Murdock A152400F-BF4 Installation and operating instructions

A152/FG-BF4 Series
Rounded Box Barrier-Free Wall Mount Bi-Level Drinking
Fountain with Sensor Activated Bottle Filler
A152400F-BF4 / A152400S-BF4 / A152400F-FG-BF4 / A152400S-FG-BF4
TECHNICAL ASSISTANCE TOLL FREE TELEPHONE NUMBER:
1.800.591.9360
Technical Assistance Fax: [phone]
** U.S. DESIGN PATENT D545,607 (Bowl Design)
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS
NOTES TO INSTALLER:
1. Please leave this documentation with the owner of the fixture when finished.
2. Please read this entire booklet before beginning the installation.
3. Check your installation for compliance with plumbing, electrical and other applicable codes.
LIMITED WARRANTY - UNITED STATES & CANADA
Murdock warrants that its products are free from defects in material or workmanship under normal use and
service for a period of one year from date of install or for 18 months after the date of shipment from the factory,
whichever comes first. Murdock’s liability under this warranty shall be discharged solely by replacement or repair
of defective material, provided Murdock is notified in writing within one year from date of shipment, F.O.B.
Industry, California.
This warranty does not cover installation or labor charges and does not apply to materials, which have been
damaged by other causes such as mishandling or improper care or abnormal use. The repair or replacement of the
defective materials shall constitute the sole remedy of the Buyer and the sole remedy of Murdock under this
warranty. Murdock shall not be liable under any circumstances for incidental, consequential or direct charges
caused by defects in the materials, or any delay in the repair or replacement thereof. This warranty is in lieu of all
other warranties expressed or implied. Product maintenance instructions are issued with each unit and disregard
or non-compliance with these instructions will constitute an abnormal use condition and void the warranty.
Stainless steel must be protected on job site during construction and must be properly maintained after the water
has been introduced into the water cooler or drinking fountain, or Murdock’s limited warranty is void.
LIMITED EXPORT WARRANTY - One year on parts only.
COMPLIES WITH
7020-951-001 Date: 02/02/18
Test rating conditions are
compliant with ARI 1010.
Federal
Public Law
111-380
(No Lead) Member of
MURDOCK
15125 Proctor Ave.
City of Industry, CA
91746 U.S.A.
Phone [phone]
626-336-4561
Fax [phone]
www.murdockmfg.com
Murdock assumes no responsibility for use of void or
suspended data. © Copyright Murdock, City of
Industry, CA Member of Morris Group International.
Please visit www.murdockmfg.com for most
current specifications.

IMPORTANT
This fixture is intended to dispense water that has been lowered in temperature, but otherwise remains
unchanged by the materials in the drinking fountain. It is common for electrical equipment to be grounded to
water lines either within a structure or away from it. Every attempt should be made to prevent this kind of
grounding from generating electrical feedback into the drinking fountain creating electrolysis. Electrolysis will
cause a metallic taste or cause water metal content to increase.
ROUGHING-IN AND DIMENSIONAL DRAWING
Prior to roughing in, consult with local, state, and federal codes for proper mounting height.
A152/FG-BF4 Wall Mounted Drinking Fountain
Note: There are no mounting changes to be made for -SO models.
NOTES: Dimensions shown for Adult ADA compliant installation. For Child ADA compliant parallel approach
installation, decrease height of installation by 3 inches. Provide clear floor space as required. Adjust vertical
dimensions as required to comply with federal, state, and local codes.
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS
A152-BF4
Page 2 of 22
Revised: 02/02/18
7020-951-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
10"
185
8"
6"
145
8"
27
8"
32"
321
4"
143
4"
23"
111
2"
12"
*33"
13
8"
13
8"
83
8"
General Notes:
1. All dimensions are in inches
*2. Dimensions shown are for recommended adult
height. Adjust vertical dimensions as necessary
to comply with federal, state, & local codes.
Finished
Floor
16"31
2"

