MyKronoz ZeRound2 HR User manual

Ｓｍａｒｔ Ｗａｔｃｈ

ENGLISH
CHARGING...............
SET UP.......................
CALLS.......................
CALL HISTORY/SMS..
NOTIFICATIONS........
VOICE CONTROL......
ACTIVITY....................
HEART-RATE..............
SLEEP TRACKING..............
FIND MY PHONE..............
CAMERA REMOTE............
APPS...................................
MUSIC................................
SETTINGS...........................
TECH SPECS.......................
06
07
09
11
12
13
14
14
15
15
15
16
16
16
17
Round
2

4
TOUCHSCREEN
SPEAKER BUTTON
TOUCH-SENSITIVE
AREA
MICROPHONE
OVERVIEW
i
BUTTON
I Power ON / OFF:
long press for 3 seconds
I Press to go to the clock face
TOUCH-SENSITIVE AREA
I Tap on the touch-sensitive area
to go back to previous menu
I RESET long press for 8 seconds

5
i
If you want to change your watch face, press firmly on the current watch
face, swipe left or right to go through the different watch faces available and tap on
the one you want to select and use
NAVIGATE THE TOUCHSCREEN
I Tap with one finger
to open or select a
menu item
I Slide to the right
for activity menu
I Slide to the left for
main menu
I Slide up for notifications
I Slide down for shortcuts
round
2
ｅ
Ｒ

6
i
2.
3.
1.
1. CHARGING
Charge ZeRound
2
for two hours before your
first use
1. Put the charging cradle beneath the watch
2. Make sure the pins on the cradle fit correctly
onto the charging terminals on the back of
ZeRound
2
3. Connect the charging cradle with the USB
cable
4. Plug the big end of the USB cable to a
power source
5. A battery indicator will fill to indicate charging
is in progress. Once ZeRound
2HR
is charged, the
battery indicator will be full
i
A full charge takes 2 hours. Unplug the
cable after ZeRound2is fully charged.
When the battery level gets low, a low
battery indicator will appear
ＨＲ
ＨＲ
ＨＲ

7
2. SET UP
STEP 1: PAIR VIA BLUETOOTH
I Enable Bluetooth on your mobile device
I Select ZeRound2in the Bluetooth Devices List
STEP 2: PAIR VIA MOBILE APP
I Make sure the Bluetooth is enabled on your mobile device
I Download ZeRound2App from the App store or Google Play Store
I Open ZeRound2settings tab and click on «Connect ZeRound2»
I Select ZeRound2in the accessory list and tap Pair to confirm the pairing
i
You only need to pair your device once. After the initial pairing, ZeRound2will
automatically connect to your phone as long as it is turned on and within range.
To pair ZeRound2to another device, repeat the same steps
ＨＲ
ＨＲ
ＨＲ
ＨＲ
ＨＲ

8
ZeRound2will sync the notifications of SMS, emails, social media, calendar events, and per-
sonal life reminders once ZeRound2App has been successfully installed on your smartphone.
Please note some features will not work unless ZeRound2App has been installed on your smart-
phone
Visit www.mykronoz.com to get the latest compatibility list.
System Requirements
iOS 8+
iPhone 4s, 5, 5c, 5s, 6, 6s, 6s plus, 7,
7 plus, iPad (3rd , 4th and 5th generation)
iPad Mini, iPod touch (5th generation)
SELECT ANDROID 5.0 +
ZeRound2app is available for select
Android 5.0 + devices that support
Bluetooth 4.0
i
ＨＲ

9
3. CALLS
ZeRound2allows you to make and receive calls.
MAKING A CALL
FROM THE PHONE MENU
MAKING A CALL
FROM THE PHONEBOOK
Go to the Phone menu, enter a
number with the dialer
pad and tap on
Go the Phonebook panel,
select a contact and
tap on
ＨＲ

10
1. ANSWER
2. REJECT
3. MUTE
1. TURN OFF THE MICROPHONE
2. END CURRENT CALL
INCOMING
CALL OPTIONS
IN-CALL
OPTIONS
12 12
3

11
5. SMS
After a successful Bluetooth connection and installation of ZeRound2App,
you can read SMS messages on your ZeRound2.
QUICK REPLY
You can reply using the SMS template (Android only).
4. CALL HISTORY
From the Call history menu, see the list of recent incoming and outgoing
calls. Tap on the call to view the contact’s name, phone number and make a
call directly or send a SMS (Android only).
ＨＲ

12
6. NOTIFICATIONS
After successful Bluetooth connection and installation of ZeRound2App on
your smartphone, ZeRound2will show notifications of SMS, emails, social
media, calendar events and personal life reminders.
SETTING UP NOTIFICATIONS FOR IOS USERS
Go to the Settings of your iOS device:
I Tap on Notifications
I Select which type of notifications you wish to receive on ZeRound2
I Enable Show in Notifications to receive the notification on ZeRound2
i
You can also set up daily life reminders: open ZeRound
2
mobile application, click on
the reminders tab, set up your preferred reminder type and time. ZeRound will
gently vibrate and display the corresponding icon to alert you
ＨＲ
ＨＲ
ＨＲ
ＨＲ
2
ＨＲ

