·I·N·D·E·X·
Package Contents
Connection
Operation
System Setting
Function
Camera Set up
Normal/Mirror
Auto Picture Scan
Camera Trigger
Distance Marker Adjust
Scan ON/OFF Function
Lock ON/OFF Function
Installation
Monitor installation with Stand bracket & Sunvisor
Installation of heavy duty mounting brackets
Specication
03
11
04
05
05
06
06
07
07
08
09
10
10
12
12
13
14
All manuals and user guides at all-guides.com

3
Owner’s Manual
PACKAGE CONTENTS
MONITOR SUNVISOR STAND BRACKET MANUAL
BRACKET SCREWS
SUNVISOR SCREWS
CABLE CLIP
ITEM Q’TY
MONITOR 1
SUNVISOR 1
SUNVISOR SCREW 4
STAND BRACKET 1
BRACKET SCREW 3
CABLE CLIP 2
CAMERA INPUT CABLE 1
MANUAL 1
CAMERA INPUT CABLE
All manuals and user guides at all-guides.com

47" TFT DIGITAL LCD Moniter
OPERATION
d
b
a
c
f
e
ghi
j
A. DAY/NIGHT SENSOR (CDS)
Automatic brightness control sensor.
B. HEATER LAMP
Orange color will be illuminated in case heater function is
activated.
C. MENU
Press [MENU] button for system setting.
D. SELECT
Press [SELECT] button to select the respective camera channel.
(CAM1-CAM2-CAM3-CAM1..)
E. POWER
Press [POWER] button to turn on/off the monitor.
F. UP
G. DOWN
H. LEFT
I . RIGHT
J. VIEW AREA
Press [UP/DOWN] button to navigate the menu for
system setting.
Press [LEFT/RIGHT] button to adjust monitor volume.
Use [LEFT/RIGHT] button to change OSD setting
during system setting.
All manuals and user guides at all-guides.com

5
Owner’s Manual
SYSTEM SETTING
DIMMER (Automatic Brightness Control)
Select AUTO or OFF to haveAutomatic or Manual brightness of the monitor.
REMARK: By activating DIMMER AUTO function, the monitor adjusts the brightness
according to the environment.
LANGUAGE
Provide 6 Multi-lingual OSD [ENGLISH, SWEDISH, DANISH, NORWEGIAN, DUTCH,
FINNISH].
Select the preferred LANGUAGE.
AUTO POWER
Select monitor activation function as below.
[AUTO] Monitor keeps the last setting in memory.
[ON] Monitor starts up௲Power-ON௳mode automatically.
[OFF] Monitor starts up௲Stand-By௳mode automatically.
MONITOR HEATER
Select MONITOR HEATER௲ON௳to have automatic heating function in order to enable
fast picture start during extreme cold weather condition.
RESET
Press >>button to go the factory default setting.
SYSTEM INFO.
Refers to system information of the monitor.
FUNCTION
REMARK
: B
y
activatin
g
D
IMMER AUTO
f
unction, the monitor ad
j
usts the bri
g
htness
a
ccordin
g
to the environment.
FUNCTION
DIMMER AUTO/OFF
LANGUAGE ENGLISH/…
AUTO POWER AUTO/ON/OFF
MONITOR HEATER ON/OFF
RESET >
SYSTEM INFO. VER 1.0
Remark:During MONITOR HEATER ON mode,
Heating activates automatically when the temperature of inside monitor is below 0
degree Celcius.
When the temperature of inside monitor is over 0 degree Celcius, heating stops
automatically.
All manuals and user guides at all-guides.com

67" TFT DIGITAL LCD Moniter
SYSTEM SETTING
Press [LEFT/RIGHT] button to adjust preferred PICTURE of the monitor.
TRIG. DELAY
When a TRIGGER wire is connected to a pulse DC power signal (e.g. direction
indicator lights) then the [TRIGGER DELAY] function avoids repeating ON/OFF of the
monitor.
CAMERA NAME
CAMERA NAME can be selected as CAM1, 2, 3/REAR/LEFT/RIGHT/FRONT.
CAMERA SET UP
CONTRAST 50 (0-100)
BRIGHTNESS 50 (0-100)
COLOR 50 (0-100)
TINT 50 (0-100)
CAMERA SET UP
CAM1 TRIG. DELAY
2 SEC (0-9)
CAM2 TRIG. DELAY
2 SEC (0-9)
CAM3 TRIG. DELAY
2 SEC (0-9)
CAM1 NAME
CAM1/REAR/LEFT/RIGHT/FRONT
CAM2 NAME
CAM2/REAR/LEFT/RIGHT/FRONT
CAM3 NAME
CAM3/REAR/LEFT/RIGHT/FRONT
All manuals and user guides at all-guides.com
all-guides.com