A152-RBL-BF4 Refrigerated Reverse Bi-Level Wall Mounted Drinking Fountain with Bottle Filler
NOTES: Dimensions shown for Adult ADA compliant installation. For Child ADA compliant parallel
approach installation, decrease height of installation by 3 inches. Provide clear floor space as required.
Adjust vertical dimensions as required to comply with federal, state, and local codes.
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS
A152-BF4
Page 3 of 22
Revised: 02/02/18
7020-951-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
10"
185
8"
6"
145
8"
27
8"
32"
321
4"
143
4"
23"
111
2"12"
*33"
13
8"
13
8"
83
8"
General Notes:
1. All dimensions are in inches
*2. Dimensions shown are for recommended adult
height. adjust vertical dimensions as necessary
to comply with federal, state, & local codes.
FINISHED
FLOOR
16" 31
2"

A152/FG-BF4 Refrigerated Wall Mounted Drinking Fountain Inlet & Outlet Rough-Ins
Note: There are no mounting changes to be made for -SO models.
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS
A152-BF4
Page 4 of 22
Revised: 02/02/18
7020-951-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
16"
8"
**38"
C
L
2
1
General Notes:
1. Dimension indicated with (**) is
for 33" drinking fountain
discharge height. if discharge
height differs, adjust accordingly.
2. Standard Bi-Level rough-ins
shown. For -RBL Reverse
Bi-Level, -RBL Mounting Frame
rough-ins opposite.
1-1/4" O.D. Drinking Fountain Waste Outlet
3/8" NCT Drinking Fountain Supply Inlet
Alternate 3/8" NCT Bottle Filler Supply Inlets
Alternate 1-1/4" O.D. Bottle Filler Waste Outlet
Electrical Service Rough2
3
4
5
1

DIMENSIONAL DRAWING
Prior to roughing in, consult with local, state, and federal codes for proper mounting height.
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS
A152-BF4
Page 5 of 22
Revised: 02/02/18
7020-951-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
301
4"
311
8"
16"
Finished
Floor
1
2
561
4"
Installation Instructions:
A- Provide 30-1/4" wide x 31-1/8" tall wall opening at
appropriate height. Provide structure support around
inside of the opening for frame anchoring.
B- Carefully remove Bi-Level Mounting Frame 1 , and
panel from packaging, preventing damage.
C- Center frame within wall opening with side, top, and
bottom lips overlapping outside the opening and up
against finished wall face. Secure to wall through
the sides, top and bottom using hardware 2 by
others ensuring 16" centerline dimension
left-to-right.
Notes:
1-Standard Bi-Level rough-ins shown. For -RBL Reverse Bi-Level, -RBL
Mounting Frame rough-ins opposite

