Murdock M-OBR4-GRD-FRA3 Series Installation and operating instructions

M-OBR4-GRD-FRA3 Series
OUTDOOR BI-LEVEL DRINKING FOUNTAIN
WITH RECESSED BOTTLE FILLER
TECHNICAL ASSISTANCE TOLL FREE TELEPHONE NUMBER:
1.800.591.9360
Technical Assistance Fax: [phone]
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS
Murdock warrants that its products are free from defects in material or workmanship under normal use and
service for a period of one year from date of install or for 18 months after the date of shipment from the factory,
whichever comes first. The sealed refrigeration system is warranted for five years. Murdock’s liability under this
warranty shall be discharged solely by replacement or repair of defective material, provided Murdock is notified in
writing within one year from date of shipment, F.O.B. Industry, California.
NOTES TO INSTALLER:
1. Please leave this documentation with the owner of the fixture when finished.
2. Please read this entire booklet before beginning the installation.
3. Check your installation for compliance with plumbing, electrical and other applicable codes.
LIMITED WARRANTY - UNITED STATES & CANADA
LIMITED EXPORT WARRANTY - One year on parts only.
This warranty does not cover installation or labor charges and does not apply to materials, which have been
damaged by other causes such as mishandling or improper care or abnormal use. The repair or replacement of the
defective materials shall constitute the sole remedy of the Buyer and the sole remedy of Murdock under this
warranty. Murdock shall not be liable under any circumstances for incidental, consequential or direct charges
caused by defects in the materials, or any delay in the repair or replacement thereof. This warranty is in lieu of all
other warranties expressed or implied. Product maintenance instructions are issued with each unit and disregard
or non-compliance with these instructions will constitute an abnormal use condition and void the warranty.
Stainless steel must be protected on job site during construction and must be properly maintained after the water
has been introduced into the water cooler or drinking fountain, or Murdock’s limited warranty is void.
COMPLIES WITH
Member of
MURDOCK
15125 Proctor Ave.
City of Industry, CA
91746 U.S.A.
Phone [phone]
626-336-4561
Fax [phone]
www.murdockmfg.com
Murdock assumes no responsibility for use of void or
suspended data. © Copyright Murdock, City of
Industry, CA Member of Morris Group International.
Please visit www.murdockmfg.com for most
current specifications.
7020-953-001 Rev: 09/01/17
Federal
Public Law
111-380
(No Lead)
Test rating conditions are
compliant with ARI 1010.

Prior to roughing in, consult with local, state, and federal codes for proper mounting height.
IMPORTANT
DIMENSIONAL DRAWING
NOTICE
M-OBR4-GRD Recessed Outdoor Bottle Filler with Bi-Level Drinking Fountain
A dielectric coupling must be used to connect the drinking fountain to the water supply . A nonmetallic coupler is
furnished with this water cooler to meet this requirement.
This fixture is intended to dispense water that has been lowered in temperature, but otherwise remains
unchanged by the materials in the drinking fountain.
NOTES: Dimensions shown for Adult ADA compliant installation. For Child ADA compliant parallel approach installation,
decrease height of installation by 3 inches. Provide clear floor space as required. Adjust vertical dimensions as required to
comply with federal, state, and local codes.
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS
M-OBR4-GRD-FRA3
Page 2 of 15
Revised: 09/01/17
7020-953-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
8"
[203]
18"
[457]
203
4"
[527]
125
8"
[320]
131
4"
[337]
8"
[203]
13"
[330]
19" [483]
43
4"
[121]
Shown with
2x6 Stud Wall
*243
4"
[629]
General Notes:
1. All dimensions are in inches [mm]
*2. Dimensions shown are for recommended adult height.
Adjust vertical dimensions as necessary to comply with
federal, state & local codes
3. Stop valve not provided

