Mytee UltraGlide RD-13 User manual

1
Instructions for
RD-13 
13655 Stowe Dr., Poway, Ca. 92064
Model #
Serial #
Form # ADM-RD13
2-14
Please read before use.
Register your product
athttp://www.mytee.
com/support/register
Set up p. 3
General information p. 5
Parts & pricing p. 8
Wiring diagram p. 10
Notes p.11

2

3


While holding the safety switch lock in disengaged posi-
tion, squeeze power triggers to operate machine. To stop
the machine, simply release the triggers.


1. Safety Switch
2. Handle Adjustment Lever
3. Cord Storage Hook
4. Wheels
5. Power Triggers
6. Power Cord
7. Chrome Plated Motor
3
1
2
To turn the machine on, the operation handle must be
lowered to the operating position before switching the ma-
chine ON. Disengage the safety switch lock by pushing it
forward with either thumb.
4
5
6
7


4

The handle can be adjusted to any desired working posi-
tion by simply squeezing the adjustment lever. Move the
handle to the desired position, then release adjustment
lever locking handle in place.
Once you release adjustment height lever, handle will lock
on to gear.
When not in use, loosely wind the power cord around the
cord storage hook on the handle shaft and handle grip.
Note: Disconnect the power cord from electrical outlet be-
fore installing a brush or pad driver. ON - Push the brush
or pad driver rmly in position, then turn it counter-clock-
wise until it locks into place. REMOVE - Turn clockwise
until it stops, then lift off.
ON OFF
 


5

Congratulations on the purchase of your new UltraGlide™ RD-13. As you are
already aware, the scene of the equipment world is becoming more high tech, and
we at Mytee Products Inc. strive to keep you on the cutting edge with superior quality
and technology.
Keep in mind that the UltraGlide™ RD-13 is a machine, so neglect or abuse
will cause unnecessary damage and void the warranty. However with simple
maintenance the RD-13 will give quality performance for many years to come.
If warranty questions arise, please consult your user manual or get in touch with
your distributor. If you have questions about maintenance, replacing parts or
ordering parts, please call an authorized Mytee Products Inc. Service Center.
To see an updated list, visit our website at www.mytee.com.
Before you begin using your new machine, please read your manual thoroughly.
Sincerely,
Mytee Customer Care Dept.


This machine must be grounded. If it should malfunction or breakdown, grounding
provides a path of least resistance for electrical shock. This machine is equipped with
a cord having an equipment-grounding conductor and grounding plug. The plug must
be plugged into an appropriate outlet that is properly installed in accordance with all
local code and ordinances. Do not remove ground pin; if missing, replace plug before
use.
Improper connection of the equipment-grounding conductor can result in a risk of
electric shock. Check with a qualied electrician or service person if you are in doubt
as to whether the outlet is properly grounded. Do not modify the plug provided with
the machine. If it will not t the outlet, have a proper outlet installed by a qualied
electrician.
This appliance is for use on a nominal 120-volt circuit, and has a grounding plug
that looks like the plug illustrated in Figure 1 below. A temporary adapter illustrated
in Figures 2 and 3 may be used~to connect this plug to a 2-pole receptacle as
shown in Figure 2 if a properly grounded outlet is not available. The temporary
adapter should be used only until a properly grounded outlet (Figure 1) can be
installed by a qualied electrician. The green colored rigid ear, tab or the like
extending from the adapter must be connected to a permanent ground such as a
properly grounded outlet box cover. Whenever the adapter is used, it must be held
in place by a metal screw. Grounding adapters are not approved for use in Canada.
Replace the plug if the grounding pin is damaged or broken.
The Green (or GreenYellow) wire in the cord is the grounding wire. When replacing
a plug, this wire must be attached to the grounding pin only.
DO NOT use extension cords.


Repairs, when required, should be performed by Mytee service personnel or Mytee
authorized Service Center using Mytee original replacement parts and accessories.
Call Mytee for repair parts or service. Please specify the Model and Serial Number
when discussing your machine.

