NAMI ELECTRIC KLIMA User manual

user manual

English version
Original user manual
Importer
NAMI
16 avenue christian doppler
77700 Bailly Romainvilliers
www.nami-electric.com
Manufacturer
Ningbo Xingyue Vehicle
CO.,LTDDong Chun Yanzi Wo,
Henjie Town, Haishu Distric,
Ningbo, China

TABLE OF CONTENTS
INTRODUCTION�����������������������������������������������������������������������5
Who is NAMI?............................................................................................................................ 5
Before you begin....................................................................................................................7
FEATURES OF THE NAMI KLIMA
ELECTRIC SCOOTER������������������������������������������������������������
8
Overview......................................................................................................................................8
Driving elements.................................................................................................................10
Technical specifics............................................................................................................. 11
HOW TO SET UP THE SCOOTER���������������������������������� 12
Description of the folding system........................................................................12
How to fold and unfold the scooter.....................................................................13
Assembly of the scooter...............................................................................................14
Dashboard power supply............................................................................................15
Turn on/off the scooter ..................................................................................................16
Maintenance of the scooter......................................................................................18
SAFETY INSTRUCTIONS AND WARNINGS����������� 20
BATTERY������������������������������������������������������������������������������������ 22
Loading........................................................................................................................................22
Storage........................................................................................................................................22
Warnings...................................................................................................................................23
DASHBOARD�������������������������������������������������������������������������� 26
Description of the different pictograms....................................................... 26
Description of displayed values.......................................................................... 29
Settings...................................................................................................................................... 30
List of error codes...............................................................................................................33
Default settings.................................................................................................................. 34
Basic settings....................................................................................................................... 35
TRAVELOGUE������������������������������������������������������������������������� 98
DIGITAL PASSPORT AND WARRANTY
���������������������������� 100

WHO IS NAMI?
New Age Mobility Innovation. These four words sum up NAMI’s
ambition to design, develop and manufacture high-end
electric mobility vehicles.
New and innovative, this brand was created in 2020 to give
aboost to the electromobility market.
Power, reliability, design.
We have redefined the criterias for the mobility of tomorrow.
USER MANUAL - EN 5

You are about to explore a new way of riding
on two wheels with your KLIMA scooter by
NAMI Electric. And we are delighted that you
are ready to live this experience!
6 USER MANUAL - EN

BEFORE
YOU
BEGIN
Fast, solid and reliable, the Nami Electric brand is aimed at all users looking
for new sensations in the urban space.
Before you get started, here are some useful instructions to
read and follow to get the most out of your KLIMA’s features.
When opening the box, please inspect the contents and verify
that all of the following are present:
• Klima scooter
• 1 charger 5 A
• tool kit
• reflector stickers to stick on: the front fork (right and left)
rear fork (right and left)
Your scooter comes in a cardboard box that requires two people at each
end to transport it. To unpack the product, please remove the upper
protection that wraps your scooter, then lift it by holding it by both ends of
the frame. For convenience, you can ask a second person to help you. Once
the scooter is out of the box, make sure the kickstand is unfolded.
Please read this user manual. Keep it safe or download it at the following
address: www nami-electric com
Have a good trip !
The NAMI team
Nota Bene : this user manual is valid for the Klima and Klima Max.
The differences between the two variants are specified in the technicalspecifications.
USER MANUAL - EN 7

FEATURES OF THE NAMI KLIMA ELECTRIC SCOOTER
Overview
Length:
1285 mm
Width :
230 mm
High :
1230 mm
Tire sire :
10 X 3.0 inches
PSI recomended:
50 on both tires
8 USER MANUAL - EN

1- Horn
2- Front light
3- Dashboard
4- Handlebar
5- Steering column
6- Lock system
7- Folding system
8- Suspension
9- Wheel
10 - Front fork
11 - Kickstand
12 - Battery
13 - Footrest
14 - Platform
15 - Charging port
16 - Brake disc
17 - Brake caliper
18 - Mudguard
19 - NFC system
FEATURES OF THE NAMI KLIMA
Overview
2
15
3
7
5
14
1
13
6
16 17
8
9
18
12
10
11
4
19
USER MANUAL - EN 9

