Mytee Escape Plus ETM-LX-PLUS User manual

Escape Plus Model:
ETM-LX-PLUS
User Manual
13655 Stowe Dr. Poway, CA 92064
P: [phone]
F: [phone]
www.mytee.com
REV. 2/16/23
®

2
Introduction
Dear Customer:
Congratulations on the purchase of your new Escape® Plus Electric
Truckmount. As technology continues to develop you can work condently
knowing that both Mytee and its employees are equally dedicated to develop-
ing with the industry and its advances.
Like any other piece of machinery or technology, the Escape® Plus also
requires proper maintenance and care to keep the product working over
extended use. Neglecting your machine, abusing it or not operating it properly
can void its warranty and prevent the machine from performing to the quality
and standard you’d expect out of the Mytee line.
If you have any warranty concerns or questions, please review this manual
thoroughly or do not hesitate to contact your distributor. If there are questions
regarding maintenance, replacement, or ordering parts please contact an
authorized Mytee Service Center. To see an updated list please visit our
website at https://www.mytee.com/support/nd-distributors/.
Before using your Mytee product, please read this manual thoroughly.
Sincerely,
Mytee Customer Care Dept.

3
Table of Contents
1
2
3
4
Important Safety Information 4
At a Glance 6
1.1 - Technical Specications 6
1.2 - Included with the Escape® Plus 6
1.3 - Escape® Plus Front View 7
1.4 - Escape® Plus Rear View 8
1.5 - Escape® Plus Switch Plate 9
Machine Operation 10
2.1 - Powering the Escape® Plus 10
2.2 - Connecting Vacuum & Solution Hoses 10
2.3 - Transfer Pump and Auto-Fill 10
2.4 - Chemical Injection 10
2.5 - Using the Pump-Out 10
2.6 - Operating the Escape® Plus 11
2.7 - Emptying the Solution and Recovery Tanks 11
2.8 - Preparing for Freezing Weather 11
Machine Maintenance 12
3.1 - Opening the Unit for Maintenance 12
3.2 - System Maintainer 12
Troubleshooting 13

4
Important Safety Information
Please read and understand this manual completely
before operating this machine.
Grounding Instructions
This machine must be grounded. If it should malfunction or
break down, grounding provides a path of least resistance
for electrical shock. This machine is equipped with a cord
having an equipment-grounding conductor and grounding
plug. The plug must be plugged into an appropriate outlet
that is properly installed in accordance with all local code
and ordinances. Do not remove ground pin; if missing,
replace plug before use.
Improper installation of the equipment-grounding
conductor can result in a risk of electric shock. Be sure to
check with a qualied electrician or service person if you
are in doubt as to whether the outlet is properly grounded.
If the plug will not t in the outlet do not modify the plug or
the machine’s cord, instead have a proper outlet installed
by a qualied technician.
This machine is for use on a nominal 120-volt circuit and
with a grounding plug similar to the one in Figure 1 below.
If a proper outlet is not available, follow the illustrations of
Figure 2 & 3 to install a temporary-grounding plug. This
temporary work-around should be used only until a proper
outlet (Figure 1) can be installed by a qualied electrician.
When and if this type of adapter is employed, screw the
adapter’s extended tab into place with a metal screw.
However, grounding adapters are not approved for use in
Canada.
Again, be sure to check the grounding pin for damages
and replace if necessary.
The Green, or Green-Yellow, wire in the cord is the
grounding wire. When replacing a plug, this wire must be
attached to only the grounding pin.
DO NOT use extension cords.
Please Note for America use only.
Parts and Service
Please contact Mytee service personnel or a Mytee au-
thorized Service Center using Mytee original replacement
parts and accessories if repairs need to be performed.
When and if calling Mytee for support, please have your
Model and Serial Number available for faster assistance.
Name Plate
The Model and Serial Number are located on the lower half
of the back of the machine near the power plug and will be
required for ordering replacement parts. You can use the
space provided in this manual to note down both for future
referencing.
Unpacking the Machine
When your new machine is delivered, please carefully
inspect both the shipping carton and the machine for
damages. If damage is evident, save both the shipping
carton and machine so that the delivering carrier can
inspect it. Contact the carrier immediately to le a freight
claim if there has been any damage.
Caution and Warnings
Symbols
Mytee uses the symbols below to signal potential-
ly dangerous conditions. Always read this informa-
tion carefully and take the necessary steps to protect
personnel and property.
Is used to warn of immediate hazards that will cause
severe personal injury or death.
Figure 1
Grounding Pin
Grounded Outlet
Grounded Outlet Box
Adapter
Tab for Grounding
Screw
Metal
Screw
Figure 2 Figure 3