IMPORTANT:
2. Waste is 1-1/4” Outer Diameter. Drinking Fountain water inlet is 1/4” outer diameter Push-In Fitting. Bottle
Filler water inlet is 1/4” Outer Diameter Push-In Fitting. Water line by others.
3. Completely flush supply lines of all foreign debris before connecting to fixture. Optional Water Filter (WF1), is
available should any of these problems arise from the water supply.
4. Do NOT solder tubes inserted into the chiller, bottle filler or the fountain strainer as damage to the o-rings on
the push-in fittings may result.
6. WARNING: Warranty is voided if installation is not made following current Murdock Mfg. installation
instructions and if components are assembled to the fixture that are not approved by Murdock Mfg.
7. Fixture operates within water pressure range of 25 PSIG (174 kPa) to 105 PSIG (724 kPa). Murdock Mfg. will
not warranty chiller damaged when connected to supply lines with flow pressure lower than 25 PSIG (174
kPa) or higher than 105 PSIG (724 kPa). A pressure regulator must be furnished by others on supply line if
inlet pressure is greater than 105 PSIG (724 kPa).
1. Water Supply Service Stop Valve, and Water Connections to be supplied by others in accordance with local
codes.
PRIOR TO INSTALLATION:
5. All burrs must be removed from outside of cut tubes before inserting into strainer or other components.
1. Read all installation instructions carefully, before proceeding.
2. Carefully remove all fixture components from packaging, preventing scratching or damage. Inspect fixture and
all parts from damages and all parts that are bolted on.
8. Per UPC 609.10-All building water supply systems in which quick acting valves are installed shall be
provided with devices to absorb the hammer caused by high pressure resulting from the quick closing of the
valve. These pressure-absorbing devices shall be approved mechanical devices. Water pressure-absorbing
devices shall be installed as close as possible to the quick closing valve
3. Provide mounting surface, adequate to support the fixture and loads on the fixture.
5. Completely flush water supply lines of all foreign debris, before connecting to the fixture.
4. Provide rough-ins as shown on the roughing-in and dimensional drawing, including water supply, drain pipe
and gravel drain well. (See rough-in details)
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS
M-OBR4-GRD-FRA3
Page 3 of 15
Revised: 09/01/17
7020-953-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of

I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS
M-OBR4-GRD-FRA3
Page 4 of 15
Revised: 09/01/17
7020-953-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
Frame Installation
NOTES: Dimensions shown for Adult ADA compliant installation. For Child ADA compliant parallel approach installation,
decrease height of installation by 3 inches. Provide clear floor space as required. Adjust vertical dimensions as required to
comply with federal, state, and local codes.
1-1/4" O.D. Drinking Fountain Waste
1-1/4" O.D. Bottle Filler/Drinking Fountain Waste
1
2
1Provide wall opening as indicated in rough-in detail provided, ensuring to block out and provide
structural support to allow frames to be anchored with installer provided anchoring hardware for Ø1/4"
anchoring holes provided.
281
2"
36"
16"
Stud Frame
Wall Spacing
321
8"
41
2"
121
2"
16"
Ø1"
19" 81
2"1
2"
31
2" 16"
2"
5
8"
4"
1
4"
3
3
41
2"
2
57
8"
1
21"
143
8"
1/4" O.D. Drinking Fountain Supply Inlet
3
1/4" Anchoring Hardware, by others
5/16" Threaded Studs
5
6
2x6 Stud Wall, for reference only
7
5
6
7
7
Mounting Holes
4
4
17
8"
53
8"
GFCI Electrical Service Protected Circuit
8
8
for -SO Sensor Operated units
26 3
4"
A.F.F.
113
16"

I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS
M-OBR4-GRD-FRA3
Page 5 of 15
Revised: 09/01/17
7020-953-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
Frame Installation (Continued)
Mounting Panel
2x6 Stud Frame
Finish Wall, Ref. only
1
2
3
2Remove Mounting Plate, Bottle Filler Frame, Bottle Filler Panel and #10-32 x
1/4" screws from packaging careful to avoid damage to fixtures and fixture sub
assemblies
5
Anchoring Hardware,
4
4
1
2
3
Finished
Floor
36"
263
4"
1
281
2"
3Locate Mounting Panel within stud frame with back side of panel mounted flush
to wall. Position shelf into place aligning mounting holes to center of wall studs
and fix plate to wall using appropriate, installer provided anchoring hardware.
provided by others
2
3
4
Bottle Filler Panel
Mounting Plate
Waste Outlet, Ref. only
1
2
3
Bottle Filler Frame
4
(Plumbing may vary)
(4) #10-32 x 1/4" Phillps
5
Head Screws