IMPORTANT:
1. Water Supply Service Stop Valve, Water Connections and Electrical Connections to be supplied by others in
accordance with local codes.
2. Waste is 1-1/4” Outer Diameter. Drinking Fountain water inlet is 3/8” Outer Diameter copper tube. Bottle
Filler water inlet is 3/8” Outer Diameter copper tube. Water line by others.
3. Completely flush supply lines of all foreign debris before connecting to fixture. Optional Water Filter (WF1), is
available should any problems with taste, odor, color, or sediment arise from the water supply.
4. Do NOT solder tubes inserted into the bottle filler or the fountain strainer as damage to the o-rings on the
push-in fittings may result.
5. All burrs must be removed from outside of cut tubes before inserting into strainer or other components.
6. Provide electrical service to J-Box to power sensor and solenoid valve.
7. This unit must be grounded per the requirements of applicable electrical codes.
8. Fixture operates within water pressure range of 174 kPa (25 psig) to 724 kPa (105 psig). Murdock Mfg. will
not warranty chiller damaged when connected to supply lines with flow pressure lower that 174 kPa (25 psig)
or higher than 724 kPa (105 psig). A pressure regulator must be furnished by others on supply line if inlet
pressure is greater than 724 kPa (105 psig).
9. Per UPC 609.10-All building water supply systems in which quick acting valves are installed shall be
provided with devices to absorb the hammer caused by high pressure resulting from the quick closing of the
valve. These pressure-absorbing devices shall be approved mechanical devices. Water pressure-absorbing
devices shall be installed as close as possible to the quick closing valve.
PRIOR TO INSTALLATION:
1. Read all installation instructions carefully, before proceeding.
2. Carefully remove all fixture components from packaging, preventing scratching or damage. Inspect fixture
and all parts from damages and all parts that are bolted on.
3. Provide mounting surface, adequate to support the fixture and loads on the fixture.
4. Provide rough-ins as shown on the roughing-in and dimensional drawing, including water supply, drain pipe
and gravel drain well. (See rough-in details)
5. Electrical Receptacle(s) must be wired to a GFCI protected circuit. Fixture must be earth grounded per NEC
(National Electrical Code).
6. Completely flush water supply lines of all foreign debris, before connecting to the fixture.
A152-BF4 SERIES DRINKING FOUNTAIN INSTALLATION:
1. Insert Mounting Frame into the Rough-In Block Out and secure using 1/4”-20 UNC Mounting Hardware
(Provided by Others).
2. Hang Trim Panel on Mounting Frame. Note: The included 1” brackets do not get used with this installation
and the Plastic Spacers are typically not required and can be discarded.
3. Install the eight (8) Threaded Studs into the Wall Mounting Frame.
4. Remove the Drinking Fountain Top by unfastening the Drain Screw and lifting at the front while pulling
forward. Disconnect Tubing from Bubblers by unfastening Ferrule Nuts. Set Top aside in a safe place where
it will not be damaged. Place the Drain Screw in a secure location where it will not be lost.
5. Align Fixture Mounting Points with Studs and slide Fixture to finished wall. Anchor with Nuts and Washers
provided.
6. Assemble P-Trap to Drain Adapter and then Assemble to unit with Phillips Head Screws.
7. Make-up 1-1/4” outer diameter Waste Connection.
8. After thoroughly flushing the 3/8” outer diameter supply line, connect water supply to the 3-Way Divider
Assembly. From the 3-Way Divider Assembly, connect to 1/4” Nominal Copper Tube Inlets, Stops on
Supplies recommended. See Water Tubing Connections for visual.
9. Reconnect 1/4” OD Polyethylene Tube to Bubbler with Ferrule Nuts.
10. Test operation of Bubblers by depressing buttons and adjust the flow rate as required, see Water Tubing
connections for detail. Check all connections and Waste Piping for leaks. Correct if present.
11. Set Drain Gasket on Drain Adapter.
12. Re-install tops to unit by engaging the back clip and securing with Drain Screw.
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS
A152-BF4
Page 6 of 22
Revised: 02/02/18
7020-951-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of

