Murdock A172-UG Series Installation and operating instructions

COMPLIES WITH
7020-984-001 Date: 09/01/2020
Test rating conditions are
compliant with ARI 1010.
Federal
Public Law
111-380
(No Lead) Member of
MURDOCK
15125 Proctor Ave.
City of Industry, CA
91746 U.S.A.
Phone [phone]
626-336-4561
Fax [phone]
www.murdockmfg.com
LIMITED WARRANTY - UNITED STATES & CANADA
LIMITED EXPORT WARRANTY - One year on parts only.
This warranty does not cover installation or labor charges and does not apply to materials, which have been
damaged by other causes such as mishandling or improper care or abnormal use. The repair or replacement of the
defective materials shall constitute the sole remedy of the Buyer and the sole remedy of Murdock under this
warranty. Murdock shall not be liable under any circumstances for incidental, consequential or direct charges
caused by defects in the materials, or any delay in the repair or replacement thereof. This warranty is in lieu of all
other warranties expressed or implied. Product maintenance instructions are issued with each unit and disregard
or non-compliance with these instructions will constitute an abnormal use condition and void the warranty.
Stainless steel must be protected on job site during construction and must be properly maintained after the water
has been introduced into the water cooler or drinking fountain, or Mudock’s limited warranty is void.
NOTES TO INSTALLER:
1. Please leave this documentation with the owner of the fixture when finished.
2. Please read this entire booklet before beginning the installation.
3. Check your installation for compliance with plumbing, electrical and other applicable codes.
Murdock warrants that its products are free from defects in material or workmanship under normal use and
service for a period of one year from date of original shipment or for 18 months after the date of shipment from the
factory, whichever comes first. Murdock’s liability under this warranty shall be discharged solely by replacement
or repair of defective material, provided Murdock is notified in writing within one year from date of shipment,
F.O.B. Industry, California.
Murdock assumes no responsibility for use of void or
suspended data. © Copyright Murdock, City of
Industry, CA Member of Morris Group International.
Please visit www.murdockmfg.com for most
current specifications.
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAIN
A172-UG Series / A172-UG-VR Series & A172-UG-SO Series
Universal Bi-Level, Barrier Free, Wall Mounted Drinking Fountain
A172100F-UG / A178400F-UG / A172100S-UG / A172400S-UG
172100F-UG-VR / A172400F-UG-VR / A172100S-UG-VR / A172400S-UG-VR
A172100F-UG-SO / A172400F-UG-SO / A172100S-UG-SO / A172400S-UG-SO
TECHNICAL ASSISTANCE TOLL FREE TELEPHONE NUMBER:
1.800.591.9360
Technical Assistance Fax: [phone]
A172100F-UG A172400S-UG-VR A172100F-UG-SO

