Rain Bird PGA Manual

PGA阀
安装和操作说明
故障排除指南

1
INSTALLATION & OPERATING INSTRUCTIONS
1. Flush main line thoroughly before installing valves.
2. Install valve onto main line. Ensure inlet side is connected
to main line and outlet side is connected to lateral line. Note
arrow on valve indicating direction of water flow. Solenoid
should be on the downstream side of the valve.
3. NOTE: Valve is configured for globe installation. For angle
installation, remove inlet plug then thread into globe inlet.
We recommend using a closed end wrench to avoid strip-
ping any molded parts.
4. Use two wraps “Teflon Tape” along the full length of the inlet
and outlet pipe threads. Do not use pipe thread or pipe
dope compound. Thread inlet pipe and fitting into the inlet
port of the valve and hand tighten. Thread outlet pipe and
fitting into the outlet port of the valve and hand tighten. Do
not exceed two turns beyond hand tight.
5. Connect one solenoid wire to the controller common wire
and the other to the controller power wire. Use only water-
tight wire connectors, like RAIN BIRD ST-03.
6. After installing valves, slowly open water supply at point of
connection. Valves may discharge water momentarily, then
shut off.
7. To activate the valve using the internal manual bleed fea-
ture, turn the solenoid handle counter clockwise 1⁄4to 3⁄4turn
or until you hear water flowing through the valve. To close
valve, turn the solenoid handle clockwise 1⁄4to 3⁄4turn and
wait a moment for the valve to close. Only hand tighten the
solenoid to close the valve.
8. For automatic valve operation, turn on the controller that
has been wired to the valve according to the controller oper-
ating instructions, as controllers operate differently.
9. Use the flow control handle to adjust the amount of water
flowing through the valve. Counter clockwise turns increase

flow; clockwise turns decrease flow. Close the valve before
making large flow adjustments, then activate the valve to
fine tune flow adjustments. Good adjustment practice,
when not intentionally trying to limit the flow, is to turn the
flow control stem (from the full up position) clockwise until
resistance is felt on the flow control stem handle.
10. If necessary, install Rain Bird’s pressure regulating module
PRS-B according to the installation manual.
2
Internal Bleed
Handle
Controller Wires
Flow Control
Handle
Inlet
(Globe)
Inlet
(Angle)
Outlet
PRS-B Module
Accessory

TROUBLESHOOTING GUIDE
1. Sprinkler heads emit water when valve is turned off.
Dirt or debris is lodged on the diaphragm seat.
Remove bonnet and diaphragm to dislodge debris.
Solenoid is not fully closed after manual operation.
Turn solenoid handle clockwise to fully seated position.
Solenoid o-ring is damaged or twisted.
Turn off the water supply and turn the solenoid counter-clock-
wise to remove and inspect the o-ring. Remove any debris,
then reset or replace the o-ring as necessary.
Diaphragm is damaged or not properly aligned.
Turn off the water supply and remove the bonnet. Check align-
ment of the diaphragm with the valve body and positioning tabs.
Inspect the diaphragm for nicks or damage, then realign or
replace diaphragm as necessary.
Dirt is interfering with proper solenoid operation.
Turn off the water supply and turn the solenoid counter-clock-
wise to remove and flush solenoid seating bowl in bonnet with
clean water. Rinse solenoid bottom in clean water. For internal
cleaning, remove the white retainer using a small flat screw-
driver. Remove the plunger and screen and rinse with clean
water. Return plunger, spring and retainer to solenoid. Return
solenoid to bonnet by turning the solenoid clockwise.
Solenoid is shorted or damaged.
Turn off water supply and turn the solenoid counter-clockwise to
remove. Replace with new solenoid by turning clockwise.
3

4
2. Water will not shut off.
Controller may be operating the valve automatically.
Check controller to confirm it is turned off.
Valve is set in the manual “ON” position.
Use finger-tight pressure to turn the solenoid clockwise to the
“OFF” position. CAUTION: Over-tightening risks the possibility
of damaging the solenoid seat. Re-tighten bleed screw on top
of valve if leakage is observed. Verify that the o-ring is not dam-
aged.
Diaphragm filter screen is blocked.
Turn off the water supply and remove the bonnet. Inspect the
diaphragm filter screen located on the bottom of the diaphragm.
Remove debris, rinse screen in clean water and return
diaphragm and bonnet to valve body.
Solenoid is shorted or damaged.
Turn off water supply and turn the solenoid counter-clockwise to
remove. Replace with new solenoid by turning clockwise.
3. Low or inadequate flow condition.
Flow control stem is turned down.
Adjust flow control stem by turning counter-clockwise in order to
allow the diaphragm to open further.
Water pressure is being used elsewhere on the site.
Check the water requirements of all areas using the same water
supply.

Too many sprinklers are operating at one time.
Check to see that the controller is only running one valve at one
time. The system hydraulics may only be capable of single
valve operation. If you find that all the sprinklers are located on
one circuit, an additional valve may be required to better meet
maximum hydraulic flow rates.
System gate or master valve is not fully open.
Locate the gate or master valve and open.
Obstruction in the mainline pipe.
Isolate obstruction and remove.
4. Valve will not turn on electrically.
Controller not supplying power to valve.
Check the controller for output power to the valve. If no power
is detected at controller, then service controller. Check power
input at the solenoid of the valve. If output is detected at the
controller, but no input is detected at the solenoid, then a power
wire is broken or damaged. Isolate and repair.
Main water supply is turned off.
Locate main gate or master valve and open.
Solenoid problem.
If power input is detected at solenoid, but valve still is not oper-
ating, then turn off the water supply. Without cutting wires,
swap solenoids with the next valve (if present). If other solenoid
operates valve, replace solenoid. If other solenoid does not
operate valve, continue troubleshooting.
5

Flow control stem is turned all the way down.
Adjust the flow control stem by turning it counter-clockwise until
water flows through the valve, but do not leave the stem in a full
up position. While water is flowing through the valve, turn the
flow control stem (from the full up position) clockwise until resis-
tance is felt on the flow control stem handle. Then turn the flow
control stem handle counter-clockwise one turn, as the valve
will operate more effectively with the flow control stem handle in
this position.
5. Valve with PRS-B Pressure Regulating Module.
Consult the PRS-B instruction manual for additional trou-
bleshooting information.
For further assistance, please call the Rain Bird Spec Hotline at
1-800-458-3005.
