Murdock A481CUSP Series Installation and operating instructions

A481400S, A481400S-CUSP, & A4804000-CUSP
1.800.591.9360
Technical Assistance Fax: [phone]
TECHNICAL ASSISTANCE TOLL FREE TELEPHONE NUMBER:
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS
NOTES TO INSTALLER:
1. Please leave this documentation with the owner of the fixture when finished.
2. Please read this entire booklet before beginning the installation.
3. Check your installation for compliance with plumbing, electrical and other applicable codes.
LIMITED WARRANTY - UNITED STATES & CANADA
Murdock warrants that its products are free from defects in material or workmanship under normal use and
service for a period of one year from date of original shipment or for 18 months after the date of shipment from the
factory, whichever comes first. Murdock’s liability under this warranty shall be discharged solely by replacement
or repair of defective material, provided Murdock is notified in writing within one year from date of shipment,
F.O.B. Industry, California.
This warranty does not cover installation or labor charges and does not apply to materials, which have been
damaged by other causes such as mishandling or improper care or abnormal use. The repair or replacement of the
defective materials shall constitute the sole remedy of the Buyer and the sole remedy of Murdock under this
warranty. Murdock shall not be liable under any circumstances for incidental, consequential or direct charges
caused by defects in the materials, or any delay in the repair or replacement thereof. This warranty is in lieu of all
other warranties expressed or implied. Product maintenance instructions are issued with each unit and disregard
or non-compliance with these instructions will constitute an abnormal use condition and void the warranty.
Stainless steel must be protected on job site during construction and must be properly maintained after the water
has been introduced into the water cooler or drinking fountain, or Mudock’s limited warranty is void.
LIMITED EXPORT WARRANTY - One year on parts only.
COMPLIES WITH
7020-005-001 Date: 03/09/16
Test rating conditions are
compliant with ARI 1010.
Federal
Public Law
111-380
(No Lead) Member of
MURDOCK
15125 Proctor Ave.
City of Industry, CA
91746 U.S.A.
Phone [phone]
626-336-4561
Fax [phone]
www.murdockmfg.com
Murdock assumes no responsibility for use of void or
suspended data. © Copyright Murdock, City of
Industry, CA Member of Morris Group International.
Please visit www.murdockmfg.com for most
current specifications.
A481CUSP Series
Fully Recessed, Fountain & Cuspidor

A481CUSP SERIES FULLY RECESSED FOUNTAIN & CUSPIDOR
ROUGHING-IN AND DIMENSIONAL DRAWING
Prior to roughing consult with local, state, and federal codes for proper mounting height.
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS
A481-CUSP
Page 2 of 9
03/09/16
7020-005-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
GENERAL NOTES:
1. ALL DIMENSIONS ARE IN INCHES [MM].
*2. DIMENSIONS SHOWN ARE FOR RECOMMENDED ADULT HEIGHT. ADJUST VERTICAL
DIMENSIONS AS NECESSARY TO COMPLY WITH FEDERAL, STATE, & LOCAL CODES.
3. STOP VALVE AND MOUNTING HARDWARE NOT PROVIDED.
13
8"
251
2"
*33"
6"
37" 2" 91
2"
12" MIN
WALL
OPENING
17" WALL
OPENING
1-1/4" OD SLIP JOINT
WASTE CONNECTION
321
4" WALL
OPENING
*25"
*281
2"
(4) Ø1
4" MOUNTING HOLES, MOUNTING
HARDWARE BY OTHERS
(4) Ø1
8" MOUNTING HOLES,
MOUNTING HARDWARE BY
OTHERS
(4) Ø1
8" MOUNTING
HOLES
*29"
43
8"
3/8" NCT
SUPPLY INLET

IMPORTANT:
1. Waste P-Trap and Water Supply Service Stop Valve to be supplied by others in accordance with
local codes.
2. Water supply inlet is 3/8” OD copper tube (Fountain) and ½” NPSM (Cuspidor). See Figure “D”.
Waste is 1-1/4” OD female slip joint connection.
3. Completely flush supply lines of all foreign debris before connecting to the fixture. Optional water
filter is available should there be problems from the water supply with taste, odor, color, or
sediment.
4. WARNING: Warranty is voided if installation is not made following current Murdock Manufacturing
Installation instructions and if components are assembled to the fixture that are not approved by
Murdock Manufacturing.
5. Fixture operates within water pressure range of 20 to 105 psig. Murdock Manufacturing will not
warranty fixtures damaged when connected to supply lines with flow pressure lower than 20 psig or
higher than 105 psig. A pressure regulator must be furnished by others on the supply line if inlet
pressure is greater than 105 psig.
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS
A481-CUSP
Page 3 of 9
03/09/16
7020-005-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of