7
Owner’s Manual
NORMAL/MIRROR
Each camera picture (CAM1/CAM2/CAM3) can be switchable as NORMAL/MIRROR image.
UP/DOWN
Camera pictures can be switchable as UP/DOWN image.
Each scanning time of CAM1/CAM2/CAM3 can be selected.
REMARK: If the SCAN TIME is set as௲0௳, monitor skips its channel during the
scanning.
Press [UP] button for 4 seconds to ACTIVATE/INACTIVATE auto scanning function.
NORMAL/MIRROR
AUTO PICTURE SCAN
NORMAL/MIRROR
CAM1 NORMAL/MIRROR
CAM2 NORMAL/MIRROR
CAM3 NORMAL/MIRROR
UP/UPSIDE DOWN UP/UPSIDE DOWN
AUTO PICTURE SCAN
AUTO SCAN ON/OFF
CAM1 SCAN TIME 2 SEC (0~9)
CAM2 SCAN TIME 2 SEC (0~9)
CAM3 SCAN TIME 2 SEC (0~9)
All manuals and user guides at all-guides.com

87" TFT DIGITAL LCD Moniter
SYSTEM SETTING
TRIGGER 1/2/3 (Trigger source selection)
Select the required trigger source at CAM1/CAM2/CAM3.
REMARK
TRIGGER PRIORITY: TRIGGER 1 > TRIGGER 2 > TRIGGER 3
CAM1 DIST. MARKER
Select ON to have distance marker (parking line) for CAM1.
Distance marker is displayed as soon as TRIGGER 1 signal is activated.
SPEED SWITCH
The orange wire needs to be connected with the vehicle’s tacho signal and via MENU
the SPEED SWITCH needs to be selected ON.
At FREQUENCY 67Hz setting(and most common used tacho signal) the selected
camera will be displayed during a speed of 0~33km/h. Select the concerning camera
via௲UNDER FREQUENCY CH:௳(At different type tacho signals the FREQUENCY needs
to be adjusted into higher or lower value than this example)
Over 33km/h (72Hz) the selected camera will be switched OFF automatically. When
the speed slows down, then the selected camera will be switched ON automatically
again at 30km/h. Instead of automatic switch OFF at a speed over 33km/h it is also
possible to activate another video source, such as a navigation picture from an optional
navigation computer. In this case user needs to select௲OVER FREQUENCY DISPLAY:
ON௳and user needs to select௲OVER FREQUENCY CH:௳
In case of TRIGGER activation during௲SPEED SWITCH ON௳mode, then TRIGGERS
1~ 3 will overrule௲SPEED SWITCH௳function.
CAMERA TRIGGER
REMARK
TRI
GG
ER PRI
O
RITY: TRI
GG
ER 1 > TRI
GG
ER 2 > TRI
GG
ER
3
CAMERA TRIGGER
TRIGGER 1 CAM1/CAM2/CAM3
TRIGGER 2 CAM2/CAM3/CAM1
TRIGGER 3 CAM3/CAM1/CAM2
CAM1 DIST. MARKER MARKER ON/OFF
SPEED SWITCH ON/OFF
FREQUENCY 67 Hz
UNDER FREQ. CAM CAM3/CAM1/CAM2
OVER FREQUENCY DISPLAY ON/OFF
OVER FREQ. CAM CAM1/CAM2/CAM3
All manuals and user guides at all-guides.com

9
Owner’s Manual
User can adjust location of distance marker.
At Power ON mode, select distance marker by pressing [UP/DOWN] buttons.
When color of distance markers is seen as RED color, user can adjust the lines UP/
DOWN or LEFT/RIGHT.
When both color of distance markers are seen as RED color, both lines can be
adjusted LEFT/RIGHT.
When left color of distance marker is seen as RED color, left line of distance marker
can be adjusted LEFT/RIGHT.
When right color of distance marker is seen as RED color, right line of distance marker
can be adjusted LEFT/RIGHT.
DISTANCE MARKER ADJUST
All manuals and user guides at all-guides.com