A172-UG SERIES UNIVERSAL BI-LEVEL DRINKING FOUNTAIN
(Standard Configuration Left Unit High with Right Unit Low)
ROUGHING-IN AND DIMENSIONAL DRAWING
Prior to roughing consult with local, state, and federal codes for proper mounting height.
NOTES: Adjust vertical dimensions as required to comply with federal, state, and local codes.
Dimensions indicated are for ADA frontal approach installation. For Child ADA compliant parallel
approach installation, decrease height of installation for spout to be 30” maximum above finished floor.
Provide clear floor space as required. Adjust vertical dimensions as required to comply with federal,
state, and local codes.
A172-UG
Page 2 of 17
Date: 09/01/2020
7020-984-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAIN
1-1/4" [32] O.D.
TAILPIECE FOR
P-TRAP BY
OTHERS
13
8"
[35]
6"
[151]
12"
[305]
*33"
[838]
6"
[152]
D
E
C
B
A
GENERAL NOTES:
1. ALL DIMENSIONS ARE IN INCHES [MM]
2. ALLOW 4 INCHES [102MM] MINIMUM CLEARANCE PER SIDE FOR
VENTILATION
3. DIMENSIONS SHOWN ARE FOR ADA ADULT HEIGHT. ADJUST
VERTICAL DIMENSIONS AS NECESSARY TO COMPLY WITH
FEDERAL, STATE & LOCAL CODES
4. STOP VALVE, P-TRAP & ELECTRICAL OUTLET NOT SUPPLIED
5. IMPORTANT: COOLERS MUST BE ATTACHED TO WALL WITH
APPROPRIATE ANCHOR SCREWS
A. 3/8" O.D. SUPPLY INLET
B. WASTE OUTLET FOR P-TRAP BY OTHERS FOR PROVIDED
1-1/4" O.D. TAILPIECE
C. ELECTRICAL SERVICE ROUGH (IF REQUIRED)
D. Ø3/8" HANGER BRACKET PUNCHING, 6 PLACES ON EACH
FIXTURE FOR ANCHORING HARDWARE BY OTHERS
E. Ø1/4" PUNCHING, 2 PLACES ON EACH FIXTURE FOR
ANCHORING HARDWARE, BY OTHERS
F. PUSHBUTTON ASSEMBLY OR SENSOR
*
2"
[51]
33
4"
[95]
*157
8"
[403]
*177
8"
[454]
13
8"
[35]
3"
[76]
*305
8"
[778]
2"
[51]
6"
[152]
2"
[51]
*365
8"
[930]
77
8"
[200]
TYP
63
8"
[163]
123
4"
[324]
41
4"
[108]
D
E
F
185
8"
[473]

A172UBL SERIES UNIVERSAL BI-LEVEL DRINKING FOUNTAIN
(Alternate Configuration Left Unit Low with Right Unit High)
4. All burrs must be removed from outside of cut tubes before inserting into coupler or other components.
1. Water supply is 3/8” Outside Diameter copper tube. Waste is 1-1/4” Outside Diameter.
IMPORTANT:
7. Per UPC 609.10- All building water supply systems in which quick acting valves are installed shall be
provided with devices to absorb the hammer caused by high pressure resulting from the quick closing
of the valve. These pressure-absorbing devices shall be approved mechanical devices. Water
pressure-absorbing devices will be installed as close as possible to the quick closing valve.
5. WARNING: Warranty is voided if installation is not made following current Acorn Engineering
installation instructions and if components are assembled to the fixture that is not approved by Acorn
Engineering.
3. Do NOT solder copper tube when inserted into the coupler as damage to the o-ring will result.
6. Fixture operates within water pressure range of 20 to 105 psig. Acorn Engineering will not warranty
fixtures damaged when connected to supply lines with flow pressure lower than 20 psig or higher than
105 psig. A pressure regulator must be furnished by others on supply line if inlet pressure is greater
than 105 psig.
2. Completely flush supply lines of all foreign debris before connecting to fixture. Water cooler designed
to not affect taste, odor, color, or sediment. Optional water filter (WF1) is available should any of these
problems arise from the water supply.
A172-UG
Page 3 of 17
Date: 09/01/2020
7020-984-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAIN
1-1/4" [32] O.D.
TAILPIECE FOR
P-TRAP BY
OTHERS
13
8"
[36]
6"
[151] 12"
[305]
*33"
[838]
6"
[152]
D
EC
B
A
GENERAL NOTES:
1. ALL DIMENSIONS ARE IN INCHES [MM]
2. ALLOW 4 INCHES [102MM] MINIMUM CLEARANCE PER SIDE FOR
VENTILATION
3. DIMENSIONS SHOWN ARE FOR ADA ADULT HEIGHT. ADJUST
VERTICAL DIMENSIONS AS NECESSARY TO COMPLY WITH
FEDERAL, STATE & LOCAL CODES
4. STOP VALVE, P-TRAP & ELECTRICAL OUTLET NOT SUPPLIED
5. IMPORTANT: COOLERS MUST BE ATTACHED TO WALL WITH
APPROPRIATE ANCHOR SCREWS
A. 3/8" O.D. SUPPLY INLET
B. WASTE OUTLET FOR P-TRAP BY OTHERS FOR PROVIDED
1-1/4" O.D. TAILPIECE
C. ELECTRICAL SERVICE ROUGH (IF REQUIRED)
D. Ø3/8" HANGER BRACKET PUNCHING, 6 PLACES ON EACH
FIXTURE FOR ANCHORING HARDWARE BY OTHERS
E. Ø1/4" PUNCHING, 2 PLACES ON EACH FIXTURE FOR
ANCHORING HARDWARE, BY OTHERS
F. PUSHBUTTON ASSEMBLY OR SENSOR
*
D
E
G
185
8"
[473]
6"
[152]
*157
8"
[403]
63
8"
[162]
77
8"
[200]
TYP
*237
8"
[606]
13
8"
[35]
305
8"
[778]
2"
[51]
*365
8"
[930]
2"
[51]
2"
[51]
33
4"
[95]
63
8"
[163]
TYP
123
4"
[324]
TYP
63
8"
[162]
TYP

