Murdock A191.8-BF Series Installation and operating instructions

TECHNICAL ASSISTANCE TOLL FREE TELEPHONE NUMBER:
1.800.591.9360
Technical Assistance Fax: [phone]
A191.8-BF Series
Barrier Free, Wall Mounted Chilled Drinking Fountain
with Bottle Filler and Trim Panel
COMPLIES WITH
7021-033-001 Date: 10/04/2021
Federal
Public Law
111-380
(No Lead)
Murdock assumes no responsibility for use of void or
suspended data. © Copyright Murdock, City of
Industry, CA Member of Morris Group International.
Please visit www.murdockmfg.com for most
current specifications.
Member of 15125 Proctor Ave, City of Industry,
CA, 91746 U.S.A.
Phone [phone]
626-336-4561
Fax [phone]
www.murdockmfg.com
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS
IMPORTANT: INSTALLATION FOR FREEZE RESISTANT OPTION “-FRA” WILL DIFFER FROM STANDARD!
REFER TO DESIGNATED FREEZE RESISTANT INSTALLATION DETAILS PRIOR TO ROUGH-IN AND FIXTURE
INSTALL -FRA SERIES OPTIONS. FOR ADDITIONAL INFORMATION VISIT: www.MurdockMfg.com/Resources
OR CONTACT YOUR LOCAL SALES REPRESENTATIVE.
Murdock warrants that every cooler, bottle filling station, packaged water chiller, fountain and accessory to be free from defects
in material and workmanship under normal use for one (1) year from date of install or eighteen (18) months after the date of
shipment from the factory, whichever comes first.
Murdock warrants the compressor and hermetically sealed refrigeration system, including cooling coil assembly when part of
the hermetically sealed refrigeration system, to be free from defects in material and workmanship under normal use for an
additional four (4) years from the end of the one (1) year period described above.
NOTES TO INSTALLER:
1. Please leave this documentation with the owner of the fixture when finished.
2. Please read this entire booklet before beginning the installation.
3. Check your installation for compliance with plumbing, electrical and other applicable codes.
This warranty does not cover installation or labor charges and does not apply to materials, which have been damaged by other
causes such as mishandling or improper care or abnormal use. The repair or replacement of the defective materials shall
constitute the sole remedy of the Buyer and the sole remedy of Murdock under this warranty. Murdock shall not be liable under
any circumstances for incidental, consequential or direct charges caused by defects in the materials, or any delay in the repair or
replacement thereof. This warranty is in lieu of all other warranties expressed or implied. Product maintenance instructions are
issued with each unit and disregard or non-compliance with these instructions will constitute an abnormal use condition and
void the warranty. Stainless steel must be protected on job site during construction and must be properly maintained after the
water has been introduced into the water cooler or drinking fountain, or Murdock’s limited warranty is void.
LIMITED WARRANTY - UNITED STATES & CANADA
LIMITED EXPORT WARRANTY - One year on parts only.

A191.8-BF
Page 2 of 16
New: 10/04/2021
7021-033-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS
Some options may slightly alter installation. To ensure proper installation review the manual thoroughly
and verify rough-ins before beginning any work. File this manual with the owner or maintenance
personnel upon completion of installation.
MGI Engineered Plumbing Products are designed in accord with applicable National Codes and
Standards, which may include UPC, ANSI, and ASSE. Installers should use industry standard practice
for details not covered within Manual. Prior to installation, supply lines must be flushed of all foreign
material such as pipe dope, chips, or solder. Debris or foreign material in water supply may damage
valve. An appropriate thread sealant is recommended on all threaded waste and supply connections to
reduce the possibility of leaks.
This fixture is intended to dispense water that has been lowered in temperature, but otherwise remains
unchanged by the materials in the water cooler. It is common for electrical equipment to be grounded
to water lines either within a structure or away from it. Every attempt should be made to prevent this
kind of grounding from generating electrical feedback into the water cooler creating electrolysis.
Electrolysis will cause a metallic taste or cause water metal content to increase.
When applicable: ANSI, UFAS or ADA compliance is subject to the interpretation and requirements of
the local code authority and is the responsibility of the installer for verification.
When applicable: Electrical receptacle(s) must be wired to a GFCI protected circuit. Fixture must be
earth grounded per N.E.C. (National Electrical Code).
When applicable: Industry standard wall backing, for wall hung fixtures, is required. Installer provided
wall anchors and wall anchoring hardware must be appropriate for wall construction and have a
minimum pull-out rating of 1000 lbs. (453.6 kg).
NOTICE
IMPORTANT
A dielectric coupling must be used to connect the water cooler to the water supply. A nonmetallic
coupler is furnished with this water cooler to meet this requirement.