FEATURES OF THE NAMI KLIMA ELECTRIC SCOOTER
Driving elements
1
1- NFC system
2 - Right switch
(Lights / Turn signals / Horn)
3- Left hand switch
(Pedestrian mode / Instrument panel adjustment system)
4- Rear brake lever (left)
5- Front brake lever (right)
6 - Throttle
5
3
2
46
10 USER MANUAL - EN

FEATURES OF THE NAMI KLIMA ELECTRIC SCOOTER
Technical specifications
FRAME
One-piece forged aluminum/tubular welding
frame, heat treatment against aging
SWING ARM, FRONT SUSPENSION HOLDER,
FOLDING LOCK
One piece aluminum forging frame
BATTERY
60V 30AH 21700 / Premium cells
Battery energy in KWh : 1,8
NET WEIGHT KG
30
MAX SPEED KM/H
25
RANGE WITH AVERAGE SPEED AROUND
25KM/H
85 KM
MOTORS
1KWx2
CONTROLLERS
40A x 2 sine wave, IP65, all waterproof connections
DASHBOARD
5riding modes, parameter settings for each
controller is independent,
7parameter settings under each of the riding
modes are
1 - Rear motor starting power, from 1 to 5
2 - Front motor starting power, from 1 to 5
3 - Rear motor max output, from 10 to 100
(percentage)
4 - Front motor max output, from 10 to 100
(percentage)
5 - Max speed, from 10 to 100 (percentage)
6 - E-brake force, from 0 to 5
7 - Turbo strength, from 0 to 5 (Turbo will add
max speed and reduce the torque of the motor)
Over heat protection, able to set up the max
temperature for the heat protection start,
temperature in each controller can be checked
any time.
Low voltage protection, able to set up the
min power percentage for the low power
protectionstart
IP65
BRAKES
Front and Rear full hydraulic brakes, 2 pistons brake
Size of discs : 140mm
SUSPENSION
Hydraulic shock with rebound adjustment
LIGHTS AND HORN
2000 lumens front led light, side LED strips
integrated with turn signal, motorcycle horn, ip 55
CABLE SYSTEM AND IP RATING
Quick connections for all electric components, for
the cables close to handle bar and under the deck.
IP 55 for the whole scooter
FOLDING SYSTEM
Own design 2 points thread lock taper, stainless
steel folding parts
HANDLE BAR AND STEERING COLUMN
31.8mm diameter, full carbon fiber steering column
TIRES
10 x 3.0 inch tubeless CST, street tires
CHARGER
60V 5A
MAIN DIMENSIONS (LENGTH X WIDTH X
HEIGHT)
Overall size: 1285 mm x 230 mm x 1230 mm
PACKAGE SIZE (LENGTH X WIDTH X HEIGHT)
1320mm x 600mm x 260mm
TOTAL VALUE OF VIBRATIONS
Less than 2,5 m/s2
AIRBORNE NOISE
Less than 70 dB
FRAME
One-piece forged aluminum/tubular welding
frame, heat treatment against aging
SWING ARM, FRONT SUSPENSION HOLDER,
FOLDING LOCK
One piece aluminum forging
BATTERY
60V 25AH / Standard capacty cells
Battery energy in KWh : 1,5
NET WEIGHT KG
30
MAX SPEED KM/H
25
RANGE WITH AVERAGE SPEED AROUND
25KM/H
65 KM
MOTORS
1kWx2
CONTROLLERS
40A x 2, sine wave, IP65, all waterproof connections
DASHBOARD
5riding modes, parameter settings for each
controller is independent,
7parameter settings under each of the riding
modes are
1 - Rear motor starting power, from 1 to 5
2 - Front motor starting power, from 1 to 5
3 - Rear motor max output, from 10 to 100
(percentage)
4 - Front motor max output, from 10 to 100
(percentage)
5 - Max speed, from 10 to 100 (percentage)
6 - E-brake force, from 0 to 5
7 - Turbo strength, from 0 to 5 (Turbo will add
max speed and reduce the torque of the motor)
Over heat protection, able to set up the max
temperature for the heat protection start,
temperature in each controller can be checked
any time.
Low voltage protection, able to set up the
min power percentage for the low power
protectionstart
IP65
BRAKES
Front and Rear full hydraulic brakes, 2 pistons brake
Size of discs
SUSPENSION
Non adjustable hydraulic shock
LIGHTS AND HORN
2000 lumens front led light, side LED strips
integrated with turn signal, motorcycle horn, ip 55
CABLE SYSTEM AND IP RATING
Quick connections for all electric components, for
the cables close to handle bar and under the deck.
IP 55 for the whole scooter
FOLDING SYSTEM
Own design 2 points thread lock taper, Stainless
steel one piece clamp
HANDLE BAR AND STEERING COLUMN
31.8mm diameter, full carbon fiber steering column
TIRES
10 x 3.0 inch tubeless CST, street tires
CHARGER
60V 5A
MAIN DIMENSIONS (LENGTH X WIDTH X
HEIGHT)
Overall size: 1285 mm x 230 mm x 1230 mm
PACKAGE SIZE (LENGTH X WIDTH X HEIGHT)
1320mm x 600mm x 260mm
TOTAL VALUE OF VIBRATIONS
Less than 2,5 m/s2
AIRBORNE NOISE
Less than 70 dB
KLIMA MAX KLIMA
USER MANUAL - EN 11