5. Thoroughly flush the 3/8” O.D. supply line and then connect drinking fountain to water supply angle
stop valve (by others) with supplied 3/8” O.D. copper tube.
4. Anchor the drinking fountain to the wall at the lower mounting points in each back panel. Shim lower
mounting points to level unit if necessary.
6. Use supplied flexible hose and clamps to connect waste tailpiece from the upper unit to the waste
tailpiece of lower unit and then make up 1-1/4” O.D. p-trap waste connection. Waste p-trap by others.
1. Mount hanger bracket to wall horizontally level as shown in Roughing-In and Dimensional Drawing.
Note: Adjust height of bracket if bubbler outlet height is required to vary from that shown.
WARNING: Hanger Bracket MUST be securely anchored to wall with fasteners sufficient to support 3
times the weight of drinking fountain. If wall can not provide adequate support, order and install
optional fixture support carrier.
NOTE: If wall cannot provide adequate support, order and install optional fixture support carrier.
NOTE: If replacing a competitors Water Cooler you may be able to use existing mounting bracket
INSTALLATION:
Choose configuration; Remove and reinstall filler plate, item 31 and reverse drain assembly if
required for alternate mounting configuration.
2. Remove the bottom cover from the drinking fountain and set aside in a safe place. Save the screws in
a secure location for re-use in later stages of installation.
3. Hang the drinking fountain on the hanger brackets ensuring the bracket tabs engage AND seat in the
slots in the back of the drinking fountain. Verify drinking fountain are level, left to right AND front to
back from bottom of unit. NOTE: The bubbler stream may be adversely affected if units are not
square and level. Bottom of units and louvers should be used as reference to verify unit is square and
plumb.
STANDARD WASTE CONFIGURATION ALTERNATE WASTE CONFIGURATION
ITEM 31
FILLER PLATE
ITEM 31
FILLER PLATE
A172-UG
Page 4 of 17
Date: 09/01/2020
7020-984-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAIN

OUTDOOR INSTALLATION INSTRUCTIONS FOR A172-UG-VR SERIES ONLY:
NOTE: THIS PROCEDURE NOT APPLICABLE FOR A172-UG & UNITS WITH A172-SO-UG OR
-BF11 OR UNITS WITH -BF12 BOTTLE FILLERS
1. Caulk all around the basins where it contacts the wall and where aprons contact the wall as shown, to prevent rain water
from leaking into the cabinet. DO NOT CAULK THE REMOVABLE ACCESS COVER. Add 1/4” thick piece of soft rubber
weather strip (provided by installer) between the units as shown.
STANDARD CONFIGURATION
ALTERNATIVE CONFIGURATION
CAULKING
WEATHER STRIP
WEATHER STRIP
(BETWEEN UPPER
AND LOWER UNITS)
CAULKING
WEATHER STRIP
(BETWEEN UPPER
AND LOWER UNITS)
CAULKING
WEATHER STRIP
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAIN
A172-UG
Page 5 of 17
Date: 09/01/2020
7020-984-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of