The Model and Serial Number of your machine are shown on the Nameplate on the
back panel of the machine. This information is needed when ordering repair parts
for the machine. Use the space provided on the front cover to note the Model and
Serial Number of your machine for future reference.

When the machine is delivered, carefully inspect the shipping carton and the
machine for damage. If damage is evident, save the shipping carton so that it can
be inspected by the carrier that delivered it. Contact the carrier immediately to le a
freight damage claim.



Mytee uses the symbols below to signal potentially dangerous conditions. Always
read this information carefully and take the necessary steps to protect personnel
and property.
Is used to warn of immediate hazards that will cause severe personal injury or death.
Is used to call attention to a situation that could cause severe personal injury.
Is used to call attention to a situation that could cause minor personal injury or
damage to the machine or other property. When using an electrical appliance, basic
precautions should always be followed, including the following: Read all instructions
before using this machine. This product is intended for commercial use only.
To reduce the risk of re, electrical shock, or injury:
1. Read all instructions before using equipment.
2. Use only as described in this manual. Use only manufacturer’s recommended
attachments.
3. Your oor machine is equipped with a safety switch lock and power switch triggers
designed for your safety. Do not attempt to bypass or defeat the safety switch lock.
Never use any device to lock the power switch triggers in the “ON” position.
4. Always unplug power cord from electrical outlet before attempting any adjustments
or repairs.
5. Use care to keep the electrical supply cord from contacting the rotating brush or
drive block.
6. Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.
7. Do not pull or carry by cord. Do not close a door on cord or pull cord around sharp
edges or corners.
8. Connect to properly grounded (3-wire) outlet only refer to grounding instructions.
9. Do not run appliance over cord. Keep cord away from heated surfaces.
10. Do not use with damaged cord or plug. If cord is damaged, repair immediately.
11. Turn off all controls before unplugging.
12. Do not use outdoors.
13. Always unplug or disconnect the appliance from power supply when not in use.
14. Do not handle the plug or oor machine with wet hands.
15. Do not allow to be used as a toy. Close attention is necessary when used by or
near children.
16. Wind the cord no tighter than is necessary to retain it during storage.
17. Do not use in areas where ammable or combustible material may be present.
18. Do not leave the unit exposed to harsh weather elements. Temperatures below
freezing may damage components and void warranty.
19. Use only the appropriate handles to move and lift unit. Do not use any other parts
of this machine for this purpose.
20. Keep hair, loose clothing, ngers, and all parts of the body away from all
openings and moving parts.
21. Use extra care when working near stairs.
22. To reduce the risk of re or electric shock, do not use this machine with a solid-
state speed control device.
23. The voltage and frequency indicated on the name plate must correspond to the
wall receptacle supply voltage.
24. When cleaning and servicing the machine, local or national regulations may apply
to the safe disposal of liquids which may contain: chemicals, grease, oil, acid, alka-
lines, or other dangerous liquids.
25. Store your oor machine indoors in a cool, dry area.
26. Keep your work area well lit.
27. Do not leave operating unattended.
Use of ammable chemicals could cause explosion, re, and death.
Figure 1
Grounding Pin
Grounded Outlet
Grounded Outlet Box
Adapter
Tab for Grounding
Screw
Metal
Screw
Figure 2 Figure 3


6

1. The ON/OFF switch is conveniently located in the form of dual triggers underneath
the handle grips.
2. To turn the machine on, the operation handle must be lowered to the operating
position before switching the machine ON.
3. Do not apply pressure on the triggers before the safety switch lock is disengaged.
4. Disengage the safety switch lock by pushing it forward with either thumb. Then,
while holding the safety switch lock in disengaged position, squeeze the power trig-
gers toward the handle grips and return your thumb to the handle grip.
5. To stop the machine, simply release the triggers. The safety switch lock will auto-
matically return to the engaged position.


