Nakamichi DELTA 10B User manual

DELTA 10B / DELTA 10R / DELTA 10S
User manual

1
Delta 10
Wireless Speaker Bluetooth Receiver
Instrucon Manual
CAUTION: Risk of electrical shock. Please do not open the unit.
1. Please read, keep and follow these instrucons.
2. Install in accordance with the manufacturer’s instrucons.
3. Do not install near any heat sources such as radiators, heat registers, stoves, or other products (including
amplifiers) that produce heat.
4. Only use aachments/accessories specified by the manufacturer.
5. Protect the power cord from being walked on or pinched, parcularly at plugs, convenience receptacles,
and the point where they exit from the product.
6. Unplug this product during lightning storms or when unused for long periods of me.
7. Do not let foreign objects or liquids enter the product.
8. Refer all servicing to qualified service personnel. Servicing is required when the product has been
damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have
fallen into the product, the product has been exposed to rain or moisture, does not operate normally,
or has been dropped.
9. Opening the unit by unauthorized personnel will void the warranty.
CAUTION: Use of controls, adjustments or performance of procedures other than herein may result in
hazardous radiaon exposure or other unsafe operaon.
Cleaning: Use a so, dry cloth to avoid scratching to the surface. Do not use cleaning alcohol, or other
solvent fluids to clean the surface of the Cabinet as this can both damage the coang and also cause electrical
failures or fire if it enters the electronics in the unit! Before cleaning, please unplug the unit from the AC
power outlet.
Overloading: To prevent risk of fire or electric shock, avoid overloading wall outlets or extension cords.
Open fire: Keep this sound system a safe distance away from any open flames such as a lit candle. No open
flame sources, such as lighted candles, should be placed on the unit.
Operang temperatures: The recommended operang temperature range for the sound system is 5 to 40
degrees Celsius (41 to 104 degrees Fahrenheit).
Label locaon: The product labels and safety related markings are located on the back of the unit and the power
adaptor.
Unplugging while in operaon: Do not remove the AC power cord if music is playing.

2
DC IN - Connect with provided Power Adaptor.
AUX IN - Insert with external input source (e.g. Smartphone or MP3 Player), the unit will turn to Aux
mode automacally when this jack is inserted. (Please Note: During Aux mode, the Bluetooth source
will not have sound playback. 3.5mm Aux cable not supplied)
USB Port for charging - 5V output for Smartphone charging at 1A current. (USB cable not supplied)
BACK PLATE
1.
2.
3.
Bluetooth LED Indicators
KEY PANEL
1.
Standby key - Press to turn on your Delta 10. Indicator 1 will light up in Blue if the source is Bluetooth,
whereas if the source is AUX, indicator 5 will light up in green.
PAIR key - Press key to enter pairing mode, indicator 1 (Blue & Red) will flash alternavely.
Play/Pause key - Press to play or pause playback, indicator 1 Blue will flash once each me you press
this buon.
Aux LED
2.
3.
4.
5.
Connect the speaker with the power adaptor provided.
Press “Standby” key to turn on the speaker, it will go to Pairing mode the first me you turn ON.
1.
2.
CONNECTING TO THE SPEAKER FOR THE FIRST TIME
Flashing Red & Blue alternavely - Pairing mode
Flashing Blue - Waing for connecon
Blue ON - BT device connected
•
•
•
Aux mode: Green•
PAIR
1 2 3 54
PAIR
AUX IN
9V DC 1. 5A
1

3
Your Bluetooth speaker can pair with most Bluetooth 2.0 and 2.1 devices. Pairing may vary by devices. Consult
your Bluetooth device’s owner’s manual for pairing instrucons.
This is a quick method to connect your Speaker with the latest Paired Device.
Turn on your unit by pressing the key, it will connect with the device automacally, the BT
LED will stay ON when the connecon is successful. If the speaker cannot find the latest Device, it will
go to Waing for Connecon mode. Please check that your device (Smartphone) is visible to other
devices refer your device owner’s manual.
1.
2.
PAIRING WITH BLUETOOTH DEVICES
When the speaker is ON, press the once. The speaker will take around 3 seconds to shut down,
the LEDs will turn OFF and remember your Bluetooth device.
TO TURN YOUR BLUETOOTH SPEAKER TO STANDBY MODE
CONNECTING THE LATEST BLUETOOTH DEVICE
If you want to connect another device instead of the current paired one, please make sure the
Bluetooth connecon of the current device is turned off.
Disconnect your current playing device, the speaker will change to Waing for Connecon mode, the
BT LED will keep flashing slowly.
Turn ON your Bluetooth device (e.g. Smartphone) Bluetooth seng.
Select the Speaker from your device’s Bluetooth list and push the key for 3 seconds to connect to
the speaker.
The Bluetooth LED will stay Blue when connecon is successful. You can play your music wirelessly
with BT Speaker.
You can also connect your paired device under pairing mode.
Under Waing for Connecon mode, you can simply reconnect to your latest paired device by just
pressing the key once.
1.
2.
3.
4.
5.
6.
7.
CONNECTING A PREVIOUSLY PAIRED BLUETOOTH DEVICE
Press key to switch to Bluetooth mode.
Turn on Bluetooth on your device (e.g. Smartphone), Delta 10 will be shown on your device’s
Bluetooth list. Please select.
Press and hold key for 3 seconds unl consecuve “beep” sound is played, the Bluetooth LED
will keep flashing RED and BLUE alternavely quickly waing for your Bluetooth device to pair.
Connect your device to the BT Speaker with Bluetooth, your device menu will show “Connected”, the
Bluetooth LED will stay Blue when pairing is successful.
You can now play your music wirelessly with the BT Speaker.
IMPORTANT PLEASE NOTE: If you wish to connect a different device, please TURN speaker off and then
repeat steps (1-3) for new device.
1.
2.
3.
4.
5.
6.
PAIR
PAIR
PAIR
Please Note:
For mobile phones with Bluetooth 2.0 your device may request you enter a pass code during pairing,
please press 0000.
The Delta 10 can remember up to 8 Bluetooth devices, to clear the memory, press key for 3 seconds
unl you hear a “Beep” sound from your speaker, the Bluetooth LED will flash quickly. Then press the key
twice, the Blue LED will stop. When the Blue LED starts flashing again the unit is in pairing mode. You
will need to run through the pairing setup again with your device (e.g. Smartphone).
PAIR