13
7. VOICE CONTROL
Use the Voice Control feature to voice command your mobile device remotely or
search information from the Internet.
To start using the feature, tap on the Voice Control icon to open the respective page
on ZeRound2.
Then tap on the Voice Control again to turn the function on or off.
Examples of what you can ask or do:
I Call (name of your contact)
I Send a SMS to (name of your contact)
I What’s the weather like?
I Set an alarm for tomorrow 5 am
This feature is available with iOS 8+ devices that support Siri and Select Android 5.0 +
devices that support Google Now. To use voice control, your smartphone must have
access to the Internet using either 3/4G or Wifi
i
ＨＲ

14
8. ACTIVITY
9. HEART-RATE
Tap on the Activity icon to open the Activity menu.
I Swipe left or right to see your results of steps, distance, calories
and active minutes
Activity Goals:
I Press on the Goals icon to change your daily goals
In order to activate the Heart rate monitor, please select the heart rate interface
on your device.
I Then, tap once the screen to start monitoring your heart rate.
I You can also enable automatic monitoring by going to the Settings tab of your
mobile App, then click on the Heart Rate section and enable automatic tracking.
I Once activated, the device emits a green light via two LEDs installed at the back
of the unit.

15
11. FIND MY PHONE
To enjoy this feature, make sure ZeRound2is connected to your smartphone
via Bluetooth and mobile app. Enabling Find my phone function will make
your phone ring and help you find it.
10. SLEEP
ZeRound2tracks the hours slept and the quality of your sleep (light sleep & deep sleep).
Start/Exit sleep mode:
I Press on the sleep icon on ZeRound2
I Long press on Start to start monitoring your sleep
I Long press on End to stop monitoring your sleep
Sleep goals:
I Press on the sleep icon on ZeRound2
I Slide to the right to set up your daily sleep goals
I Sleep Goal is 8 hours by default
12. CAMERA REMOTE
To enjoy this feature, make sure the camera of your smartphone is on. Enabling
Camera Remote function will let you take pictures remotely from your ZeRound2.
ＨＲ
ＨＲ
ＨＲ
ＨＲ
ＨＲ

16
14. MUSIC
The music of your paired smartphone will be synchronized to ZeRound2.
In the Music panel, play / pause the current song streamed on your phone,
choose the previous or next song.
15. SETTINGS
Use the Settings panel to configure the settings of your ZeRound2
I Bluetooth
I Clock
I Wake screen on wrist flick
I Reset
I Sound
I Display
I Watch info
I Language
I Power display
13. APPS
Several applications can be found in this menu:
I Calendar I Alarm I Calculator
I Anti-Lost Alert I Stopwatch I Sound recorder
ＨＲ
ＨＲ

17
16. TECH SPECS
Dimensions 45*12 mm
Weight ZeRound2 Premium 53 g
ZeRound2Elite 56 g
Connectivity Bluetooth 3.0 + 4.0
Battery type Lithium-ion 260mAh
Talk time 2.5 hours
Standby time 3 days
Charging time 2 hours
Display TFT 1.22 inches / 240*204 pixels
Sensor 3-axis accelerometer & optical HR sensor
Operating temperature -10°C to + 60°C
Water resistance IP67
International warranty 1 year
ＨＲ
ＨＲ

36
SAFETY INSTRUCTIONS
ZeRound
2
has built-in batteries. Do not disassemble the battery on your own. KRONOZ LLC is not
responsible for any damage or personal injury caused by the removal of the battery or any component.
smoke, fire or deformation of the battery or even explosion. Avoid excessive temperatures. Do not expose
ＨＲ

37
Do not attempt to repair or maintain the watch by yourself, service and maintenance should be performed
by authorized technicians.
Inapropriate use of photography, video and photo, audio recording function records could violate the
copyright owner’s rights. For this, the user must assume full responsability. KRONOZ LLC is not responsible
for any damage caused by improper use of the device.
This device is not waterproof. Do not immerse the device in water or any other liquids.
Do not disassemble the battery on your own. KRONOZ LLC is not
RF exposure statements
This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.

38
REGULATORY NOTICES
FCC ID : 2AA7D-ZERD2
Any changes or modifications not expressly approved by the party responsible for compliance could void your authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection
against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning the equipment off and on,
, the user is encouraged to try to correct the interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.

39
IC : 12131A-ZERD2
This device complies with the ISED RSS-102 RF exposure limit
set forth for an uncontrolled environment and are safe for intended operation as described in this manual.
Déclaration d'exposition aux radiationsCet appareil est conforme aux limites d'exposition aux rayonnements
Canada établies au pour un environnement non contr-lé et ne présente pas de risque
dans le cadre d’une utilisation conforme à celle décrite dans ce manuel.
