HDMI 2.0 Fiber
Extender Kit
Installation Guide
500464-V2

HDMI 2.0 Fiber Extender Kit Installation Guide
© MuxLab Inc. 2020 2
SAFETY PRECAUTIONS
To insure the best from the product, please read all instructions carefully before using
the device. Save this manual for further reference.
⚫Follow basic safety precautions to reduce the risk of fire, electrical shock and injury
to persons.
⚫Do not dismantle the housing or modify the module. It may result in electrical shock
or may burn.
⚫To prevent fire or shock hazard, do not expose the unit to rain, moisture or install this
product near water. Keep the product away from liquids.
⚫Spillage into the housing may result in fire, electrical shock, or equipment damage. If
an object or liquid falls or spills on to the housing, unplug the module immediately.
⚫Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to
the device before cleaning.
⚫Using supplies or parts not meeting the product’s specifications may cause damage,
deterioration or malfunction.
⚫Refer all servicing to qualified service personnel.
⚫Install the device in a place with good ventilation to avoid damage caused by
overheating.
⚫Unplug the power cord when left unused for a long period of time.
⚫Do not put any heavy items on the unit.
⚫Do not remove the housing of the device as you may be exposed to dangerous
voltage or other hazards.
⚫Do not twist or pull with force ends of the optical cable attached to the unit, as it may
cause damage.
⚫Information on disposal of devices: do not burn or mix with general household waste,
please treat this device as normal electrical wastes.
⚫Unpack the equipment carefully and save the original box and packing material for
possible future shipment
NOTICE:
•Please read this user manual carefully before using the product.

HDMI 2.0 Fiber Extender Kit Installation Guide
© MuxLab Inc. 2020 3
Contents
1. Introduction .................................................................................................................4
1.1 Introduction to the 500464-V2 ...........................................................................4
1.2 Features ............................................................................................................4
1.3 Package Contents .............................................................................................4
2. Specifications..............................................................................................................5
3. System Requirement for Installation ...........................................................................5
3.1 Hardware requirements .....................................................................................5
3.2 Software requirements ......................................................................................6
3.3 AC/DC Power Adapter (Technical Advisory) ......................................................6
4. System Connection.....................................................................................................6
4.1 Safety Precautions ............................................................................................6
4.2 System Diagram ................................................................................................6
4.3 Connection Procedure.......................................................................................7
5. Troubleshooting & Maintenance .................................................................................9
Maintenance..........................................................................................................10
Technical Support and Service ..............................................................................10
Certification of Eye Safety .....................................................................................10
Regulatory Compliance ................................................................................................11

HDMI 2.0 Fiber Extender Kit Installation Guide
© MuxLab Inc. 2020 4
1. Introduction
1.1 Introduction to the 500464-V2
The HDMI 2.0 Fiber Extender Kit, 500464-V2 enables the user to transmit 4K
(4096x2160) video at 60Hz signal up to 3300ft (1000m) with OM4 multimode fiber, with
any form of scaling or data compression being applied to the signal. This device
supports a total data throughput of 18Gbps (6Gbps per lane).
The unit supports one (1) SC connector and may be connected with OM3 or OM4
multi-mode fiber between the Transmitter and Receiver, providing a clean, secure and
easy installation with ideal electrical isolation, and immune to electrical hazard and
interference. Maximum distance will be achieved with OM4 fiber. The 500464-V2
Transmitter may be powered via USB power (with the included power supply), or from
the 5V supplied from pin #18 of the HDMI connector of the source side only. Note that if
the source does not adequately supply this power on its HDMI connector, then the
included power supply must be used. This kits includes two (2) 1m HDMI 2.0 Premium
Certified Cables to connect to source and sink devices.
1.2 Features
•Supports the HDMI 2.0 standard
•Up to 3300ft (1000m) over 50/125m multi-mode fiber at 4K (4096x2160)
resolution, @ 60Hz refresh rate
•Bandwidth of 18Gbps, supporting up to 4K (4096X2160) @ 60Hz
•Supports CEC, ARC, EDID and HDCP 1.4 & 2.2
•Supports HDR formats, including HDR10+, Dolby Vision, and HLG
•Includes two (2) 1m HDMI 2.0 Premium Certified Cables
•Compact enclosure for tight spaces
1.3 Package Contents
•One (1) HDMI 2.0 Fiber Transmitter
•One (1) HDMI 2.0 Fiber Receiver
•Two (2) Power Supplies, 5VDC @ 1A with interchangeable US, UK & Euro
Blades
•Two (2) 1m HDMI 2.0 Premium Certified Cables
•Two (2) USB type A to micro USB cables
•One (1) User Manual (available via download from the MuxLab website)
Notes：Confirm that the product and accessories are all included, if not please contact
your dealer.