A152FG-BF4 DRINKING FOUNTAIN INSTALLATION:
1. Insert mounting frame into the rough-in block out and secure using 1/4”-20 UNC mounting hardware
(Provided by Others).
2. Hang Trim Panel on Mounting Frame. Note: The included 1” brackets do not get used with this installation
and the plastic spacers are typically not required and can be discarded.
3. Install the eight (8) threaded studs into the Wall Mounting Frame
4. Carefully remove Drinking Fountain Fixtures from packaging material and Bottom Access Panel to prevent
scratching or damage.
5. Inspect Fixture Housing to ensure all Tubing connections, Bubblers and Pushbuttons have not become loose
during shipping. Correct if necessary.
5. Align Fixture Mounting Points with Studs and slide Fixture to finished wall. Anchor with Nuts and Washers
provided.
6. Assemble P-Trap to Drain Adapter. Position Drain Gasket on Drain Adapter and mount Drain Adapter to
Drinking Fountain Basin with #10-32 x 1” Center Reject Drain Screw.
7. Make-up 1-1/4” outer diameter waste connection.
8. After thoroughly flushing the 3/8” outer diameter supply line, connect water supply to the 3-Way Divider
Assembly. From the 3-Way Divider Assembly, connect to 1/4” Nominal Copper Tube Inlets, Stops on
Supplies recommended. See Water Tubing Connections for visual.
9. Test operation of Bubblers by depressing buttons and adjust the flow rate as required, see Water Tubing
connections for detail. Check all connections and Waste Piping for leaks. Correct if present.
10. Install Bottom Access Panel to complete the installation.
BF3/BF4 BOTTLE FILLER INSTALLATION:
1. With Drinking Fountain installed, connect water supply line from 3-Way Divider Assembly to Bottle Filler.
2. Loosen Slip Nuts to orientate P-Trap to desired direction then tighten Slip Nuts and make up 1-1/4” O.D.
Waste Connection.
3A. FOR -BF3 ONLY Make up Air-Line Supply from Pneumatic Valve to Pushbutton.
3B. FOR -BF4 ONLY Make up power connections to the ground, neutral & hot within the electrical box.
NOTE: BEFORE PERFORMING STEP 4, REFER TO ELECTRICAL INSTALLATION.
4. Test for leaks and proper operation, and then install the Bottle Filler Panel using the Water Filler Bracket and
secure the Bottle Filler by tightening the Screws under the Bottle Filler.
DRINKING FOUNTAIN START UP:
1. Before connecting power supply, but after thoroughly flushing the supply line, turn on building water supply
and check all connections for leaks.
2. Air within the drinking fountain system or the structure supply piping will cause an irregular bubbler outlet
stream until purged out by incoming water. Covering the bubbler with a clean cup (or similar object) is
recommended when first activating drinking fountain to prevent excessive splashing. Depress front push pad
until steady water stream is achieved.
3. If water flow requires adjustment, insert a slotted narrow blade screwdriver in the hole centered on the
underside of the fixture in the knee clearance area up to the flow regulator. Turning clockwise will increase
flow and turning counterclockwise will decrease flow.
4. Recheck all water connections with water flowing through system.
BOTTLE FILLER START UP:
1. PUSHBUTTON OPERATED :Air within the Bottle Filler System or the structure supply piping will cause an
irregular spout outlet stream until purged out by incoming water. Press and hold Pushbutton until steady
water stream is achieved
2. SENSOR OPERATED: Hold container to be filled just below the Sensor in the center of the Filler Spout and
then move the container upward and water flow will start automatically. When the container is almost filled,
lower the container below the Sensor until the water stops flowing. (See label on the Bottle Filler.
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS
A152-BF4
Page 7 of 22
Revised: 02/02/18
7020-951-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of

I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS
A152-BF4
Page 8 of 22
Revised: 02/02/18
7020-951-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
WATER TUBING CONNECTIONS:
PE Tubing
PE Tubing
Fill
Spout
9-12VDC Solenoid Valve
Solenoid Valve Outlet
Elbow w/ Flow Control
Solenoid Valve
Inlet Fitting
3-Way Divider
Assembly
Y-Strainer
Increase
Flow
Decrease
Flow
Flat Tip
Screwdriver
Increase
Flow
Decrease
Flow
A152FG-BF4
Flow Rate Detail
A152-BF4
Flow Rate Detail
Pushbutton