I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS
M-OBR4-GRD-FRA3
Page 6 of 15
Revised: 09/01/17
7020-953-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
Bottle Filler Installation:
Finished Wall
1
1Position Bottle Filler Frame in the center of the Mounting Panel
opening and secure with #10-32 x 1/4" Phillips Head Screws.
2Position Bottle Filler Panel and center to Mounting Plate and
secure with #10-32 x 1/2" Stainless Steel Flat Head Center
Reject Hex Screw.
3With Bottle Filler Panel installed, to open Bottle Filler,
remove #10-32 x 3/4" Flat Head Center Reject Screws and
swing open Bottle Filler.
Mounting Plate
2
Bottle Filler Frame
3
10-32 x 1/4" Screws
4
1
2
3
2
43
1
23
4
3
Finished Wall
1
Mounting Plate
2
Bottle Filler Panel
3
10-32 x 1/2" Screws
4
Bottle Filler Panel
1
Bottle Filler
2
#10-32 x 3/4" Screws
3
1
2
32
1
2

I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS
M-OBR4-GRD-FRA3
Page 7 of 15
Revised: 09/01/17
7020-953-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
Drinking Fountain Installation
Finished Wall1
1Install the drinking fountain threaded studs through the Bottle
Filler Panel and into the Mounting Plate so that a minimum of
1-1/4" of thread projects beyond Bottle Filler Panel .
3Align threaded studs with drinking fountain mounting
openings and slide fixtures to panel and secure with nuts
and washers.
2Remove the Drinking Fountain bottom Access Panel by
removing the Access Panel Vandal Resistant Screws. Be
sure to safeguard drain Access Panel screws.
Bottle Filler Panel2
5/16"-18 Threaded Studs
3
1
3
2
Drinking Fountain
1
Bottom Access Panel2
#10-32 x 3/8" Screws
3
Finished Wall
1
5/16"-18 Threaded Studs
2
Drinking Fountain Housing
3
1
3
2
2
3
5/16"-18 Hex Nut4
5/16"-18 Zinc Plated Washer
5
1
33
2
5
4

I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS
M-OBR4-GRD-FRA3
Page 8 of 15
Revised: 09/01/17
7020-953-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
Waste Plumbing Installation
Flush Valve Inlet Elbows
1
1Remove Flush Valve Inlet Elbows, 1-1/4" Tee Assembly with
compression, 1-1/4" x 4" Brass Tubing, 1-1/4" x 17" Drain
Tube and 1-1/4" x 8" Brass Tubing from packaging.
3Install Flush Valve Inlet Elbows to Drinking Fountain
Tailpiece Outlets. Make-up plumbing as shown.
2Cut Bottle Filler Waste Outlet Tailpiece and install Flush
Valve Inlet Elbow and 1-1/4" x 4" Brass Tubing.
1-1/4" x 17" Drain Tube
2
1-1/4" x 8" Brass Tubing
3
Bottle Filler Tailpiece Waste Outlet
1
Flush Valve Inlet Elbow
2
1-1/4" x 4" Brass Tubing
3
Flush Valve Inlet Elbow
1
1-1/4" x 17" Drain Tube
2
1-1/4" Tee Assembly with Compression
3
1-1/4" x 8" Brass tubing
4
1-1/4" x 4" Brass Tubing
5
1
23
4
5
1-1/4" x 4" Brass Tubing
4
1-1/4" Tee Assembly with Compression
5
Back View Side View
51
8"
19"
15"
2°
71
4"
Back View Side View
1
2
51
8"
3
Drinking Fountain Tailpiece Waste Outlet
6
16
4
4
3
2
5