4
Play/Pause key
Your device must support AVRCP (Audio Video Remote Control Profile) to control your device’s playback
from the Speaker. Please check your device’s owner’s manual.
When the music is being played:
Please use your Bluetooth device (e.g. Smartphone) seng to control the volume level.
•
Press once to pause the playback
Press twice to resume the playback
•
•
TO CONTROL YOUR MUSIC PLAYBACK
Insert the AUX in jack with external device (e.g. Smartphone or MP3 player) via an AUX cable (not
provided).
The speaker will switch to AUX mode automacally, AUX LED will be ON.
Use your device to control the playback and Volume level of the speaker.
Please use your Bluetooth device seng to control the volume level.
1.
2.
3.
4.
PLAYBACK AUX IN DEVICE
Press key on top of the unit to switch on.
Turn on the NFC funcon on your Bluetooth device (e.g. Smartphone).
Place your device surface near the NFC sensor area of your speaker (top of unit). Push the key
for 3 seconds on your speaker to pair your device. (Some devices may have a pop up message to confirm
the speaker connecon, select YES to accept).
You can play your music wirelessly with your Bluetooth speaker.
To disable the connecon, just place your device surface near the NFC sensor area of the speaker
again or turn off the NFC funcon on your device.
IMPORTANT PLEASE NOTE: If you wish to connect a different device TURN unit off and then please
repeat steps (1-3) for new devices.
Your Bluetooth speaker can pair with most Bluetooth devices. Pairing may vary on different devices on your device.
Please consult your Bluetooth device owner’s manual for pairing instrucons.
1.
2.
3.
4.
5.
6.
PAIRING YOUR BLUETOOTH DEVICE WITH NFC (NEAR FIELD COMMUNICATION)
FUNCTION
PAIR

5
Wireless Bluetooth Speaker x 1 pc
Power Adaptor (DC 9V 1.5A) x 1 pc
Bluetooth specificaon
ITEM’S INCLUDED
SPECIFICATIONS
•
•
Bluetooth v2.1 includes profiles: A2DP, AVRCP
Advanced Audio Distribuon Profile (A2DP) for wireless music streaming
Audio Video Remote Control Profile (AVRCP) for wireless audio playback control
Range up to (10M) in open areas
GENERAL SPECIFICATIONS
•
•
•
•
Model
Output power maximum
Transmission distance
AUX input
USB charging
Product size
Product weight
Bluetooth V2.1
Delta 10
2 x 5W
10m music transmission without barrier
3.5mm Stereo
DC 5V 1A
L250 x W88.5 x H132.5mm
1.3kg
CHARGING A DEVICE VIA USB CONNECTION
Connect your wireless speaker to Mains power using power lead supplied.
Plug one end of the USB cable (not supplied with unit) into the USB port on the back of your speaker, plug
the other end of the USB cable into your device (I.E. Smartphone) for USB charging.
1.
2.
TROUBLE SHOOTING AND SUPPORT
If your wireless speaker does not work as expected please first read this manual.
No operaon: Check the power adaptor and mains power have been turned on.
If sll not successful please contact Nakamichi Service Support. Please refer to page 6 for details.
1.
2.
3.

6
New Zealand
Telephone: [phone]
Fax: [phone]
Email: [e-mail]
Website: www.nakamichi.com.au
Address: 84 Kerrs Road, Manukau Auckland 2104
New Zealand
Hours of Operaon
Monday - Friday
9am to 5:00pm excluding Public Holidays
Or visit the Nakamichi website anyme 24/7 and use the e-warranty
service to make a claim.
NAKAMICHI SERVICE CONTACT DETAILS
Australia
Telephone: [phone]
Fax: [phone]
Email: [e-mail]
Website: www.nakamichi.com.au
Address: 178 Boundary Road, Braeside Victoria 3195
Australia
Hours of Operaon
Monday - Friday
9am to 5:30pm AEST excluding Public Holidays