1. Disconnect the power cord from the electrical outlet before installing a brush or
pad driver.
2. To install a brush or pad driver, leave the handle in the upright position and tip the
machine backwards so it rests on its wheels and upper handle section.
3. Align the cut-outs on the inner ring of the brush or pad driver with the tabs on the
inside of the ring of the drive hub.
4. Push the brush or pad driver rmly in position.
5. Turn it counter-clockwise until it locks into place.
6. Return machine to upright position.
7. To remove, turn brush or pad driver clockwise until it stops, then lift it off.
8. Always remove the brush or pad driver when the machine is not in use.

1. Squeeze Adjustment Height lever.
2. Pivot handle to desired position (best is at waist height).
3. Release lever to lock handle in place.


1. Vacuum carpet and upholstery and remove other debris.
2. Perform machine setup procedures.
3. Inspect power cord for damage.


1. Squeeze the Adjustment Height lever.
2. Pivot handle to desired position (best is at waist height) .
3. Release lever to lock handle in place.
4. Place both hands rmly on the handle grips with your ngers around the power
triggers. Do not apply pressure on the triggers before the safety lock is disengaged.
5. Disengage the ambidextrous safety switch lock by pushing it forward with your
thumb.
6. While holding the safety switch lock forward, squeeze the power triggers and
remove your thumb from the safety switch lock.
7. To stop the machine, simply release the triggers. The safety switch lock will auto-
matically return to the engaged position.


1. Work away from outlet and power cord to prevent cord damage.
2. To clean heavily soiled areas, repeat cleaning path from different direction.

1. For ease of operation, always keep the brush or pad surface level, balanced, and
at on the oor at all times.
2. Always adjust the operating handle to a comfortable height at which the brush or
pad surface is balanced before starting the machine.
3. Your oor machine will operate differently on various surfaces. There will be more
resistance when the machine is used with a brush on carpet than when it is used with
a pad on a smooth surface.
4. To move the machine to the right, apply slight upward pressure on the handle.
5. To move the machine to the left, apply slight downward pressure on the handle.
6. To move the machine forward or backward, push or pull in the desired direction,
keeping the pad or brush level on the oor at all times.


1. Unplug.
2. Inspect hoses and replace if damaged.
3. Loosely wind up the power cord around the handle bar and the hook at the bottom
of the shaft.
4. After each use, wipe your oor machine with a clean, soft, damp cloth.
5. Store in a clean, dry place.
6. Do not expose to rain. Store indoors.

Maintenance item Daily Once a week
Clean and inspect chrome motor
Check power supply cable
Clean machine with all purpose cleaner and cloth
Inspect machine for water leaks and loose hardware
x
x
x
x



1. Plug machine in proper outlet.
2. Disengage safety interlocks
3. Make sure switch is being activated by lever.
4. Ensure that switch is not damaged or defective.


A: HD-13 is 67 pounds, shipping weight is 72 pounds - Box dimensions are
22 3/4” x 17 3/8” x 25 5/8”. Must ship motor freight.

A: The machine ships completely assembled. Pads, drivers, and brushes
sold separately.

A: Mytee® does carry drivers for the RD-13 UltraGlide. Visit mytee.com for more
information.

A: The RD-13 requires a grounded circuit. Please note: GFI outlets may trip
before the breaker setting.

A: Check all parts for wear regularly. Keep machine clean. Do not store with brush or
pad driver installed. Doing so will crush brush or pad driver.