DIMENSIONAL DRAWING
Prior to roughing in, consult with local, state, and federal codes for proper mounting height.
A191.8-BF
Page 3 of 16
New: 10/04/2021
7021-033-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS
NOTES:
1. Dimensions shown for ADA compliant installation. For Child ADA 2010 compliant parallel approach installation,
decrease height of * dimensions by 2-3/4".
2. Provide clear floor space as required. Adjust vertical dimensions as required to comply with federal, state, and
local codes.
GENERAL NOTES:
1. ALL DIMENSIONS ARE IN INCHES [MM]
*2. DIMENSIONS SHOWN ARE FOR RECOMMENDED HEIGHT. ADJUST
VERTICAL DIMENSIONS AS NECESSARY TO COMPLY WITH FEDERAL,
STATE, & LOCAL CODES
233
4"
[603]
*27"
[686]
13
8"
[35]
181
2"
[470]
*33"
[838]
491
8"
[1248]
*51
2"
[141]
211
8"
[537]
11"
[279]
*41
2"
[114]
213
8"
[543]
TRIM PANEL
1-1/4" [32] O.D.
P-TRAP
PROVIDED
19"
[483]
11
2"
[38]

A191.8-BF
Page 4 of 16
New: 10/04/2021
7021-033-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
A191408S-BF Rough-In and Mounting Plate Detail
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS
1. Dimensions shown for ADA compliant installation. For Child ADA 2010 compliant parallel approach installation,
decrease height of * dimensions by 2-3/4".
2. Provide clear floor space as required. Adjust vertical dimensions as required to comply with federal, state, and
local codes.
NOTES:
General Notes:
1. Dimension indicated with (*)
is for 33" drinking fountain
discharge height. If discharge
height differs, adjust
accordingly.
2. Framed wall shown for
reference. (Site conditions
may differ)
31
4"
[83]
4
1/4" Screw and Washers by Installer
5
Supplied Wall Mounting Plate
1-1/4" OD Waste Outlet
2
3
Support Framing by Installer
6
4
5
5
43
4"
[121]
1
4"
[6]
2
*295
8"
[752]
3
8"
[9]
*277
8"
[708]
*515
8"
[1311]
1
*51
2"
[140]
211
2"
[546]
Opening
41
4"
[108]
C
L
21"
[533] Opening
191
2"
[495]
3
4"
[19]
5"
[127]
Typ 6
3/8" NCT Supply Inlet
5/16-18 UNC Studs and Hardware (Provided)
"S" Clip Mounting Bracket (Provided)
7
7
1
4
5
7
3
7