5
Important Safety Information
Is used to call attention to a situation that could cause
severe personal injury.
Is used to call attention to a situation that could cause
minor personal injury or damage to the machine or other
property. When using an electrical appliance, basic
precautions should always be followed, including the
following: Read all instructions before using this machine.
This product is intended for commercial use only.
To reduce the risk of re, electrical shock, or injury:
1. Read all instructions before using equipment.
2. Use only as described in this manual. Use only manu-
facturer’s recommended attachments.
3. Always unplug power cord from electrical outlet before
attempting any adjustments or repairs.
4. Do not unplug by pulling on cord. To unplug, grasp the
plug, not the cord.
5. Do not pull or carry by cord. Do not close a door on
cord or pull cord around sharp edges or corners.
6. Do not run appliance over cord. Keep cord away from
heated surfaces.
7. Do not use with damaged cord or plug. If cord is
damaged, repair immediately.
8. Do not use outdoors or on wet surfaces and/or standing
water.
9. Always unplug or disconnect the appliance from power
supply when not in use.
10. Do not allow to be used as a toy. Close attention is
necessary when used by or near children.
11. Do not use in areas where ammable or combustible
material may be present.
12. Do not leave the unit exposed to harsh weather
elements. Temperatures below freezing may damage com-
ponents and void warranty.
13. Use only the appropriate handles to move and lift
unit. Do not use any other parts of this machine for this
purpose.
14. Keep hair, loose clothing, ngers, and all parts of the
body away from all openings and moving parts.
15. Use extra care when using on stairs.
16. To reduce the risk of re or electric shock, do not use
this machine with a solid-state speed control device.
17. The voltage and frequency indicated on the name plate
must correspond to the wall receptacle supply voltage.
18. When cleaning and servicing the machine, local or
national regulations may apply to the safe disposal of
liquids which may contain: chemicals, grease, oil, acid,
alkalines, or other dangerous liquids.
19. Do not leave operating unattended.

6
1 - At a Glance
1.1 - Technical Specications 1.2 - Included with the Escape® Plus
Solution Tank 12 gallon capacity
Recovery Tank 12 gallon capacity
Vacuum
Motors
Three exclusive Mytee® LX™ Vacuum
Motors - 350 CFM, 17.5 in. Hg
(approx.)
Solution Pump 1,200 PSI piston pump (regulated to
1,000 PSI), 2.2 GPM
Pump-Out 3.5 GPM
Power Cord Single 5’ 4-prong dryer plug
Amp Draw 30 amps @ 230V 60Hz
Product
Weight 190 lbs.
Product
Dimensions 37” x 25.5” x 38.5”
F200 Lint Hog™ In-Line Filter
7 qt. Big Mouth™ Bottle

7
1 - At a Glance
1. Switch Panel (see pg. 9)
2. 7 qt. Big Mouth™ Bottle
3. Solution Tank Opening
4. 12 Gallon Solution Tank
5. Winterizing Pump Drain Valve
6. Solution Tank Drain Valve
7. Recovery Tank Drain Valve
8. Auto Fill Hose Connection
9. Vacuum Hose Connection
10. 12 Gallon Recovery Tank
11. Recovery Tank Lids
1.3 - Escape® Plus Front View
1
2
3
4
6
57
8
9
10
11

8
1 - At a Glance
1. 5’ Power Cord with 4-Prong Dryer Plug
2. Vacuum Exhaust Ports
3. Mounting Feet
1.4 - Escape® Plus Rear View
1
3
2

9
1 - At a Glance
1. Circuit Breakers
2. Chemical Injection Knob
3. Prime Valve
4. Pump-Out Hose Connection
5. Wash Out Hose
6. Solution Hose Connection
7. Pressure Regulator
8. Pressure Gauge
9. Auxiliary Switch for 115V Transfer Pump
1.5 - Escape® Plus Switch Plate
1
2
5
6
7
9
8
3
4

10
2 - Machine Operation
2.1 - Powering the Escape® Plus
The Escape® Plus is designed to be mounted in a van
and powered by a generator. The Escape® Plus runs o
a minimum of 8,625 watts, however, Mytee recommends
running the machine o a 12,000 watt generator.
The Escape® Plus requires a 230V 60Hz power source
capable of providing 30 amps. ♦
2.2 - Connecting Vacuum & Solution Hoses
The Escape® Plus features
a 2” Cu-Lynx™ vacuum
hose connection as well as
a standard 1/4” quick dis-
connect tting for solution
hoses. ♦
2.3 - Using the
Auto-Fill
The auto-ll tting is on the
front of the machine just to
the right of the solution tank
opening. To use the auto-
ll, just connect a garden
hose to the auto-ll tting
and turn on the water. The
oat will shut o the auto-ll
when the tank is full. ♦
2.4 - Chemical Injection
Fill the included 7 qt. bottle with chemical concentrate of
your choice. With a cleaning tool connected, switch on
the pump and pull the trigger on your tool to keep water
owing. Turn the chemical injection knob counter-clock-
wise to open the valve. This allows chemical to siphon
into the line. Turn the knob until you see the bubble reach
the desired gallons per hour of chemical. Follow chemical
manufacturer’s instructions for correct ratio.
IMPORTANT: If chemical injection will not be used,
make sure the chemical injector is closed by turning
the knob all the way clockwise. ♦
2.5 - Using the Pump-Out
Connect a garden hose to the pump-out tting on the
front of the machine. The other end of the hose can be
placed in a holding tank for recovered water. Switch on
the PUMP-OUT and open the ball valve. Recovered water
12,000 WATTS
Runs o 230V 60Hz

