Hurricane Slide Door Lock Instrucons
P/N 15-14822 Rev 8-21-14
Nabco Entrances Inc. S82 W18717 Gemini DriveMuskego, Wisconsin 53150
Phone: [phone] Fax: [phone] www.nabcoentrances.com
1 The 3-Point Lock
The Hurricane Door Slide door is installed with a 3-Point Lock that operates with a Thumb Turn, or Lever Turn. The 3-Point Lock is
used to simultaneously lock the Slide door with (1) Hook Bolt and (2) Lock Rods. Please see Figure 1.
Figure 1 3-Point Lock
DN 1124
Unlocked Posi on
THUMB TURN
3POINT LOCK
Locked Posi on
Lock Rod
Lock Rod
LEVER TURN
3POINT LOCK
Unlocked Posi onLocked Posi on
Lock Rod
Lock Rod
Hook Bolt Hook Bolt
When the 3-Point Lock is turned to lock the Slide door; the Hook Bolt simultaneously inserts into the Strike Sle while the Upper Lock
Rod inserts into the Header and the Lower Lock Rod inserts into the Track/Floor. Please see Figure 2.
2 Troubleshoot the 3-Point Lock
2.1 The Lower Lock Rod can not be inserted into the Drilled Hole
1. Open the Slide door to inspect the Drilled hole. Please see Figure 2.
2. Remove any dirt or debris that is lodged inside the hole.
a. It is important to keep the Drilled Hole free from dirt and/or debris at all mes.
b. It may be necessary to redrill the hole if dirt or debris becomes too ghtly packed and cannot be removed otherwise.
2.2 The Lower Lock Rod hits the Track/Floor
1. Jiggle the Slide door to carefully center the Lower Lock Rod to the Drilled Hole.
a. Please call your Corporate Headquarters according to procedure, to start a Service Work Order if the Lower Lock Rod sll
can not be inserted into the Drilled Hole.
DN 1125
Drilled Hole that is
packed with Dirt or Debris
Slide Door
Lock Rod not centered
to the Drilled Hole
Lock Rod
Figure 2 Troubleshooting the Lower Lock Rod

Hurricane Slide Door Lock Instrucons www.NabcoEntrances.com
P/N 15-14822 Rev 8-21-14
2 of 2
2.3 The Thumb Turn or Latch Turn is Stuck
1. Please call your Corporate Headquarters according to procedure, to start a Service Work Order.
3 Flush Bolts
Flush Bolts are locked only during a Hurricane no matter where they are installed.
DO NOT lock the Flush Bolt otherwise.
Flush Bolts installed on GT H60 Hurricane Slide Door Units are inserted into the Header and the Track/Floor on the:
XSidelite Panel
• Full Open Bi-Part Unit
XSlide Door
• Full Open Bi-Part Unit
DN 1127
Upper Flush Bolt
(in Unlocked Posi on)
Lower Flush Bolt
(in Locked Posi on)
FLUSH BOLTS ARE LOCKED
DURING A HURRICANE ONLY
Upper Flush Bolt
(in Locked Posi on)
Lower Flush Bolt
(in Unlocked Posi on)
Figure 3 The Flush Bolt
WARNING