A191.8-BF
Page 5 of 16
New: 10/04/2021
7021-033-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS
IMPORTANT:
5. It is common for electrical equipment to be grounded to water lines either within a structure or away; otherwise,
remains unchanged by the materials in the water cooler. Every attempt should be made to prevent this kind of
grounding from generating feedback into the water cooler creating electrolysis. Electrolysis will cause a
metallic taste or cause water content to increase.
2. Provide 4” minimum clear space in front of bottom trim panel and above in-wall chiller to allow for proper
ventilation.
1. Water Supply Service Stop Valve, Water Connections and Electrical Connections to be supplied by others in
accordance with local codes.
8. This unit must be grounded per the requirements of applicable electrical codes.
9. WARNING: Warranty is voided if installation is not made following current Murdock Mfg. installation
instructions and if components are assembled to the fixture that are not approved by Murdock Mfg.
7. Completely flush water supply lines of all foreign debris, before connecting to the fixture.
10. Fixture operates within water pressure range of 174 kPa (25 psig) to 724 kPa (105 psig). Murdock Mfg. will
not warranty chiller damaged when connected to supply lines with flow pressure lower than 174 kPa (25
psig) or higher than 724 kPa (105 psig). A pressure regulator must be furnished by others on supply line if
inlet pressure is greater than 724 kPa (105 psig).
4. Completely flush supply lines of all foreign debris before connecting to fixture. Water cooler designed to not
cause problems with taste, odor, color, or sediment. Optional Water Filter, is available should any of these
problems arise from the water supply.
12. Per UPC 609.10-All building water supply systems in which quick acting valves are installed shall be
provided with devices to absorb the hammer caused by high pressure resulting from the quick closing of the
valve. These pressure-absorbing devices shall be approved mechanical devices. Water pressure-absorbing
devices shall be installed as close as possible to the quick closing valve
5. Do NOT solder tubes inserted into the chiller, bottle filler or the fountain strainer as damage to the o-rings on
the push-in fittings may result.
3. Waste is 1-1/4” Outer Diameter. Chiller water inlet is 3/8” Outer Diameter copper tube. Chiller water outlet is
3/8” Outer Diameter copper tube. Drinking Fountain water inlet is 3/8” Outer Diameter copper tube. Bottle
Filler water inlet is 3/8” Outer Diameter copper tube. Water line by others from in-wall chiller to drinking
fountain must have adequate insulation.
PRIOR TO INSTALLATION:
2. Carefully remove all fixture components from packaging, preventing scratching or damage. Inspect fixture and
all parts from damages and all parts that are bolted on.
6. All burrs must be removed from outside of cut tubes before inserting into strainer or other components.
7. Power supply must be identical in voltage, cycle and phase to that specified on the chiller data plate. Refer to
submittal.
11. Due to cold waste water, Murdock Mfg. recommends that waste piping supplied by installer be insulated
appropriately to prevent excessive condensation.
3. Provide mounting surface, adequate to support the fixture and loads on the fixture.
4. Provide rough-ins as shown on the roughing-in and dimensional drawing, including water supply and drain
pipe. (See rough-in details)
1. Read all installation instructions carefully, before proceeding.
6. Electrical Receptacle(s) must be wired to a GFCI protected circuit. Fixture must be earth grounded per NEC
(National Electrical Code).

DRINKING FOUNTAIN INSTALLATION:
1. Position Wall Mounting Plate and fix to wall using 1/4” wood screws and washers (Provided by Others).
11. Place Lower Trim Panel onto Upper Trim Panel and secure to Brackets on both sides with screws provided.
1. Before connecting power supply, but after thoroughly flushing the supply line and connecting it to the cooler, turn
on building water supply and check all connections for leaks.
3. Place the Chiller Unit onto the base pan of the Frame Assembly.
6. Remove the Drinking Fountain top by taking out side screws and the drain screw and lifting at the front while pulling
forward. Disconnect bubbler tube. Set top aside in a safe place where it will not be damaged. Place the screw in a
secure location where it will not be lost.
9. Make-up 1-1/4” outer diameter waste connection.
7. Slide Fixture over studs and secure with nuts and washers.
10. Place drain gasket on drain adapter. Reconnect bubbler tube. Reassemble top to unit by engaging back clip and
securing with screw.
2. Insert Frame Assembly into the rough-in block out and secure using 1/4”-20 UNC mounting hardware (Provided by
Others).
4. Hang Upper Trim Panel on Mounting Clip.
5. Install the four threaded studs into the Wall Mounting Plate.
8. Assemble P-Trap to drain adapter and then assemble to unit with phillips head screws.
DRINKING FOUNTAIN START UP:
2. Air within the drinking fountain system or the structure supply piping will cause an irregular bubbler outlet stream
until purged out by incoming water. Covering the bubbler with a clean cup (or similar object) is recommended
when first activating drinking fountain to prevent excessive splashing.
3. Depress front pushbutton until steady water stream is achieved.
4. If water flow requires adjustment, insert a slotted narrow blade screwdriver in the hole centered on the underside
of the fixture in the knee clearance area up to the flow regulator. Turning clockwise will increase flow and turning
counterclockwise will decrease flow.
6. With power still NOT connected, carefully manually rotate cooling fan to ensure proper clearance and free fan
action
7. Provide power to water chiller and make sure unit begins to function.
8. Assemble louvered bottom trim panel with screws provided to brackets on either side of wall mounting frame.
5. Recheck all water connections with water flowing through system.
A191.8-BF
Page 6 of 16
New: 10/04/2021
7021-033-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS
6
2
11
4
3
4
11
5
1