I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS
M-OBR4-GRD-FRA3
Page 9 of 15
Revised: 09/01/17
7020-953-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
Freeze Resistant Valve System (-FRA3) Installation
1
2
3
1Remove 1-Station and 2-Station Freeze Resistant Valve Box Assembly from
packaging careful to avoid damage to fixtures and fixture sub assemblies.
4
2Assembly Drinking Fountains and Bottle Filler Waste outlet thru wall to
Fixture close elbow. Anchor Valve and Waste box on Interior Wall by
aligning Freeze Resistant box elbow with fixture waste outlets. All wall
Anchors and Anchoring Hardware are provided by the installer. Make-up
waste connections to FP box 1-1/2" IPS P-Trap Waste Outlet.
Ø2"
21
2"
22"
Ø3
8"
11
2"
91
2"
Ø2"
Ø1"
3
4"
31
2"
11
2"
71
2"
21
2"
4"
81
4"
51
2"
2"
Ø2"
Ø1"
11
2"
Ø3
8"
18"
7"
Ø1"
1
Drinking Fountain and
Bottle Filler thru Wall
Waste Outlets.
1-Station Freeze
Resistant Valve Box
2-Station Freeze
Resistant Valve box
1-1/2" IPS P-Trap
Waste Outlet
Freeze Resistant
Close Elbow
5
11-Station Freeze
Resistant Valve Box
22-Station Freeze
Resistant Valve Box
2x6 Wall Stud
6

I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS
M-OBR4-GRD-FRA3
Page 10 of 25
Revised: 09/01/17
7020-953-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
Supply Connections
1
2
1Connect supply and air Tubing from Valve thru box opening to fixtures
Bubblers, Bottle Filler Spout and Pushbuttons. All tubing and wiring to Bottle
filler must enter on hinge side of door. Install Y-Strainers to each Supply
Line.
3
Flush water supply line of all debris prior to connecting to valve. Connect
supply line to valve 1/2" NPS hose end valve inlet connection. Installer will
determine Supply line installation.
1-Station Freeze
Resistant Valve Box
2-Station Freeze
Resistant Valve box
1/2" NPS hose
11-Station Freeze
Resistant Valve Box
22-Station Freeze
Resistant Valve Box
2
3Drinking Fountain
Bubbler
4Pushbuttons
51/8" OD low density
PE Tubing
61/4" OD low density
PE Tubing
Bottle Filler
Front View 7Shut-Off Valve
82x6 Wall Studs
42x6 Wall Stud
91/4" Y-Strainer

I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS
M-OBR4-GRD-FRA3
Page 11 of 15
Revised: 09/01/17
7020-953-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
Fixture Final Step Installation
Finished Wall
Drinking Fountain Access Panel
1
2
1With fixture tested and operating to customer's specifications, re-mount the Drinking Fountain Access
Panels with #10-32 x 3/8" screws and the Freeze Resistant Valve Box Access Panels with #10-32 x
3/4" Phillips Head Round Screws.
Freeze Resistant Valve Box
3
10-32 x 3/8" Hex Head Center Reject Screw
10-32 x 3/4" Phillips Round Head Screw
4
5
Freeze Resistant Valve Box Access Panel
6
2
4
1
2
4
3
5
66
5