Mytee Products, Inc. endeavors to provide high quality products and product support
to its customers and therefore backs up all of its new products purchased from Mytee
Products Inc. (“Mytee”) or any authorized Mytee distributor/service center with this
limited warranty. This limited warranty begins on the date of the customer’s purchase
and is valid and available to the original purchaser only. Mytee’s products are for
commercial use only and are not intended for personal, family or household uses.
HOWEVER, OTHER THAN SET FORTH HEREIN, MYTEE GIVES NO WARRANTY,
EXPRESS OR IMPLIED, AS TO DESCRIPTION, QUALITY, MERCHANTABILITY,
FITNESS FOR ANY PARTICULAR PURPOSE, PRODUCTIVENESS, INFRINGE-
MENT, OR OTHER MATTER, OF ANY GOODS WHICH MYTEE SHALL SUPPLY.
THERE ARE NO WARRANTIES THAT EXTEND BEYOND THE DESCRIPTION ON
THE FACE HEREOF. MYTEE SHALL IN NO WAY BE RESPONSIBLE FOR THE
PROPER USE AND APPLICATION OF THE GOODS. MYTEE NEITHER ASSUMES
NOR AUTHORIZES ANY OTHER PERSON TO ASSUME FOR MYTEE ANY OTHER
LIABILITY IN CONNECTION WITH THE SALE OF MYTEE’S GOODS. THIS LIM-
ITED WARRANTY POLICY MAY BE CHANGED OR WITHDRAWN BY MYTEE AT
ANY TIME WITHOUT NOTICE.
WEAR PARTS 90-DAY LIMITED WARRANTY: Mytee will replace all wear parts for
90 days from the date of original purchase. “Wear parts” are items which wear out
as a result of usage or the passage of time and are consumed despite attempts to
maintain them, such as bumpers, wheels, cords, wires, electrical terminals, switches,
thermostats, plastic parts, lters, bearings, brushes, solenoids, or other parts deemed
wear items in Mytee’s sole discretion. This warranty covers the cost of replacement
only and does not cover shipping or labor costs.
FLOOR MACHINE MOTOR 1-YEAR LIMITED WARRANTY: Mytee warrants that
motors will be free from manufacturing defects, defects in workmanship, and defects
in material for one (1) year from the date of original purchase. This warranty does
not apply and is void if the motor has water damage, evidence of abuse, neglect, or
tampering. This warranty covers the cost of replacement or repair only and does not
cover shipping or labor costs.
METAL PARTS 5-YEAR LIMITED WARRANTY: For ve (5) years from the date of
purchase, Mytee warrants all metal stamped and formed parts to be free from manu-
facturing defects, defects in workmanship, and defects in material. This warranty
does not apply and is void if the part has evidence of abuse, neglect, or tampering.
This warranty covers the cost of replacement or repair only and does not cover ship-


7
ping or labor costs.
LIMITATION OF DAMAGES: THE REMEDY OF REPLACEMENT OR REPAIR
OF ANY DEFECTIVE GOODS SHALL BE THE EXCLUSIVE REMEDY UNDER
ANY WARRANTY MADE BY MYTEE, WHETHER EXPRESS OR IMPLIED. IN NO
EVENT SHALL MYTEE BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL
DAMAGES, PROPERTY DAMAGES, OR PERSONAL INJURIES.
All limited warranties are void for, and Mytee does not warrant in any way, any prod-
uct that evidences misapplication, improper installation, abuse, lack of maintenance,
negligence in use or care, abnormal use, alteration of design, use of incompatible or
corrosive chemicals, use in a rental service, and/or servicing, installation of parts, or
repairs by anyone other than Mytee or a Mytee authorized distributor or service cen-
ter. Mytee may make changes in products it manufactures and markets at any time;
these change are made without obligation to change, retrot, or upgrade any product
previously sold or manufactured.
Mytee has no obligation to honor the limited warranties set forth herein unless the
original purchaser, promptly upon discovering the warranty claim and prior to continu-
ing to use the product, contacts Mytee or a Mytee authorized distributor or service
center to describe the claim and to receive and follow instructions for documenting
and resolving the claim. In addition, the purchaser must provide the product to which
the claim applies to Mytee or a Mytee authorized distributor or service center for a
thorough inspection.
If any provision or portion of this limited warranty policy is found to be unenforceable,
then the remaining provisions and portions shall remain valid and enforceable. If any
provision or portion of this limited warranty policy is found to be limited by law, then
that provision or portion shall be construed to make it effective within the bounds
of law. For example, if there are legal limitations on the duration of warranties, the
warranties made herein shall be construed to have the minimum duration required
by law, or, if there are legal limitations of exclusion of remedies, the exclusions made
herein shall be construed to apply to the fullest extent possible without violating the
law.
The validity, construction and performance of this warranty policy shall be governed
by the laws of the State of California, without respect to conicts of laws principles.
The exclusive jurisdiction of any legal action arising from or related to this warranty
policy shall be in the State of California and no legal action shall be commenced
elsewhere.