HDMI 2.0 Fiber Extender Kit Installation Guide
© MuxLab Inc. 2020 5
2. Specifications
Environment
HDMI 2.0
Devices
Plasma, projectors, monitors, Television, PC, laptops, and servers
supporting HDMI.
Transmission
Transparent to the user
Video Bandwidth
18 Gbps (6 Gbps per lane)
Video Resolution
Up to 4096x2160 @ 60Hz
Signals
HDMI 2.0
Connectors per unit
One (1) HDMI Female Connector
One (1) SC Optical Connector
One (1) Micro USB connector for external power
Maximum Distance
3300ft (1000 m) over 50/125m multi-mode OM4 fiber.
(OM3 fiber may also be used, but with slightly less distance)
Cable
•Includes two (2) 1m HDMI 2.0 Premium Certified Cables
•Requires one (1) SC multi-mode fiber, having a 50/125m core
for the link connection (fiber cable not included)
Power Supply
Two (2) 110-240V to 5VDC, 1A power supply with interchangeable
blades for US, UK & Euro
Temperature
Operating: 0° to 50°C Storage: -30° to 70°C
Humidity: Up to 85% non-condensing
Enclosure
Plastic
Dimensions
2.49” x 1.37” x 0.57” (63 x 35 x 15 mm)
Weight
0.70 lbs (0.32 kg)
Compliance
Regulatory: FCC, CE, RoHS
Safety
Optical Fiber Communication System Class 1 Eye Safety per IEC
60825-1
Warranty
2 years
Order Information
500464-V2 HDMI 2.0 Fiber Extender Kit
3. System Requirement for Installation
3.1 Hardware requirements
1) A HDMI source and display is required, supporting the graphic resolution of the

HDMI 2.0 Fiber Extender Kit Installation Guide
© MuxLab Inc. 2020 6
HDMI 2.0 Fiber Extender Kit.
2) No special requirements for memory size, CPU speed and chipsets are needed,
assuming the HDMI graphic controllers/cards have already been properly installed.
3.2 Software requirements
No special restrictions, considering that the HDMI graphic controller and OS have
already been properly installed.
3.3 AC/DC Power Adapter (Technical Advisory)
The included power supply adaptors and USB cables can provide power to both the
Transmitter and Receiver. Although the HDMI interface of the source typically provides
5VDC on pin #18 of the HDMI connector, the USB power supply option is recommended
as a more stable power source for the Transmitter.
4. System Connection
4.1 Safety Precautions
This system should be installed in a clean environment with temperature and
humidity within the specified operating levels (see the specifications table).
4.2 System Diagram

HDMI 2.0 Fiber Extender Kit Installation Guide
© MuxLab Inc. 2020 7
4.3 Connection Procedure
a) Connect the Transmitter to the source equipment (such as a Blu-Ray Player), and
connect the Receiver to the sink equipment (such as a display). Use the two (2)
included 1m HDMI 2.0 Premium Certified cables to connect the Transmitter and
Receiver to source devices and Displays, respectively. Connect the USB Power
Supply to the Receiver. Power on the HDMI source and display. The Transmitter
will be turned on due to the 5V supplied by pin #18 of HDMI interface of the source.
Even though the units are being powered, it is recommended that the USB Power
Supply be used as well for a more stable power source for the Transmitter, since
some sources may not be capable of providing sufficient power.
b) The Power LED will illuminate when the 500464-V2 is connected to the HDMI
interface of the source and display via the included HDMI cables.
c) Connect an SC terminated multimode optical fiber between the Transmitter and
Receiver. Ensure the connectors are fully inserted.
d) The LED changes colors depending on the unit status. The table below describes
the colors and their meaning.
LED Color Status Indicators
LED Color
Link Status
OFF
Extender end has no power.
Red
Extender detects an open fiber connection and has disabled
the lasers.
Yellow
Fiber link detected, but HDMI initialization failed.
White
Video active, without HDCP encryption.
Green
Video active, with HDCP 1.x encryption.
Blue
Video active, with HDCP 2.x encryption.
Purple
Fiber connection is open and lasers have been disabled.
Bootloader connected for firmware upgrade.
Note: The status LED will turn OFF after 2 minutes of no status change, however
the LED will re-illuminate when the status changes.

