NANOLUX LEDex F630 User manual

The fixture is suitable for both indoor and greenhouse environment. Do not install your
LED in wet environment. Do not operate the fixture close to combustible materials.
The fixture will get hot during operation. Do not touch the fixture during or right after
operation. Make sure the power cord does not touch any hot part of the fixture. Make
sure the light bar is clean and inserted correctly. The normal operating environment
temperature should be below 104°F. Exceeding the maximum environmental
temperature will stress electronic components, which will lead to shorter lifetime and
decreased reliability.
Our fixture comes with a heat sink and other cooling components, which enable it to
dissipate heat effectively and allow maximum heat conductivity during the operation.
● Comply with local installation regulations.
● Store the fixture in a dry and clean environment, with an ambient temperature of
-10°C ~ 50°C and ambient humidity of less than 90% RH. It is recommended that
the fixture shall not stay unused for more than six months. If it has stayed unused
for more than six months, please test to ensure fixture is functioning at 100%.
● Please keep products safe. Avoid mechanical pressure, excessive vibration and
dropping the unit during the process of assembly to protect the light bar.
● Keep away from water, oil and organic solvent, or it will reduce the efficacy and have
the potential risk of electric leakage.
● All equipment, devices and machines shall be effectively grounded.
● Regularly check and clean the dust from the heatsink and LED array.
1. Disconnect from power supply before general care.
2. Remove the dust from the light bar by using low-pressure compressed air.
3. Clean the diode array with a soft cloth to prevent it from being scratched.
4. Be sure not to touch the diode with your bare hands, even after the LED is
disconnected from power supply.
● It is recommended that you contact a licensed electrician or an expert if any of the
following happens:
1. The cable or the plug has been damaged.
2. The unit has been exposed to rain.
3. Significant changes in the unit performance.
4. Fixture or light bar dropped and corner of its enclosure got bent.
● There are no serviceable parts inside the LED. Opening the LED will void its
warranty.
Nanolux warrants manufacturing defects of this product if it is used under normal
operating conditions for a period of three (3) years from the original date of purchase.
If the product shows manufacturing defects within this period and that defect is not
caused by user error or improper use, Nanolux shall, at its discretion, either replace or
repair the product by using applicable new or refurbished parts. For any service, return
the product to your shop along with the original sales receipt.
SCOPE OF USE AND MAINTENANCE
ALWAYS COMPLY WITH LOCAL
INSTALLATION REGULATIONS AND CODES
OPERATING
MANUAL
LED
Modular design
0-10V SLC COMPATIBLE
LED TOP LIGHTING 630W
WARRANTY
TROUBLE SHOOTING
Problem
One or more
fixtures are
completely off.
Disconnect from power source.
Broken cable or wire connecting
controller to fixture or wire
connecting fixture to fixture.
The power supply settings do
not match with local AC
voltage and frequency.
Make sure power is on and
cables are plugged in.
Dimming
failure
LED will not
come on.
Probable cause(s) Possible fixes or
corrective maintenance
Repair or replace any
damaged cables if necessary.
Disconnect fixture from the
power supply. Check settings
and correct if necessary.
Designed by NANOLUX in California
Made in China
PATENTED PRODUCTS, COUNTERFEITING NOT ALLOWED.

Fixture Hanging (Wires/Ratchets)
1. Attach the carabiners from the steel wire hanger (optional) to the hanging hole on
the light bar and LED driver.
2. Hang the fixture in the required location.
This model is compatible with SLC controller.
Connect the signal wire plug on the LED driver to the 1 end of the Y shape signal wire,
then connect the 2 end of the Y shape signal wire to the output port on the SLC
controller with a telephone wire. Then the dimming function on the LED fixture is
enabled.
● Maximum of 120 units can be controlled by SLC.
● Simulate sunrise and sunset for dimming.
● Turn off the device automatically following the setting time and temperature.
TECHNICAL SPECIFICATIONS
ASSEMBLY INSTRUCTIONS
ABOUT PRODUCT
0-10V DIMMING
LEDex F630
AC120V/208V/240V/277V
@ 277V 600-660W
@ 277V 2.9~3.0µmol/J
Full Spectrum
46.5x3.9x3.1inch / 13.9lbs
1182x100x80mm / 6.3kgs
≧50,000hrs
0-10V SLC compatible
120°
Lifetime
Model
Light Distribution
Dimming
Input Voltage
Light Bar Input Power
Efficacy
Spectrum
Light Bar Dimension
/ Weight
It is recommended that you keep a mounting height of 70”-86”(1.8m-2.2m) above
canopy for optimal light efficiency and uniformity. Growers should regularly monitor the
temperature at the canopy level to ensure the height of the fixture is appropriate, as
canopy temperature and ambient room temperature can differ.
Output Plug
Signal Wire Plug
CAUTION:
After installation, verify if installation was a success by cycling the lights on / off a few
times, setting 'over temperature shut down' to a low value like 85°F, and rubbing the
temperature probe with your fingers, tricking the SLC controller into an over
temperature condition and shutting the lights off. Then leave the probe alone, and
after 10-15 minutes as recommended, the SLC controller should turn all the lights
back on.
For detailed instructions, please refer to SLC controller operating manual.
PLEASE READ THESE INSTRUCTIONS
FIRST BEFORE INSTALLATION
Welcome to purchase and use this new LED luminaire. We have done everything to
ensure a product of long lifespan and safe operation, but the installation and use of the
product is at the responsibility of the user. Incorrect use or installation can lead to
failure and damage to the luminaire. Damage to the luminaire or electronic circuitry as
a result of incorrect installation or use will revoke your warranty. Read this manual
carefully before installing your luminaire.
CAUTION :
* Don’t remove the protective paper so as to prevent damage to the diode array when
handing light bar.
* Be sure light bar is clean, and user shall wear cotton gloves.
-02-
*Subject to change without notice, Tolerance ±10%.
NOTE: The light bar needs to connect our LED Driver to work well, please don’t
connect other one.
LED Driver
Light Bar
Output Cable
a
b
Max 60 Units
Max 60 Units
LED
LED LED LED
LED LED
21
Signal Wire Plug
Signal Wire Plug
Telephone Wire
3
Y Shape
Signal Wire
LED DRIVER
LED DRIVER
Input Plug