10 7" TFT DIGITAL LCD Moniter
SYSTEM SETTING
At Power-ON mode, hold [UP] buttons pressed for 4 seconds to activate Auto Scan
Picture function.
During the auto scanning mode, press [UP] button for 4 seconds to inactivate Auto
Scan Picture function.
LOCK ON/OFF FUNCTION
The set up menu can be locked as prevention against unauthorized users.
LOCK ON mode
At Power-ON mode, hold [DOWN] button pressed for 3 seconds to set up LOCK ON
function.
When [LOCKED] is displayed on the screen, user can use [POWER, SELECT, VOLUME]
buttons only and use can do setting for PICTURE menu.
LOCK OFF mode
At Power-ON mode, hold [DOWN] button pressed for 3 seconds to set up LOCK OFF
function.
When [UNLOCKED] is displayed on the screen, user can use all functions of the set up
menu.
SCAN ON/OFF FUNCTION
LOCK ON/OFF FUNCTION
CAM1
SCAN
C
AM
2
S
CAN
C
AM
3
S
CA
N
LOCKED
UNLOCKED
All manuals and user guides at all-guides.com

11
Owner’s Manual
CONNECTION
Camera 1(Option)
Camera 2(Option)
Camera 3(Option)
N
AL)-
S
Spee
e
d
Sw
w
itch
h
(TA
TAC
H
HO
S
IG
N
O
rang
e
TR
RI
IG
G
G
GE
ER
3-
-
B
l
ue
B
TR
RI
IG
G
G
GE
ER
2-
-
W
hit
e
W
TR
RI
IG
G
G
GE
ER
1
-
G
r
ee
n
G
7” TFT DIGITAL LCD Monitor
4V D
C
via i
g
nition
(
+15
)
-
M
Main
n
po
ow
w
er
1
2
2V /
/
2
Red
Gr
rou
u
n
d-
-
B
l
ack
AUDIO INPUT +12V DC OUTPUT,
HEATER & SHUTTER
+12V DC OUTPUT,
POWER VIDEO INPUT
GROUND
CAMERA INPUT
C
C
All manuals and user guides at all-guides.com
all-guides.com

12 7" TFT DIGITAL LCD Moniter
INSTALLATION
A
ཿ
ྀ
B C
D
MONITOR installation with STAND BRACKET & SUNVISOR
Remove a protection tape and attach STAND BRACKET into stand place, then fix it with the supplied screws.
Connect STAND BRACKET with monitor and adjust height/angle.
Attach SUNVISOR to the MONITOR and fix it with the supplied screws.
Connect CAMERA INPUT CABLE to the MONITOR.
A
B
C
D
All manuals and user guides at all-guides.com

13
Owner’s Manual
TYPE A(option) TYPE B(option)
Installation of heavy duty mounting brackets
MONITOR can be connected with different type of heavy duty mounting brackets.
Please check the compatibility in advance, then please follow installation as described below.
FMBK 5Ý10mm FMs 3.5Ý10mm
38mm
40mm
30mm
38mm
38mm
YWXYTWXTZXGGG㝘䟸G[aX^aY^
All manuals and user guides at all-guides.com

14 7" TFT DIGITAL LCD Moniter
SPECIFICATION
ITEM SPECIFICATION
LCD Screen Size 7” Wide Diagonal
Dimensions 190(W)GÝ 142(H)Ý42.85(D)mm
Display dimensions 152.4GÝ 91.44mm
Power Input DC 12 to 30 Volt Free Input
Power Consumption 12 Watt Max.
Video System NTSC / PAL / SECAM Auto Detection
Sync. System Internal
Brightness 500 cd/m2
Display Resolution 800 Ý480 pixel
Viewing Angle Top: 50. Bottom: 60. Left: 65. Right: 65.
Color Configuration RGB Stripe
Dimmer Automatic / Manual
Speaker Impedance 8 ohm, 0.3 Watt Max.
Operating Temp. -25°C ~ +75°C
Storage Temp. -30˚C to + 85˚C
Impact Rating 4G
Camera Connector 4-pin mini DIN (MXN configuration)
Housing Soft black(Al12)
ON-Screen Display
Control Functions Volume · Brightness · Color · Contrast · Tint · CAM Screen 1/2/3 · CAM Trigger 1/2/3 · Heater ·
Speedswitch · Auto Power · Distance marker ·Auto Picture Scan · Dimmer · Language · Direction · Reset.
Supplied Accessory Die-Cast Mounting Bracket / 1 pce, Screw Kit / 1set, Manual, Sun Shield / 1 pce, Power cable / 1 set
Weight 790g