OPTIONAL -WF1 WATER FILTER INSTALLATION
Page for models with -WF1 filter (A152-BF4-WF1 SERIES)
A152-BF4
Page 9 of 22
Revised: 02/02/18
7020-951-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS
FILTER MOUNTING
DETAIL
(BACKVIEW)
Out In
Mount Filter Bracket to
Corner of Mounting
Frame
1
2
3
4
5
In
Out
Connect 1
4" Tubings
to Drinking Fountains
and Bottle Filler Valve
7
6
WATER TUBING
DIAGRAM
7
7012-055-000
Foam Pipe Insulation
6
2169-000-000
Tubing, 1/4" O.D. LLDPE, (Blue)
5
7012-311-000
WF1 Filter 1500 Gallon
4
1895-709-000
Elbow, 1/4" Push-In x 1/4" Stem
3
0124-031-000
#8 x 3/8" Hex Washer Head Screw
2
7014-035-199
Water Filter Bracket
1
0250-006-000
#10 x 5/8" Phillips Truss Head Screw
ITEM
PART NUMBER
DESCRIPTION

OPTIONAL -WF3 DUAL WATER FILTER INSTALLATION
A152-BF4
Page 10 of 22
Revised: 02/02/18
7020-951-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS
FILTER MOUNTING
DETAIL
(BACKVIEW)
1
2
3
4
5
WATER TUBING
DIAGRAM
In
Out
Connect 1
4" Tubings
to Drinking Fountains
and Bottle Filler Valve
6
Mount Filter Bracket
to Corner of Mounting
Frame
8
1
4" Supply from Y-Strainer
1
4" Outlet from WF3
8
1895-710-000
Union Tee, 1/4" Push-In
7
7012-055-000
Foam Pipe Insulation (Not Shown)
6
2169-000-000
Tubing, 1/4" O.D. LLDPE, (Blue)
5
7012-311-000
WF1 Filter 1500 Gallon
4
1895-709-000
Elbow, 1/4" Push-In x 1/4" Stem
3
0124-031-000
#8 x 3/8" Hex Washer Head Screw
2
7014-055-199
Bracket, Dual Filter Mount
1
0250-006-000
#10 x 5/8" Phillips Truss Head Screw
ITEM
PART NUMBER
DESCRIPTION

A152-BF4
Page 11 of 22
Revised: 02/02/18
7020-951-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS
-WF1 WATER FILTER CARTRIDGE REPLACEMENT
1. Remove front panel, this allows access to the filter
and the inlet valve (provided by others). Turn inlet
valve knob 1/4 turn clockwise to close.
2. With the filter assembly secured on the unit, hold
the cap firmly, turn the replaceable cartridge filter
counterclockwise to remove.
3. Remove and replace the cartridge turning clockwise
to secure.
4. Turn inlet valve knob 1/4 turn counterclockwise to
open and test for leaks and proper operation before
installing bottom access panel back onto unit.
Panel Assembly
Replacement
Cartridge
Water Inlet
Valve Closed
Water Inlet
Valve Open

A152-BF4
Page 12 of 22
Revised: 02/02/18
7020-951-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS
ELECTRICAL INSTALLATION:
NOTE: Plug in power is a standard feature.
1A. Plug-In Operation: Plug transformer provided into GFCI protected electrical service, used by the semi-
recessed bottle filler. Plug in transformer to power supply and connect to red sensor wire.
Red Wire
Blue Wire
Sensor
Plug-In Transformer
Junction Box
Provided
9-12VDC Solenoid
Valve

A152-BF4
Page 13 of 22
Revised: 02/02/18
7020-951-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS
-BCT BOTTLE COUNTER DISPLAY & SENSOR ELECTRICAL INSTALLATION:
Solenoid
Connection
Power Supply Connection
(Black Cables)
Sensor Connection
(Black & Red Cables)
Sensor Connection Transformer
Solenoid Valve
Bottle Count Display
Sensor