3. If water flow requires adjustment, insert a slotted narrow blade screwdriver in the hole centered on
the underside of the fixture in the knee clearance area up to the flow regulator. Turning clockwise will
increase flow and turning counterclockwise will decrease flow.
2. Do NOT use harsh chemicals, abrasive or petroleum based cleaners. Use of these will void the Acorn
warranty.
CLEANING & MAINTENANCE GUIDE:
START UP:
1. Before connecting water supply and assembling bottom cover to drinking fountain, but after
thoroughly flushing the supply line and connecting it to the fixture, turn on building water supply and
check all connections for leaks.
4. Recheck all water and drain connections with water flowing through system.
3. Exterior panels can be cleaned using mild household detergents or warm, soapy water. Extra care
must be used cleaning chrome plated items and mirror finished stainless steel.
They can scratch easily and should only be cleaned using a clean,
2. Air within the drinking fountain system or the structure supply piping will cause an irregular bubbler
outlet stream until purged out by incoming water. Covering the bubbler with a clean cup (or similar
object) is recommended when first activating drinking fountain to prevent excessive splashing.
Depress the pushbutton until steady water stream is achieved.
5. Assemble bottom cover to drinking fountain with screws furnished.
1. Periodically remove access panels and clean out in-line strainer.
2
4
3
1
5
ITEM PART NUMBER DESCRIPTION
5 7003-830-000 UNIVERSAL MAINTANANCE TOOL
4 7003-864-000 STRAINER FILTER SCREEN
3 7003-097-001 O-RING &STRAINER PLUG
2 7000-060-000 FLOW REGULATOR CARTRIDGE(05 GPMG)
1 7003-095-001 VALVE ASSEMBLY
CARTRIDGE VALVE PARTS
BREAKDOWN
A172-UG
Page 6 of 17
Date: 09/01/2020
7020-984-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAIN

I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAIN
A172-UG
Page 7 of 17
Date: 09/01/2020
7020-984-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
1. Strainer plug 4 must be removed before cartridge replacement and strainer
maintenance (no need to turn the water off at the angle stop). Some residual water will drain
during plug removal.
2. Clean strainer 4 as needed using clean water.
4. Remove cartridge retaining nut 10 . Remove and replace cartridge 2 . When replacing cartridge be sure to align the inlet
and outlet ports on the cartridge with the ports in the valve body.
3. Cartridge replacement - Rotate and remove -VR pushbutton escutcheon 6 to release pushbutton 7 and springs 8 9 to
access cartridge.
6. Install button assembly items 6 7 8 9 using maintenance tool 5 . Insure springs are installed in button correctly.
7. Reinstall strainer 4 and plug 3 using maintenance tool 5 .
Note: Use the -VR maintenance tool to perform the following:
-VR VANDAL RESISTANT CARTRIDGE REPLACEMENT/ STRAINER MAINTENANCE
5. Install item 10 using maintenance tool 5 (Be careful not to over tighten)
NOTE: STRAINER FILTER SCREEN
MUST BE IN PLACE FOR
WATER TO FLOW.
ITEM PART NUMBER DESCRIPTION
1 7003-095-001 VALVE ASSEMBLY
2 7000-060-000 FLOW REGULATOR CARTRIDGE(0.5 GPM)
3 7003-097-001 O-RING &STRAINER PLUG
4 7003-864-000 STRAINER FILTER SCREEN
5 7003-194-199 (-VR) MAINTENANCE TOOL
6 7003-197-199 (-VR) PUSHBUTTON ESCUTCHEON, CHROME
7 7003-196-199 (-VR) PUSHBUTTON, CHROME
8 7003-195-000 (-VR) PUSHBUTTON OVERTRAVEL SPRING
9 7003-193-000 (-VR) PUSHBUTTON RETURN SPRING
10 7000-052-000 RETAINING NUT
2
4
3
1
5
5
6
7
8
9
10

