to 724 kPa). Murdock Mfg. will not warranty
fixtures damaged when connected to supply lines with flow pressure lower than 20 PSIG (138 kPa) or higher than
105 PSIG (724 kPa). A pressure regulator must be furnished by others on supply line if inlet pressure is greater
than 105 PSIG (724 kPa).
7. Per UPC 609.10- All building water supply systems in which quick acting valves are installed shall be provided with
devices to absorb the hammer caused by high pressure resulting from the quick closing of the valve. These
pressure-absorbing devices shall be approved mechanical devices. Water pressure-absorbing devices will be
installed as close as possible to the quick closing valve.
INSTALLATION:
1. Mount Hanger Bracket to wall horizontally level as shown in Roughing-In and Dimensional Drawing. Note: Adjust
height of bracket if Bubbler outlet height is required to vary from that shown.
WARNING: Hanger Bracket MUST be securely anchored to wall with fasteners sufficient to support 3 times the
weight of Drinking Fountain. If wall can not provide adequate support, order and install optional fixture support
carrier.
2. Remove the Bottom Cover from the Drinking Fountain and set aside in a safe place. Save the Screws in a secure
location for re-use in later stages of installation.
3.
START UP:
1. Before connecting water supply and assembling Bottom Cover to Drinking Fountain, but after thoroughly flushing
the supply line and connecting it to the fixture, turn on building water supply and check all connections for leaks.
2. Air within the Drinking Fountain system or the structure supply piping will cause an irregular Bubbler outlet stream
until purged out by incoming water. Covering the Bubbler with a clean cup (or similar object) is recommended when
first activating Drinking Fountain to prevent excessive splashing. Depress the Pushbutton until steady water stream
is achieved.
3. If water flow requires adjustment, insert a Slotted Narrow Blade Screwdriver in the hole centered on the underside
of the fixture in the knee clearance area up to the Flow Regulator. Turning clockwise will increase flow and turning
counterclockwise will decrease flow.
4. Recheck all water and drain connections with water flowing through system.
5. Assemble Bottom Cover to Drinking Fountain with Screws furnished.
Hang the Drinking Fountain on the Hanger Brackets ensuring the Bracket Tabs engage AND seat in the slots in the
back of the Drinking Fountain. Verify Drinking Fountain are level, left to right AND front to back from bottom of unit.
NOTE: The Bubbler stream may be adversely affected if units are not square and level. Bottom of units and
Louvers should be used as reference to verify unit is square and plumb.
4. Anchor the Drinking Fountain to the wall at the lower mounting points in each Back Panel. Shim lower mounting
points to level unit if necessary.
5. Thoroughly flush the 3/8” O.D. supply line and then connect Drinking Fountain to Water Supply Angle Stop Valve (by
others) with supplied 3/8” O.D. Copper Tube.
6. Use supplied Flexible Hose and Clamps to connect Waste Tailpiece from the upper unit to the Waste Tailpiece of
lower unit and then make up 1-1/4” O.D. P-Trap Waste Connection. Waste P-Trap by others.
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAIN
A172-SO
Page 3 of 10
Revised: 12/20/17
7020-961-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of