A152-BF4
Page 14 of 22
Revised: 02/02/18
7020-951-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS
-BCD BOTTLE COUNTER DISPLAY ADJUSTING & RESETTING INSTRUCTIONS:
NOTE: Bottle Counter Has Multiple Functions
Reset/ Mode Button
• Counts refilled bottles, otherwise purchased
• Adjustable for Units with and without filters
• “REPLACEMENT FILTER” alert function
• Alert reset, when filter is replaced
Description
Illuminated LCD display, counts bottles, and has a filter replacement alert function
Bottle Counting Function
The software applies a flow volume of approximately 16.9 fl oz (volume in standard size plastic water
bottle) to each bottle counted. If the flow volume is less than 16.9 fl oz there will be no count but the
volume will accumulate, so that part way through the next cycle the total bottle count will change.
Illuminated LCD Display

A152-BF4
Page 15 of 22
Revised: 02/02/18
7020-951-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS
-BCD BOTTLE COUNTER DISPLAY FILTER REPLACEMENT FUNCTIONS:
NOTE: When the volume accumulates to 1500 gallons (recommended maximum filter flow volume) the
“REPLACE FILTER” alert will appear on the display every time the bottle filler is activated.
Counter Modes
Located on the back of the display you will find the reset button for the mode settings. The Reset/Mode
selection button is accessible by removing the bottle filler panel assembly, then locate the large hole in the
back of the display mounting bracket. Use your finger or nonconductive implement to depress the
Reset/Mode Selection Button.
!!!DO NOT USE SHARP OR METAL IMPLEMENTS!!!
With this reset button, you are able to indicate whether or not the unit has a filter or does not have a filter.
The reset button will also take away the “REPLACE FILTER” alert once the filter has been replaced.
Systems With or Without Filter
• Depress the Reset/Mode selection button for 6
Seconds, the number of seconds will count up on the
display.
• At the end of the 6 seconds, “FLTR YES” or “FLTR NO”
WILL APPEAR on the display.
• “FLTR YES” means that there is a filter in the system
and a “REPLACE FILTER” alert WILL APPEAR on the
display when the maximum filter flow volume is reached.
• “FLTR NO” means that there is no filter in the system
and a “REPLACE FILTER” alert WILL NOT APPEAR
on the display.
• Release button when the option required is on the
display (Filter Yes or No)
CLEARING “REPLACE FILTER” ALERT:
NOTE: This Function only applies if the system has a filter
• Replace old filter with new filter.
• Depress the Reset/Mode selection button for 2 SECONDS
• The “REPLACE FILTER” will no longer appear on the display
• Test by actuating the bottle filler, alert will not appear.
Reset/Mode Button

I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS
A152-BF4
Page 16 of 22
Revised: 02/02/18
7020-951-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
PUSH-IN FITTING INSTALLATION
NOTE: FITTINGS AND TUBE SHOULD BE KEPT
CLEAN, BAGGED AND UNDAMAGED PRIOR
TO INSTALLATION.
2. Pull on the fitted tubing to ensure it is secure.
Tube should not come free from the fitting. Water
test the connection assembly prior to leaving the
site to ensure there are no leaks.
DISCONNECTING THE TUBE:
To disconnect the tube from the fitting ensure that
the water line is depressurized. Push collet square
towards the push-in fitting body and hold. While
holding the collet in, pull on the PE tubing to remove
from the push-in fitting.
TO CUT TUBE:
Cut to fit length of 1/4” PE tubing and remove any
burrs or sharp edges. Ensure that the outside
diameter is free from score marks. Tube ends
should be square.
INSERTING THE TUBE:
1. Firmly and fully insert the tubing end into the
push-in fitting up to the tube stop located
approximately ½” deep.
COLLET
COLLET
O-RING
O-RING
TUBE STOP
COLLET
COLLET
COLLET