HDMI 2.0 Fiber Extender Kit Installation Guide
© MuxLab Inc. 2020 8
Note1: DO NOT look directly into the SC receptacles of the Transmitter, while it is
powered on, even though this product is strictly regulated to operate under
LASER Class I, classified by CDRH/FDA for eye safety.
Note2: Units support an extension distance up to 1000m using OM4 multimode fiber.
OM3 fiber may also be used, but your distance may be slightly reduced.
Note3: Use the included 1m HDMI 2.0 Premium Certified cables to connect these
devices to the end equipment (such as Blu-ray Players, Media Players, etc.,
and TVs).
a) Connect the Transmitter to the HDMI connector of the source using the
included 1m HDMI 2.0 Premium Certified cable.
b) Connect the Receiver to the HDMI connector of the display using the
included 1m HDMI 2.0 Premium Certified cable.
c) These units should be connected together with a single length of multimode
fiber cable (sold separately) meeting the spec herein, while ensuring that
the optical SC connector end-faces are clean.
d) To ensure proper connectivity, confirm that the LEDs on both the
Transmitter and Receiver are indicating proper operation, see the LED
Color Status Indicator table above.

HDMI 2.0 Fiber Extender Kit Installation Guide
© MuxLab Inc. 2020 9
5. Troubleshooting & Maintenance
The following section describes some of the symptoms, probable causes and possible
solutions in regard to the installation of the 500464-V2 HDMI 2.0 Fiber Extender Kit.
The display only shows a blank (black) screen.
- Ensure that the USB power supplies are firmly connected and that both Transmitter
and Receiver Power LEDs are ON.
- Ensure that the HDMI connectors are firmly plugged into the HDMI connector of the
source and display using the two (2) included 1m HDMI 2.0 Premium Certified
cables.
- Ensure that the Transmitter and Receiver modules are plugged in the correct order
to the source and display, respectively (reversing the order will not work).
- Check if the source and display are powered on.
- Ensure that the multimode fiber SC connector is properly inserted into both the
Transmitter and Receiver.
- Reset the system by disconnecting and reconnecting the Transmitter HDMI or
Receiver HDMI side units, or by disconnecting and reconnecting the USB power
cables that are plugged in the Transmitter and Receiver modules.
- If necessary try to re-boot the system and re-connect the HDMI 2.0 Fiber Extender
Kit.
Screen is distorted or the display is noisy.
- Check if the graphic resolution is properly set. Go to the display properties and
confirm the settings.
- Ensure that the resolution is set to a maximum of 4K (4096x2160) at 60Hz refresh
ratio.
- Reset the system.
- Disconnect and reconnect the HDMI Fiber Extender Kit units or their power supply
adapters.
If you still cannot diagnose the problem, please call MuxLab Customer Technical
Support at 877-689-5228 (toll-free in North America) or ([phone]
(International).

HDMI 2.0 Fiber Extender Kit Installation Guide
© MuxLab Inc. 2020 10
Maintenance
No special maintenance is required for the HDMI 2.0 Fiber Extender Kit and power
adapters. Ensure that the HDMI modules and power adapters are stored or used in an
environment free from high temperature, humidity or dust/dirt contamination. Use
accordingly to the specifications.
There are no user serviceable parts inside these units. Refer all service and repair
issues to MuxLab.
Technical Support and Service
For commercial or general product support, contact your reseller. For technical service,
contact MuxLab by email [email protected] or visit MuxLab’s website at
www.muxlab.com
Certification of Eye Safety
This laser component is certified by CDRH/FDA referred as classified in Laser Class 1
(IEC60825-1).
Caution – Use of controls, adjustments or performance of procedures other than those
specified herein may re using a Premium High Speed HDMI Cable between 0.5m to 3m
in length sult in hazardous radiation exposure.