HOW TO SET UP THE SCOOTER
Description of the folding system
Steering
column
Steering column base Clamp
Clamb
Keep your fingers away from the swivel mechanism when folding or unfolding the scooter to avoid the risk of pinching.
12 USER MANUAL - EN

HOW TO SET UP THE SCOOTER
How to fold and unfold the scooter
TO FOLD THE SCOOTER:
1. Unlock the locking system using its clamp.
2. Bring the locking system upwards to
release the steering column.
3. Fold down the steering column.
TO UNFOLD THE SCOOTER:
1. Unfold the steering column to put it straight in its
axis.
2. Bring the locking system down.
3. Close the locking system using its clamp.
USER MANUAL - EN 13

HOW TO SET UP THE SCOOTER
Assembly of the scooter
MAKE SURE THE KICKSTAND IS UNFOLDED BEFORE PREPARING THE
NEXT SETUP:
1. Position the handlebars using the stem in line with
the steering column.
2. Tighten the 2 M5 screws of the stem as tight as
possible.
3. Once the handlebars are positioned and tight,
position the steering column cover and tighten it with
the center screw..
4. Find the correct angle and position of the brake
lever by tightening the screw with the 4mm Allen key.
ADJUST THE FOLLOWING ITEMS ACCORDING TO YOUR DRIVING
PREFERENCE:
• dashboard support
• the dashboard switch
• the accelerator and the lighting stalk
• the horn
Then screw them in properly using the supplied tool
kit.
IF ANY OF THE ITEMS MENTIONED ARE MISSING, IMMEDIATELY CONTACT THE STORE WHERE YOU PURCHASED THIS
SCOOTER.
HANDLING THE SCOOTER AFTER ITS COMMISSIONING: IF THE SCOOTER IS STILL IN THE FOLDED POSITION, WE ADVISE
YOU TO MOVE IT WITH THE HELP OF A SECOND PERSON HOLDING BOTH ENDS OF THE VEHICLE TO LIFT IT IF THE
SCOOTER IS UNFOLDED, PLACE YOUR TWO HANDS ON BOTH HANDLEBARS, YOU CAN THEN MOVE IT BY PUSHING IT
WHILE WALKING NEXT TO IT
ONCE THE ASSEMBLY IS COMPLETE, YOU CAN START THE SCOOTER, MAKING SURE YOU HAVE FOLDED THE STAND.
PLACE ONE FOOT ON THE PLATFORM AND STEP FORWARD WITH A FORWARD PUSH ON THE FLOOR WITH THE OTHER
FOOT WITHOUT USING THE ACCELERATOR. AND MAKE SURE THAT BOTH OF YOUR HANDS ARE POSITIONED ON THE
BRAKE LEVERS. YOU MUST REACH A SPEED OF 4KM / H FOR THE VEHICLE TO START
14 USER MANUAL - EN