A191.8-BF
Page 7 of 16
New: 10/04/2021
7021-033-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS
BF11/BF12 INSTALLATION INSTRUCTIONS
Unfasten screws that hold the Bottle Filler Housing to the Mounting
Channel. Disconnect insulated 1
4" riser tubing from Solenoid Valve to
separate. Place Bottle Filler Housing and screws in a secure location.
1
5
1
3
3
1
Bottle Filler Housing
1
Mounting Channel
2
#10-32 x 1" Button Head Screw
3
Solenoid Valve
4
4
21/4" OD Insulated Tubing
5
Center BF Mounting Channel over Fountain deck and anchor to
upper trim panel, securing with wall anchors and anchoring hardware
provided.
14" Typ (A)
7"
Typ (A)
15"
Typ
(A)
2
43
1
2
2
3
C
L
(A)
(A)(A)
(A)
BF12 Shown
1Drinking Fountain deck and cabinet
Mounting Channel
2
34x Mounting Holes (A)
4Anchoring Hardware provided
*NOTE: Thread 1/4" OD insulated inlet
tubing through Grommet and into
cabinet prior to securing to wall.
*NOTE: Insulation Tubing may overlap
Fittings. Illustrations may show exposed
1/4" OD Tubing for clarity only.
Ø1/4"
Mounting
Holes

CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS
A191.8-BF
Page 8 of 16
New: 10/04/2021
7021-033-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
BF11/BF12 INSTALLATION INSTRUCTIONS (Continued)
!IMPORTANT
FOR BF12 SERIES, FOLLOW STEP 3B
FOR BF11 SERIES, FOLLOW STEP 3A
With Mounting Panel secured, place Bottle Filler Housing on top of
the Water Cooler and connect water supply line from Bottle Filler to
Pneumatic Valve Outlet. Connect 1/8" Air-Line to Pushbutton and
Pneumatic Valve Inlet.
3A
With Mounting Panel secured, place Bottle Filler Housing on top
of the Water Cooler and connect water supply line from Bottle
Filler to Solenoid Valve Outlet.
3B
BF11 SERIES
BF12 SERIES
Bottle Filler Housing
1
Water Cooler Assembly
2
1/4" O.D. Polyethylene Supply Line
3
Pneumatic Valve
4
3
6
Mounting Panel
5
1/4"
Min.
1
2
5
4
3
6
1/4"
Min.
1
2
5
4
Valve Water Supply Outlet Elbow
6
Valve Air-Line Supply Inlet
7
1/8" O.D. Polyethylene Supply Line
8
Pushbutton
9
1/4"
Min.
Bottle Filler Housing
1
Water Cooler Assembly
2
1/4" O.D. Polyethylene Supply Line
3
Solenoid Valve
4
Mounting Panel
5
Valve Water Supply Outlet Elbow
6
7
8
8
9

CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS
A191.8-BF
Page 9 of 16
New: 10/04/2021
7021-033-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
-BCD Bottle Count Display
1
Sensor
2
Solenoid Valve
3
Power Supply
4
Black Wire - BCD
5
Connect Electrical wiring as shown in diagram. If unit does not have
-BCD Bottle Count Display, skip to step 4B.
4A
Connect Electrical wiring as shown in diagram. If unit has -BCD
Bottle Count Display, see step 4A before continuing.
4B
Sensor
1
Solenoid Valve
2
Power Supply
3
BF12-BCD SERIES
BF12 SERIES
1
3
4
3
2
1
5
4
3
2
BF11/BF12 INSTALLATION INSTRUCTIONS (Continued)

OPTIONAL WATER FILTER
A191.8-BF
Page 10 of 16
New: 10/04/2021
7021-033-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS
(-WF1 Water Filter Tubing)
After thoroughly flushing supply line, make up the supply line
connection to the 1/4" OD x 3/8" OD Push-In Y-Strainer and from
Y-Strainer to the Water Filter inlet. From Filter outlet, make up
connections to chiller inlet.
2A
If the optional -WF1 or -WF3 Water Filter is included with Fixture, slide
and mount Water Filter Bracket to Chiller Mounting Frame Assembly.
Secure Bracket with #8 x 3/8" Hex Washer Head Screw.
1
1
Chiller Mounting Frame Assembly
Water Filter Bracket Assembly
Water Filter
1
2
3
#8 x 3/8" Hex Washer Head Screw4
1
4
2
3
3
2
1
5
4
3
1
2
(-WF3 Water Filter Tubing)
After thoroughly flushing supply line, make up the supply line
connection to the 1/4" OD x 3/8" OD Push-In Y-Strainer and from
Y-Strainer to the Water Filter inlet. From Filter outlet, make up
connections to chiller inlet.
2B
4
5
3
1
2
1/4" OD PE Tubing
1/4" x 3/8" Tube Union Push-In
Chiller
1
2
3
-WF1 Water Filter4
1/4" OD x 3/8" OD Push-In Y-Strainer5
Angle Stop Recommended, by others6
Supply Line, provided by installer7
1/4" OD PE Tubing
1/4" x 3/8" Tube Union Push-In
Chiller
1
2
3
-WF3 Water Filter4
1/4" OD x 3/8" OD Push-In Y-Strainer5
Angle Stop Recommended, by others6
Supply Line, provided by installer7
To Building Water
Supply Line
To Building Water
Supply Line
6
7
6
7

A191.8-BF
Page 11 of 16
New: 10/04/2021
7021-033-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
PUSH-IN FITTING INSTALLATION
NOTE: FITTINGS AND TUBE SHOULD BE KEPT
CLEAN, BAGGED AND UNDAMAGED PRIOR TO
INSTALLATION.
2. Pull on the fitted tubing to ensure it is secure.
Tube should not come free from the fitting. Water
test the connection assembly prior to leaving the
site to ensure there are no leaks.
DISCONNECTING THE TUBE:
To disconnect the tube from the fitting ensure that
the water line is depressurized. Push collet square
towards the push-in fitting body and hold. While
holding the collet in, pull on the PE tubing to remove
from the push-in fitting.
TO CUT TUBE:
Cut to fit length of 1/4” PE tubing and remove any
burrs or sharp edges. Ensure that the outside
diameter is free from score marks. Tube ends
should be square.
1. Firmly and fully insert the tubing end into the
push-in fitting up to the tube stop located
approximately ½” deep.
INSERTING THE TUBE:
COLLET
COLLET
O-RING
O-RING
TUBE STOP
COLLET
COLLET
COLLET
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS

4. COMPRESSOR CYCLING ON OVERLOAD PROTECTOR:
6. RESTRICTED OR NO WATER FLOW:
c. A restriction or moisture in the system will also cause intermittent cycling. A certified refrigeration
mechanic should be contacted in this situation.
f. Check flow adjustment. See start up note #3.
g. Flow control in solenoid valve outlet elbow clogged remove & clean.
a. Check the electrical supply for power and correct voltage. The incoming voltage must be within 10% of
the rated voltage on the serial nameplate.
c. An incorrect refrigerant charge, restriction or defective compressor (not pumping) will also cause the
compressor to run without producing cold water. All these signs indicate a problem within the refrigeration
system and the water chiller must be checked by an authorized service company.
a. Cartridge – The water flow can be adjusted using a slotted narrow blade screwdriver and turning
clockwise to increase flow and counterclockwise to decrease flow.
IMPORTANT: BEFORE MAKING ANY OF THE REPAIRS LISTED, MAKE SURE THE WATER CHILLER IS
DISCONNECTED FROM THE ELECTRICAL SUPPLY AND THEWATER SUPPLY VALVE IS SHUT OFF.
2. COMPRESSOR DOES NOT RUN:
a. The most common cause for a water chiller to run without producing cold water is a loss of refrigerant.
The water chiller must be taken to a certified refrigerant technician for repairs.
3. COMPRESSOR RUNS - WATER IS WARM:
b. Make sure the condenser fan motor is operative. The fan blade must turn freely to help remove the heat
of compression.
b. Check the incoming voltage to make sure it is within 10% of the serial nameplate rating.
5. NOISY OPERATION:
a. Ensure water supply service stop valve is fully open.
c. Bubbler Stream - Bubbler can be rotated slightly to direct the stream backwards or forwards. Adjust the
stream to minimize splashing. Splashing may occur from bubbler stream if the unit is not level. Shim lower
mounting point, if necessary, to level chiller.
b. Cold Water Thermostat – The water temperature can be adjusted using a slotted screwdriver and turning
clockwise to make colder and counterclockwise to make warmer.
e. The cartridge valve located in the water control assembly or bubbler can also become clogged with
foreign material. The cartridge valve can only be replaced and not repaired.
d. If all components check positive for continuity, then test the wiring harness plug for continuity to see if
there is a broken wire within the wiring harness insulation.
b. If the cold thermostat capillary bulb loses its charge or becomes kinked, it will fail in the open position
causing a disruption of power to the compressor. Disconnect electrical supply to the water chiller and
using an ohm meter check, for continuity across the two electrical terminals on the thermostat. Install a
new thermostat if there is no continuity.
d. Change the overload or relay if defective.
b. Check the compressor mounting to make sure the pins and clips are not rattling. If the compressor
appears to be noisy internally, it must be replaced.
a. A dirty condenser or a blocked fan will cause a high head pressure and frequent cycling of the overload
protector.
c. Check for loose wires within the compressor box. The incoming power leads must be connected to the
overload and relay.
TROUBLE SHOOTING:
1. ADJUSTMENTS:
a. Check to make sure the fan blade is rotating freely.
b. Verify minimum 20 psig supply line flow pressure.
c. Check for twists or kinks in outlet tubing.
d. Check the water inlet “Y” strainer. Sediment from the main supply can get trapped in the screen along
with installation materials such as pipe dope and flux. The screen should be cleaned and checked on a
regular basis and replace if needed.
A191.8-BF
Page 12 of 16
New: 10/04/2021
7021-033-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS

h. The water chiller may also develop a freezing condition in which the water will become frozen inside the
evaporator coil. This indicates a refrigeration problem or thermostat failure; in which case, the water
chiller needs to be checked by a qualified technician.
7. WATER DRIPS OR WILL NOT SHUT OFF:
1. Motors have lifetime lubrication and do not require scheduled maintenance.
b. Replace valve cartridge.
1. To Remove water spots or rust spots, stainless steel cleaner/polish on a cloth is recommended.
I. No power to transformer connections, loose or wires cut.
a. Open fixture. Loosen nuts holding valve bracket assembly to bottom of fixture but, do not remove. Move
complete valve bracket assembly further back from the front push pad and tighten to lock in place.
CLEANING & MAINTENANCE GUIDE:
2. Excess dirt or poor ventilation will cause the compressor overload protector to turn the compressor off and it
will cycle on and off with no cold water coming out of bubbler. Periodically clean with vacuum cleaner, air
hose or brush the condenser fins and cabinet ventilation louvers. In environments where dirt and dust is
more prevalent, clean more frequently.
3. Periodically remove fountain top and clean out in-line strainer.
4. Periodically remove panel of bottle filler and clean out inline “Y’’ strainer
For Stainless steel units:
2. If there are stubborn spots or if you wish to treat a scratch, using synthetic abrasive general
purpose pads, such as Scotch-Brite™, are recommended.
3. Apply stainless steel cleaner/ polish to the synthetic abrasive pads and carefully rub the panel with the grain.
4. DO NOT use harsh chemicals, abrasive or petroleum based cleaners. Use of these will void the Murdock
warranty.
5. Stainless steel should be kept clean at all times. If a coating of stainless steel cleaner/ polish is maintained,
stainless steel surfaces will retain their new, clean, polished appearance indefinitely.
A191.8-BF
Page 13 of 16
New: 10/04/2021
7021-033-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
CARTRIDGE VALVE PARTS BREAKDOWN
3. Cartridge Replacement - insert diamond end of the Universal Tool into Pushbutton, rotate 90 degrees and pull
firmly to remove the Button. Remove Cartridge Retaining Nut . Remove and replace Cartridge. When replacing
Cartridge, be sure to align the inlet and outlet Ports on the Cartridge with the Ports in the Valve Body.
2. Clean Strainer as needed using clean water.
1. Strainer Plug must be removed before Cartridge replacement and Strainer maintenance (no need to turn the
water off at the Angle Stop). Some residual water will drainduring Plug removal.
CARTRIDGE REPLACEMENT/ STRAINER MAINTENANCE
— NOTE: STRAINER SCREEN MUST BE IN PLACE FOR WATER TO FLOW.
Note: Use the Universal Maintenance Tool to perform the following:
ITEM # PART NUMBER DESCRIPTION
1 7003-095-000 Valve Body Sub Assembly
2 7000-060-000 Valve Cartridge
3 7000-052-000 Retaining Nut
4 7003-864-000 Strainer, Auto Stop
5 7003-097-001 Strainer Cap
6 7003-194-199 Maintenance Tool
3
2
1
5
4Universal Maintenance Tool
-Button Removal
-Cartridge Retaining Nut
Push-in Fittings
-Removal of P.E. Tubing from
-Strainer Plug
6
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS

A191.8-BF
Page 14 of 16
New: 10/04/2021
7021-033-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
Repairs must be made with Murdock Manufacturing parts only. Please order through your local
representative or distributor. The phone number to locate your local representative is 1.800.591.9360.
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS
NOTE:
** Flow Restrictor Only Available
With Low Flow Bubbler.
DRINKING FOUNTAIN PARTS BREAKDOWN DRAWING
16
9
10
11
8
15
14
13
12
5
6A
6B
19
1
2
3
4
7
17
18
ITEM # PART NUMBER DESCRIPTION ITEM # PART NUMBER DESCRIPTION
1 7000-005-199 Drain Adapter 10 7003-196-199 Pushbutton, Chrome
2 0116-016-000 #10-32 x 3/8" Phillips Truss Head Screw 11 7003-197-199 Escutcheon, Chrome
3 7000-006-000 Flat Drain Adapter Gasket 12 0161-060-000 #6-32 x 1/2" Socket Cap, Flat Hd Screw
4 7000-015-000 1-1/4" OD P-Trap 13 0124-055-000 #8 x 3/4" Phillips, Round Head Screw
5 0126-209-000 #10-32 x 3/4" Torx Button Head Screw 14 7003-198-199 Mounting Sleeve
6A 7000-012-001 Stainless Steel Bubbler Assembly 15 7003-095-001 Valve Body Sub Assembly
6B 7000-099-002 Flexible Gray Bubbler Assembly 16 7003-093-001 Flow Restrictor - Low-Flow Bubbler Only
7 1895-710-000 1/4" Push-In Union Tee 17 1895-715-000 1/4" Acetal Plug
8 7003-195-000 Spring, Overtravel 18 0250-016-000 No. 10 x 3/4" Sheet Metal Screw
9 7003-193-000 Spring, Pushbutton Return 19 7003-166-000 Round Plug