I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAIN
A172-UG
Page 8 of 17
Date: 09/01/2020
7020-984-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
ITEM # PART NUMBER DESCRIPTION
1 7000-050-001 Valve Cartridge Assembly
2 7000-060-000
Valve Cartridge
3 7000-053-199 Jam Nut
-SO SENSOR OPERATED CARTRIDGE VALVE PARTS BREAKDOWN
WHITE
CAP
WHITE
CAP
WHITE
PLUG
WHITE
PLUG
BOTTLE FILLER
SOLENOID VALVE
BOTTLE FILLER
SENSOR
RED
PLUGS
RED
CAPS
TRANSFORMER
RED
CAP
RED
PLUG
LOWER FOUNTAIN
SOLENOID VALVE
LOWER
FOUNTAIN
SENSOR
UPPER
FOUNTAIN
SENSOR
WHITE
CAP
WHITE
PLUG
UPPER FOUNTAIN
SOLENOID VALVE
-SO SENSOR OPERATED WIRING DIAGRAM WITH -BF12

A172-UG
Page 9 of 17
Date: 09/01/2020
7020-984-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAIN
Water Supply
Tubing
Cartridge Valve
Assembly
Electronic Valve
Assembly
Cartridge Valve
Assembly
To Bottle Filler
Water Supply
Tubing
Remove For Bottle
Filler Use
Water Supply
Tubing
Water Supply
Tubing
Remove For
Bottle Filler Use
Cartridge Valve
Assembly
Electronic Valve
Assembly
Water Supply
Tubing
To Bottle
Filler
A172-UG & A172-VR-UG BI-LEVEL UNIT PIPING INSTALLATION (WITH -BF OPTIONS)
A172-UG-SO BI-LEVEL UNIT PIPING INSTALLATION

NOTE: FITTINGS AND TUBE SHOULD BE KEPT
CLEAN, BAGGED AND UNDAMAGED PRIOR TO
INSTALLATION.
PUSH-IN FITTING INSTALLATION
2. Pull on the fitted tubing to ensure it is secure. Tube
should not come free from the fitting. Water test the
connection assembly prior to leaving the site to ensure
there are no leaks.
DISCONNECTING THE TUBE:
To disconnect the tube from the fitting ensure that the
water line is depressurized. Push collet square towards
the push-in fitting body and hold. While holding the collet
in, pull on the PE tubing to remove from the push-in fitting.
TO CUT TUBE:
Cut to fit length of 1/4” PE tubing and remove any burrs
or sharp edges. Ensure that the outside diameter is free
from score marks. Tube ends should be square.
INSERTING THE TUBE:
1. Firmly and fully insert the tubing end into the push-in
fitting up to the tube stop located approximately ½”
deep.
COLLET
COLLET
O-RING
O-RING
TUBE STOP
COLLET
COLLET
COLLET
A172-UG
Page 10 of 17
Date: 09/01/2020
7020-984-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAIN

A172-UG
Page 11 of 17
Date: 09/01/2020
7020-984-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAIN
A. Disconnect sensor from power supply.
C. Reconnect the sensor to the power supply.
SENSOR RANGE ADJUSTMENT
Check sensor activation distance. If
unsatisfactory, repeats steps A through E.
B. Create a short circuit between the positive
and negative connections on the sensor for
five seconds. WARNING: Do NOT create a
short circuit on the power supply or while the
sensor is connected to the power supply.
D. Within 5 seconds of making the connection to
the power supply, place and hold hand 2" to
4" in front of sensor.
E. Once red light within sensor begins flashing
quickly, move hand to preferred activation
distance and hold there until light stops
flashing.
Disconnect from power supply.
A
Jumper by
others
Short circuit sensor for 5 seconds.
B
Reconnect sensor to power supply.
C
Within 5 seconds, place hand
in front of sensor.
D
Move hand to desired range.
E
FOR A171.8-UG-SO ONLY