2. Excess dirt or poor ventilation will cause the compressor overload protector to turn the compressor off and it
will cycle on and off with no cold water coming out of bubbler. Periodically clean with vacuum cleaner, air
hose or brush the condenser fins and cabinet ventilation louvers. In environments where dirt and dust is
more prevalent, clean more frequently.
For Powder coated units: Units should be cleaned using a mild soap solution with a sponge or cotton cloth.
Wipe down surfaces then rinse with clean water.
3. Apply stainless steel cleaner/ polish to the synthetic abrasive pads and carefully rub the
panel with the grain.
CLEANING & MAINTENANCE GUIDE:
For Stainless steel units:
5. Stainless steel should be kept clean at all times. If a coating of stainless steel cleaner/
polish is maintained, stainless steel surfaces will retain their new, clean, polished
appearance indefinitely.
3. Periodically remove fountain top and clean out in-line strainer.
1. To Remove water spots or rust spots, stainless steel cleaner/polish on a cloth is
recommended.
2. If there are stubborn spots or if you wish to treat a scratch, using synthetic abrasive general
purpose pads, such as Scotch-Brite™, are recommended.
1. Motors have lifetime lubrication and do not require scheduled maintenance.
4. Periodically remove access panel of cooler and clean out inline “Y’’ strainer
4. DO NOT use harsh chemicals, abrasive or petroleum based cleaners. Use of these will
void the Murdock warranty. DO NOT use abrasives on powder coated units.
TROUBLE SHOOTING:
1. ADJUSTMENTS:
a. Cartridge – The water flow can be adjusted using a slotted narrow blade screwdriver and turning
clockwise to increase flow and counterclockwise to decrease flow.
a. Open fixture. Loosen nuts holding valve bracket assembly to bottom of fixture but, do not remove. Move
complete valve bracket assembly further back from the front push pad and tighten to lock in place.
b. Replace valve cartridge.
e. The cartridge valve located in the water control assembly or bubbler can also become clogged with
foreign material. The cartridge valve can only be replaced and not repaired.
a. Ensure water supply service stop valve is fully open.
c. Bubbler Stream - Bubbler can be rotated slightly to direct the stream backwards or forwards. Adjust the
stream to minimize splashing. Splashing may occur from bubbler stream if the unit is not level. Shim lower
mounting point, if necessary, to level chiller.
f. Check flow adjustment. See start up note #3.
WATER SUPPLY VALVE IS SHUT OFF.
g. Flow control in solenoid valve outlet elbow clogged remove & clean.
2. RESTRICTED OR NO WATER FLOW:
WATER CHILLER IS DISCONNECTED FROM THE ELECTRICAL SUPPLY AND THE
b. Cold Water Thermostat – The water temperature can be adjusted using a slotted screwdriver and turning
clockwise to make colder and counterclockwise to make warmer.
IMPORTANT: BEFORE MAKING ANY OF THE REPAIRS LISTED, MAKE SURE THE
c. Check for twists or kinks in outlet tubing.
d. Check the water inlet “Y” strainer. Sediment from the main supply can get trapped in the screen along
with installation materials such as pipe dope and flux. The screen should be cleaned and checked on a
regular basis and replace if needed.
b. Verify minimum 20 psig supply line flow pressure.
3. WATER DRIPS OR WILL NOT SHUT OFF:
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS
M-OBR4-GRD-FRA3
Page 12 of 15
Revised: 09/01/17
7020-953-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of

FREEZE RESISTANT ROUND OUTDOOR MOUNTED FOUNTAIN PARTS BREAKDOWN
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS
M-OBR4-GRD-FRA3
Page 13 of 15
Revised: 09/01/17
7020-953-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
Repairs must be made with Murdock Manufacturing parts only. Please order through your local
representative or distributor. The phone number to locate your local representative is 1.800.591.9360.
ITEM # PART NUMBER DESCRIPTION ITEM # PART NUMBER DESCRIPTION
1 7002-125-001 Pushbutton Valve Assy., Freeze Resist 6 7000-006-000 Flat Drain Adapter Gasket
2 2566-001-000 Diaphragm 7 0401-128-000 O-Ring
3 7002-125-002 Pushbutton Cap Assembly 8 7000-017-001 Elbow Assembly
4A 7000-002-001 Standard Chrome Plated Brass Bubbler 9 7000-112-199 1-1/4" OD x 20" Lg Drain Tube
4B 7000-410-002 "F" option Flexible Bubbler Assembly 10 0112-002-000 Center Reject Allen Button Head Screw
5 0152-010-000 Center Reject Allen Flat Head Screw 11 0296-025-199 Center Reject Hex Driver Bit
11
10
8
7
2
1
3
9
4B
4A
6
5