It is the responsibility of any Authorized Service Center (ASC) or Distributor with
written authorization to ensure the Customers equipment is repaired as soon as
possible. Only Mytee Products Inc. or it’s authorized dealers with written authoriza-
tion, service centers, and agents may make warranty repairs on these products. All
others do so at their own risk and expense.
The Distributor must follow Mytee Products, Inc. standard RMA procedure:
1. When a repair falls within the Warranty time period for a piece of equipment, the
Distributor will ll out a RMA/Warranty claim form. This form will act as a repair order
to replace any defective parts.
2. All defective parts must be returned to Mytee Products, Inc. with the RMA/claim
form for evaluation at the customer’s expense. This shipping is non-refundable. All
warranty claims are subject to an evaluation by Mytee Products, Inc. to determine if
warranty will be approved. Any credit for repair and/or parts will only be issued upon
evaluation and approval from Mytee Products, Inc.
3. When Warranty is approved, the Distributor’s account will be credited for the
replacement part(s). Mytee Products, Inc. will ship the warranted replacement part(s)
to the Distributor prepaid. If Warranty is denied the Distributor’s account will not be
credited for any parts sent for this claim.


8

ITEM
NO.
PART NO.
DESCRIPTION
QTY.
MSRP
1
G038
bumper, 13" oor machine
1 $28.99 ea
2
P569
bell housing, 13", oor machine
1 $39.99 ea
3
H169
bolt, 1/4-20 x 2", hex head
8 $3.99 ea
4
H213
washer, 1/4" lock, s/s
8 $0.99 ea
5
H210
washer, 1/4" at, s/s
8 $0.99 ea
6
P540
spacer, bell housing/chassis
8 $0.99 ea
7
C307
motor, 1.5 HP, 60HZ, 120/240 V
1 $578.99 ea
8
H021
motor cover, RD-13
1 $8.99 ea
9
H458A
acorn nut, 10-32, 18-8, s/s
4 $0.99 ea
10
H151
bolt, 5/16-18 x 3/4"
10 $0.99 ea
11
H421
washer, 5/16" lock, s/s
10 $0.99 ea
12
H843
locking arc, handle adj, oor machine
1 $51.99 ea
13
H841
support, pivot, oor machine
2 $21.99 ea
14
H702
roll pin, 1 3/4" x 1/2"
2 $0.99 ea
15
H148
washer, 5/16", narrow
8 $0.99 ea
16
H153
cottor pin, 1 1/2" x 5/32"
1 $0.99 ea
17
H427
washer, wave
4 $1.49 ea
18
H212
at washer, 9/16"ID x 1 1/16"OD
2 $0.99 ea
19
H219 cap, axle, 1/2"
2 $0.99 ea
20
H170
wheel, 5"
2 $11.99 ea
21
H340
axle, 11.93" x .50" dia
1 $7.99 ea
22
H848
chassis, oor machine
1 $41.99 ea
23
H341
handle pivot, oor machine
1 $74.99 ea
24
H159
cable, handle adj, oor machine
1 $6.99 ea
25
H216
nut, lock, 1/4-20, nylon insert, s/s
1 $0.99 ea
26
H144
strain relief, power cord, oor machine
1 $6.99 ea
27
E532
power cord, end, 25', 14/3