TROUBLE SHOOTING:
IMPORTANT: BEFORE MAKING ANY OF THE REPAIRS LISTED, MAKE SURE THE WATER COOLER IS
DISCONNECTED FROM THE ELECTRICAL SUPPLY AND THE WATER SUPPLY VALVE IS SHUT OFF.
1. Adjustments
a. Cartridge – The water flow can be adjusted through the Pushbutton using a Straight Blade
Screwdriver and turning clockwise to increase flow and counterclockwise to decrease flow.
b. Cold Water Thermostat – The water temperature can be adjusted using a Slotted Screwdriver
and turning clockwise to make colder and counterclockwise to make warmer.
c. Bubbler Stream – Bubbler can be rotated slightly to direct the stream backwards or forwards.
Adjust the stream to minimize splashing. Splashing may occur from Bubbler Stream if the unit
is not level. Shim lower mounting points, if necessary, to level Drinking Fountain.
2. Restricted Or No Water Flow
a. Ensure Water Supply Service Stop Valve is fully open.
b. Verify minimum 20 PSIG (138 kPa) supply line flow pressure.
c. Check for twists or kinks in Bubbler Tubing.
d. Check the Water Inlet Strainer. Sediment from the main supply can get trapped in the
Screen along with installation materials such as Pipe Dope and Flux. The screen should
be cleaned and checked on a regular basis and replace if needed.
NOTE: STRAINER SCREEN MUST BE IN PLACE FOR WATER TO FLOW.
e. The Cartridge Valve located in the Water Control Assembly or Bubbler can also become
clogged with foreign material. The Cartridge Valve can only be replaced and not repaired.
f. Check flow adjustment. See start up note #3.
g. Flow control in Solenoid Valve Outlet Elbow clogged remove & clean.
h. No power to Power Supply connections, loose or wires cut.
3. Water Drip Or Will Not Shut Off:
a. Remove Pushbutton, adjust flow regulator to the highest setting using a
Flat Head Screwdriver and turning clockwise. Check if water drip continues, if it is no longer
dripping turn Screwdriver counter-clockwise until you have desired flow rate. Assure that
Retaining Nut is tighten to Valve Assembly, 25 in-lb (2825 mNm) torque is required. If issue still continues after
adjusting flow and tightening Retainer Nut, replacement of the Flow Regulator Cartridge will be
required.
b. Replace Valve Cartridge.
4. If light within sensor does not flash once when user is within range:
a. Verify 120VAC input & 9VDC output transformer output 9VDC.
b. Replace defective transformer.
c. Transformer polarity crossed. Replace transformer, sensor may be damaged and also need replacement.
d. Sensor in “Security Mode” after 30 seconds of consistent detection. Remove source of detection and wait 30
seconds before checking.
e. Sensor is picking up a highly reflective surface. Eliminate cause of reflection and wait 30 seconds before
checking.
5. If light within sensor lens flashes once when the user is within range:
a. Repair bad connection from Sensor to Solenoid.
b. There is debris or scale in the Solenoid Assembly. Remove Solenoid, pull out Plunger and Spring. Clean
with scale remover solution.
c. There is debris or scale in the center or two holes in convolution of the Water Diaphragm. Remove and
clean.
IMPORTANT : ASSUREZ-VOUS QUE LA FONTAINE D'EAU POTABLE RÉFRIGÉRÉE SOIT DÉBRANCHÉE DE LA
PRISE DE COURANT MURALE ET QUE LE ROBINET D'ALIMENTATION D'EAU SOIT FRMÉ AVANT
D'EFFECTUER LES RÉPARATIONS NÉCESSAIRES.
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAIN
A172-SO
Page 4 of 10
Revised: 12/20/17
7020-961-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of

I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAIN
A172-SO
Page 5 of 10
Revised: 12/20/17
7020-961-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
CLEANING & MAINTENANCE GUIDE:
CARTRIDGE REPLACEMENT/ STRAINER MAINTENANCE
Note: Use the universal maintenance tool to perform the following:
1. Strainer plug must be removed before cartridge replacement and strainer
maintenance (no need to turn the water off at the angle stop). Some residual water will drain
during plug removal.
2. Clean strainer as needed using clean water.
3. Cartridge replacement - insert diamond end of the universal tool into push button, rotate 90 degrees and pull firmly to
remove the button. Remove cartridge retaining nut . Remove and replace cartridge. When replacing cartridge be sure to
align the inlet and outlet ports on the cartridge with the ports in the valve body.
— NOTE: STRAINER SCREEN MUST BE IN PLACE FOR WATER TO FLOW.
1. Periodically remove fountain top and clean out in-line strainer.
2. DO NOT use harsh chemicals, abrasive or petroleum based cleaners. Use of these will void the Murdock warranty.
3. Exterior panels can be cleaned using mild household detergents or warm, soapy water. Extra care must be used cleaning
chrome plated items and mirror finished stainless steel. They can scratch easily and should only be cleaned using a clean,
soft cloth and mild soap with water or a mild glass cleaner.
For Stainless steel units:
1. To Remove water spots or rust spots, stainless steel cleaner/polish on a cloth is recommended.
2. If there are stubborn spots or if you wish to treat a scratch, synthetic abrasive general purpose pads such as scotch brite
are recommended.
3. Apply stainless steel cleaner/ polish to the synthetic abrasive pads and carefully rub the panel with the grain.
4. DO NOT use harsh chemicals, abrasive or petroleum based cleaners. Use of these will void the Murdock warranty. DO
NOT use abrasives on powder coated units.
5. Stainless steel should be kept clean at all times. If a coating of stainless steel cleaner/polish is maintained, stainless steel
surfaces will retain their new, clean, polished appearance indefinitely.
ITEM
PART NUMBER
DESCRIPTION
1
7003-095-001
VALVE ASSEMBLY
2
7000-060-000
FLOW REGULATOR CARTRIDGE (0.5 GPM)
3
7003-097-001
O-RING & STRAINER PLUG
4
7003-864-000
STRAINER FILTER SCREEN
5
7003-830-000
UNIVERSAL MAINTENANCE TOOL
2
4
3
1
5