A191.8-BF
Page 15 of 16
New: 10/04/2021
7021-033-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
Repairs must be made with Murdock Manufacturing parts only. Please order through your local
representative or distributor. The phone number to locate your local representative is 1.800.591.9360.
A191.8-BF SERIES BREAKDOWN
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS
ITEM # PART NUMBER DESCRIPTION
1 7001-724-001 Upper Trim Panel Assembly
BF11 Bottle Filler with Pushbutton Operation
BF12 Bottle Filler with Sensor Operation
BF12-BCD Bottle Filler w/ Sensor Operation & Bottle Counter Display
3 7001-700-001 Wide Contour Fountain
4 7000-239-199 Lower Trim Panel
5 7008-010-001 Chiller Assembly
6 7014-230-001 Frame Assembly, Chiller Mount
7 0701-722-001 #8 x 3/8" S/S Phil Hd Sheet Metal Screw
8 7014-213-199 Bracket, Trim Panel Mount
7014-060-001 Filter Assembly, 1,500 Gallons
7014-061-001 Filter Assembly, 3,000 Gallons
10 0250-013-000 Wood Screw, No. 12 x 1-1/4", Flat Head, S/S
11 7001-709-199 Bracket, Upper Trim Panel Support
12 0243-026-000 Stud, 5/16-18 UNC x 4" Lg, Zinc Plated
13 0332-006-000 Flat Washer, 5/16" Zinc Plated
14 0304-006-000 Hex Nut, 5/16-18, Zinc Plated Steel
15 7001-706-001 Weldment, Wall Mounting Plate
2
9
3
2
6
8
7
11
10
5
9
1
4
121314
1

CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS
A191.8-BF
Page 16 of 16
New: 10/04/2021
7021-033-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
Optional -WF1 Water Filter
Optional -WF3 Water Filter
3
4
2
9
1
4
3
4
5
6
2
1
7
7
6
5
9
8
8
ITEM PART NUMBER DESCRIPTION
1 7014-060-001 FILTER ASSY, 1,500 GALLONS
2 7014-060-002 BRACKET, FILTER MOUNT
3 7012-309-001 WF1 FILTER, 1,500 GALLONS
4 2169-000-000 1/4" OD TUBE, 3-1/2 FEET LONG
5 1895-709-000 ELBOW, 1/4" OD PUSH-IN x 1/4" OD STEM
6 0124-010-000 #10 x 1/2" LONG TRUSS HEAD SCREW
7 0124-031-000 #8 x 3/8" LONG SLOTTED WASHER SCREW
8 1895-123-000 1/4" x 3/8" O.D. TUBE UNION PUSH-IN
9 7012-313-000 REPLACEMENT CARTRIDGE
ITEM PART NUMBER DESCRIPTION
1 7014-061-001 FILTER ASSY, 3,000 GALLONS
2 7014-060-002 BRACKET, FILTER MOUNT
3 7012-333-001 WF3 FILTER, 3,000 GALLONS
4 2169-000-000 1/4" OD TUBE, 3-1/2 FEET LONG
5 1895-709-000 ELBOW, 1/4" PUSH-IN x 1/4" OD STEM
6 0250-011-000 #10 x 1/2" LONG TRUSS HEAD SCREW
7 0124-010-000 #8 x 3/8" LONG SLOTTED WASHER SCREW
8 1895-123-000 1/4" x 3/8" O.D. TUBE UNION PUSH-IN
9 7012-318-000 REPLACEMENT CARTRIDGE