TROUBLE SHOOTING:
1. ADJUSTMENTS:
a. Cartridge – The water flow can be adjusted using a slotted narrow blade screwdriver and turning
clockwise to increase flow and counterclockwise to decrease flow.
b. Cold Water Thermostat – The water temperature can be adjusted using a slotted screwdriver and turning
clockwise to make colder and counterclockwise to make warmer.
c. Bubbler Stream - Bubbler can be rotated slightly to direct the stream backwards or forwards. Adjust the
stream to minimize splashing. Splashing may occur from bubbler stream if the unit is not level. Shim lower
mounting point, if necessary, to level chiller.
2. RESTRICTED OR NO WATER FLOW:
a. Ensure water supply service stop valve is fully open.
b. Verify minimum 20 psig supply line flow pressure.
c. Check for twists or kinks in outlet tubing.
d. Check the water inlet “Y” strainer. Sediment from the main supply can get trapped in the screen along
with installation materials such as pipe dope and flux. The screen should be cleaned and checked on a
regular basis and replace if needed.
e. The cartridge valve located in the water control assembly or bubbler can also become clogged with
foreign material. The cartridge valve can only be replaced and not repaired.
f. Check flow adjustment. See start up note #3.
g. Flow control in solenoid valve outlet elbow clogged remove & clean.
h. No power to transformer connections, loose or wires cut.
3. WATER DRIPS OR WILL NOT SHUT OFF:
a. Open fixture. Loosen nuts holding valve bracket assembly to bottom of fixture but, do not remove. Move
complete valve bracket assembly further back from the front push pad and tighten to lock in place.
b. Replace valve cartridge.
SENSOR TROUBLE SHOOTING:
4. IF LIGHT WITHIN SENSOR DOES NOT FLASH ONCE WHEN USER IS WITHIN RANGE:
a. Verify 120VAC input & 9VDC output transformer output 9VDC.
b. Replace defective transformer.
c. Transformer polarity crossed. Replace transformer, sensor may be damaged and also need replacement.
d. Sensor in “Security Mode” after 30 seconds of consistent detection. Remove source of detection and wait
30 seconds before checking.
e. Sensor is picking up a highly reflective surface. Eliminate cause of reflection and wait 30 seconds before
checking.
5. IF LIGHT WITHIN SENSOR LENS FLASHES ONCE WHEN THE USER IS WITHIN RANGE:
a. Repair bad connection from sensor to solenoid.
b. There is debris or scale in the solenoid assembly. Remove solenoid, pull out plunger and spring. Clean
with scale remover solution.
c. There is debris or scale in the center or two holes in convolution of the water diaphragm. Remove and
clean.
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS
A152-BF4
Page 17 of 22
Revised: 02/02/18
7020-951-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of

CLEANING & MAINTENANCE GUIDE:
1. Motors have lifetime lubrication and do not require scheduled maintenance.
2. Excess dirt or poor ventilation will cause the compressor overload protector to turn the compressor off and it
will cycle on and off with no cold water coming out of bubbler. Periodically clean with vacuum cleaner, air
hose or brush the condenser fins and cabinet ventilation louvers. In environments where dirt and dust is
more prevalent, clean more frequently.
3. Periodically remove fountain top and clean out in-line strainer.
4. Periodically remove access panel of cooler and clean out inline “Y’’ strainer
For Powder coated units: Units should be cleaned using a mild soap solution with a sponge or cotton cloth.
Wipe down surfaces then rinse with clean water.
For Stainless steel units:
1. To Remove water spots or rust spots, stainless steel cleaner/polish on a cloth is
recommended.
2. If there are stubborn spots or if you wish to treat a scratch, using synthetic abrasive general
purpose pads, such as Scotch-Brite™, are recommended.
3. Apply stainless steel cleaner/ polish to the synthetic abrasive pads and carefully rub the
panel with the grain.
4. DO NOT use harsh chemicals, abrasive or petroleum based cleaners. Use of these will
void the Murdock warranty. DO NOT use abrasives on powder coated units.
5. Stainless steel should be kept clean at all times. If a coating of stainless steel cleaner/
polish is maintained, stainless steel surfaces will retain their new, clean, polished
appearance indefinitely.
DRINKING FOUNTAIN CARTRIDGE REPLACEMENT/ STRAINER MAINTENANCE
Note: Use the universal maintenance tool to perform the following:
1. Strainer plug must be removed before cartridge replacement and strainer maintenance (no need to turn the
water off at the angle stop). Some residual water will drain during plug removal.
2. Clean strainer as needed using clean water.
3. Cartridge replacement - insert diamond end of the universal tool into pushbutton, rotate 90 degrees and pull
firmly to remove the button. Remove cartridge retaining nut . Remove and replace cartridge. When replacing
cartridge be sure to align the inlet and outlet ports on the cartridge with the ports in the valve body.
—NOTE: STRAINER SCREEN MUST BE IN PLACE FOR WATER TO FLOW.
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS
A152-BF4
Page 18 of 22
Revised: 02/02/18
7020-951-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
2
1
3
CARTRIDGE VALVE PARTS BREAKDOWN
3
7000-053-199
Jam Nut
2
7000-060-000
Flow Regulator Cartridge (0.5 GPM)
1
7000-050-001
Valve Cartridge Assembly
ITEM
PART NUMBER
DESCRIPTION