1 $44.99 ea
28
H610
switch cover oor machine
1 $16.99 ea
29
H230
screw, 10-32 x 1/2" phil pan head, s/s 3 $0.99 ea
30
H149
bolt, 5/16" shldr x 5/8" w/ 1/4-20 thrd
1 $0.99 ea
31
H167
switch, oor machine
1 $13.99 ea
32
H211
washer, 1/4"id x 1"od, at, s/s
1 $0.99 ea
33
H166
insulation, switch, oor machine
1 $3.99 ea
34
H855
lever, switch, oor machine
1 $6.99 ea
35
H160
spring, switch/lever
2 $0.99 ea
36
P541
lockout, oor machine
1 $1.99 ea
37
H161
roll pin, 1 3/4" x 1/8"
2 $0.99 ea
38
H168
spring, lockout, oor machine
1 $1.99 ea
39
H273
nut, kep, #10-32 zinc
3 $0.99 ea
40
H839
lever, handle adj., oor machine
1 $7.99 ea
41
P529
spacer, lever, handle adj.
1 $1.99 ea
42
H215
nut, hex, 1/4-20 s/s
1 $0.99 ea
43
P524
plug, plastic, oor machine handle
1 $0.99 ea
44
H231
screw, 10-32 x 1" phil pan head, s/s
1 $0.99 ea
45
H916
clip, cord, 5/16", nylon- BLACK
1 $0.99 ea
46
H165
cord, hook, oor machine
1 $23.99 ea
47
H164
grommet, oor machine, 5/8" ID
1 $1.99 ea
48
G040
grip, handle, oor machine
2 $1.99 ea
49
H849
handle, oor machine
1 $89.99 ea
50
H150
bolt, 5/16-18 x 1 1/4"
2 $0.99 ea
ITEM
NO.
PART NO.
DESCRIPTION
QTY.
MSRP
51
H157
spring, handle adjustment
1 $5.99 ea
52
H047
screw, 1/4-20 x 1/2", button, s/s, blk oxide
1 $0.99 ea
53
H847
bushing, locking piston
1 $17.99 ea
54
H152
retaining ring, internal 1 1/2"
1 $0.99 ea
55
H844
locking piston, handle adj.
1 $19.99 ea
D
C
B
A
B
C
D
1
2
3
4
5
6
7
8
8
7
6
5
4
3
2
1
E
F
E
F
RD-13
SHEET 1 OF 3
13" Floor Machine
2/2014
B
SCALE: 1:16
REV
DWG. NO.
C
SIZE
TITLE:
NAME
DATE
COMMENTS:
CHECKED
DRAWN
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF MYTEE PRODUCTS, INC. ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF MYTEE PRODUCTS, INC. IS PROHIBITED.
A
DO NOT
SCALE DRAWING
858-679-1191
mytee
PRODUCTS, INC.
M. LaBarbera

9

1
2
3 5 6
7
9
8
10
11
12
11
10
13 14
15
11
10
16
17 18
17
19
20
21
22
23
24
26
27
30
15
28
29
31
32
33
34 29
35
36
37
38
39
40 41
42
43
44
39
45
39
25
47
46
50
15
50
48
49
51
52 53
54
55
4
D
C
B
A
B
C
D
1
2
3
4
5
6
7
8
8
7
6
5
4
3
2
1
E
F
E
F
RD-13
SHEET 2 OF 3
13" Floor Machine
2/2014
B
SCALE: 1:8
REV
DWG. NO.
C
SIZE
TITLE:
NAME
DATE
COMMENTS:
CHECKED
DRAWN
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF MYTEE PRODUCTS, INC. ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF MYTEE PRODUCTS, INC. IS PROHIBITED.
A
DO NOT
SCALE DRAWING
858-679-1191
mytee
PRODUCTS, INC.
M. LaBarbera

10

G
X Y
RD-13
115 Volt System
1/28/2014

11


12
Mytee Products Inc.
13655 Stowe Dr.
Poway, Ca. 92064
www.mytee.com
© 2014 Mytee Products Inc.
Printed in the U.S.A.