M-OBR4-GRD-FRA3 SERIES BREAKDOWN
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS
M-OBR4-GRD-FRA3
Page 14 of 15
Revised: 09/01/17
7020-953-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
Repairs must be made with Murdock Manufacturing parts only. Please order through your local
representative or distributor. The phone number to locate your local representative is 1.800.591.9360.
1
14
15
17
18
19
20 21
25
22
24
4
3
2
4
6
7
9
5
11
12
13
10
26
27
31
30
29
28
8
16
23
32
28
28
33
34
35

A132.8-BF4 SERIES BREAKDOWN
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS
M-OBR4-GRD-FRA3
Page 15 of 15
Revised: 09/01/17
7020-953-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
Repairs must be made with Murdock Manufacturing parts only. Please order through your local
representative or distributor. The phone number to locate your local representative is 1.800.591.9360.
ITEM # PART NUMBER DESCRIPTION
1 JSMBF501-001 MOUNTING PLATE FOR M-OBR4-GRD
2 JSMBF505-001 COVER PLATE FOR M-OBR4-GRD BOTTLE
3 0152-002-000 #10-32 x 1/2" S/S HEX FLHD C/R SCREW
4 DRINKING FOUNTAIN SEE DRINKING FOUNTAIN BREAKDOWN, PG 13
5 JSMBF452-001 DOOR ASSY, M-OBR4-MO
6 0302-005-000 1/4-20 UNC STN. STL. HEX NUT
7 JSMBF480-199 ALCOVE SCREEN PLATE FOR M-OBR4
8 JSMBF479-199 BTM SCREEN FOR M-OBR4 BOTTLE
9 7002-125-002 FREEZE-RESIS. PUSHBUTTON WELD ASSY.
10 0152-006-000 #10-32 X 3/4" S/S HEX FLAT HD C/R SCREW
11 1895-450-000 1/8" O.D. NYLON COMPRESSION NUT
12 2566-056-199 DIAPHRAGM RETAINER, BACK OUTLET
13 2566-001-000 AIR DIAPHRAGM
14 2566-022-000 ESCUTCHEON RETAINER
15 JSMBF462-199 BOX FOR M-OBR4 BOTTLE FILLER
16 0116-004-000 #10-32 X 1/4" S/S PHIL RD HD SCREW
17 7003-180-000 ACCESS DRAIN, SINGLE LEVEL
18 7000-006-000 DRAIN ADAPTER GASKET
19 JSMBF483-002 DRAIN TRAY FOR M-OBR4 BOTTLE
20 0112-011-000 #10-32 x 3/8" BTN HD ALN NO/CTR REJ SCR
21 0124-055-000 #8X3/4 PHILLIPS ROUND HEAD SS SM SCREW
22 0713-000-000 NYLON TWIST TIE, 3/8" MAX BUNDLE DIA
23 7000-420-000 1/4 TURN SHUTOFF VALVE
24 2169-015-199 1/4" OD LLDPE TUBING, BLUE X 15"
25 1895-709-000 ELBOW, 1/4" PUSH-IN X 1/4" STEM
26 7002-033-199 1-1/4 X 0.65 WALL BRS TUBING X 8"
27 7002-026-001 1-1/4" TEE ASSY WITH COMPRESSION
28 7002-043-199 1-1/4 X 0.65 WALL BRS TUBING X 4"
29 7000-114-199 1 1/4" OD X 17" LG DRAIN TUBE
30 2950-024-000 SLOAN FLUSH VALVE INLET ELBOW
31 0431-125-000 NYLON COMPRESSION WASHER FOR 1-1/2 COMPR
32 2950-025-000 SLOAN F.V. COUPLING NUT & GASKET
33 4872-000-001 1-STN FREZ-RESIS VALVE BOX ASSY NO LEAD
34 4872-020-001 2-STN FREZ-RESIS VALVE BOX ASSY NO LEAD
35 4102-777-001 Y STRAINER ASSEMBLY, 1/4" NPT