HOW TO SET UP THE SCOOTER
Dashboard power supply
PEDESTRIAN MODE:
To activate pedestrian mode,
press the button for 3 seconds.
To deactivate pedestrian mode,
press the button for 3 seconds. This
mode limits the speed to 6 km/h in
pedestrian zones.
MODE BUTTON:
press for 3 seconds, activate the
USB port in the dashboard, so that
the USB mark shows up.
BUTTON:
press for 1 second to activate the
turbo. Press once to change driving
mode.
BUTTON:
When the resettable information
is displayed, press +and -
simultaneously for 1second to reset
the value.
The dashboard is delivered with a control unit located on the handlebar with 4 buttons:
YOUR SCOOTER HAS AN ELECTRONIC KEY ALREADY ACTIVATED WHEN SWITCHING ON THE ORIGINAL CODE IS 0000
THE + AND - SIGNS ON THE LEFT SWITCH WILL BE USED TO ADJUST THE VALUE PRESS THE M BUTTON TO VALIDATE
THE INITIAL POSITION AND SKIP NEXT ONCE THE CODE IS ENTERED, ACTIVATE IT BY PRESSING THE M BUTTON.
SO THAT UNAUTHORIZED PERSONS DO NOT USE THE SCOOTER, USE THE ELECTRONIC KEY.
USER MANUAL - EN 15

HOW TO SET UP THE SCOOTER
TURN ON/OFF THE SCOOTER
USE THE NFC TO START AND TURN OFF YOUR ELECTRIC SCOOTER
WITH THE CARD:
A box located to the right of the dashboard constitutes
the unlocking and locking system of the electric scooter.
To use it, two NFC cards have been provided in the
packaging box.
N.B : one of the two cards is a duplicate key in case of
loss.
HOW IT WORKS:
1. Place the card on the NFC box.
2. As soon as the NFC box light turns on, the
dashboard will also be on.
3. To switch off the vehicle, place the card again on
the NFC box.
HOW TO DUPLICATE NFC CARDS:
You can duplicate your NFC card up to 5 times by
purchasing blank NFC cards.
To copy the blank card, you need to hold the supplied
NFC card near the NFC box for 5 seconds. The NFC LED
will then start flashing and enter registration mode. At
this moment, take the blank card and press it against
the NFC box.
As soon as the NFC box LED stops flashing and stays on,
the NFC card has been successfully duplicated.
If no card is copied, the LED stops flashing after 15
seconds and exits the registration mode.
Only 5 cards can be copied.
NFC card provided
16 USER MANUAL - EN

HOW TO SET UP THE SCOOTER
TURN ON/OFF THE SCOOTER
USE NFC WITH SMARTPHONE TO START AND TURN OFF THE ELECTRIC
SCOOTER
A box located to the right of the dashboard is the
unlocking and locking system of the electric scooter.
To use it with smartphone, please make sure NFC
mode is installed
N.B : Make sure that the NFC mode is activated on the
smartphone to turn the scooter on and off.
HOW IT WORKS: :
1. Copy the NFC card to the smartphone by
activating the NFC mode.
2. Place the NFC card under the smartphone. The
NFC mode then opens on the smartphone screen.
3. Follow the instructions on the smartphone
screen to finalize the copying of the card and the
activation of the NFC.
4. Place the smartphone on the NFC box located to
the right of the scooter’s dashboard to turn on the
vehicle. As soon as the NFC box light comes on, the
dashboard will also be on.
5. To switch off the vehicle, place the smarthpone
again on the NFC box.
NFC box on NFC box off
USER MANUAL - EN 17