11
2 - Machine Operation
will automatically be pumped from the Escape® Plus’s
recovery tank to your holding tank. ♦
2.6 - Operating the Escape® Plus
The Switch Plate:
VACUUMS: These switches control each vacuum motor
individually.
PUMP: This switch controls the solution pump.
PUMP-OUT: This switch controls the auto pump-out.
TRANSFER: This switch controls the Transfer Pump (if
installed).
Adjusting the Solution Pump PSI:
Turn the pressure regulator clockwise to increase the PSI
(up to 1,000) and twist counter-clockwise to decrease
PSI. ♦
2.7 - Emptying the Solution and Recovery
Tanks
The Escape® Plus features tank drain valves on the
recovery and solution tanks. The pump-out can also be
used to empty the recovery tank. ♦
2.8 - Preparing for Freezing Weather
Read this if you’re in a cold climate.
Freezing temperatures
can cause damage to the
internal components of the
Escape® Plus if there is
excess water in the system.
If freezing temperatures are
expected, be sure to drain
all the water from both tanks
and use the winterizing
pump drain valve on the
front of the machine to drain any excess water from the
pump. ♦

12
3 - Machine Maintenance
In order to keep the Escape® Plus running smoothly and
reduce the risk of damage to the machine and subsequent
downtime, Mytee recommends following the maintenance
schedule below:
Maintenance Item Daily Weekly
Clean and inspect tanks. X
Clean and inspect hoses. X
Check and clean internal lters. X
Check power supply cables. X
Clean machine with all-purpose
cleaner and cloth. X
Check spray nozzles. X
Flush solution system with Mytee
System Maintainer. X
Run clean water through the
chemical injection system. X
Inspect vacuum hoses for holes and
loose cus. X
Inspect machine for water leaks and
loose hardware. X
3.1 - Opening the Unit for Maintenance
To open your Escape® Plus for maintenance, make sure
the 7 qt. bottle is removed and, with a Phillips screwdriver,
remove the screws holding the side panel on. Place the
side panel o to the side. ♦
3.2 - System Maintainer
Weekly ushing of the solution system with Mytee®
System Maintainer helps keep lines clean and prevents
chemical build-up, improving pump life, performance and
pressure.
How to use System Maintainer:
1. Mix 1-quart 3601 System Maintainer with 1-quart of
warm water.
2. After thoroughly mixing, pour this solution into the
solution tank.
3. Turn the pump on and run solution through your
cleaning tool. NOTE: The jet should be removed from the
cleaning tool in order to prevent clogging due to loosening
of deposits in line.
4. After running all of the solution through the machine, ll
the tank with clean, warm water. Run the water through the
machine to clear the solution completely out of the tank &
lines. ♦

13
4 - Troubleshooting
Issue Possible Cause Solution
Machine is not
turning on.
Power cord unplugged. Plug the power cord into a grounded 20 amp
outlet.
Circuit breaker tripped. Reset breaker in.
Faulty switch or power cord. Contact a Mytee Service Center.
Vacuum not
producing
suction.
Vacuum tank is full. Empty vacuum tank.
Vacuum hose blockage. Check for blockages in vacuum hoses inside
and outside machine.
Clogged lter in vacuum tank. Clean out lter regularly.
Hose cus are loose and causing air leakage. Tighten all hose cus regularly as may loosen
over time.
Lid on tank is loose and is causing air leakage. Make sure the lid is tight.
Blows water out
exhaust. Foam building up inside vacuum tank. Use a defoaming solution in vacuum tank.
Vacuum makes
loud grinding
noise.
Debris has been sucked into the vacuum motor
chamber. Usually results from dry vacuuming.
Replace the vacuum motor. To avoid repeat
problem, DO NOT dry vacuum with your
extractor.
Pump is running
but there is no
spray.
Empty tank. Fill the tank.
Blockage or kink somewhere in the line. Locate where the blockage is and repair
accordingly.
Pump valves are clogged or damaged. Examine valves and clean or replace.
Low PSI.
Worn nozzle. Replace nozzle with a new one of the same size.
Leak in high pressure hose or connections. Check hose and connections. Replace as
needed.
Filter is clogged. Clean lter.
Pump valves are clogged or damaged. Examine valves and clean or replace.
Pump pulsated
when spraying.
Filter is clogged. Clean lter.
Pump valves are clogged or damaged. Examine valves and clean or replace.
Pump motor
does not
operate.
Blown circuit breaker. Replace circuit breaker. Check circuit for wire or
component damage.
Leaks seen
under pump Pump seals are worn. Replace with new plunger and seals.
No water ow
from pump-out.
Filter is clogged. Clean the lter.
Kinked hose inside the machine. Open the machine and check hoses. If any
hoses are kinked, undo the kink.
Pump-out
doesn’t turn on.
Obstructed oat switch. Check oat switch. Clear any obstructions.
Clogged pump. Clean around the pump-out with clean water.

Mytee, LLC
13655 Stowe Dr.
Poway, CA 92064
www.mytee.com
© 2022 Mytee, LLC
NOTES