I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAIN
A172-SO
Page 6 of 10
Revised: 12/20/17
7020-961-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
OPTIONAL -WF1 WATER FILTER
See the following page for models with -WF1 Water Filter (A172-SO-WF1)
ITEM
PART NUMBER
DESCRIPTION
1
7012-311-000
WF1 FILTER, 1500-GALLON
2
7003-010-002
FILTER WELD ASSEMBLY
3
7012-055-000
FOAM PIPE INSULATION, 3/8” I.D. x 1/4” THK
4
2169-000-000
1/4” O.D. LLDPE TUBING, BLUE
5
0124-031-000
#8 ZINC, HEX, SHEET METAL SCREW
6
0124-010-000
#10 PHILLIPS ROUND HEAD
7
1895-709-000
ELBOW, PUSH-IN 1/4” O.D. x 1/4” STEM
1
TOP VIEW
This end from
Supply Y-Strainer
(Open Frame Unit)
-WF1 Water Filter
Open Frame Unit
2
5
4
3
7
6
This end to Union Tee
1/4" Push-In

I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAIN
A172-SO
Page 7 of 10
Revised: 12/20/17
7020-961-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
OPTIONAL -WF1 WATER FILTER INSTALLATION
1. Remove the Bottom Housing and turn off unit water
supply.
2. With the Filter Assembly secured on the unit, hold
the Cap firmly, turn the Replaceable Cartridge Filter
counterclockwise to remove.
3. Remove and replace the Cartridge turning
clockwise to secure.
4. Turn on Water and check for leaks.
Important: Flush 5 gallons of water through the
Filter before allowing fixture use.
5. Re-install Bottom Housing.
FILTER CARTRIDGE REPLACEMENT:
ITEM
PART NUMBER
DESCRIPTION
1
7012-313-000
WF1 FILTER REPLACEMENT CARTRIDGE
BOTTOM HOUSING
-WF1 WATER FILTER
REPLACEMENT
CARTRIDGE
1

PUSH-IN FITTING INSTALLATION
NOTE: FITTINGS AND TUBE SHOULD BE KEPT
CLEAN, BAGGED AND UNDAMAGED PRIOR TO
INSTALLATION.
2. Pull on the fitted Tubing to ensure it is secure. Tube
should not come free from the Fitting. Water test the
connection assembly prior to leaving the site to ensure
there are no leaks.
DISCONNECTING THE TUBE:
To disconnect the Tube from the Fitting, ensure that the
water line is depressurized. Push Collet square towards
the Push-In Fitting Body and hold. While holding the Collet
in, pull on the PE Tubing to remove from the Push-In
Fitting.
TO CUT TUBE:
Cut to fit length of 1/4” PE Tubing and remove any
burrs or sharp edges. Ensure that the outside diameter
is free from score marks. Tube ends should be square.
INSERTING THE TUBE:
1. Firmly and fully insert the Tubing End into the Push-In
Fitting up to the Tube Stop located approximately ½”
deep.
COLLET
COLLET
O-RING
O-RING
TUBE STOP
COLLET
COLLET
COLLET
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAIN
A172-SO
Page 8 of 10
Revised: 12/20/17
7020-961-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of