INSTALLATION:
1. Install Mounting Brackets to the bottom and top of the Rough-In opening. WARNING: Mounting
Brackets MUST be securely anchored and centered within the opening. See Figure B.
2. Install the Air Valve Assembly roughly in position as shown in Figure B. This is supplied for the
Cuspidor unit only and the installation method will be by others.
3. Hang the Fountain and Cuspidor on the upper Mounting Bracket making sure the bracket and flange
from the Fountain and Cuspidor engage. The Fountain and Cuspidor must sit flush against the wall.
4. Locate the provided “L” brackets in relation to the Tabs from the Fountain and Cuspidor. Mark the
hole locations, remove the Fountain and Cuspidor and then mount the brackets.
5. Install the captive nuts into the “L” Brackets as shown in Figure C.
6. Re-hang the Fountain and Cuspidor assembly. Secure the Fountain and Cuspidor to the “L” brackets
using the supplied #10-32 screws and washers. The screws need to pass through the tab and into
the “L” brackets containing the captive nut. Tighten the screws to pull the Fountain and Cuspidor
flush with the wall.
7. Install water supply and drain as required per Figure A Rough-In dimensions.
8. Thoroughly flush the supply line, connect water supply to the Cuspidor.
9. Make up 1-1/4” OD P-Trap waste connection.
CAPTIVE NUT "L" BRACKET
LOWER MOUNTING
BRACKET, CENTERED
IN OPENING
MOUNTING TAB
REMOVABLE
ACCESS PANEL
CUSPIDOR
FOUNTAIN
THIS END
SEALED
TO SPRAY
NOZZLE
TO
PUSHBUTTON
½" NPSM
SUPPLY
UPPER MOUNTING
BRACKET, CENTERED
IN OPENING
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS
A481-CUSP
Page 4 of 9
03/09/16
7020-005-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of

START UP:
1. Before assembling bottom access covers to Cuspidor and Fountain, but after thoroughly flushing the
supply line and connecting it to the fixture, turn on building water supply and check all connections
for leaks.
2. Air within the Fountain and Cuspidor or the structure supply piping will cause an irregular outlet
stream until purged out by incoming water.
3. Recheck all water and drain connections with water flowing through system.
4. Install Removable Access Coves to the Fountain and Cuspidor bottom Mounting Bracket, install the
supplied #8-32 screws and washers from the bottom of the Removable Access Cover.
CLEANING & MAINTENANCE GUIDE:
1. Periodically remove access panels and clean out in-line strainer.
2. Do NOT use harsh chemicals, abrasive or petroleum based cleaners. Use of these will void the
Acorn warranty.
3. Exterior panels can be cleaned using mild household detergents or warm, soapy water. Extra care
must be used cleaning chrome plated items and mirror finished stainless steel. They can scratch
easily and should only be cleaned using a clean, soft cloth and mild soap with water or a mild glass
cleaner.
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS
A481-CUSP
Page 5 of 9
03/09/16
7020-005-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of

TROUBLE SHOOTING:
IMPORTANT: BEFORE MAKING ANY OF THE REPAIRS LISTED, MAKE SURE THE WATER
SUPPLY VALVE IS SHUT OFF.
1. Adjustments:
a. Cartridge - The flow can be adjusted using a slotted narrow blade screwdriver and turning
clockwise to increase flow and counter clockwise to decrease flow.
b. Bubbler stream - Bubbler can be rotated slightly to direct the stream backwards or forwards.
Adjust the stream to minimize splashing. Splashing may occur from bubbler stream if the unit
is not level.
2. Restricted or No Water Flow
a Ensure water supply service stop valve is fully open
b. Verify minimum 20 psig supply line flow pressure.
c. Check for twists or kinks in bubbler tubing.
d. Check water inlet strainer. Sediment from the main supply can get trapped in the screen
along with installation material such as pipe dope and flux. The screen should be cleaned and
check on a regular basis and replace if needed. NOTE: STRAINER SCREEN MUST BE IN
PLACE FOR WATER TO FLOW.
e. The cartridge valve located in the water control assembly or bubbler can also become
clogged with foreign material. The cartridge valve can only be replaced and not repaired.
f. Check flow adjustment.
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS
A481-CUSP
Page 6 of 9
03/09/16
7020-005-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of

PARTS BREAKDOWN DRAWING
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS
A481-CUSP
Page 7 of 9
03/09/16
7020-005-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
2
7
8
6
19 15
9
11
10
12
20
14
13
18
16
21
22
23
1
5
4
3
17

