MyBinding DFG EC1000 User manual

Instruction Manual
Provided By
http://www.MyBinding.com
http://www.MyBindingBlog.com
DFG EC1000
Heavy Duty Coil
Punch/Bind Machine

EC1000 –Heavy Duty Coil Punch and Power Coil Binding Machine
Coil Size Selector
For professional appearance of
ll d t
Upper Mounted Electric
Power Roller Binding
Increases productivity and reduces
operator fatigue
Punch Handle
High strength die cast metal
Foot Pedal (Not shown)
or Power switch
Operated
Open Punch Throat
For punching larger
document
size
a
ll
d
ocumen
t
s
Punch Margin Control
Maximizes the tear resistance
of all documents
document
size
Sturdy Die Cast
Metal Construction
For many years of
fi
Side Margin Control
For evenly centered
of
all
documents
worry
f
ree operat
i
on
Non Skid Feet
For
evenly
centered
document punching
Huge Punch Capacity
Up to 22 sheets (20 lbs) punch capacity
Large Trash Drawer
Digital Finishing Group
1260 Kempar, Madison Heights, MI 48071, U.S.A. Phone:[phone], Fax: [phone]
Email: [email protected] Website: www.dfgus.com
Up
to
22
sheets
(20
lbs)
punch
capacity

1260 Kempar, Madison Heights, MI 48071, U.S.A. Phone:[phone], Fax: [phone]
Email: [email protected] Website: www.dfgus.com
Warning:
Do not connect this product to electrical power or attempt to operate it before you
read these operating instructions and have been fully trained to operate this product.
1. Indoor use only. Do not expose to rain.
2. Keep hands, long hair, neckties, necklaces and other loose articles away from
roller.
3. Do not place this product on an unstable stand, cart, or surface. The product may
fall and hurt you. If you use a cart, move the product and cart carefully.
4. Do not insert objects or spill liquids into the product. They may short out
components that may result in fire.
5. The power outlet shall be installed near this product and shall be easily accessible.
6. Unplug the product before moving it. Unplug the power supply when it will not
be in use for an extended period of time.
7. Do not attempt to service this product. Contact your DFG or your dealer if you
need service.
8. In case you need to replace fuse, please use 3.0 A fuse.
9. Do not operate the machine when the cover is not on the machine.
This machine should only plug into 110 V single-phase power outlets. When
using the roller, some motor and roller noises are normal. Roller is tested to last
10,000+ binding. We provide one-year part and labor warranty for this machine.

1260 Kempar, Madison Heights, MI 48071, U.S.A. Phone:[phone], Fax: [phone]
Email: [email protected] Website: www.dfgus.com
Dear Customer,
Thank you for purchasing Our EC1000 machine. The following are basic installation and
operation instruction. For advanced punching and binding, please contact DFG.
Installation
Remove the blue knob from machine. Slide the punch handle on the exposed knob. Screw
the blue knob back onto machine. Connect power cord and connect the foot pedal.
How to Punch (EtitanCoil machine showed following)
2. Select the punch margin (tip – the
thicker the book, the larger the punch
margin can be. However, you can use
a small punch margin for any book)
1. Set the side guide to center the
sheet for punching
3. Make sure your sheets are all the
way inside, against the back wall, and
then move sheets to the left side
against the side guide. Pull the
punching handle to punch.
Remove the blue
knob Install the punch handle and blue knob Connect foot pedal and
power cord (not shown)

1260 Kempar, Madison Heights, MI 48071, U.S.A. Phone:[phone], Fax: [phone]
Email: [email protected] Website: www.dfgus.com
How to Bind Books with PowerRoller (up to 7/8”)
1. Manually turn the spiral coil into
the first 4 or 5 holes
2. Press the foot pedal. Touch the
coils against the moving roller to spin
the coil through the book. (You can
speed up binding by moving the book
to the right side while the roller is
spinning the coil through the book)

1260 Kempar, Madison Heights, MI 48071, U.S.A. Phone:[phone], Fax: [phone]
Email: [email protected] Website: www.dfgus.com
3. Cut and crimp the ends of the
spiral coil.
Right handed
A. Hold pliers with red dot up,
with the coil near you.
B. Place pliers with jaws inside
the coil, near the center.
C. Close the pliers to cut the coil
and keep them closed
D. Optionally twist pliers to bend
crimp more before releasing
E. Release coil, flip the book
over sideways and crimp the
other side using the same
procedure (coils still near
you)
Left handed
Use pliers as described above but
hold them in your left hand and put
the red dot down.

1260 Kempar, Madison Heights, MI 48071, U.S.A. Phone:[phone], Fax: [phone]
Email: [email protected] Website: www.dfgus.com
How to Make Books Manually (any thickness)
How to Determine Appropriate Coil Size
There are three ways you can choose an appropriate coil size:
1. Use any size coil you like, as long as the coils size is larger than book thickness
2. Use coil that is 2 – 6 mm (1/8” to ¼”) larger than book thickness
3. Use our coil size selector. See following picture:
Specification:
Punch: Max. 25 sheets of paper (20 lbs), 15-20 Normal
Punch size: Any size
Binding Size: Electric power binding up to 7/8". Manual binding to any size.
Full 46 Disengagement Pins: center punching with any size paper without "half-moons"
Electrical Coil Binding: up to 7/8”
Side Margin Control: Lets you center holes quickly and easily for perfect alignment
Coil Size Selector: Built-in selector takes the guesswork out of choosing the proper size
element
Punch margin control: Provide strongest binding for any book size
Open Throat and Easy Punch Support: Easily punch any book length
Manually turn your coil into the
book. This is a very easy process.
(Tip: It will be much easier to twist
the front end of coils)
Cut and crimp the coils (see #3 of
power roller binding)
Put book on machine base, under the
“Size Selector”.
Move the “Size Selector” down until
its bottom touches the top sheets of
the book.
The top of the “Size Selector” will
point to a size you can use on the
scale