A172-UG
Page 12 of 17
Date: 09/01/2020
7020-984-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAIN
-Removal of P.E. Tubing from
Universal Maintenance Tool
-Strainer Plug
-Button Removal
-Cartridge Retaining Nut
Push-in Fittings
26
NOTE:
** Flow Restrictor Only Available
With Low Flow Bubbler.
NOTE: See page #10 for fixture drawing corresponding to table of parts below.
A172-UG DRINKING FOUNTAIN PARTS BREAKDOWN
5
4
3
2
1
13
15
9
18 15"
21
19
23
22
18 24"
24
26
25
23
22
18 24"
24
18 15"
7
7
6
4
3
2
1
8
9
10
14
13
20
11
12
21
11
12
17
16
18 2"
25
18 15"

Repairs must be made with Acorn Engineering parts only. Please order through your local
representative or distributor. The phone number to locate your local representative is 1.800.591.9360.
A172-UG DRINKING FOUNTAIN PARTS BREAKDOWN TABLE
NOTE: See previous page for fixture drawing corresponding to table of parts below.
A172-UG
Page 13 of 17
Date: 09/01/2020
7020-984-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAIN
ITEM # PART NUMBER DESCRIPTION
1 7003-161-001 BASIN TOP w/ PLUG
7000-099-002 STANDARD FLEXIBLE BUBBLER ASSEMBLY
7000-012-001 LEAD -FREE STAINLESS STEEL BUBBLER ASSEMBLY
3 0124-008-000 #8 x 3/4" LG FLAT HD SELF TAPPING TORX C/R SCREW
4 7000-006-000 FLAT DRAIN GASKET
5 7003-181-000 DRAIN TAILPIECE (LONG)
6 7003-180-000 DRAIN ADAPTER
7 7003-184-000 7/8" SPRING CLAMP
8 7003-183-199 DRAIN HOSE
9 7003-950-199 HANGER BRACKET
7003-956-020 FILLER PLATE - GRAY
7003-125-199 FILLER PLATE - STAINLESS STEEL
11 7003-900-199 BACK PANEL
12 7003-007-199 SUPPORT STRUT
13 0124-036-000 #8 x 1/2" LONG TORX ROUND HEAD C/R SCREW
14 0124-050-000 #8 x 3/8" LONG PHILLIPS PAN HEAD SCREW
15 1895-123-000 1/4" x 3/8" O.D. PUSH-IN SUPPLY INLET CONNECTION
16 1895-715-000 1/4" PLUG
17 1895-710-000 1/4" x 3/8" O.D. TUBE UNION TEE (PUSH-IN)
18 2169-000-000 1/*4" O.D. PE TUBING (BLUE)
7003-955-020 RIGHT CABINET - GRAY
7003-824-199 RIGHT CABINET - STAINLESS STEEL
7003-954-020 LEFT CABINET - GRAY
7003-823-199 LEFT CABINET - STAINLESS STEEL
21 0124-031-000 #8x3/8" LONG SLOTTED HEX WASHER HEAD SCREW
22 7003-095-001 VALVE ASSEMBLY
7003-953-020 APRON ASSEMBLY - GRAY
7003-826-001 APRON ASSEMBLY - STAINLESS STEEL
24 7003-093-001 FLOW RESTRICTOR - LOW-FLOW BUBBLER ONLY
25 7003-099-000 PUSHBUTTON
26 7003-830-000 UNIVERSAL MAINTENANCE TOOL
2
23
10
19
20