3
2
4
5
6
8
9
7
10
11
21
13
14
16 12
17
19
24
25
1
22
21 22
21 22
23
4
20
6
15"
34"
27"
18
23
26
31
30
33
32
30
29
31
27
28
31
34 35
30
36
13
2122
15"
SENSOR OPERATED DRINKING FOUNTAIN PARTS BREAKDOWN DRAWING:
NOTE: See next page for table of part numbers corresponding to drawing above.
All 1/4" O.D. Plastic tubing 21 must be insulated with 22 foam insulation.
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAIN
A172-SO
Page 9 of 10
Revised: 12/20/17
7020-961-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of

Repairs must be made with Murdock Mfg. parts only. Please order through your local representative or
distributor. The phone number to locate your local representative is 1.800.591.9360.
DRINKING FOUNTAIN PARTS BREAKDOWN TABLE
NOTE: See previous page for fixture drawing corresponding to table of parts below.
ITEM #
PART NUMBER DESCRIPTION
1 7003-001-199 BASIN TOP
7000-099-002 LOW FLOW FLEXIBLE BUBBLER ASSEMBLY
7000-012-001 STAINLESS STEEL BUBBLER ASSEMBLY
3 0124-032-000 #8 x 3/4" LG PHIL FLAT HD SELF-TAPPING SCREW
4 7000-006-000 FLAT DRAIN GASKET
5 7003-182-000 DRAIN ADAPTER
6 7003-184-000 7/8" SPRING HOSE CLAMP
7 7003-181-000 1-1/4" DIA. DRAIN TUBE
8 7003-183-199 DRAIN HOSE
9 7003-003-199 BACK PANEL
10 7003-007-199 SUPPORT STRUT
7003-817-020 LEFT COVER - GRANITE
7003-823-299 LEFT COVER - STAINLESS STEEL
7003-818-020 RIGHT COVER - GRANITE
7003-824-299 RIGHT COVER - STAINLESS STEEL
7003-029-020 SENSOR OP APRON ASSEMBLY - GRANITE
7003-029-005 SENSOR OP APRON ASSEMBLY - STAINLESS STEEL
14 7003-099-000 PUSHBUTTON
15 7000-050-001 VALVE ASSEMBLY
16 0124-031-000 #8 x 3/8" LG. SLOTTED HEX WASHER HD SCREW
17 1895-121-000 SUPPLY INLET CONNECTION
18 1895-710-000 1/4" OD PUSH-IN "TEE" CONNECTION
7003-819-020 FILLER PLATE - GRANITE
7003-825-199 FILLER PLATE - STAINLESS STEEL
20 0124-050-000 #8 x 3/8" LG PHILLIPS PAN HEAD SCREW
21 2169-000-000 1/4" O.D. TUBING
22 7012-055-000 TUBE INSULATION
23 7003-093-001 FLOW RESTRICTOR - LOW FLOW BUBBLER ONLY
24 7003-014-199 HANGER BRACKET
25 0124-056-000 #8 x 3/8" LG PHILLIPS PAN HEAD SHEET METALSCREW
26 7001-200-001 SOLENOID/VALVE MOUNTING ASSEMBLY
27 7003-027-199 SENSOR BRACKET
28 2562-369-001 9VDC SENSOR
29 7001-202-199 SENSOR SPACER
30 0331-023-000 #8 S/S FLAT WASHER
31 0308-009-000 #8 - 32 NYLON INSERT LOCKNUT
32 0711-407-199 POWER SUPPLY, 240VAC/9VDC
33 7003-028-199 TRANSFORMER BRACKET
34 7003-023-199 CARTRIDGE MTG BRACKET
35 7000-059-199 1-1/4" - 18 NORMALLY OPEN VALVE CAP
36 7000-050-001 VALVE CARTRIDGE ASSEMBLY
11
12
19
2
13
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAIN
A172-SO
Page 10 of 10
Revised: 12/20/17
7020-961-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