I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS
Repairs must be made with Murdock Manufacturing parts only. Please order through your local
representative or distributor. The phone number to locate your local representative is 1.800.591.9360.
8
7000-060-000
Valve Cartridge
7B
7000-099-002
Flexible Bubbler Assembly
16
7003-093-001
Flow Restrictor (Flexible Bubbler Only)
7A
7000-012-001
Stainless Steel Bubbler
15
7000-004-000
Push Pad
6
0152-010-000
Center Reject Allen Flat Head Screw
14
7000-100-199
Black Delrin Shaft
5
7000-021-001
“Y” Strainer
13
0341-100-000
Wire Clip
4
7000-005-199
Drain Adapter
12
7001-008-001
Valve Activation Assembly
3
7000-006-000
Flat Drain Adapter Gasket
11
0331-004-000
Flat Washer
2
0116-016-000
Phillips Truss Head Screw
10
0308-009-000
Nylon Insert Locknut
1
7000-005-199
Drain Adapter
9
7000-050-000
Valve Assembly
ITEM
PART NUMBER
DESCRIPTION
ITEM
PART NUMBER
DESCRIPTION
A152-BF4
Page 19 of 22
Revised: 02/02/18
7020-951-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
A152-BF4 DRINKING FOUNTAIN PARTS BREAKDOWN
1
2
3
4
5
6
15
11
14
13
8
7A
10
12
9
7B
16
NOTE:
** Flow Restrictor only available
with Low Flow Bubbler
**

Repairs must be made with Murdock Manufacturing parts only. Please order through your local
representative or distributor. The phone number to locate your local representative is 1.800.591.9360.
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS
A152-BF4
Page 20 of 22
Revised: 02/02/18
7020-951-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
A152FG-BF4 DRINKING FOUNTAIN PARTS BREAKDOWN
1
0112-002-000
Center Reject Allen Button Head Screw
7A
7000-012-001
Stainless Steel Bubbler
2
7000-015-000
1-1/4” Reject Allen Button Head Screw
7B
7000-099-002
Flexible Bubbler Assembly
3
7000-021-001
“Y” Strainer
8
7000-068-001
Retaining Ring & Button Assembly
4
7000-005-199
Drain Adapter
9
7000-069-001
Valve Cartridge with Foam Washer
5
7000-006-000
Flat Drain Adapter Gasket
10
7000-065-001
Recessed Pushbutton Valve Assembly
6
0152-010-000
Center Reject Allen Flat Head Screw
11
7003-093-001
Flow Restrictor - Low-Flow Bubbler Only
ITEM
PART NUMBER
DESCRIPTION
ITEM
PART NUMBER
DESCRIPTION
NOTE:
** Flow Restrictor only available
with Low Flow Bubbler
**
1
2
3
4
10
7B
7A
8
5
6
9
11
