8Mytek Brooklyn ADC
4.2 Rear Panel
1. Balanced XLR / TRS Analog Input - right channel
2. Balanced XLR / TRS Analog Input - left channel
3. AES/EBU Digital Output - professional balanced XLR output which sends digital signal up to 192
kHz/24bit, DSD up to x64 (DoP). Sample rate of 384 kHz is possible if the Brooklyn ADC is
connected to Brooklyn DAC+. It can also be used to transmit digital audio from computer (USB2).
4. Wordclock BNC Input Can be used for professional clock distribution and for syncing multiple units
and as DSD reference clock. Can also be used for connecting the Brooklyn ADC to an external clock.
However, we recommend running Mytek on Internal Clock, using the built in Mytek FemtoClock
which is by far superior (<1ps jitter) to any clock source connected from outside.
5. Wordclock BNC Output used for professional clock distribution. Feeds up to 384kHz for PCM and
DSD reference clock. Clock is derrived from Mytek Femtoclock Generator (tm)” with 0.82ps internal
jitter, allows stacking multiple units for multichannel operation, includes multichannel DSD.
6. SDIF2/3 DSD BNC output, left channel for use with professional DSD recording equipment (such
as Tascam Master Recorders).
7. SDIF2/3 DSD BNC output, right channel for use with professional DSD recording equipment (such
as Tascam Master Recorders).
8. S/PDIF Digital Output (RCA) - sends digital signal up to 192kHz/24bit, DSD up to DSD64. Sample
rate of 384 kHz is possible if the Brooklyn ADC is connected to Brooklyn DAC+. This output can
also be used to send digital audio signal from a computer (USB2). To obtain the best results, use a
high quality 75 ohm digital RCA cable.
9. S/PDIF Optical Digital Output (Toslink) - sends digital signal up to 192kHz/24bit, DSD up to x64
(DoP). This output can also be used to send digital audio signal from a computer (USB2). For best
results use short high quality TOSLINK cable. Special glass ber Toslink cable allows for longer
cable runs and is less jittery than regular plastic ber.
10. Mytek proprietary USB 2.0 Class 2, up to 32bit/384k, DSD256, llows to send digital data to AES,
SPDIF and Toslink outputs.
11. Optional external DC / Battery Power input; 12VDC. Connecting a large external battery or large
power supply may have positive impact on sound quality.
12. The build in automatic power supply operates in the range of 100V to 240V AC
All analog inputs (XLR/TRS) and digital outputs (AES, S/PDIF,
Toslink, SDIF) can be used in a DAW simultaneously.
1234
5
6
7
8
910 11 12