I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAIN
A172-UG
Page 14 of 17
Date: 09/01/2020
7020-984-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
NOTE:
** Flow Restrictor Only Available
With Low Flow Bubbler.
NOTE: See page #13 for fixture drawing corresponding to table of parts below.
A172-UG-VR DRINKING FOUNTAIN PARTS BREAKDOWN
from Push-in Fittings
-Button Removal
-Removal of P.E. Tubing
Universal Maintenance Tool
-Cartridge Retaining Nut
-Strainer Plug
34
5
4
3
2
1
13
15
9
18 15"
21
19
23
22
18 24"
24
34
23
22
18 24"
24
18 15"
7
7
6
4
3
2
1
8
9
10
14
13
20
11
12
21
11
12
17
16
18 2"
18 15"
22
25
26
27
28
29
30
27
31
26
32
33
VANDAL RESISTANT BUTTON &
VALVE BREAKDOWN
NOT TO SCALE

I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAIN
A172-UG
Page 15 of 17
Date: 09/01/2020
7020-984-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
A172-UG-VR DRINKING FOUNTAIN PARTS BREAKDOWN TABLE
NOTE: See previous page for fixture drawing corresponding to table of parts below.
Repairs must be made with Acorn Engineering parts only. Please order through your local
representative or distributor. The phone number to locate your local representative is 1.800.591.9360.
ITEM # PART NUMBER DESCRIPTION
1 7003-161-001 BASIN TOP w/ PLUG
7000-099-002 STANDARD FLEXIBLE BUBBLER ASSEMBLY
7000-012-001 LEAD -FREE STAINLESS STEEL BUBBLER ASSEMBLY
3 0124-006-000 #8 x 3/4" LG FLAT HD SELF TAPPING TORX C/R SCREW
4 7000-008-000 FLAT DRAIN GASKET
5 7003-181-000 DRAIN TAILPIECE (LONG)
6 7003-180-000 DRAIN ADAPTER
7 7003-184-000 7/8" SPRING CLAMP
8 7003-183-199 DRAIN HOSE
9 7003-950-199 HANGER BRACKET
7003-956-020 FILLER PLATE - GRAY
7003-825-199 FILLER PLATE - STAINLESS STEEL
11 7003-900-199 BACK PANEL
12 7003-007-199 SUPPORT STRUT
13 0124-036-000 #8 x 1/2" LONG TORX ROUND HEAD C/R SCREW
14 0124-050-000 #8 x 3/8" LONG PHILLIPS PAN HEAD SCREW
15 1895-123-000 1/4" x 3/8" O.D. PUSH-IN SUPPLY INLET CONNECTION
16 1895-715-000 1/4" PLUG
17 1895-710-000 1/4" x 3/8" O.D. TUBE UNION TEE (PUSH-IN)
18 2169-000-000 1/*4" O.D. PE TUBING (BLUE)
7003-955-020 RIGHT CABINET - GRAY
7003-824-199 RIGHT CABINET - STAINLESS STEEL
7003-954-020 LEFT CABINET - GRAY
7003-823-199 LEFT CABINET - STAINLESS STEEL
21 0124-031-000 #8 x 3/8" LONG SLOTTED HEX WASHER HEAD SCREW
22 7003-095-001 VALVE ASSEMBLY
7003-952-020 APRON ASSEMBLY - GRAY
7003-826-001 APRON ASSEMBLY - STAINLESS STEEL
24 7003-093-001 FLOW RESTRICTOR - LOW-FLOW BUBBLER ONLY
25 7003-198-199 (-VR) PUSHBUTTON MOUNTING SLEEVE
26 0124-055-000 #8 x 3/4" LONG PHILLIPS ROUND HEAD SCREW
27 0161-062-000 #6-32 x 1/2" LONG PHILLIPS ROUND HEAD SCREW
28 7003-195-000 (-VR) PUSHBUTTON OVERTRAVEL SPRING
29 7003-196-199 (-VR) PUSHBUTTON, CHROME
30 7003-197-199 (-VR) PUSHBUTTON ESCUTCHEON, CHROME
31 7003-193-000 (-VR) PUSHBUTTON RETURN SPRING
32 7003-200-000 AUTO-STOP CONDESATION GASKET, LOWER
33 7003-199-000 AUTO-STOP CONDESATION GASKET, UPPER
34 7003-830-000 UNIVERSAL MAINTENANCE TOOL
2
23
10
19
20