HOW TO SET UP THE SCOOTER
Maintenance of the scooter
HOW TO ADJUST THE SUSPENSIONS
You can adjust in two different ways:
• Preload adjustment: you can adjust it by the lock nut under
the suspension spring. Screw it in for more hardness when
starting the rebound, or unscrew it for less hardness when
starting the rebound.
• Rebound adjustment: use the red ring on the top of the spring
(see attached photo). It adjusts the speed at which hydraulic
oil moves as damping.
Srefers to slower hydraulic displacement, which is more
hardfelling.
Frefers to a faster hydraulic displacement which means a
feeling of solfter.
18 USER MANUAL - EN

HOW TO SET UP THE SCOOTER
Maintenance of the scooter
HOW TO ADJUST THE BRAKES
1. please check if the disc is well balanced
2. please check if the disc pad is in the well condition with enough
thickness to provide the braking power needed
3. please adjust the brake pad postion via the two srews on the caliper Screw 1 Screw 2
• Your tires are fitted with pressure valves.
Use them to re-inflate your tires to a
maximum of 50 psi.
• Any repair must be carried out by a
professional and / or official distributor
of the NAMI Electric brand.
• Never perform maintenance on the
displayed battery is on or charging.
• Clean any stains from your scooter with
a damp cloth.
• Do not use alcohol, gasoline, kerosene,
or other corrosive and volatile
chemicalcleaners.
• Do not wash off with water.
• Make sure that the scooter is switched
off and unplugged during cleaning and
that no water drop or trace of moisture
enters the charging port.
N.B : Non contractual pictures.
Your vehicle may come wth different
brands of brake calipers.
USER MANUAL - EN 19

• Before each use, check the general condition of the
scooter, such as wear of the tires and brake pads as well
as their properfunctioning.
• Remember to check that the screws are tightened
as much as possible. Make sure the folding system is
securely locked.
• The electric scooter should be placed with the kickstand
against the slope to avoid tipping. Do not park your
scooter on a slope. Make sure the kickstand is positioned
on a flat surface.
SAFETY INSTRUCTIONS AND WARNINGS
• Please comply with the traffic laws and related
regulations of the country in which you are driving.
• The speed of the scooter is limited to 25km/h.
• The use of new electric mobility devices is subject to
maximum speed.
• Check that the regulations in your country are in line
with this speed limit.
• Any modification to the scooter resulting in an increase
in the maximum speed is prohibited, and will void your
entirewarranty.
• The age of riding an electric scooter varies by country.
• Please take note of the legislation in force in the country
where you wish to drive.
• According to European Standard EN 17128: 2020, the user
must be at least 12 years old.
• For your safety, be sure to wear a full face helmet and
other protective gear for the knees, elbows, hands,
upper body.
• Make sure you have the right shoes for riding the
scooter. Wearing shoes at all times is compulsory.
• At night, consider wearing retro-reflective gear and any
signage accessories.
• Watch out for the rotating parts of the scooter.
• Pay attention to the position of your body and your
clothing when driving: if any of your fabrics curl up on
any of the rotating parts of the vehicle such as the
engine, disc, section folding, suspension or front / rear
fork this can cause serious injury.
• Do not make any modifications to the scooter or the
spare parts by yourself.
• This creates a risk of accident and malfunction of
thescooter.
• Do not ride two people on the electric scooter.
• NAMI electric vehicles are designed for one person.
• Always handle the electric scooter with care to
avoidinjury.
• Watch out for weather conditions: watch out for the
humidity level on the road.
• KLIMA is water resistant, but for your safety and to ensure
the life of your vehicle, it is recommended not to be used
in rainyconditions.
• Do not immerse the scooter in water.
• The maximum payload allowed on the scooter is 120kg.
20
USER MANUAL - EN