A481400S-CUSP PART LIST:
A481400S PART LIST:
ITEM
PART NUMBER DESCRIPTION
7000-002-001 CHROME PLATED BRASS BUBBLER
7000-099-002 FLEX BUBBLER GREY
2 7035-128-199 UPPER MOUNTING BRACKET
3 1720-010-000 REDUCING ELBOW
4 5200-151-001 SPRAY NOZZLE
5 1896-002-000 1/4" COMPRESSION NUT
6 0316-020-000 CAPTIVE NUT
7 7035-117-199 L BRACKET
8 7035-412-001 CHECK STOP & AIR VALVE ASSY
9 4926-055-001 GRID STRAINER w/ CLOSE ELL ASSY
10 0331-004-000 #10 FLAT WASHER
11 0321-011-000 #10 STAR WASHER
12 0116-006-000 #10-32 PHILLIPS SCREWS
13 7002-125-001 WELDED PUSHBUTTON AIR TROL VALVE ASSY
14 7002-125-002 PUSHBUTTON ASSY, AIR VALVE
15 7035-306-001 BRACKET, FRAME, LWR, FTN ONLY
16 7035-106-199 PANEL, LOWER, LONG
17 0279-002-000 #8-32 SOCKET CAP BUTTON HD SCREW 3/4" LG
18 0322-001-000 #8 PLATED STAR LOCK WASHER (EXTERNAL)
19 7000-415-000 SELF RETAINING J NUT
20 7000-021-001 "Y" STRAINER ASSEMBLY
21 7000-091-001 PUSHBUTTON w/ HEX ASSY
22 7000-060-000 FLOW REGULATOR CARTRIDGE (0.5 GPM)
23 7000-050-001 VALVE ASSEMBLY
1
ITEM
PART NUMBER DESCRIPTION
7000-002-001 CHROME PLATED BRASS BUBBLER
7000-099-002 FLEX BUBBLER GREY
2 7035-128-199 UPPER MOUNTING BRACKET
3 N/A N/A
4 N/A N/A
5 N/A N/A
6 0316-020-000 CAPTIVE NUT
7 7035-117-199 L BRACKET
8 N/A N/A
9 4926-055-001 GRID STRAINER w/ CLOSE ELL ASSY
10 0331-004-000 #10 FLAT WASHER
11 0321-011-000 #10 STAR WASHER
12 0116-006-000 #10-32 PHILLIPS SCREWS
13 N/A N/A
14 N/A N/A
15 7035-306-001 BRACKET, FRAME, LWR, FTN ONLY
16 7035-106-199 PANEL, LOWER, LONG
17 0279-002-000 #8-32 SOCKET CAP BUTTON HD SCREW 3/4" LG
18 0322-001-000 #8 PLATED STAR LOCK WASHER (EXTERNAL)
19 7000-415-000 SELF RETAINING J NUT
20 7000-021-001 "Y" STRAINER ASSEMBLY
21 7000-091-001 PUSHBUTTON w/ HEX ASSY
22 7000-060-000 FLOW REGULATOR CARTRIDGE (0.5 GPM)
23 7000-050-001 VALVE ASSEMBLY
1
Repairs must be made with Murdock Manufacturing parts only. Please order through your local
representative or distributor. The phone number to locate your local representative is 1.800.591.9360.
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS
A481-CUSP
Page 8 of 9
03/09/16
7020-005-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of

A4804000-CUSP PART LIST:
Repairs must be made with Murdock Manufacturing parts only. Please order through your local
representative or distributor. The phone number to locate your local representative is 1.800.591.9360.
ITEM
PART NUMBER DESCRIPTION
1 N/A N/A
2 7035-128-199 UPPER MOUNTING BRACKET
3 1720-010-000 REDUCING ELBOW
4 5200-151-001 SPRAY NOZZLE
5 1896-002-000 1/4" COMPRESSION NUT
6 0316-020-000 CAPTIVE NUT
7 7035-117-199 L BRACKET
8 7035-412-001 CHECK STOP & AIR VALVE ASSY
9 4926-055-001 GRID STRAINER w/ CLOSE ELL ASSY
10 0331-004-000 #10 FLAT WASHER
11 0321-011-000 #10 STAR WASHER
12 0116-006-000 #10-32 PHILLIPS SCREWS
13 7002-125-001 WELDED PUSHBUTTON AIR TROL VALVE ASSY
14 7002-125-002 PUSHBUTTON ASSY, AIR VALVE
15 7035-306-001 BRACKET, FRAME, LWR, FTN ONLY
16 7035-106-199 PANEL, LOWER, LONG
17 0279-002-000 #8-32 SOCKET CAP BUTTON HD SCREW 3/4" LG
18 0322-001-000 #8 PLATED STAR LOCK WASHER (EXTERNAL)
19 7000-415-000 SELF RETAINING J NUT
20 N/A N/A
21 N/A N/A
22 N/A N/A
23 N/A N/A
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS
A481-CUSP
Page 9 of 9
03/09/16
7020-005-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