I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAIN
A172-UG
Page 16 of 17
Date: 09/01/2020
7020-984-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
NOTE:
** Flow Restrictor Only Available
With Low Flow Bubbler.
A172-UG-SO DRINKING FOUNTAIN PARTS BREAKDOWN
NOTE: See page #15 for fixture drawing corresponding to table of parts below.
5
4
2
3
1
13
15
9
17 15"
20
18
22
21
17 24"
23
22
21
17 24"
23
18 15"
7
7
6
4
3
2
1
8
9
10
14
13
19
11
12
20
11
12
16
17 2"
17 15"
26
293031
2728
2524
17
5"
17
5"
262728
293031
32

I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAIN
A172-UG
Page 17 of 17
Date: 09/01/2020
7020-984-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
A172-UG-SO DRINKING FOUNTAIN PARTS BREAKDOWN TABLE
NOTE: See previous page for fixture drawing corresponding to table of parts below.
Repairs must be made with Acorn Engineering parts only. Please order through your local
representative or distributor. The phone number to locate your local representative is 1.800.591.9360.
ITEM # PART NUMBER DESCRIPTION
1 7003-161-001 BASIN TOP w/ PLUG
7000-099-002 STANDARD FLEXIBLE BUBBLER ASSEMBLY
7000-012-001 LEAD -FREE STAINLESS STEEL BUBBLER ASSEMBLY
3 0124-008-000 #8 x 3/4" LG FLAT HD SELF TAPPING TORX C/R SCREW
4 7000-006-000 FLAT DRAIN GASKET
5 7003-181-000 DRAIN TAILPIECE (LONG)
6 7003-180-000 DRAIN ADAPTER
7 7003-184-000 7/8" SPRING CLAMP
8 7003-183-199 DRAIN HOSE
9 7003-950-199 HANGER BRACKET
7003-956-020 FILLER PLATE - GRAY
7003-825-199 FILLER PLATE - STAINLESS STEEL
11 7003-900-199 BACK PANEL
12 7003-007-199 SUPPORT STRUT
13 0124-036-000 #8 x 1/2" LONG TORX ROUND HEAD C/R SCREW
14 0124-050-000 #8 x 3/8" LONG PHILLIPS PAN HEAD SCREW
15 7000-021-002 "Y" STRAINER ASSEMBLY 3/8" O.D. x 1/4" O.D.
16 1895-715-000 1/4" PLUG
17 1895-710-000 1/4" x 3/8" O.D. TUBE UNION TEE (PUSH-IN)
18 2169-000-000 1/*4" O.D. PE TUBING (BLUE)
7003-955-020 RIGHT CABINET - GRAY
7003-824-199 RIGHT CABINET - STAINLESS STEEL
7003-954-020 LEFT CABINET - GRAY
7003-823-199 LEFT CABINET - STAINLESS STEEL
21 0124-031-000 #8 x 3/8" LONG SLOTTED HEX WASHER HEAD SCREW
22 7003-095-001 VALVE ASSEMBLY
7003-922-020 APRON ASSEMBLY - GRAY
7003-826-001 APRON ASSEMBLY - STAINLESS STEEL
24 7003-093-001 FLOW RESTRICTOR - LOW-FLOW BUBBLER ONLY
25 0711-407-001 240VAC / 9VDC TRANSFORMER
26 7003-028-199 TRANSFORMER BRACKET
27 7000-050-001 VALVE CARTRIDGE
28 7000-060-000 FLOW REGULATOR CARTRIDGE (0.5 GPM)
29 7003-023-199 CARTRIDGE MOUNTING BRACKET (SENSOR OP)
30 2562-369-001 SENSOR ASSEMBLY, INFRARED, LATCHING
31 7003-027-199 SENSOR BRACKET
32 7001-200-199 SENSOR SPACER
33 0711-413-001 3 STATION 9VAC WIRING HARNESS
2
23
10
19
20
